www.grupopim.com
Integral Solutions that raise your value
MECHANIZATION
BOILER MAKING & WELDING
ENGINEERING
INDUSTRIAL MAINTENANCE
CONTROL & REWORKING
O&M RENEWABLE ENERGIES
INTEGRAL SERVICES
AUTOMOTIVE
ENERGY
AERONAUTICS
NAVAL
PAPER
INDUSTRIAL
MAIN SECTORS
IN WHICH OUR CLIENTS WORK
RAILWAYS
IRON & STEEL
SPAIN
Grupo PIM
PORTUGAL
GERMANY
FRANCE
ITALY
SWEDEN
MEXICO
MdM
BRAZIL
CHINA
CZECH REPUBLIC
INTERNATIONALISATION
Where you can find our products?
MOROCCO
THE THREE DIVISIONS AT THE PIM GROUP
HOW WE OPERATE
OUTSOURCING INDUSTRIAL MAINTENANCE & AUXILIARY SERVICES
MANUFACTURING BESPOKE MACHINERY
MACHINING
MACHINING DIVISION
16,500
m
2
workshops
MACHINING DIVISION
90,000
hours machining per year
3
shifts
Up to 10 m beds & 3+2 axis
13
CNC milling machines
4
x 20/12.5-ton gantry cranes
Traceability and dimension control for 100% of the production
MACHINING DIVISION
10,000
hours of technical office work
6
CAD/CAM
licences
Highly qualified personnel
MACHINING DIVISION
MACHINERY
Bridge-type mill ZAYER KF10000
TNC-530 Heidenhain CNC
Travel: 10,000 x 4,500 x 250
Passage between uprights: 3,500
Bridge-type mill ZAYER KP5000
TNC-530 Heidenhain CNC
Travel: 5,000 x 3,350 x 1,200
Passage between uprights, e.g. Y 2,600
Bridge-type mill CORREA FP40-50
TNC-530 Heidenhain CNC
Travel: 5,000 x 3,250 x 1,000
Passage between uprights, e.g. Y 2,700
Bridge-type mill CORREA FP40
TNC-530 Heidenhain CNC
Travel: 3,850 x 2,500 x 800
Passage between uprights, e.g. Y 2,300
Bridge-type mill CORREA FP30-40
TNC-530 Heidenhain CNC
Travel: 3,850 x 2,500 x 800
Passage between uprights, e.g. Y 2,100
Bridge-type mill CORREA FP40/40
TNC-530 Heidenhain CNC
Table surface: 4,000 x 1,250 mm
Longitudinal Travel (X-axis) 3,500 mm
Transversal Travel (Y-axis) 2,500 mm
Vertical Travel (Z-axis) 1,000 mm
Passage between uprights: 2,300 mm
Bridge-type mill CORREA FP30/30
TNC-530 Heidenhain CNC
Table surface: 3,000 x 1,250 mm
Longitudinal Travel (X-axis) 2,500 mm
Transversal Travel (Y-axis) 2,000 mm
Vertical Travel (Z-axis) 1,000 mm
Passage between Uprights 1,750 mm
Bed-type milling machine CORREA CF40
TNC-430 Heidenhain CNC
Travel: 4,000 x 1,200 x 1,500
Bed-type milling machine ZAYER 30KF
TNC-430 Heidenhain CNC
Travel: 2,700 x 1,250 x 1,000
Milling machine
ZAYER 20KF
TNC-430 Heidenhain CNC
Travel: 1,800 x 1,250 x 1,000
Milling machine
ZAYER 20KF-3000
TNC-540 Heidenhain CNC
Table surface: 2,700 x 1,000 mm
Longitudinal Travel (X-axis) 2,725 mm
Transversal Travel (Y-axis) 1,200 mm
Vertical Travel (Z-axis) 1,000 mm
CME
Milling machine
TNC-530 Heidenhain CNC
Travel: 3,000 x 1,500 x 1,500
Milling machines
Bed-type Milling Machine Nicolás CORREA CF-22 PLUS:
TNC-410 Heidenhain CNC
X-axis (longitudinal) 2,500 mm
Y-axis (transversal) 800 mm
Z-axis (vertical) 800 mm
MACHINING DIVISION
MACHINERY
Machining section
CHEVALIER
CNC type: TNC 530 HEIDENHAIN
X-axis (longitudinal) 1,000 mm
Y-axis (transversal) 650 mm
Z-axis (vertical) 650 mm
Conventional lathe
PINACHO
2,000 mm between points
Tumbling 550 mm
Flat grinder
1,500mm x 600mm
Radial drill
1,500mm
5 welding units
MIG-MAG 500A Linlcon
3 x 20/12.5-ton
gantry cranes
MACHINING DIVISION
MACHINING DIVISION
DIE MANUFACTURING
Production of stamping dies
Extensive experience in hot stamping
Hot and cold machining of 100% of the parts comprising the die.
