Private Transactions on Ethereum

Suyash Bagad

Merkle Tree

Suppose we want to store $2^{k}$ files in a decentralized and succinct way

$h = H\big($

$\big)$

Here, $h$ indeed is a succinct representation of the files $\{f_i\}_{i \in [8]}$
The problem is: to check if a file in included in $h$ , you need all $\{f_i\}_{i \in [8]}$ files
A better way to achieve this is using Merkle trees!

$f_1$

$f_2$

$f_3$

$f_4$

$f_5$

$f_6$

$f_7$

$f_8$

Merkle Tree

Suppose we want to store $2^{k}$ files in a decentralized and succinct way

$f_1$

$f_2$

$f_3$

$f_4$

$f_5$

$f_6$

$f_7$

$f_8$

$H(f_1)$

$H(f_2)$

$H(f_3)$

$H(f_4)$

$H(f_5)$

$H(f_6)$

$H(f_7)$

$H(f_8)$

Merkle Tree

Suppose we want to store $2^{k}$ files in a decentralized and succinct way

$H(f_1)$

$H(f_2)$

$H(f_3)$

$H(f_4)$

$H(f_5)$

$H(f_6)$

$H(f_7)$

$H(f_8)$

$H'(H(f_1), H(f_2))$

$H'(H(f_3), H(f_4))$

$H'(H(f_5), H(f_6))$

$H'(H(f_7), H(f_8))$

$h^1_1$

$h^1_2$

$h^1_3$

$h^1_4$

$h^2_1$

$h^2_2$

$h^3_1$

$H'(h^1_1, h^1_2)$

$H'(h^1_3, h^1_4)$

$H'(h^2_1, h^2_2)$

Merkle Tree

$H(f_1)$

$H(f_2)$

$H(f_3)$

$H(f_4)$

$H(f_5)$

$H(f_6)$

$H(f_7)$

$H(f_8)$

$h^1_1$

$h^1_2$

$h^1_3$

$h^1_4$

$h^2_1$

$h^2_2$

$h^3_1$

Indeed, $h_1^3$ is succinct form of the files. How do we prove inclusion?

Merkle Tree

$H(f_1)$

$H(f_2)$

$H(f_3)$

$H(f_4)$

$H(f_5)$

$H(f_6)$

$H(f_7)$

$H(f_8)$

$h^1_1$

$h^1_2$

$h^1_3$

$h^1_4$

$h^2_1$

$h^2_2$

$h^3_1$

Indeed, $h_1^3$ is succinct form of the files. How do we prove inclusion?

Merkle Tree

$H(f_1)$

$H(f_2)$

$H(f_3)$

$H(f_4)$

$H(f_5)$

$H(f_6)$

$H(f_7)$

$H(f_8)$

$h^1_1$

$h^1_2$

$h^1_3$

$h^1_4$

$h^2_1$

$h^2_2$

$h^3_1$

Only $\left( H(f_6), h^1_4, h_1^2 \right)$ are enough to prove inclusion of $f_5$ ! Sister nodes!

Tornado.Cash

Brings transaction privacy by breaking the on-chain link between the recipient and destination addresses
Works in two stages: Deposit and Withdraw

Deposit

Deposit: $(i)$ Generate $k, r \leftarrow \mathbb{F}_p$ and compute $C_1 = H(k, r)$

$H(0)$

$h^1_1$

$h^1_2$

$h^1_3$

$h^1_4$

$h^2_1$

$h^2_2$

$(ii)$ Send $N$ ETH to contract $\mathcal{C}$ which adds $C_1$ to the Merkle tree

$h^3_1$

Deposit: $(i)$ Generate $k, r \leftarrow \mathbb{F}_p$ and compute $C_1 = H(k, r)$

$C_1$

$H(0)$

$h^1_1$

$h^1_2$

$h^1_3$

$h^1_4$

$h^2_1$

$h^2_2$

$(ii)$ Send $N$ ETH to contract $\mathcal{C}$ which adds $C_1$ to the Merkle tree

