January 25-29, 2021

CS3 2021

Virtual

Terrell Russell, Ph.D.

@terrellrussell

Chief Technologist, iRODS Consortium

Policy Composition:

Configuration, Not Code

Policy Composition:

Configuration, Not Code

Our Membership

Consortium

Member

Consortium

Member

Consortium

Member

Consortium

Member

iRODS as the Integration Layer

Institutional repositories

As data matures and reaches a broader community, data management policy must also evolve to meet these additional requirements.

Policy Composition: Configuration, Not Code

With a twenty-five year history, iRODS open source technology has been used to automate data management across many scientific and business domains. The scale and value of data across these domains drives the necessity for automation. This variety also demands a flexibility in data management policies over time. Organizations have satisfied their own needs by investing in the development of their own policy, but this has led to monolithic, specific policy sets tailored to a particular organization.



As a community, we have observed common themes and duplication of effort across these organizations and now worked to provide generalized implementations that can be deployed across multiple domains. This new approach allows multiple policies to be configured together, or composed, without the need for custom development. For example, our Storage Tiering capability is a composition of several basic policies: Replication, Verification, Retention, and the Violating Object Discovery.

What is Data Management

A Definition of Data Management





"The development, execution and supervision of plans, policies, programs, and practices that control, protect, deliver, and enhance the value of data and information assets."





Organizations need a future-proof solution to managing data and its surrounding infrastructure

What is a Policy

A Definition of Policy





A set of ideas or a plan of what to do in particular situations that has been agreed to officially by a group of people...





So how does iRODS do this?

iRODS Policies

The reflection of real world data management decisions in computer actionable code.



(a plan of what to do in particular situations)

Possible Policies

  • Data Movement
  • Data Verification
  • Data Retention
  • Data Replication
  • Data Placement
  • Checksum Validation
  • Metadata Extraction
  • Metadata Application
  • Metadata Conformance
  • Replica Verification
  • Vault to Catalog Verification
  • Catalog to Vault Verification
  • ...

The iRODS Data Management Model

Core Competencies

Policy

Capabilities

  Patterns

  • How can we help new users get started?
  • How can we make policy reusable?
  • How can we simplify policy development?
  • How can we provide a cook book of deployments?
  • How do we get from Policy to Capabilities?

Policy Composition

Consider Policy as building blocks towards Capabilities

Follow proven software engineering principles:

    Favor composition over monolithic implementations

Rules and Dynamic Policy Enforcement Points can be overloaded and fall through

Implement or configure several rule bases or rule engine plugins to achieve complex use cases

Policy Composition

Consider Storage Tiering as a collection of policies:

  • Data Access Time
  • Identifying Violating Objects
  • Data Replication
  • Data Verification
  • Data Retention

The New Approach

Continue to separate the concerns:

  • When : Which policy enforcement points
  • What  : The policy to be invoked
  • Why   : What are the conditions necessary for invocation
  • How   : Synchronous or Asynchronous

Write simple policy implementations

Each policy may now be reused in a generic fashion, favoring configuration over code.

  • Not tied to a Policy Enforcement Point
  • Do one thing well
  • How it is invoked is of no concern

Examples

Synchronous Access Time

 {
    "instance_name": "irods_rule_engine_plugin-event_handler-data_object_modified-instance",
    "plugin_name": "irods_rule_engine_plugin-event_handler-data_object_modified",
    "plugin_specific_configuration": {
        "policies_to_invoke" : [
            {
                "active_policy_clauses" :  ["post"],
                "events" : ["put", "get", "create", "read", "write", "rename",
                            "register", "unregister", "replication", "checksum",
                            "copy", "seek", "truncate"],
                "policy"    : "irods_policy_access_time",
                "configuration" : {
                }
            }
        ]
    }
}

Synchronous Replication

{
    "instance_name": "irods_rule_engine_plugin-event_handler-data_object_modified-instance",
    "plugin_name": "irods_rule_engine_plugin-event_handler-data_object_modified",
    "plugin_specific_configuration": {
        "policies_to_invoke" : [
            {   "active_policy_clauses" : ["post"],
                "events" : ["create", "write", "registration"],
                "policy"    : "irods_policy_data_replication",
                "configuration" : {
                    "source_to_destination_map" : {
                        "source_resource_0" : ["destination_resource_0a", "destination_resource_0b"],
                        "source_resource_1" : ["destination_resource_1a"],
                    }
                }
            },
            {   "active_policy_clauses" : ["post"],
                "events" : ["create", "write", "registration"],
                "policy"    : "irods_policy_data_replication",
                "configuration" : {
                    "destination_resource" : "destination_resource_3"
                    }
                }
            },
        ]
    }
}

Asynchronous Replication

{
    "instance_name": "irods_rule_engine_plugin-event_handler-data_object_modified-instance",
    "plugin_name": "irods_rule_engine_plugin-event_handler-data_object_modified",
    "plugin_specific_configuration": {
        "policies_to_invoke" : [
            {
                "active_policy_clauses" : ["post"],
                "events" : ["create", "write", "registration"],
                "policy" : "irods_policy_enqueue_rule",
                "delay_conditions" : "<ET>PLUSET 1</ET>",
                "payload" : {
                    "policy" : "irods_policy_execute_rule",
                    "payload" : {
                        "policy_to_invoke" : "irods_policy_data_replication",
                        "configuration" : {
                            "source_to_destination_map" : {
                                "source_resource_0" : ["destination_resource_0a", "destination_resource_0b"],
                                "source_resource_1" : ["destination_resource_1a"],
                             }
                        }
                    }
                }
            }
        ]
    }
}

