Setting Up

getpostman.com

Freenode IRC: #barbican-workshop

https://etherpad.openstack.org/p/

barbican-workshop-qa

Barbican: Securing Your Secrets

Freenode IRC:

#barbican-workshop

Who We Are

Chelsea Winfree

@chellygel

IRC: chellygel

John Vrbanac

IRC: jmvrbanac

+JohnVrbanac

Steven Heyman

@330cic

IRC: hockeynut

Freenode IRC:

#barbican-workshop

Barbican: Securing Your Secrets

Importance of Secret Storage

Why Barbican?

How do you use Barbican?

What is Barbican?

#barbican-workshop

Importance of Secret Storage

Key Management

Private Data

Trusted Data

#barbican-workshop

Key Management

Where are my keys?

#barbican-workshop

Key Management

#barbican-workshop

Key Management

#barbican-workshop

Private Data

Medical or Financial Records

Contracts

Surprise Birthday Party

Database Passwords

#barbican-workshop

Trusted Data

Who do you trust?

How do you know you can trust them?

SSL / TLS

Why Barbican?

Key Management

Private Data

Trusted Data

#barbican-workshop

Why Barbican?

Key Management

Where is your Key?

Where is your Data?

#barbican-workshop

Why Barbican?
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Encryption and Decryption is hard!

Private Data

#barbican-workshop

Why Barbican?

Trusted Data

Managed Private Key

Secure Certificate

Trust Built

#barbican-workshop

What is Barbican?

Open Source

Python

REST API

Incubated in OpenStack

Key Management System

Tools of the Trade

Secret

Order

Container

Setting Up

https://www.getpostman.com/

Freenode IRC:

#barbican-workshop

https://etherpad.openstack.org/p/

barbican-workshop-qa

#barbican-workshop

Using Barbican

#barbican-workshop

Authentication

Keystone

Get an Auth Token

Verify Auth Token

Makes Request w/ Token

Returns Response

#barbican-workshop

Authentication

POST http://workshop-lon-auth.cloudkeep.io/v2.0/tokens
Content-Type: application/json
Accept: application/json
BODY:
{
  "auth": {
    "passwordCredentials": {
      "username": "{YOUR_USERNAME}",
      "password": "{YOUR_PASSWORD}"
    },
    "tenantName": "{YOUR_TENANT_NAME}"
  }
}
RESPONSE:
{
    "access": {
        "token": {
            "id": "{YOUR_AUTH_TOKEN}",
            "expires": "2014-10-10T22:23:47Z",
            "issued_at": "2014-10-10T21:23:47.498474"
        },
       ----------------- snip ----------------
    }
}

Exercise A-1

#barbican-workshop

Secrets

A singular item that lives inside Barbican

Metadata

Payload

Content Type

Algorithm

Bit Length

Name

Mode

Expiration Date

Plain Text

Base 64

Raw Binary*

#barbican-workshop

Create a Secret

POST http://workshop-lon-api.cloudkeep.io/v1/secrets
Content-Type: application/json
X-Auth-Token: {YOUR_AUTH_TOKEN}

BODY:
{
  "name": "Super secret thing",
  "expiration": "2014-12-28T19:14:44.180394",
  "payload": "beer",
  "payload_content_type": "text/plain"
}

RESPONSE:

{
    "secret_ref": "http://workshop-lon-api.cloudkeep.io/v1/secrets/fe0eac05-8eff-4eff-81e3-16e2e640241b"
}

Exercise S-1

#barbican-workshop

Retrieve Secret Metadata

GET http://workshop-lon-api.cloudkeep.io/v1/secrets/{YOUR_SECRET_UUID}
X-Auth-Token: {YOUR_AUTH_TOKEN}

RESPONSE:

