A socket

 A socket address is the combination of an IP address and

 Based on this address, internet sockets deliver incoming

 data packets to the appropriate application process or thread.

Create Socket

require 'socket'

socket=Socket.new(Socket::AF_INET,Socket::SOCK_STREAM)

require 'socket'

socket = Socket.new(:INET6, :STREAM)

Client vs Server

When you create a socket it must assume one of two roles:

                             1) initiator or

                             2) listener

                   A socket that listens is a server

         A socket that initiates a connection is a client

Server

Server socket listens for connections rather than initiating them.

The typical life-cycle looks something like this:

       1. CREATE
2. BIND

    3. LISTEN
      4. ACCEPT
   5. CLOSE

CREATE

require 'socket'
socket = Socket.new(:INET, :STREAM)

Bind

require 'socket'
socket = Socket.new(:INET, :STREAM)

# Create a C struct to hold the address for listening.

addr = Socket.pack_sockaddr_in(4481,'0.0.0.0')
socket.bind(addr)


LISTEN

require 'socket'

server = Socket.new(:INET, :STREAM)
addr =Socket.pack_sockaddr_in(4481,'0.0.0.0')

server.bind(addr)

server.listen(Socket::SOMAXCONN)

ACCEPT

require 'socket'

server = Socket.new(:INET, :STREAM)
addr = Socket.pack_sockaddr_in(4481,'0.0.0.0')
server.bind(addr)
server.listen(Socket::SOMAXCONN)

connection, _ = server.accept

CLOSE

read / write / shutdown

require 'socket'

server = Socket.new(:INET, :STREAM)
addr= Socket.pack_sockaddr_in(4481,'0.0.0.0')
server.bind(addr)
server.listen(Socket::SOMAXCONN)
connection, _ = server.accept

# Create a copy of the connection.
copy = connection.dup

# This shuts down communication on all
# copies of the connection.
connection.shutdown

# This closes the original connection.
# The copy will be closed when the GC
# collects it.
connection.close


RUBY WRAPPERS

require 'socket'

Socket.tcp_server_loop(4481) do |connection|
  # handle connection
  connection.close
end

Client

The client lifecycle:

       1. CREATE

2. BIND

          3. CONNECT

    4. CLOSE

CREATE

require 'socket'
socket = Socket.new(:INET, :STREAM)

BIND

require 'socket'socket = Socket.new(:INET, :STREAM)

remote_addr= Socket.pack_sockaddr_in(80,'google.com')

CONNECT

require 'socket'

socket = Socket.new(:INET, :STREAM)

remote_addr= Socket.pack_sockaddr_in(80,'google.com')
socket.connect(remote_addr)

CLOSE

nothing new here ;)

Client / Server app

SERVER

require 'socket'

module CloudHash

class Server
  def initialize(port)
    @server = TCPServer.new(port)
    puts "Listening on port
    #{@server.local_address.ip_port}"
    @storage = {}
  end  def start
Socket.accept_loop(@server) do |connection|
     handle(connection)
     connection.close
   end
  end

  def handle(connection)
    request = connection.read
    connection.write process(request)
  end

  def process(request)
    command, key, value = request.split
    case command.upcase
    when 'GET'
      @storage[key]
    when 'SET'
      @storage[key] = value
    end
   end
 end
end

server = CloudHash::Server.new(4481)
server.start

CLIENT

require 'socket'
  module CloudHash
    class Client
      class << self
        attr_accessor :host, :port
      end

      def self.get(key)
        request "GET #{key}"
      end

      def self.set(key, value)
        request "SET #{key} #{value}"
      end

      def self.request(string)
        @client = TCPSocket.new(host, port)
        @client.write(string)
        # Send EOF after writing the request.
        @client.close_write
        @client.read
      end
    end
  end

CloudHash::Client.host = 'localhost'
CloudHash::Client.port = 4481

puts CloudHash::Client.set 'Charlie','Unicorn'
puts CloudHash::Client.get 'Charlie'

Architectural Solutions

                                        Process per connection

                                        Thread per connection

                                        Preforking

                                        Thread Pool

                                        Evented (Reactor)

module FTP
  module Common
 CRLF = "\r\n"
 def  initialize(port = 21)
      @control_socket = TCPServer.new(port)
      trap(:INT) { exit }
 end

    def respond(response)
@client.write(response)
@client.write(CRLF)
   end

    class CommandHandler
attr_reader :connection

  def initialize(connection)
@connection = connection
 end

      def pwd
 @pwd || Dir.pwd
     end

      def handle(data)
        cmd = data[0..3].strip.upcase
        options = data[4..-1].strip

case cmd
when 'USER'
 # Accept any username anonymously
"230 Logged in anonymously"

      when 'SYST'
      # what's your name?
      "215 UNIX Working With FTP"
      when 'CWD'
        if File.directory?(options)
          @pwd = options
          "250 directory changed to #{pwd}"
        else
          "550 directory not found"
        end
      when 'PWD'
        "257 \"#{pwd}\" is the current directory"

