Vídeo VR en el navegador

Raúl Jiménez

Un poco de autobombo

Toptal Partner

Angular GDE

videogular

Google Partner

¿Qué es el vídeo VR?

  • Archivo de vídeo equirectangular 360

  • Reproductor de vídeo compatible

  • Hardware compatible (las gafas)

  • Hardware de selección (punteros)

VR es Realidad Virtual

Vídeo 360

  • Cámara con grabación 360

  • Modelos entre los 250€ y 55000€

  • Formato MP4, WebM, OGG a 30fps

  • Calidad 1920x1080

Reproductores de vídeo

Hardware compatible

WebVR vs Emulación

  • Nuevo estándar HTML5

  • API web nativa para dispositivos VR

  • Soporte para Windows y dispositivos Android/iOS

  • Navegadores Chromium Experimental, Firefox Nightly y Samsung Gear VR

  • Emulación a través de WebGL

  • Cargar vídeo y pintarlo en canvas

  • Rendimiento pobre en móviles

  • Rendimiento muy bueno en PCs

Emulación

<!DOCTYPE html>
<html lang="en">
	<head>
		<title>three.js webgl - equirectangular video panorama</title>
		<meta charset="utf-8">
		<meta name="viewport" content="width=device-width, user-scalable=no, minimum-scale=1.0, maximum-scale=1.0">
		<style>
			body {
				background-color: #000000;
				margin: 0px;
				overflow: hidden;
			}

			#info {
				position: absolute;
				top: 0px; width: 100%;
				color: #ffffff;
				padding: 5px;
				font-family:Monospace;
				font-size:13px;
				font-weight: bold;
				text-align:center;
			}

			a {
				color: #ffffff;
			}
		</style>
	</head>
	<body>

		<div id="container"></div>

		<script src="../build/three.js"></script>

		<script>

			var camera, scene, renderer;

			var texture_placeholder,
			isUserInteracting = false,
			onMouseDownMouseX = 0, onMouseDownMouseY = 0,
			lon = 0, onMouseDownLon = 0,
			lat = 0, onMouseDownLat = 0,
			phi = 0, theta = 0,
			distance = 500;

			init();
			animate();

			function init() {

				var container, mesh;

				container = document.getElementById( 'container' );

				camera = new THREE.PerspectiveCamera( 75, window.innerWidth / window.innerHeight, 1, 1100 );
				camera.target = new THREE.Vector3( 0, 0, 0 );

				scene = new THREE.Scene();

				var geometry = new THREE.SphereBufferGeometry( 500, 60, 40 );
				geometry.scale( - 1, 1, 1 );

				var video = document.createElement( 'video' );
				video.width = 640;
				video.height = 360;
				video.autoplay = true;
				video.loop = true;
				video.src = "textures/pano.webm";

				var texture = new THREE.VideoTexture( video );
				texture.minFilter = THREE.LinearFilter;
				texture.format = THREE.RGBFormat;

				var material   = new THREE.MeshBasicMaterial( { map : texture } );

				mesh = new THREE.Mesh( geometry, material );

				scene.add( mesh );

				renderer = new THREE.WebGLRenderer();
				renderer.setPixelRatio( window.devicePixelRatio );
				renderer.setSize( window.innerWidth, window.innerHeight );
				container.appendChild( renderer.domElement );

				document.addEventListener( 'mousedown', onDocumentMouseDown, false );
				document.addEventListener( 'mousemove', onDocumentMouseMove, false );
				document.addEventListener( 'mouseup', onDocumentMouseUp, false );
				document.addEventListener( 'mousewheel', onDocumentMouseWheel, false );
				document.addEventListener( 'MozMousePixelScroll', onDocumentMouseWheel, false);

				//

				window.addEventListener( 'resize', onWindowResize, false );

			}

			function onWindowResize() {

				camera.aspect = window.innerWidth / window.innerHeight;
				camera.updateProjectionMatrix();

				renderer.setSize( window.innerWidth, window.innerHeight );

			}

			function onDocumentMouseDown( event ) {

				event.preventDefault();

				isUserInteracting = true;

				onPointerDownPointerX = event.clientX;
				onPointerDownPointerY = event.clientY;

				onPointerDownLon = lon;
				onPointerDownLat = lat;

			}

			function onDocumentMouseMove( event ) {

				if ( isUserInteracting === true ) {

					lon = ( onPointerDownPointerX - event.clientX ) * 0.1 + onPointerDownLon;
					lat = ( event.clientY - onPointerDownPointerY ) * 0.1 + onPointerDownLat;

				}

			}

			function onDocumentMouseUp( event ) {

				isUserInteracting = false;

			}

			function onDocumentMouseWheel( event ) {

				// WebKit

				if ( event.wheelDeltaY ) {

					distance -= event.wheelDeltaY * 0.05;

