August 2022
DUAL TECH HYBRID
TOPIC
Chalk Talk
Overview
Background
Product Overview
What Problem Are We Solving?
Sales & Support
Traditional Solutions
Available Materials
Hybrid Exit Sign Innovation
How To Get More Information
- The Maintenance Regime
- The Cost of Maintenance
- UL924 Approval
All Battery Devices Must Be Maintained to NFPA101 - 7.0.3.1.1
- Monthly 30-Second Tests
- Yearly 90-Minute Tests
- Self-Diagnostics Can Reduce Test Burden by Automatically Performing the Test, Documentation Still Needs to be Gathered Monthly
ISOLITE
DUAL TECH HYBRID
Chalk Talk
I. BACKGROUND
Maintenance & Code Obligations
I. BACKGROUND
The Cost Of Ownership
- Assume a $50 Exit Sign
- Assume Labor Rates of $30/Hour ($0.50/Minute)
- 2-Minute Walk Between Exit Signs, 30-Second Test, 30-Seconds for Documentation
Considered Over 10 Years
ISOLITE
DUAL TECH HYBRID
Chalk Talk
Over 10 Years...
The Cost of A Battery-Backed Exit Signs is more than 3x the "Sticker Price"
- 10 Years * 12 Months/Year * 3-Minutes/Month * $0.50/Minute = $180 + $50 = $230
- This doesn't account for a battery replacement that might have to happen if a test fails.
- This doesn't account for the 90-minute test that will need to be run 10 times.
I. BACKGROUND
ISOLITE
DUAL TECH HYBRID
Chalk Talk
Traditional, Single Source Exit Signs
- Batteries Have a Limited Life and are a Point of Maintenance and Cost in a Building
Problem Statement
Self-Luminous Tritium Signs
- Zero-Wires Solutions
Traditional Solutions
- Still the Best Solution if AC Power is Unavailable
- Not as Bright as a Powered Sign
- Specific Requirements About Lighting in the Space, a Design Headache
Photoluminescent Exit Signs
I. BACKGROUND
ISOLITE
DUAL TECH HYBRID
Chalk Talk
A Bad Solution...
Doesn't meet any sort of code
Isn't visible when the door is ajar
Isn't visible when the power is out
Stroke height and width are inadequate
Tape isn't a recognized permanent mounting method
This is in a location where splashes are likely, so low level paper isn't a great material
I. BACKGROUND
Hybrid Solution
- Solves the Problem by Providing the AC Powered Charging and the Photoluminescence in the Same Package
Patented Photoluminescent Diffusor
ISOLITE
DUAL TECH HYBRID
Chalk Talk
- When There is Power, It's a Normal Green Exit Sign
- When the Power Goes Out, the Pre-Charged Photoluminescent Material Will Continue to Stay Illuminated for Over 90-Minutes
I. BACKGROUND
ISOLITE
DUAL TECH HYBRID
Chalk Talk
Photoluminescent Diffusor
Material Cross-Section of DTH2.0
LED
(White)
Film
(Green)
Housing
Solid
Solid
Open
Hybrid Solution
Patented Photoluminescent Diffusor
I. BACKGROUND
ISOLITE
DUAL TECH HYBRID
Chalk Talk
Hybrid Solution
Patented Photoluminescent Diffusor
Photoluminescent Diffusor
Material Cross-Section of DTH2.0
LED
(White)
Film
(Green)
Housing
Power On
Solid
Solid
I. BACKGROUND
ISOLITE
DUAL TECH HYBRID
Chalk Talk
Hybrid Solution
Patented Photoluminescent Diffusor
Photoluminescent Diffusor
Material Cross-Section of DTH2.0
LED
(White)
Film
(Green)
Housing
Power Off
Solid
Solid
I. BACKGROUND
ISOLITE
DUAL TECH HYBRID
Chalk Talk
- Because of the technology it has to Use the UL 924 Visibility Test
- It Does Not Get Subjected to the Contrast Test
This is Tested at 50 feet, 75 feet, and 100 feet
Code Compliance
The DTH is UL 924 Listed
II. PRODUCT OVERVIEW
ISOLITE
DUAL TECH HYBRID
Chalk Talk
- Constructed of a Two-Piece, Thick Wall, Heavy Duty, Die-Cast Aluminum Alloy
- UL Approved for a 100-foot Viewing Distance
- UL Listed to UL 924 Standard, NFPA Life Safety Code 101
- Fast Recharge Time
- Isolite Offers a Lifetime Warranty
DTH2
Product Features
II. PRODUCT OVERVIEW
ISOLITE
DUAL TECH HYBRID
Chalk Talk
- Thin Architectural Profile
- Multiple Housing Colors; Custom Colors Available
- Only Available in Green Legend
- Hang Straight Pendant
- Damp Location Listed
Architectural Design
Product Features
.625"
Sales Materials
- Training Video Link (Public - For Agent Only)
- Sales Presentation PDF (Public - For Agent Sales Presentations)
- Spec Sheet
- Installation Guide
Available on the Website
Available within Follow-up Sales Packet
III. SALES & SUPPORT
ISOLITE
DUAL TECH HYBRID
Chalk Talk
Need Further Assistance?
Team of Experts
Schedule a Webinar for Advanced Sales & Engineering Training
III. SUPPORT & SUPPORT
ISOLITE
DUAL TECH HYBRID
Chalk Talk
THANK YOU
