Supercharging ActiveRecord with PostgreSQL

Who am I?

PostgreSQL

• Advanced Data Types

• Arrays
• Hstore (Hash Store, aka Key-Value store)
• JSON
• Ranges
• Powerful Features
• windowing functions
• table inheritance
• Schemas - Separate silos within a single database

What We'll Explore:
Arrays

What We'll Expore:

HStore

What We'll Explore

Rank and CTEs

Patterns we'll examine: Tagging

Patterns we'll examine: Similar Records

Patterns we'll examine: Single Table Inheritance

Patterns we'll examine: Leaderboards

Tagging

• We want to apply tags to notes entered into our system

• We don't care about generating a tag cloud
• We want to be able to find all notes with a given tag

Many to Many relation

• Usually, we'll generate a many-to-many relation between notes and tags
• We'll have a tag record for each tag applied to a note
• We'll have to generate a new tag when a user wants to use one we have not previously encountered

Using Arrays for tags

• PostgreSQL has native support for array columns
• We can store the tags as an array column on our notes
• We no longer have to worry about creating tag records when we encounter a new one

Adding our tags array to the model

class AddTagsToNotes < ActiveRecord::Migration
  def change
    add_column :notes, :tags, :string, array: true
  end
end

Finding Tagged Notes

• Now that we are tagging our notes, we need a way of finding them
• PostgreSQL has multiple ways of checking if an array contains a value
• ANY(...)
• @> - contains operator

ANY

• We can use the ANY() function to see if a value is stored in any element of the array

SELECT notes.*
FROM notes
WHERE 'useful' = ANY(notes.tags)

• This won't use any indexes

@> - Contains

• We can use the @> operator to see if an array on the left contains the array on the right of the operator (order matters)

SELECT notes.*
FROM notes
WHERE notes.tags @> '{useful}'

GIN indexing our Array

class AddTagsToNotes < ActiveRecord::Migration
  def change
    add_index :notes, :tags, using: :gin
  end
end

Some Benchmarking

Finding Via Has_Many

First Run - 370 ms

Nested Loop
   ->  Bitmap Heap Scan on post_tags
         Recheck Cond: (tag_id = 1)
         ->  Bitmap Index Scan on index_post_tags_on_tag_id
               Index Cond: (tag_id = 1)
   ->  Index Scan using posts_pkey on posts
         Index Cond: (id = post_tags.post_id)
 Total runtime: 370.139 ms

Subsequent calls - 13 ms

Nested Loop
  ->  Bitmap Heap Scan on post_tags
        Recheck Cond: (tag_id = 2)
        ->  Bitmap Index Scan on index_post_tags_on_tag_id
              Index Cond: (tag_id = 2)
  ->  Index Scan using posts_pkey on posts
        Index Cond: (id = post_tags.post_id)
Total runtime: 13.511 ms

Array: Finding via ANY

First run: 503 ms

Aggregate
  ->  Seq Scan on posts
        Filter: ('Tag #1'::text = ANY ((array_tags)::text[]))
        Rows Removed by Filter: 98989
Total runtime: 503.517 ms

Subsequent runs: 500 ms

Aggregate
  ->  Seq Scan on posts
        Filter: ('Tag #1'::text = ANY ((array_tags)::text[]))
        Rows Removed by Filter: 98989
Total runtime: 499.618 ms

Array: Finding via @>

First run - Pre index: 536 ms

Aggregate
  ->  Seq Scan on posts
        Filter: (array_tags @> '{"Tag #1"}'::character varying[])
        Rows Removed by Filter: 98989
Total runtime: 536.183 ms

 Aggregate
  ->  Bitmap Heap Scan on posts
       Recheck Cond: (gin_tags @> '{"Tag #1"}'::character varying[])
       ->  Bitmap Index Scan on index_posts_on_gin_tags
             Index Cond: (gin_tags @> '{"Tag #1"}'::character varying[])
 Total runtime: 8.056 ms

Results

Drawbacks

• You lose the ability to efficiently create a list of tags
• Getting a distinct list of tags from a series of arrays is slow
• It's also fairly complex
• GIN can be slow to update
• Multiple inserts into index (one for each key extracted)
• Can be mitigate somewhat using FASTUPDATE

Notes

• Database-side Cache matters
• You will see a performance increase on subsequent runs, as the results will be in memory
• Results across the board were quicker after the first table scan, as the table was in memory after that

Similar Records

• We want to build out the ability to have similar posts listed for a given post
• We don't care about mapping a similar post back to the source item (don't need belongs_to)

Old Way

Using Arrays

• We can build has_many-type functionality using arrays
• This allows us to retrieve all the similar item ids with a single call for the item record

Migration

class CreateMembers < ActiveRecord::Migration
  def change
    add_column :posts, :similar_post_ids, :integer, array: true
  end
end

has_many like methods

• We can add a method Post#similar_posts which will retrieve our item's by their ids stored in Post#similar_post_ids
• We can also add a Post#similar_posts= method that will take the array of items passed to it and store their ids in Post#similar_post_ids

has_many like methods

class Post < ActiveRecord::Base
  def similar_posts
    self.class.where(id: similar_posts_ids)
  end

  def similar_posts=(children)
    self.similar_posts_ids = children.map(&:id)
  end

  def similar_posts_ids=(ids)
    write_attribute :similar_posts_ids, ids.reject{ |id| id.to_i <= 0 }
  end
end

