Supercharging ActiveRecord with PostgreSQL

Who am I?


Partner at DockYard
GitHub: danmcclain
Twitter: @_danmcclain

PostgreSQL

  • Advanced Data Types
    • Arrays
    • Hstore (Hash Store, aka Key-Value store)
    • JSON
    • Ranges
  • Powerful Features
    • windowing functions
    • table inheritance
    • Schemas - Separate silos within a single database

What We'll Explore:
Arrays

  • PostgreSQL has built in support for arrays of any datatype
    • That includes user-defined types as well
  • Can be multi-dimensional
    • Child arrays must have the same number of elements as their siblings

What We'll Expore:

HStore

  • Hash Store
  • Key-Value store
  • Values are stored as strings, so plan on converting values if you want to store something else

What We'll Explore

Rank and CTEs

  • PostgreSQL has window functions
    • perform a calculation over a set of records
  • rank - determines a record's rank over a specific order
    • takes ties into account
  • CTEs or Common Table Expressions allow you to declare a specific query as a temporary table to be used in a complex query

Patterns we'll examine: Tagging

Patterns we'll examine: Similar Records

Patterns we'll examine: Single Table Inheritance


Patterns we'll examine: Leaderboards

Tagging


  • We want to apply tags to notes entered into our system
  • We don't care about generating a tag cloud
  • We want to be able to find all notes with a given tag

Many to Many relation

  • Usually, we'll generate a many-to-many relation between notes and tags
  • We'll have a tag record for each tag applied to a note
  • We'll have to generate a new tag when a user wants to use one we have not previously encountered

Using Arrays for tags

  • PostgreSQL has native support for array columns
  • We can store the tags as an array column on our notes
  • We no longer have to worry about creating tag records when we encounter a new one

Adding our tags array to the model

class AddTagsToNotes < ActiveRecord::Migration
  def change
    add_column :notes, :tags, :string, array: true
  end
end

Finding Tagged Notes

  • Now that we are tagging our notes, we need a way of finding them
  • PostgreSQL has multiple ways of checking if an array contains a value
    • ANY(...)
    • @> - contains operator

ANY

  • We can use the ANY() function to see if a value is stored in any element of the array

SELECT notes.*
FROM notes
WHERE 'useful' = ANY(notes.tags)
  • This won't use any indexes

@> - Contains

  • We can use the @> operator to see if an array on the left contains the array on the right of the operator (order matters)

SELECT notes.*
FROM notes
WHERE notes.tags @> '{useful}'
  • Without an index, this has the same performance as ANY()
  • When we index the array with GIN (Generalized Inverted Index), we can see up to ~50 X speed improvement

GIN indexing our Array

class AddTagsToNotes < ActiveRecord::Migration
  def change
    add_index :notes, :tags, using: :gin
  end
end

Some Benchmarking

  • 100,000 notes, each with 100 tags
  • 10,000 possible tags
  • Table was cached by scanning it once
  • Run on a MacBook Pro Retina with 16GB of RAM and SSD
    • Noticeably slower reads on a Mac Mini with spinning metal

Finding Via Has_Many

First Run - 370 ms

Nested Loop
   ->  Bitmap Heap Scan on post_tags
         Recheck Cond: (tag_id = 1)
         ->  Bitmap Index Scan on index_post_tags_on_tag_id
               Index Cond: (tag_id = 1)
   ->  Index Scan using posts_pkey on posts
         Index Cond: (id = post_tags.post_id)
 Total runtime: 370.139 ms

Subsequent calls - 13 ms

Nested Loop
  ->  Bitmap Heap Scan on post_tags
        Recheck Cond: (tag_id = 2)
        ->  Bitmap Index Scan on index_post_tags_on_tag_id
              Index Cond: (tag_id = 2)
  ->  Index Scan using posts_pkey on posts
        Index Cond: (id = post_tags.post_id)
Total runtime: 13.511 ms

Array: Finding via ANY

First run: 503 ms

Aggregate
  ->  Seq Scan on posts
        Filter: ('Tag #1'::text = ANY ((array_tags)::text[]))
        Rows Removed by Filter: 98989
Total runtime: 503.517 ms

Subsequent runs: 500 ms

Aggregate
  ->  Seq Scan on posts
        Filter: ('Tag #1'::text = ANY ((array_tags)::text[]))
        Rows Removed by Filter: 98989
Total runtime: 499.618 ms

Array: Finding via @>

First run - Pre index: 536 ms

Aggregate
  ->  Seq Scan on posts
        Filter: (array_tags @> '{"Tag #1"}'::character varying[])
        Rows Removed by Filter: 98989
Total runtime: 536.183 ms
First run - Post index: 8ms
 Aggregate
  ->  Bitmap Heap Scan on posts
       Recheck Cond: (gin_tags @> '{"Tag #1"}'::character varying[])
       ->  Bitmap Index Scan on index_posts_on_gin_tags
             Index Cond: (gin_tags @> '{"Tag #1"}'::character varying[])
 Total runtime: 8.056 ms

