NOT ALL LIGHTS ARE EMERGENCY LIGHTS
How to Integrate Lighting Controls with the Emergency Lighting
ISOLITE
NOT ALL LIGHTS ARE EMERGENCY LIGHTS
Chalk Talk
NFPA 101
CODE COMPLIANCE
- The Letter of the Law
- Locallized Failures
- A Good Architecture
UL924, The ALCR
ALCR GOAT
- Why It Works...
- Dimming Integration
- 0-10V
- DALI/EcoSystem
- Phase Control
Continuing Education
GOING FURTHER
- ISO-1010: EM With Lighting Controls
- The Continuing Architect
NOT ALL LIGHTS ARE EMERGENCY LIGHTS
OVERVIEW
Sales Materials
- Failure of a public utility or other outside electrical power supply
NFPA 7.9.2.3
NFPA 101
CODE COMPLIANCE
The Emergency Lighting System Shall Be Arranged To Provide the Required Illumination Automatically In The Event Of Any Interruption Of Normal Lighting Due To Any Of the Following:
- Manual act(s), including accidental opening of a switch controlling normal lighting facilities
- Opening of a circuit breaker or fuse
ISOLITE
NOT ALL LIGHTS ARE EMERGENCY LIGHTS
Chalk Talk
- Failures "in the area" of the architectural lights must be considered
- Emergencies aren't just utility power failures!
- There are also jurisdictional requirements for local fire alarm interactions
Locality
Interpretations of NFPA 101
CODE COMPLIANCE
Manual Acts...
- Does this mean that we can't control emergency lights on an inverter, ever???
- Appendix A7.9.3.2
Where emergency lighting is provided by automatic transfer between normal power service and an emergency generator, it is the intent to prohibit the installation, for any reason, of a single switch that can interrupt both energy sources.
*Phew* We're safe...
ISOLITE
NOT ALL LIGHTS ARE EMERGENCY LIGHTS
Chalk Talk
THE ALCR, AN ARCHITECTURE THAT WORKS!
CODE COMPLIANCE
ISOLITE
NOT ALL LIGHTS ARE EMERGENCY LIGHTS
Chalk Talk
Why It Works
ELCD 924
ALCR GOAT
Senses:
- Local "Normal" Power Source
- Emergency Power Source
- Local Control Signal From Lighting Control System
- Fire Alarm Signal
The ALCR is a part of every zone that has mixed emergency and normal loads.
Every zone acts independently, even from the emergency power source!
ISOLITE
NOT ALL LIGHTS ARE EMERGENCY LIGHTS
Chalk Talk
ALCR/ELCDs Allow for More than Switched Lighting Controls
What About Bob Dimming?
ALCR GOAT
- 0-10V
- DALI/EcoSystem
- Phase Control*
*Phase control integration may require a BCELTS for mixed use zones, but ALCR devices can act as a full-emergency-zone override.
There's Confusion on Power Packs, But UL924 Ed. 11 is due 2023 to clarify.
ISOLITE
NOT ALL LIGHTS ARE EMERGENCY LIGHTS
Chalk Talk
0-10V Dimming Integration
ALCR GOAT
ISOLITE
NOT ALL LIGHTS ARE EMERGENCY LIGHTS
Chalk Talk
DALI/EcoSystem Integration
ALCR GOAT
ISOLITE
NOT ALL LIGHTS ARE EMERGENCY LIGHTS
Chalk Talk
Phase Control Dimming
ALCR GOAT
ISOLITE
NOT ALL LIGHTS ARE EMERGENCY LIGHTS
Chalk Talk
NOTES
- Must verify the capacity of the inverter
- Cost of additional battery is generally less expensive than BCELTS devices
New AIA Course
ISO-1010: ALCR/BCELTS Integration with Lighting Control Systems
GOING FURTHER: CONTINUING EDUCATION
Topics Covered
- Deep Dive into Lighting Control Systems and How They Integrate with Emergency Systems
- Nuanced Differences between ALCR and BCELTS Devices
- Reducing System Costs Through Redesign
Available to give live or over Zoom
Also available on The Continuing Architect
ISOLITE
NOT ALL LIGHTS ARE EMERGENCY LIGHTS
Chalk Talk
- White Paper on ELCD Devices
- Wiring Diagrams
- Spec Sheets/Installation Notes for Each Device
Available on the Website
- Training Video Link
- Sales Presentation Slides
- White Paper on ELCD Devices
Available Within Follow-Up Sales Packet
SALES MATERIALS
SUPPORT