$h^3_1$

Deposit

Deposit: $(i)$ Generate $k, r \leftarrow \mathbb{F}_p$ and compute $C_1 = H(k, r)$

$C_1$

$H(0)$

$h^1_1$

$h^1_2$

$h^1_3$

$h^1_4$

$h^2_1$

$h^2_2$

$(ii)$ Send $N$ ETH to contract $\mathcal{C}$ which adds $C_1$ to the Merkle tree

$h^3_2$

$h^3_1$

Deposit

Deposit: $(i)$ Generate $k, r \leftarrow \mathbb{F}_p$ and compute $C_1 = H(k, r)$

$C_1$

$C_2$

$H(0)$

$h^1_1$

$h^1_2$

$h^1_3$

$h^1_4$

$h^2_1$

$h^2_2$

$(ii)$ Send $N$ ETH to contract $\mathcal{C}$ which adds $C_1$ to the Merkle tree

$h^3_3$

$h^3_1$

$h^3_2$

Deposit

Deposit: $(i)$ Generate $k, r \leftarrow \mathbb{F}_p$ and compute $C_1 = H(k, r)$

$C_1$

$C_2$

$C_3$

$C_4$

$H(0)$

$h^1_1$

$h^1_2$

$h^1_3$

$h^1_4$

$h^2_1$

$h^2_2$

$(ii)$ Send $N$ ETH to contract $\mathcal{C}$ which adds $C_1$ to the Merkle tree

$h^3_5$

$h^3_1$

$h^3_2$

$h^3_3$

$h^3_4$

Deposit

Withdraw

To withdraw a coin $k,r \in \mathbb{F}_p$ at position $l \in \mathbb{Z}_{2^{16}-1}$ , we do:

$(i)$ Select a withdrawal address $A$

$(ii)$ Select a root $R$ among the stored ones and compute opening $O(l)$ w.r.t $R$

$(iii)$ Compute nullifier hash $h= H(k)$

$(iv)$ Compute a proof using Groth16 proof system s.t. :

\begin{aligned} \texttt{wit} &\leftarrow (k, r) \in \mathbb{F}_p^{2}, \ l \in \mathbb{Z}_{2}^{16}, \ O(l) \in \mathbb{Z}_p^{16} \\ \texttt{stmt} &\leftarrow h = H(k) \ \wedge \ O(l) \text{ is opening proof of } H(k, r) \text{ at position } l \text{ to } R \end{aligned}

\begin{aligned} \texttt{wit} &\leftarrow (k, r) \in \mathbb{F}_p^{2}, \ l \in \mathbb{Z}_{2}^{16}, \ O(l) \in \mathbb{Z}_p^{16} \\ \texttt{stmt} &\leftarrow h = H(k) \ \wedge \ O(l) \text{ is opening proof of } H(k, r) \text{ at position } l \text{ to } R \end{aligned}

$(v)$ The contract verifies the proof and uniqueness of the nullifier hash.

If that succeeds, the contract transfers $N$ ETH to $A$ .

Withdraw

To withdraw $C_3$ , create a proof $\pi = \mathcal{P}\left( k_3, r_3, (C_4, h_1^1, h_2^2) \right)$
The contract verifies $\pi$ and checks if nullifier hash is unused.

$C_1$

$C_2$

$C_3$

$C_4$

$H(0)$

$h^1_1$

$h^1_2$

$h^1_3$

$h^1_4$

$h^2_1$

$h^2_2$

$h^3_5$

Comparison

Anonymity
Non-custodial
Variable amounts
Shielded payments
ZK Rollup
Proof system

$^{\dagger}$ Concerns with Tornado.cash: https://lightco.in/2019/08/07/tornado-review/

Groth16

PLONK

$^{\ddagger}$ Theoretically, ZK Rollups with Groth16 is possible. Loopring uses Groth16 with ZK Rollups.

$\dagger$

$\ddagger$