Results

Method Run 1 Run 2
has_many 370 ms 13 ms
Array: ANY 503 ms 500 ms
Array: @< (no index) 499 ms 500 ms
Array: @< (indexed) 8 ms 5 ms

Drawbacks

  • You lose the ability to efficiently create a list of tags
    • Getting a distinct list of tags from a series of arrays is slow
    • It's also fairly complex
  • GIN can be slow to update
    • Multiple inserts into index (one for each key extracted)
    • Can be mitigate somewhat using FASTUPDATE

Notes

  • Database-side Cache matters
    • You will see a performance increase on subsequent runs, as the results will be in memory
    • Results across the board were quicker after the first table scan, as the table was in memory after that

Similar Records

  • We want to build out the ability to have similar posts listed for a given post
  • We don't care about mapping a similar post back to the source item (don't need belongs_to)

Old Way

  • Create a similar_posts model
    • post_id: id of the parent post (belongs_to)
    • similar_post_id: id of the child post (belongs_to)
  • Wire up a has_many though: relation to create a similar_posts attribute on the post model

Using Arrays

  • We can build has_many-type functionality using arrays
  • This allows us to retrieve all the similar item ids with a single call for the item record

Migration

  • We want an attribute on our model to store the ids

class CreateMembers < ActiveRecord::Migration
  def change
    add_column :posts, :similar_post_ids, :integer, array: true
  end
end

has_many like methods

  • We can add a method Post#similar_posts which will retrieve our item's by their ids stored in Post#similar_post_ids
  • We can also add a Post#similar_posts= method that will take the array of items passed to it and store their ids in Post#similar_post_ids

has_many like methods

class Post < ActiveRecord::Base
  def similar_posts
    self.class.where(id: similar_posts_ids)
  end

  def similar_posts=(children)
    self.similar_posts_ids = children.map(&:id)
  end

  def similar_posts_ids=(ids)
    write_attribute :similar_posts_ids, ids.reject{ |id| id.to_i <= 0 }
  end
end

Using our fake has_many

post = Post.find(1)
post.similar_posts # => [Post, Post, Post]
post.similar_posts = [Post, Post] # Updates the similar_post_ids attribute

# the following won't work
post.similar_posts << Post # We aren't observing this array,
                           # so it won't update the ids attribute

# we can work around it with the following
post.similar_posts += [Post] # calls the setter on the array

Benefits

  • Alternate way of providing has_many
  • Avoids additional records to maintain relations

Next Steps

  • This example could be built out further using a proxy class in the has_many-like methods
    • This would allow us to perform << operations and have ActiveRecord track the changes

Single Table Inheritence

  • We are using single table inheritance to differentiate between multiple user types
  • We want to add a set of object specific attributes for each user type
  • Previously, we could move these attributes to a profile object and that profile would belong to a class

HStore

  • PostgreSQL has a Hstore or Hash Store column type
  • We can store a set of key-value properties on this column

Enabling Hstore

  • Hstore was added to PostgreSQL 9.2 as an extension
  • Rails 4.0 added enable_extension which will allow you to enable an extension via a migration
  • enable_extension 'hstore' will enable hstore in your database

An Example

  • Joe Him at DevMynd details using Hstore with Rails 3.2 via activerecord-postgres-hstore [1]
    • He extends ActiveRecord::Base to create an hstore_attribute for his models
  • We can apply the concepts to Rails 4




[1]: http://www.devmynd.com/blog/2013-3-single-table-inheritance-hstore-lovely-combination

    Our Member Class

    • The Member class will serve as the base class for our STI infrastructure



    class CreateMembers < ActiveRecord::Migration
      def change
        enable_extension 'hstore' # Let's enable Hstore

        create_table :members do |t|
          t.string :username
          t.string :type
          t.hstore :data # We'll store all our attributes in a column
                         # called data
          t.timestamps
        end
      end
    end

    Extending activeRecord

    module HstoreAccessor
        def hstore_accessor(hstore_attribute, *keys)
          Array(keys).flatten.each do |key|
            define_method("#{key}=") do |value|
              send("#{hstore_attribute}=", (send(hstore_attribute) || {}).merge(key.to_s => value))
              send("#{hstore_attribute}_will_change!")
            end
            define_method(key) do
              send(hstore_attribute) && send(hstore_attribute)[key.to_s]
            end
          end
        end
      end
    end
    ActiveRecord::Base.send(:extend, HstoreAccessor)

    • We define hstore_accessor, which will define a getter and setter against our hstore column

    Creating User class

    • Users have an email and age

    class User < Member
      hstore_accessor :data, :email, :age
    end
    • Now we can access User#email, and User#age
    • We can also validate these attributes
    class User < Member
      hstore_accessor :data, :email, :age
      validates :email, :age, presence: true
    end