Using our fake has_many

post = Post.find(1)
post.similar_posts # => [Post, Post, Post]
post.similar_posts = [Post, Post] # Updates the similar_post_ids attribute

# the following won't work
post.similar_posts << Post # We aren't observing this array,
                           # so it won't update the ids attribute

# we can work around it with the following
post.similar_posts += [Post] # calls the setter on the array

Benefits

Next Steps

Single Table Inheritence

HStore

• PostgreSQL has a Hstore or Hash Store column type
• We can store a set of key-value properties on this column

Enabling Hstore

• Hstore was added to PostgreSQL 9.2 as an extension
• Rails 4.0 added enable_extension which will allow you to enable an extension via a migration
• enable_extension 'hstore' will enable hstore in your database

An Example

Our Member Class

• The Member class will serve as the base class for our STI infrastructure

class CreateMembers < ActiveRecord::Migration
  def change
    enable_extension 'hstore' # Let's enable Hstore

    create_table :members do |t|
      t.string :username
      t.string :type
      t.hstore :data # We'll store all our attributes in a column
                     # called data
      t.timestamps
    end
  end
end

Extending activeRecord

module HstoreAccessor
    def hstore_accessor(hstore_attribute, *keys)
      Array(keys).flatten.each do |key|
        define_method("#{key}=") do |value|
          send("#{hstore_attribute}=", (send(hstore_attribute) || {}).merge(key.to_s => value))
          send("#{hstore_attribute}_will_change!")
        end
        define_method(key) do
          send(hstore_attribute) && send(hstore_attribute)[key.to_s]
        end
      end
    end
  end
end
ActiveRecord::Base.send(:extend, HstoreAccessor)

• We define hstore_accessor, which will define a getter and setter against our hstore column

Creating User class

class User < Member
  hstore_accessor :data, :email, :age
end

• Now we can access User#email, and User#age
• We can also validate these attributes

class User < Member
  hstore_accessor :data, :email, :age
  validates :email, :age, presence: true
end

User.new.email #=> nil

User.new.valid? #=> false

Creating another class

class TwitterUser < Member
  hstore_accessor :data, :twitter_handle
end

• Since we only set up twitter_handle, we don't have access to email, which we set up on our User model

twitter_user = TwitterUser.new twitter_handle: '_danmcclain', username: 'dan'
twitter_user.twitter_handle   #=> "_danmcclain"
twitter_user.username         #=> "dan"
twitter_user.email            #=> NoMethodError

Limitations

Leaderboards

• Need a leaderboard for each game
• Need the ability to return a user's best score for a given game
• Want to page through our scores, but maintain ranking

Rank()

SELECT rank() OVER(ORDER BY points DESC), username, points
FROM scores
WHERE game = 'Barking Bostons'

┌──────┬──────────┬────────┐
│ rank │ username │ points │
├──────┼──────────┼────────┤
│    1 │ Brian    │    300 │
│    2 │ Dan      │    200 │
│    3 │ Dan      │    100 │
│    4 │ Doug     │     30 │
└──────┴──────────┴────────┘

First attempt at getting a user's rank

SELECT rank() OVER (ORDER BY scores.points DESC), username, points
FROM scores
WHERE game = 'Barking Bostons' AND username = 'Dan'

• We get back the user's scores for the game
• BUT the ranks are only for the user's scores, it does not take into account other users

┌──────┬──────────┬────────┐
│ rank │ username │ points │
├──────┼──────────┼────────┤
│    1 │ Dan      │    200 │
│    2 │ Dan      │    100 │
└──────┴──────────┴────────┘

Using Common Table Expressions to get the ranks of a User's Scores

• Common Table Expressions (CTEs) allow you to alias a subquery

WITH top_scores_for_game AS (
  SELECT rank() OVER (ORDER BY points DESC), username, points
  FROM scores
  WHERE scores.game = 'Barking Bostons'
)
SELECT top_scores_for_game.*
FROM top_scores_for_game

• The above query will return all the results from the WITH statement

Attempt #2

• We'll use a CTE to get all the scores for a game, then find our user within those results

WITH top_scores_for_game AS (
  SELECT rank() OVER (ORDER BY points DESC), username, points
  FROM scores
  WHERE scores.game = 'Barking Bostons'
)
SELECT top_scores_for_game.*
FROM top_scores_for_game
WHERE top_scores_for_game.username = 'Dan'

┌──────┬──────────┬────────┐
│ rank │ username │ points │
├──────┼──────────┼────────┤
│    2 │ Dan      │    200 │
│    3 │ Dan      │    100 │
└──────┴──────────┴────────┘

Getting ranked results in ActiveRecord

query = <<-SQL
WITH top_scores_for_game AS (
  SELECT rank() OVER (ORDER BY points DESC), username, points
  FROM scores
  WHERE scores.game = 'Barking Bostons'
)
SELECT top_scores_for_game.*
FROM top_scores_for_game
WHERE top_scores_for_game.username = 'Dan'
SQL

Score.find_by_sql query
=> [#<Score ... >, #<Score ... >]

Using postgres_ext for rank and CTE

Score.ranked(points: :desc).where(game: 'Barking Bostons')

• Now lets get the user's ranked scores for the game using a CTE

Score.from_cte('top_scores_for_game',
  Score.ranked(points: :desc).where(game: 'Barking Bostons')).where(username: 'Dan')

Wrapping Up

Other PostgreSQL features to explore

Questions?

Thank You