Assembly & adjustment (off-press).
MACHINING DIVISION
Dies & moulds
PARTS & PROJECTS UNDERTAKEN
MACHINING DIVISION
PARTS & PROJECTS UNDERTAKEN
MACHINING DIVISION
Speciality parts
PARTS & PROJECTS UNDERTAKEN
MACHINING DIVISION
Die-making
PARTS & PROJECTS UNDERTAKEN
MACHINING DIVISION
INNOVATION, ENGINEERING & OPTIMISATION
Engineering
Start-up & SAT
Full manufacturing of the part or specific machine
BESPOKE MACHINERY MANUFACTURING DIVISION
VALUE CHAIN IN TURNKEY PROJECTS
Design & engineering
Paintwork
Boiler making & welding
Automation
Assembly & SAT
INNOVATION, ENGINEERING & OPTIMISATION
BESPOKE MACHINERY MANUFACTURING DIVISION
Mechanisation
BESPOKE MACHINERY MANUFACTURING DIVISION
BESPOKE MACHINERY MANUFACTURING DIVISION
BESPOKE MACHINERY MANUFACTURING DIVISION
BESPOKE MACHINERY MANUFACTURING DIVISION
MAINTENANCE & OUTSOURCING
DIVISION
Industrial maintenance
O&M Renewable Energies
Engineering
Building maintenance & facility management
COMPREHENSIVE MAINTENANCE OF FACILITIES
Outsourcing of auxiliary services
MAINTENANCE SERVICES
MAINTENANCE & OUTSOURCING
DIVISION
Consultancy & engineering
Preventive
Predictive
Corrective
CMMS
Reports & trends
Industrial maintenance
-
KPI-based maintenance contracts
-
Preventive-predictive maintenance
-
Corrective maintenance
-
Technical service
-
Skilled labour (electrical, mechanical,
instrumentation)
-
Modification maintenance (mechanisation,
welding, adaptation of production lines, etc.)
Engineering
-
Consultancy - optimisation of maintenance processes
-
Analysis and implementation of CMMS
-
Definition of preventive & predictive range
-
Savings & efficiency in management
-
Spare part storage management (defining critical items,
obsolescence, minimum stock, etc.)
O&M Renewable Energies
-
O&M contracts for photovoltaic plants
-
Preventive & predictive maintenance
-
Reworking & preventive for the wind sector
-
Comprehensive management of billing and administrative processes
-
Control centre
-
International Arena
Building maintenance & facility management
-
Integral maintenance and building management contracts
-
BT Installers / Maintainers
-
Air conditioning & hot water installations
-
Installations for fluids
OUTSOURCING & OPTIMISATION OF PACKAGING PROCESSES
Process engineering
Optimisation
Procedures
Methods & timing
Assembly
Verification
INNOVATION, ENGINEERING & OPTIMISATION
MAINTENANCE & OUTSOURCING
DIVISION
OUTSOURCING
4,000
m
2
Pneumatic systems for handling loads, compressed air installed throughout, outlets, heating, three loading bays, open-plan areas where layouts can be set up for sequential processes as required by the project.
Experienced technical team for manufacturing & quality processes who study & adapt methods to optimise time and minimise risks.
on-site for
Pre-assembly of subsections, sequencing & storage
Quality, selection and validation review/inspection
Handling, transfer and re-labelling
of parts
Reworking, repairs and packaging
MAINTENANCE & OUTSOURCING
DIVISION
tasks
MAINTENANCE PROJECTS
AUTOMOTIVE
-
Maintenance during summer downtime
-
Corrective/preventive maintenance of presses
-
Preventive maintenance for robots & welding cells
PAPER
- In-plant mechanical & modification maintenance
TEXTILE
- Maintenance & new engineering projects
- Comprehensive maintenance of pickling plants
IRON & STEEL
MAINTENANCE & OUTSOURCING
DIVISION
COMMITTED TO OUR CLIENTS, QUALITY & CONTINUOUS IMPROVEMENT
2006
'Parque Industrial del Mecanizado' (PIM) is founded, focusing its attention on the auxiliary mechanisation of individual parts in a wide range of dimensions and weights. From the outset, PIM has stood out for its specialisation in complex mechanisation operations and its rigorous quality and customer service policies.
2012
New installations, going from 450 m2 to the current 16,500 m2. New cutting-edge production machinery with the capacity to machine very large, heavy parts. Diversification into boiler-making and welding and reinforcement of the Engineering Department to cover integral machinery manufacturing projects (from the design and manufacturing through to automation and start-up).