{
    "created": "2014-10-10T19:44:57.833424",
    "updated": "2014-10-10T19:44:57.838825",
    "expiration": "2014-10-28T19:14:44.180394",
    "mode": null,
    "name": "Super secret thing",
    "status": "ACTIVE",
    "algorithm": null,
    "bit_length": null,
    "secret_ref": "http://workshop-lon-api.cloudkeep.io/v1/secrets/{YOUR_SECRET_UUID}",
    "content_types": {
        "default": "text/plain"
    }
}

Exercise S-2

#barbican-workshop

Retrieve Secret Payload

GET http://workshop-lon-api.cloudkeep.io/v1/secrets/{YOUR_SECRET_UUID}
Accept: text/plain
X-Auth-Token: {YOUR_AUTH_TOKEN}

RESPONSE:

beer

Exercise S-3

#barbican-workshop

Retrieve a List of Secrets

GET http://workshop-lon-api.cloudkeep.io/v1/secrets
X-Auth-Token: {YOUR_AUTH_TOKEN}

RESPONSE:

{
    "next": "http://workshop-lon-api.cloudkeep.io/v1/secrets?limit=10&offset=10",
    "secrets": [
        {
            "algorithm": null,
            "bit_length": null,
            "content_types": {
                "default": "text/plain"
            },
            "created": "2014-10-10T02:35:42.463513",
            "expiration": "2014-10-28T19:14:44.180394",
            "mode": null,
            "name": "Super secret thing",
            "secret_ref": "http://workshop-lon-api.cloudkeep.io/v1/secrets/{SECRET_UUID}",
            "status": "ACTIVE",
            "updated": "2014-10-10T02:35:42.470646"
        },
        --------------- snip -------------------
    ],
    "total": 3803
}

Exercise S-4

Deleting a Secret

DELETE http://workshop-lon-api.cloudkeep.io/v1/secrets/{YOUR_SECRET_UUID}
X-Auth-Token: {YOUR_AUTH_TOKEN}

Exercise S-5

#barbican-workshop

Can You Keep A Secret?

Create a Secret

Retrieve Secret Metadata

Retrieve a List of Secrets

Delete a Secret

Retrieve Secret Payload

Orders

Singular action that will generate a secret

Asynchronously encapsulates workflow and history of secret creation.

Example: SSL Certificates

#barbican-workshop

Creating an Order

POST http://workshop-lon-api.cloudkeep.io/v1/orders
Content-Type: application/json
X-Auth-Token: {YOUR_AUTH_TOKEN}

BODY:
{
  "type": "key",
  "meta": {
    "mode": "cbc",
    "bit_length": 256,
    "name": "secretname",
    "algorithm": "aes",
    "payload_content_type": "application/octet-stream"
  }
}

RESPONSE:
{
    "order_ref": "http://workshop-lon-api.cloudkeep.io/v1/orders/{YOUR_ORDER_UUID}"
}

Exercise O-1

#barbican-workshop

Get an Order

GET http://workshop-lon-api.cloudkeep.io/v1/orders/{YOUR_ORDER_UUID}
X-Auth-Token: {YOUR_AUTH_TOKEN}

RESPONSE:
{
    "status": "ACTIVE",
    "type": "key",
    "meta": {
        "algorithm": "aes",
        "bit_length": 256,
        "mode": "cbc",
        "payload_content_type": "application/octet-stream"
    },
    "order_ref": "http://workshop-lon-api.cloudkeep.io/v1/orders/{YOUR_ORDER_UUID}",
    "secret_ref": "http://workshop-lon-api.cloudkeep.io/v1/secrets/{CREATED_SECRET_UUID}",
    "created": "2014-10-10T19:43:09.828927",
    "updated": "2014-10-10T19:43:09.864890"
}

Exercise O-2

#barbican-workshop

Get a List of Orders

GET http://workshop-lon-api.cloudkeep.io/v1/orders
X-Auth-Token: {YOUR_AUTH_TOKEN}

