iRODS Client:

AWS Lambda Function for S3 1.0

June 9-12, 2020

iRODS User Group Meeting 2020

Virtual Event

Terrell Russell, Ph.D.

@terrellrussell

Chief Technologist, iRODS Consortium

iRODS Client:

AWS Lambda Function for S3 1.0

iRODS Client: AWS Lambda Function for S3 1.0

Design Goals



  • Play nicely with the universe of tools that already know how to write to S3 directly



  • Allow those updates within the S3 namespace to smoothly flow into the iRODS Catalog



  • Trigger automated data management due to crossing the policy boundary

iRODS Client: AWS Lambda Function for S3 1.0

Considerations

  • Lambda can run Python code
  • iRODS provides a python client library



Success would be...

  • near-real-time, asynchronous, catalog updates for creates/moves/deletes



iRODS Client: AWS Lambda Function for S3 1.0

Files created, renamed, or deleted in S3 appear quickly in iRODS.



iRODS is assumed to have its associated S3 Storage Resource(s) configured with HOST_MODE=cacheless_attached.



You must configure your Lambda to trigger on all ObjectCreated and ObjectRemoved events for a connected S3 bucket.



The iRODS connection information is stored in the AWS Systems Manager > Parameter Store as a JSON object string.



SSL to iRODS is supported by placing a certificate in a relative path within the Lambda package.

Lambda

S3

iRODS Client: AWS Lambda Function for S3 1.0

This Lambda function can be configured to receive events from multiple sources at the same time.

Lambda

S3

S3

S3

If the irods_default_resource is NOT defined in the environment in the Parameter Store, then the Lambda function will derive the name of a target iRODS Resource.



By default, the Lambda function will append _s3 to the incoming bucket name.

iRODS Client: AWS Lambda Function for S3 1.0

The following AWS configurations are supported at this time:

SNS

Lambda

S3

SQS

Lambda

S3

Lambda

S3

iRODS Client: AWS Lambda Function for S3 1.0

Limitations



  • S3 is decoupled from the Lambda.  A rename is actually a create and a delete message.  To iRODS, this becomes a new data object.  This means any metadata AVUs associated with the now-deleted data object is lost.  Could be remedied with full checksum comparison.  Other ideas welcome.



  • SQS configuration is limited to batch_size = 1.  Operating on more than one message at a time would reduce the cost of running this Lambda at AWS.  Unclear how to signal partial success at this time.

Questions?



https://github.com/irods/irods_client_aws_lambda_s3





Thank You!





Pre-release testing environment provided by Bristol Myers Squibb.
