Some days before the meetup...

Angular 2

Features

Latest Web Standards
Simple
Lightning fast
Works everywhere

builtwithangular2.com

ES5 / ES6 / TypeScript

ES6 (ES2015)

- Classes, modules, arrow functions

TypeScript

- Types, annotations

- Better editor support

TypeScript IDE Support

Application Design

Component Tree

source: blog

/home

/users

/about

/users/34

Bootstrap

Bootstrapping

Angular Application instantiation
Root component (App)
Global Dependencies
- Router, Http, Services
- Global Values
- Vendor dependencies

index.html

<!DOCTYPE html>
<html>
  <head>
    <!-- Polyfill(s) for older browsers -->
    <script src=".../shim.min.js"></script>
    <script src=".../zone.js@0.6.12?main=browser"></script>
    <script src=".../reflect-metadata@0.1.3"></script>
    <script src=".../systemjs@0.19.27/dist/system.src.js"></script>
    <script src="systemjs.config.js"></script>
    <script>System.import('app');</script>
  </head>
  <body>
    <my-app>
      Loading...
    </my-app>
  </body>
</html>

Bootstrap

// main.ts
import { bootstrap } from '@angular/platform-browser-dynamic';
import { App } from './app.component';
import { LoginService } from './login.service';
...

bootstrap(App, [
  // Global dependencies
  LoginService, // Singleton
])
.catch(err => console.error(err));

app.component.ts

import { Component } from '@angular/core';

@Component({
  selector: 'my-app', // <my-app>Loading...</my-app>
  template: `...`
})
export class App {
  constructor() { }
}

Services

/home

/users

login.service.ts

import { Injectable } from '@angular/core';

@Injectable()
export class LoginService {
  authorised = false;

  authorise(value) {
    this.authorised = value;
  }
}

home.component.ts

// home.component.ts
import { Component } from '@angular/core';
import { LoginService } from './login.service';

@Component({
  template: `
    <h1>Home</h1>
    <input #switch type="checkbox"
      [checked]="loginService.authorised"
      (click)="change(switch.checked)">
    <div *ngIf="loginService.authorised">
      <a>Today's best superheroe</a>
    </div>`
})
export class Home {
  constructor(private loginService:LoginService) { }

  change(checked){
    this.loginService.authorise(checked);
  }
}

/users

users.json

[{
  "id": 34,
  "username": "spiderman",
  "roles": ["admin", "user"]
}, {
  "id": 67,
  "username": "batman",
  "roles": ["user"]
}]

users.service.ts

import { Injectable } from '@angular/core';
import { Http } from '@angular/http';
import 'rxjs/add/operator/map';
import 'rxjs/add/operator/retryWhen';
import 'rxjs/add/operator/delay';

@Injectable()
export class UsersService {
  constructor(private http:Http) { }

  get(){
    return this.http.get('api/users.json')
      .map(response => response.json())
      .retryWhen(errors => errors.delay(2000));
  }
}

users.component.ts

import { Component } from '@angular/core';
import { UsersService } from './users.service';

@Component({
  selector: 'users',
  template: `
    <h1>Users</h1>
    <table class="table">
      <tr *ngFor="let user of users | async">
        <td>{{user.username}}</td>
      </tr>
    </table>`
})
export class Users {
  constructor(private service:UsersService){
    this.users = service.get();
  }
}

Component Router

Main Contributor

@victorsavkin

Main Features

Based on components
Flexible routing
- Nested views, auxiliary routes
Navigation Gards
Lazy loading (rc.5)

Setup Router

Dependencies

Choose Location Strategy
Setup routes
Include providers
- provideRouter(routes)
Include directives
- ROUTER_DIRECTIVES

Location Strategies

HashLocationStrategy
- Eg: #/home, #/users/34
PathLocationStrategy (default)
- Requires <base href=.../>
- Eg: /home, /users/34

Bootstrap

import { provideRouter } from '@angular/router';
import { HashLocationStrategy, LocationStrategy } from '@angular/common';
import { routes } from './app.routes';

bootstrap(App, [
  provideRouter(routes),
  { provide: LocationStrategy, useClass: HashLocationStrategy },
])