    when 'PORT'
      parts = options.split(',')
      ip_address = parts[0..3].join('.')
      port = Integer(parts[4]) * 256 + Integer(parts[5])
      @data_socket = TCPSocket.new(ip_address, port)
      "200 Active connection established (#{port})"
    when 'RETR'
      file = File.open(File.join(pwd, options), 'r')
      connection.respond "125 Data transfer starting #{file.size} bytes"
      bytes = IO.copy_stream(file, @data_socket)
      @data_socket.close
      "226 Closing data connection, sent #{bytes} bytes"

   when 'LIST'      connection.respond "125 Opening data connection for file list"
     result = Dir.entries(pwd).join(CRLF)
     @data_socket.write(result)
     @data_socket.close
     "226 Closing data connection, sent #{result.size} bytes"
   when 'QUIT'
     "221 Ciao"
   else
     "502 Don't know how to respond to #{cmd}"
   end
  end
end

Serial

require 'socket'
require_relative '../common'
module FTP
  class Serial
    include Common
    def run
      loop do
        @client = @control_socket.accept
        respond "220 OHAI"
        handler = CommandHandler.new(self)

        loop do
          request = @client.gets(CRLF)
          if request
            respond handler.handle(request)
          else
            @client.close                   break
          end

Process per connection

class ProcessPerConnection
  include Common
  def run
    loop do
      @client = @control_socket.accept
        pid = fork do
        respond "220 OHAI"
        handler = CommandHandler.new(self)
        loop do
          request = @client.gets(CRLF)

          if request
            respond handler.handle(request)
          else
            @client.close
            break
          end
        end
      end
        Process.detach(pid)
    end

Thread per connection

class ThreadPerConnection
  include Common
  def run
    Thread.abort_on_exception = true
    loop do
      @client = @control_socket.accept
      Thread.new do
      respond "220 OHAI"
      handler = CommandHandler.new(self)
      loop do
        request = @client.gets(CRLF)

             if request
          respond handler.handle(request)
        else
          @client.close
          break
        end
        end
    end
  end

PREFORKING

   4. Main server process keeps an eye on the child processes.

class Preforking
include Common
  CONCURRENCY = 4
def run
    child_pids = []
    CONCURRENCY.times do
      child_pids << spawn_child
end

     trap(:INT) {
      child_pids.each do |cpid|
        begin
          Process.kill(:INT, cpid)
          rescue Errno::ESRCH
          end
        end
    exit
   }
   loop do
     pid = Process.wait
     $stderr.puts "Process #{pid} quit unexpectedly"
     child_pids.delete(pid)
     child_pids << spawn_child

  def spawn_child
    fork do
      loop do
        @client = @control_socket.accept
        respond "220 OHAI"
        handler = CommandHandler.new(self)


        loop do
          request = @client.gets(CRLF)
          if request
            respond handler.handle(request)
          else
            @client.close
            break
          end
        end

Thread Pool

class ThreadPool
  include Common
  CONCURRENCY = 25
  def run
    Thread.abort_on_exception = true
    threads = ThreadGroup.new
    CONCURRENCY.times do
      threads.add spawn_thread
    end
    sleep
  end

  def spawn_thread
    Thread.new do
    loop do
      @client = @control_socket.accept
      respond "220 OHAI"
      handler = CommandHandler.new(self)
      loop do
        request = @client.gets(CRLF)
        if request          respond handler.handle(request)
        else
          @client.close
          break
        end
      end

Evented (Reactor)

class Evented
  CHUNK_SIZE = 1024 * 16
  include Common
  class Connection
    include Common
    attr_reader :client
    def initialize(io)
      @client = io
      @request, @response = "", ""
      @handler = CommandHandler.new(self)
      @response = "220 OHAI" + CRLF
      on_writable
    enc

def on_data(data)
  @request << data
  if @request.end_with?(CRLF)
  # Request is completed.
    @response = @handler.handle(@request) + CRLF
    @request = ""
  end
end

def on_writable  bytes = client.write_nonblock(@response)
  @response.slice!(0, bytes)
end

def monitor_for_reading?
  true
end

def monitor_for_writing?
  !(@response.empty?)
end

def run
  @handles = {}
  loop do
   to_read=@handles.values.select(&:monitor_for_reading?).map(&:client)
   to_write=@handles.values.select(&:monitor_for_writing?).map(&:client)

   readables,writables=IO.select(to_read + [@control_socket], to_write)

   readables.each do |socket|
     if socket == @control_socket
       io = @control_socket.accept
       connection = Connection.new(io)
       @handles[io.fileno] = connection

     else
       connection = @handles[socket.fileno]
       begin
         data = socket.read_nonblock(CHUNK_SIZE)
         connection.on_data(data)
 rescue Errno::EAGAIN
 rescue EOFError
@handles.delete(socket.fileno)
end
     end
   end
writables.each do |socket|
     connection = @handles[socket.fileno]
     connection.on_writable
  end