				// Opera / Explorer 9

				} else if ( event.wheelDelta ) {

					distance -= event.wheelDelta * 0.05;

				// Firefox

				} else if ( event.detail ) {

					distance += event.detail * 1.0;

				}

			}

			function animate() {

				requestAnimationFrame( animate );
				update();

			}

			function update() {

				lat = Math.max( - 85, Math.min( 85, lat ) );
				phi = THREE.Math.degToRad( 90 - lat );
				theta = THREE.Math.degToRad( lon );

				camera.position.x = distance * Math.sin( phi ) * Math.cos( theta );
				camera.position.y = distance * Math.cos( phi );
				camera.position.z = distance * Math.sin( phi ) * Math.sin( theta );

				camera.lookAt( camera.target );

				/*
				// distortion
				camera.position.copy( camera.target ).negate();
				*/

				renderer.render( scene, camera );

			}

		</script>
	</body>
</html>
<!DOCTYPE html>
<html lang="en">
	<head>
		<title>three.js webvr - video</title>
		<meta charset="utf-8">
		<meta name="viewport" content="width=device-width, initial-scale=1.0, user-scalable=no">
		<style>
			body {
				font-family: Monospace;
				background-color: #f0f0f0;
				margin: 0px;
				overflow: hidden;
			}
			#info {
				position: absolute;
				top: 10px;
				width: 100%;
				color: #fff;
				text-align: center;
			}
			a {
				color: #ff0
			}
		</style>
	</head>
	<body>
		<div id="container"></div>
		<div id="info">
			<a href="http://threejs.org" target="_blank">three.js</a> webgl - vr video<br />
			stereoscopic panoramic render by <a href="http://pedrofe.com/rendering-for-oculus-rift-with-arnold/" target="_blank">pedrofe</a>. scene from <a href="http://www.meryproject.com/" target="_blank">mery project</a>.
		</div>

		<script src="../build/three.js"></script>

		<script src="js/WebVR.js"></script>
		<script src="js/effects/VREffect.js"></script>
		<script src="js/controls/VRControls.js"></script>

		<script>

			if ( WEBVR.isLatestAvailable() === false ) {

				document.body.appendChild( WEBVR.getMessage() );

			}

			//

			var camera, scene, renderer;
			var video, texture;

			var controls, effect;

			init();
			animate();

			function init() {

				var container = document.getElementById( 'container' );
				container.addEventListener( 'click', function () {

					video.play();

				} );

				camera = new THREE.PerspectiveCamera( 75, window.innerWidth / window.innerHeight, 1, 2000 );
				camera.layers.enable( 1 ); // render left view when no stereo available

				// video

				video = document.createElement( 'video' );
				video.loop = true;
				video.src = 'textures/MaryOculus.webm';
				video.play();

				texture = new THREE.VideoTexture( video );
				texture.minFilter = THREE.NearestFilter;
				texture.maxFilter = THREE.NearestFilter;
				texture.format = THREE.RGBFormat;
				texture.generateMipmaps = false;

				scene = new THREE.Scene();

				// left

				var geometry = new THREE.SphereGeometry( 500, 60, 40 );
				geometry.scale( - 1, 1, 1 );

				var uvs = geometry.faceVertexUvs[ 0 ];

				for ( var i = 0; i < uvs.length; i ++ ) {

					for ( var j = 0; j < 3; j ++ ) {

						uvs[ i ][ j ].x *= 0.5;

					}

				}

				var material = new THREE.MeshBasicMaterial( { map: texture } );

				var mesh = new THREE.Mesh( geometry, material );
				mesh.rotation.y = - Math.PI / 2;
				mesh.layers.set( 1 ); // display in left eye only
				scene.add( mesh );

				// right

				var geometry = new THREE.SphereGeometry( 500, 60, 40 );
				geometry.scale( - 1, 1, 1 );

				var uvs = geometry.faceVertexUvs[ 0 ];

				for ( var i = 0; i < uvs.length; i ++ ) {

					for ( var j = 0; j < 3; j ++ ) {

						uvs[ i ][ j ].x *= 0.5;
						uvs[ i ][ j ].x += 0.5;

					}

				}

				var material = new THREE.MeshBasicMaterial( { map: texture } );

				var mesh = new THREE.Mesh( geometry, material );
				mesh.rotation.y = - Math.PI / 2;
				mesh.layers.set( 2 ); // display in right eye only
				scene.add( mesh );

				//

				renderer = new THREE.WebGLRenderer();
				renderer.setClearColor( 0x101010 );
				renderer.setPixelRatio( window.devicePixelRatio );
				renderer.setSize( window.innerWidth, window.innerHeight );
				container.appendChild( renderer.domElement );