RESPONSE:
{
    "next": "http://workshop-lon-api.cloudkeep.io/v1/orders?limit=10&offset=10",
    "orders": [
        {
            "status": "ACTIVE",
            "type": "key",
            "meta": {
                "algorithm": "aes",
                "bit_length": 256,
                "expiration": null,
                "mode": "cbc",
                "name": "secretname"
            },
            "order_ref": "http://workshop-lon-api.cloudkeep.io/v1/orders/{ORDER_UUID}",
            "secret_ref": "http://workshop-lon-api.cloudkeep.io/v1/secrets/{SECRET_UUID}",
            "created": "2014-10-10T02:47:48.564067",
            "updated": "2014-10-10T02:47:48.591162"
        },
        -------------- snip ------------
    ],
    "total": 3803
}

Exercise O-3

Delete an Order

DELETE http://workshop-lon-api.cloudkeep.io/v1/orders/{YOUR_ORDER_UUID}
X-Auth-Token: {YOUR_AUTH_TOKEN}

Exercise O-4

#barbican-workshop

Following Orders

Create an Order

GET an Order

Get a List of Orders

Delete an Order

#barbican-workshop

Containers

Stores a reference (or references) to secrets

3 Types of Containers:

Generic

RSA

Certificate

Example RSA Container:

Private Key

Public Key

Private Key Passphrase

#barbican-workshop

Creating a Container

POST http://workshop-lon-api.cloudkeep.io/v1/containers
X-Auth-Token: {YOUR_AUTH_TOKEN}
Content-Type: application/json

BODY:
{
  "type": "generic",
  "name": "Pitcher",
  "secret_refs": [
    {
       "name": "private_key",
       "secret_ref":"http://workshop-lon-api.cloudkeep.io/v1/secrets/{A_SECRET_UUID}"
    }
  ]
}

RESPONSE:
{
    "container_ref": "http://workshop-lon-api.cloudkeep.io/v1/containers/{YOUR_CONTAINER_UUID}"
}

Exercise C-1

#barbican-workshop

Get a Container

GET http://workshop-lon-api.cloudkeep.io/v1/containers/{YOUR_CONTAINER_UUID}
X-Auth-Token: {YOUR_AUTH_TOKEN}

RESPONSE:

{
    "status": "ACTIVE",
    "type": "generic",
    "name": "container name",
    "consumers": [],
    "secret_refs": [
        {
            "name": "private_key",
            "secret_ref": "http://workshop-lon-api.cloudkeep.io/v1/secrets/{SECRET_UUID}"
        }
    ],
    "container_ref": "http://workshop-lon-api.cloudkeep.io/v1/containers/{YOUR_CONTAINER_UUID}",
    "created": "2014-10-10T19:36:42.313216",
    "updated": "2014-10-10T19:36:42.313225"
}

Exercise C-2

#barbican-workshop

Get a List of Containers

GET http://workshop-lon-api.cloudkeep.io/v1/containers
X-Auth-Token: {YOUR_AUTH_TOKEN}

RESPONSE:
{
    "next": "http://workshop-ord-api.cloudkeep.io/v1/containers?limit=10&offset=10",
    "containers": [
        {
            "status": "ACTIVE",
            "type": "generic",
            "name": "container name",
            "consumers": [],
            "secret_refs": [
                {
                    "name": "private_key",
                    "secret_ref": "http://workshop-lon-api.cloudkeep.io/v1/secrets/{SECRET_UUID}"
                }
            ],
            "container_ref": "http://workshop-lon-api.cloudkeep.io/v1/containers/{CONTAINER_UUID}",
            "created": "2014-10-10T19:36:42.313216",
            "updated": "2014-10-10T19:36:42.313225"
        },
        ------------------ snip ----------------------
    ],
    "total": 2102
}

Exercise C-3

Delete a Container

DELETE http://workshop-lon-api.cloudkeep.io/v1/containers/{YOUR__UUID}
X-Auth-Token: {YOUR_AUTH_TOKEN}

Exercise C-4

#barbican-workshop

Contain Yourself!

Create a Container

GET a Container

Get a List of Containers

Delete a Container

#barbican-workshop

Wrap-Up and Questions

#barbican-workshop

Important Information