2012
2013
'Plataforma Integral del Mantenimiento' is created, a division of the group specialising in industrial maintenance covering the whole value chain, from consultancy and engineering through to full maintenance outsourcing. It offers services for specific machines, production lines, auxiliary services and even complete plants.
'Parque Industrial del Mecanizado' (PIM) is founded, focusing its attention on the auxiliary mechanisation of individual parts in a wide range of dimensions and weights. From the outset, PIM has stood out for its specialisation in complex mechanisation operations and its rigorous quality and customer service policies.
2006
New installations, going from 450 m2 to the current 16,500 m2. New cutting-edge production machinery with the capacity to machine very large, heavy parts. Diversification into boiler-making and welding and reinforcement of the Engineering Department to cover integral machinery manufacturing projects (from the design and manufacturing through to automation and start-up).
2013
2017
The PIM Group goes international, beginning to work in Mexico under the name 'Mexicana del Mecanizado (MdM)'. The company sets up a 2,000 m2 production subsidiary in Tetla, Tlaxcala, a strategic location logistically, to provide coverage to the main TIER 1 and OEM companies in the country. MdM begins working in brand new facilities with a pool of high-performance CNC machinery, enabling them to work with medium-high volume parts.
'Plataforma Integral del Mantenimiento' is created, a division of the group specialising in industrial maintenance covering the whole value chain, from consultancy and engineering through to full maintenance outsourcing. It offers services for specific machines, production lines, auxiliary services and even complete plants.
2012
New installations, going from 450 m2 to the current 16,500 m2. New cutting-edge production machinery with the capacity to machine very large, heavy parts. Diversification into boiler-making and welding and reinforcement of the Engineering Department to cover integral machinery manufacturing projects (from the design and manufacturing through to automation and start-up).
2017
The PIM Group goes international, beginning to work in Mexico under the name 'Mexicana del Mecanizado (MdM)'. The company sets up a 2,000 m2 production subsidiary in Tetla, Tlaxcala, a strategic location logistically, to provide coverage to the main TIER 1 and OEM companies in the country. MdM begins working in brand new facilities with a pool of high-performance CNC machinery, enabling them to work with medium-high volume parts.
2013
'Plataforma Integral del Mantenimiento' is created, a division of the group specialising in industrial maintenance covering the whole value chain, from consultancy and engineering through to full maintenance outsourcing. It offers services for specific machines, production lines, auxiliary services and even complete plants.
NOW
With its engineering, production and services capacity, the PIM Group has cemented its position as the leading company for comprehensive solutions for the international industrial sector.
2017
The PIM Group goes international, beginning to work in Mexico under the name 'Mexicana del Mecanizado (MdM)'. The company sets up a 2,000 m2 production subsidiary in Tetla, Tlaxcala, a strategic location logistically, to provide coverage to the main TIER 1 and OEM companies in the country. MdM begins working in brand new facilities with a pool of high-performance CNC machinery, enabling them to work with medium-high volume parts.
Evolution and growth based on reinvestment
3,500,000€
3,000,000€
2,500,000€
2,000,000€
1,500,000€
1,000,000€
500,000€
2006
2007
2008
2009
2010
2011
2012
2013
2014
2015
2016
2017
2018
2019
Foundation
PIM
Purchase of the first bridge-type machine 2011
Investment
FP10000
2013
Investment
FP30
2014
Investment
FP40
2015
Opening the Mexican subsidiary
2016
Investment
kp5000
2018
Investment in new facilities and machinery. Diversification
2013
CLIENT-ORIENTED CONTINUOUS IMPROVEMENT
QUALITY
Group-wide management system based around continuous improvement tools (KAIZEN)
Lean manufacturing
5s
CERTIFICATES
OBJECTIVE: ALL-ENCOMPASSING QUALITY
Metrology laboratory with ENAC-calibrated measurement and verification equipment that is reported within our ISO 9001 Quality System.
3-D measurement units to cover dimensional measuring needs, such as in-machine and in-line inspection and CAD comparison.
Dimensional quality & oversight. The dimensions of all our completed products are checked and various aspects of quality are reviewed: surface finishing, cleanliness, finishing of edges and packaging, etc.
The NCRs are registered and treated using corrective and preventive plans of action.
COMMITTED
Our workforce = our main asset
RISK PREVENTION
ONGOING TRAINING
Target:
'0' accidents
Priority: safety and risk prevention
IT system and training/awareness programmes
HUMAN RESOURCES
TRAINING CENTRE
Enrichment and development of the workforce
Empowerment
Theoretical/practical training based on real projects: dies and moulds, CNC, CAD/CAM, welding, electricity, PLC, etc.
Goal: personal and professional empowerment for the factory of the future
Polígono Montecicos, Calle A, 16-21
50638 · Cabañas de Ebro (Zaragoza, Spain)