/home

/users

/about

/users/34

Defining Routes

// app.routes.ts
import { Home } from './home.component';
import { About } from './about.component';
import { NotFound } from './notfound.component';

export const routes: RouterConfig = [
  { path: '',  redirectTo: 'home', pathMatch: 'full' },
  { path: 'home',  component: Home },
  { path: 'about',  component: About },
  { path: '**', component: NotFound }, //always last
];

router-outlet

// app.component.ts
import { ROUTER_DIRECTIVES }  from '@angular/router';

@Component({
  selector: 'my-app',
  template: `
    <nav></nav>
    <main>
      <router-outlet></router-outlet>
    </main>`,
  directives: [ROUTER_DIRECTIVES]
})
export class App { }

Child Routes

users

#/users

Users

users/:id

#/users/34

User

Child Routes

// users.routes.ts
import { RouterConfig } from '@angular/router';
import { Users } from './users.component';
import { User } from './user.component';

export const usersRoutes: RouterConfig = [
  { path: 'users', component: Users },
  { path: 'users/:id', component: User }
];

Navigation

Using regular links with hash
- ```
#/home
```
Using routerLink directive
- ```
['home']
```
- ```
['users', 34] //users/:id
```
Programatically
- ```
router.navigate(['users', 34]);
```

routerLink

import { Component } from '@angular/core';
import { ROUTER_DIRECTIVES } from '@angular/router';

@Component({
  selector: 'users',
  template: `
    <h1>Users</h1>
    <tr *ngFor="let user of users">
      <td>
        <a [routerLink]="['/users', user.id]">{{user.username}}</a>
      </td>
    </tr>
  `,
  directives: [ROUTER_DIRECTIVES]
})
export class Users { }

Some examples

<!-- Top Routes -->
<a href="#/home">Home</a>
<a [routerLink]="['home']">Home</a>

<!-- Nested Routes -->
<a href="#/users">Users</a>
<a [routerLink]="['users']">Users</a>

<a href="#/users/34">Spiderman</a>
<a [routerLink]="['users', 34]">Spiderman</a>

<a href="#/users/34;flag=true?q=1">Spiderman</a>
<a [routerLink]="['users', 34, {flag: true}]" [queryParams]="{q: 1}">Spiderman</a>

Current Url

// { path: 'users/:id', component: User }
import { ActivatedRoute, Router } from '@angular/router';

@Component({
  selector: 'user-details'
})
export class User implements OnInit {
  constructor(private route: ActivatedRoute, private router: Router){
    this.route.url.subscribe(s =>
      console.log(router.createUrlTree(s).toString())  // /users/34
    );
  }
  ngOnInit() {
    console.log(this.router.url); // /users/34
  }
}

Accessing Parameters

// { path: 'users/:id', component: User }
import { ActivatedRoute } from '@angular/router';

@Component({
  selector: 'user-details'
})
export class User implements OnInit {
  constructor(private route: ActivatedRoute){
    route.params.subscribe(params => {
      let id = params.id;
    });
  }
  ngOnInit() {
    let id = this.route.snapshot.params.id;
  }
}

Accessing queryParams

// #/users/34;flag=true?q=1
import { Router } from '@angular/router';

@Component({
  selector: 'user-details'
})
export class User implements OnInit {
  constructor(private router: Router){
    router.routerState.queryParams.subscribe(params => {
      let q = params.q;
    });
  }
  ngOnInit() {
    let q = this.router.routerState.snapshot.queryParams.q;
  }
}

Accessing Data

// { path: 'users/:id', component: User, data: { key: 1 } }
import { ActivatedRoute } from '@angular/router';

@Component({
  selector: 'user-details'
})
export class User implements OnInit {
  constructor(private route: ActivatedRoute){
    route.data.subscribe(v => console.log(v));
  }
  ngOnInit() {
    let data = this.route.snapshot.data.key;
  }
}

Navigation Gards

Ask before navigating

// users.routes.ts
import { RouterConfig } from '@angular/router';
import { UserCanDeactivate } from './user.canDeactivate';

export const usersRoutes: RouterConfig = [
  { path: 'users', component: Users },
  {
    path: 'users/:id', component: User,
    canDeactivate: [UserCanDeactivate]
  }
];

Ask before navigating

// user.canDeactivate.ts
import { CanDeactivate } from '@angular/router';
import { User } from './user.component';

Injectable()
export class UserCanDeactivate implements CanDeactivate<User> {
  canDeactivate() {
    return window.confirm('Do you want to continue?');
  }
}