				//

				controls = new THREE.VRControls( camera );

				effect = new THREE.VREffect( renderer );
				effect.scale = 0; // video doesn't need eye separation
				effect.setSize( window.innerWidth, window.innerHeight );

				if ( WEBVR.isAvailable() === true ) {

					document.body.appendChild( WEBVR.getButton( effect ) );

				}


				//

				window.addEventListener( 'resize', onWindowResize, false );

			}

			function onWindowResize() {

				camera.aspect = window.innerWidth / window.innerHeight;
				camera.updateProjectionMatrix();

				effect.setSize( window.innerWidth, window.innerHeight );

			}

			function animate() {

				requestAnimationFrame( animate );
				render();

			}

			function render() {

				controls.update();

				effect.render( scene, camera );

			}

		</script>
	</body>
</html>
<!DOCTYPE html>
<html>
  <head>
    <meta charset="utf-8">
    <title>360 Video</title>
    <meta name="description" content="360 Video — A-Frame">
    <script src="../../../dist/aframe.js"></script>
  </head>
  <body>
    <a-scene>
      <a-assets>
        <video id="video" src="https://ucarecdn.com/bcece0a8-86ce-460e-856b-40dac4875f15/"
               autoplay loop></video>
      </a-assets>

      <a-videosphere src="#video" rotation="0 180 0"></a-videosphere>
    </a-scene>
  </body>
</html>
<vg-player>
    <vg-controls [autohide]="true" [autohideTime]="1.5">
        <vg-play-pause></vg-play-pause>

        <vg-time-display property="current" format="mm:ss"></vg-time-display>

        <vg-scrub-bar>
            <vg-scrub-bar-current-time></vg-scrub-bar-current-time>
            <vg-scrub-bar-buffering-time></vg-scrub-bar-buffering-time>
        </vg-scrub-bar>

        <vg-time-display property="left" format="mm:ss"></vg-time-display>

        <vg-mute></vg-mute>

        <vg-fullscreen></vg-fullscreen>
    </vg-controls>

    <video src="video/pano.webm" #media vg-media id="360Video" preload="auto" loop></video>

    <vg-360 [media]="media" [vr]="true" [hotSpots]="hotSpots" [pointer]="showPointer" (onEnterHotSpot)="onEnterHotSpot($event)" (onLeaveHotSpot)="onLeaveHotSpot($event)"></vg-360>
</vg-player>

<div class="info-dialog" [class.active]="isActive">
    <div class="info-back"></div>
    <span class="info-message">You can create interactivity on your hot spot areas! Check the console log!</span>
</div>

<div class="clone info-dialog" [class.active]="isActive">
    <div class="info-back"></div>
    <span class="info-message">You can create interactivity on your hot spot areas! Check the console log!</span>
</div>
import {Component, OnInit, ElementRef} from "angular2/core";
import {VgPlayer, VgMedia, Vg360, IHotSpot} from "videogular2/core";
import { VgControls, VgTimeDisplay, VgPlayPause, VgPlaybackButton, VgScrubBar, VgScrubBarCurrentTime, VgScrubBarBufferingTime, VgMute, VgFullscreen } from "videogular2/controls";
import {VgOverlayPlay} from "videogular2/overlay-play";

@Component({
    selector: 'video-vr-player',
    templateUrl: 'src/video-vr-player.html',
    directives: [VgPlayer, VgMedia, VgOverlayPlay, VgControls, VgTimeDisplay, VgPlayPause, VgPlaybackButton, VgScrubBar, VgScrubBarCurrentTime, VgScrubBarBufferingTime, VgMute, VgFullscreen, Vg360]
})
export class VideoVrPlayer  implements OnInit {
    elem:any;
    dialog:any;
    dialogClone:any;
    hotSpots:Array<IHotSpot>;
    showPointer:boolean = true;
    isActive:boolean = false;

    constructor(ref:ElementRef) {
        this.elem = ref.nativeElement;
    }

    ngOnInit() {
        this.hotSpots = [];

        this.dialog = this.elem.querySelector('.info-dialog');
        this.dialogClone = this.elem.querySelector('.clone.info-dialog');

        var hs:IHotSpot = <IHotSpot>{};
        hs.element = this.dialog;
        hs.elementClone = this.dialogClone;
        hs.position = {
            x: -200,
            y: 0,
            z: 150
        };

        hs.rotation = {
            x: 0,
            y: 47,
            z: 0
        };

        this.hotSpots.push(hs);
    }

    onEnterHotSpot(object:IHotSpot) {
        console.log('enter', object);
        this.isActive = true;
    }

    onLeaveHotSpot(object:IHotSpot) {
        console.log('leave', object);
        this.isActive = false;
    }
}

HTML

Angular2

¡Gracias!

¿preguntas?

Video VR en el navegador

By Raúl Jiménez

Video VR en el navegador

Charla para Modern Web Event en Bilbao 2016