    User.new.email #=> nil

    User.new.valid? #=> false


    Creating another class

    class TwitterUser < Member
      hstore_accessor :data, :twitter_handle
    end
    • Since we only set up twitter_handle, we don't have access to email, which we set up on our User model
    twitter_user = TwitterUser.new twitter_handle: '_danmcclain', username: 'dan'
    twitter_user.twitter_handle   #=> "_danmcclain"
    twitter_user.username         #=> "dan"
    twitter_user.email            #=> NoMethodError


    Limitations

    • HStore stores values as strings, so you have to convert values yourself
      • We could extend hstore_attribute so that it performs type casting

    Leaderboards


    • Need a leaderboard for each game
    • Need the ability to return a user's best score for a given game
    • Want to page through our scores, but maintain ranking

    Rank()

    • PostgreSQL provides the Rank windowing function
    • Takes ties into account when ranking
    SELECT rank() OVER(ORDER BY points DESC), username, points
    FROM scores
    WHERE game = 'Barking Bostons'
    • Rank will be scoped to the current query
    ┌──────┬──────────┬────────┐
    │ rank │ username │ points │
    ├──────┼──────────┼────────┤
    │    1 │ Brian    │    300 │
    │    2 │ Dan      │    200 │
    │    3 │ Dan      │    100 │
    │    4 │ Doug     │     30 │
    └──────┴──────────┴────────┘


    First attempt at getting a user's rank

    SELECT rank() OVER (ORDER BY scores.points DESC), username, points
    FROM scores
    WHERE game = 'Barking Bostons' AND username = 'Dan'
    • We get back the user's scores for the game
    • BUT the ranks are only for the user's scores, it does not take into account other users
    ┌──────┬──────────┬────────┐
    │ rank │ username │ points │
    ├──────┼──────────┼────────┤
    │    1 │ Dan      │    200 │
    │    2 │ Dan      │    100 │
    └──────┴──────────┴────────┘


    Using Common Table Expressions to get the ranks of a User's Scores

    • Common Table Expressions (CTEs) allow you to alias a subquery
    WITH top_scores_for_game AS (
      SELECT rank() OVER (ORDER BY points DESC), username, points
      FROM scores
      WHERE scores.game = 'Barking Bostons'
    )
    SELECT top_scores_for_game.*
    FROM top_scores_for_game
    • The above query will return all the results from the WITH statement

    Attempt #2

    • We'll use a CTE to get all the scores for a game, then find our user within those results

    WITH top_scores_for_game AS (
      SELECT rank() OVER (ORDER BY points DESC), username, points
      FROM scores
      WHERE scores.game = 'Barking Bostons'
    )
    SELECT top_scores_for_game.*
    FROM top_scores_for_game
    WHERE top_scores_for_game.username = 'Dan'
    ┌──────┬──────────┬────────┐
    │ rank │ username │ points │
    ├──────┼──────────┼────────┤
    │    2 │ Dan      │    200 │
    │    3 │ Dan      │    100 │
    └──────┴──────────┴────────┘


    Getting ranked results in ActiveRecord

    • We can drop this whole block of SQL into a find_by_sql call to get models back
    query = <<-SQL
    WITH top_scores_for_game AS (
      SELECT rank() OVER (ORDER BY points DESC), username, points
      FROM scores
      WHERE scores.game = 'Barking Bostons'
    )
    SELECT top_scores_for_game.*
    FROM top_scores_for_game
    WHERE top_scores_for_game.username = 'Dan'
    SQL

    Score.find_by_sql query
    => [#<Score ... >, #<Score ... >]


    Using postgres_ext for rank and CTE

    • postgres_ext has support for ranking results and querying against CTEs
    • Return the scores ranked over their points for the game named 'Barking Bostons'
    Score.ranked(points: :desc).where(game: 'Barking Bostons')

    • Now lets get the user's ranked scores for the game using a CTE

    Score.from_cte('top_scores_for_game',
      Score.ranked(points: :desc).where(game: 'Barking Bostons')).where(username: 'Dan')

    Wrapping Up

    • PostgreSQL has some really powerful features baked in
    • Your situation ultimately dictates the best approach
    • Play with different solutions to see what is the best performance/maintainability trade off for your specific use case
    • Don't just use it because "It's new/cool"

    Other PostgreSQL features to explore

    • JSON
    • Views
    • Schemas
    • Network Types (MAC address, IP Address)
    • Ranges
    • User defined types
    • PostGIS

    Questions?

    Thank You


    • Twitter: @_danmcclain
    • GitHub: github.com/danmcclain
    • Postgres_ext: github.com/dockyard/postgres_ext

    Supercharging ActiveRecord with PostgreSQL

    By Dan McClain

    Supercharging ActiveRecord with PostgreSQL

    We'll go over some common patterns in Rails and how we can rebuild them by off loading the work onto PostgreSQL. This talk was given at Wicked Good Ruby on October 12, 2013

    • 8,451
    Loading comments...

    More from Dan McClain