Restrict Access

// users.routes.ts
import { RouterConfig } from '@angular/router';
import { AuthCanActivate } from './auth.canActivate';

export const usersRoutes: RouterConfig = [
  { path: 'users', component: Users },
  {
    path: 'users/:id', component: User,
    canDeactivate: [UserCanDeactivate],
    canActivate: [AuthCanActivate]
  }
];

Restrict Access

// auth.canActivate.ts
import { CanActivate, Router } from '@angular/router';
import { LoginService } from './login.service';

export class AuthCanActivate implements CanActivate {
  constructor(private loginService: LoginService, private router: Router) {}

  canActivate() {
    if (!this.loginService.authorised) {
      this.router.navigate(['/home']);
      return false;
    }
    return true;
  }
}

Resolve

// app.routes.ts
import { AboutResolver } from './about.resolver';

export const routes: RouterConfig = [
  { path: 'home',  component: Home },
  {
    path: 'about',  component: About,
    resolve: { magicNumber: AboutResolver }
  },
];

Resolve

// about.resolver.ts
import { Injectable } from '@angular/core';
import { Resolve, ActivatedRouteSnapshot, RouterStateSnapshot } from '@angular/router';
import { Observable } from 'rxjs/Observable';

@Injectable()
export class AboutResolver implements Resolve {
  resolve(route: ActivatedRouteSnapshot, state: RouterStateSnapshot):Observable<any> {
    console.log('Waiting to resolve...');
    let p = new Promise(resolve => setTimeout(() => resolve(4545), 2000));
    return Observable.from(p);
  }
}

Resolve

// about.component.ts
import { ActivatedRoute } from '@angular/router';

@Component({
  selector: 'about',
  template: `
    <h1>About</h1>
    <p>Magic Number: {{magicNumber}}</p>`
})
export class About {
  magicNumber: number;

  constructor(private route: ActivatedRoute){
    this.magicNumber = route.snapshot.data.magicNumber;
  }
}

Advanced Features

Auxiliary routes

// app.routes.ts
export const routes: RouterConfig = [
  {path: 'home', component: HelloCmp},
  {path: 'banner', component: BottomCmp, outlet: 'bottom'}
];
// app.component.ts
@Component({
  selector: 'my-app',
  template: `
    <router-outlet></router-outlet>
    <router-outlet name="bottom"></router-outlet>`,
})
export class App { }
// templates/code
<a href="#/home(bottom:banner)">Show Banner!</a>
<a [routerLink]="['/home(bottom:banner)']">Show Banner!</a>
router.navigate('/home(bottom:banner)');

Lazy Loading (v2)

@RouteConfig([
  { path: '/about', loader: AboutLazyLoader , name: 'AboutLazyLoad' }
])
export class App { }

//aboutLazyLoader.ts
export function AboutLazyLoader(){
  return System.import('./src/aboutLazyLoad.ts')
    .then(module => module.AboutLazyLoad);
}

//aboutLazyLoad.ts
@Component({
  selector: 'about',
  template: `<h1>About</h1>`
})
export class AboutLazyLoad { }

Demo

Features

Nested routes with parameters
Asking before leaving a route
Restricting route access
Cool SVG loading spinner

plunker

AngularConnect - Sept 27-28th

@AngularConnect

THE AMAZING

ROUTER v3

Google Developer Expert

Master of Ceremonies

International Speaker

Angular 2 Trainer

Community Leader

@angular_zone #jslnd

Some days before the meetup...

Angular 2

Features

ES5 / ES6 / TypeScript

TypeScript IDE Support

Application Design

Component Tree

Bootstrap

Bootstrapping

index.html

Bootstrap

app.component.ts

Services

login.service.ts

home.component.ts

users.json

users.service.ts

users.component.ts

Component Router

Main Contributor

Main Features

Setup Router

Dependencies

Location Strategies

Bootstrap

Defining Routes

router-outlet

Child Routes

Child Routes

Navigation

routerLink

Some examples

Current Url

Accessing Parameters

Accessing queryParams

Accessing Data

Navigation Gards

Ask before navigating

Ask before navigating

Restrict Access

Restrict Access

Resolve

Resolve

Resolve

Advanced Features

Auxiliary routes

Lazy Loading (v2)

Demo

Features

Thanks!