Synchronous Retention

{
    "instance_name": "irods_rule_engine_plugin-event_handler-data_object_modified-instance",
    "plugin_name": "irods_rule_engine_plugin-event_handler-data_object_modified",
    "plugin_specific_configuration": {
        "policies_to_invoke" : [
            {
                "active_policy_clauses" : ["post"],
                "events" : ["replication"],
                "policy" : "irods_policy_data_retention",
                "configuration" : {
                    "mode" : "trim_single_replica",
                    "source_resource_list" : ["source_resource_1", "source_resource_2"]
                }
            }
        ]
    }
}

Query Driven Asynchronous Retention

        {
            "policy" : "irods_policy_enqueue_rule",
            "delay_conditions" : "<EF>REPEAT FOR EVER</EF>",
            "payload" : {
                "policy" : "irods_policy_execute_rule",
                "payload" : {
                    "policy_to_invoke" : "irods_policy_query_processor",
                    "parameters" : {
                        "query_string" : "SELECT USER_NAME, COLL_NAME, DATA_NAME, RESC_NAME WHERE
                                          COLL_NAME like '/tempZone/home/rods%' AND
                                          RESC_NAME IN ('source_resource_1', 'source_resource_2')",
                        "query_limit" : 10,
                        "query_type" : "general",
                        "number_of_threads" : 4,
                        "policy_to_invoke" : "irods_policy_data_retention",
                        "configuration" : {
                            "mode" : "trim_single_replica",
                            "source_resource_list" : ["source_resource_1", "source_resource_2"]
                        }
                    }
                }
            }
        }

Synchronous Verification

        {
            "instance_name": "irods_rule_engine_plugin-event_handler-data_object_modified-instance",
            "plugin_name": "irods_rule_engine_plugin-event_handler-data_object_modified",
            "plugin_specific_configuration": {
                "policies_to_invoke" : [
                    {   "active_policy_clauses" : ["post"],
                        "events" : ["create", "write", "registration"],
                        "policy" : "irods_policy_data_verification",
                        "configuration" : {
                            "attribute" : "irods::verification::type"
                        }
                    }
                ]
            }
        }

The type of verification to perform is stored as metadata on the resource

  • catalog
  • filesystem
  • checksum

Asynchronous Verification

        {
            "instance_name": "irods_rule_engine_plugin-event_handler-data_object_modified-instance",
            "plugin_name": "irods_rule_engine_plugin-event_handler-data_object_modified",
            "plugin_specific_configuration": {
                "policies_to_invoke" : [
                    {   "active_policy_clauses" : ["post"],
                        "events" : ["create", "write", "registration"],
                        "policy" : "irods_policy_enqueue_rule",
                        "delay_conditions" : "<ET>PLUSET 1</ET>",
                        "payload" : {
                            "policy" : "irods_policy_execute_rule",
                            "payload" : {
                                "policy" : "irods_policy_data_verification",
                                "configuration" : {
                                    "attribute" : "irods::verification::type"
                                }
                            }
                        }
                    }
                ]
            }
        }

The type of verification to perform is stored as metadata on the resource

  • catalog
  • filesystem
  • checksum

Policy Composed Capabilities

Storage Tiering Overview

Policy Composed Storage Tiering

  • Asynchronous Discovery
  • Asynchronous Replication
  • Synchronous Retention
  • Resource associated metadata
  • Identified by 'tiering groups'
{
    "policy" : "irods_policy_execute_rule",
    "payload" : {
         "policy_to_invoke" : "irods_policy_query_processor",
         "configuration" : {
             "query_string" : "SELECT META_RESC_ATTR_VALUE WHERE META_RESC_ATTR_NAME = 'irods::storage_tiering::group'",
             "query_limit" : 0,
             "query_type" : "general",
             "number_of_threads" : 8,
             "policy_to_invoke" : "irods_policy_event_generator_resource_metadata",
             "configuration" : {
                 "conditional" : {
                     "metadata" : {
                         "attribute" : "irods::storage_tiering::group",
                         "value" : "{0}"
                     }
                 },
                 "policies_to_invoke" : [
                     {
                         "policy" : "irods_policy_query_processor",
                         "configuration" : {
                             "query_string" : "SELECT META_RESC_ATTR_VALUE WHERE META_RESC_ATTR_NAME = 'irods::storage_tiering::query' AND RESC_NAME = 'IRODS_TOKEN_SOURCE_RESOURCE_END_TOKEN'",
                             "default_results_when_no_rows_found" : ["SELECT USER_NAME, COLL_NAME, DATA_NAME, RESC_NAME WHERE META_DATA_ATTR_NAME = 'irods::access_time' AND META_DATA_ATTR_VALUE < 'IRODS_TOKEN_LIFETIME_END_TOKEN' AND META_DATA_ATTR_UNITS <> 'irods::storage_tiering::inflight' AND DATA_RESC_ID IN (IRODS_TOKEN_SOURCE_RESOURCE_LEAF_BUNDLE_END_TOKEN)"],
                             "query_limit" : 0,
                             "query_type" : "general",
                             "number_of_threads" : 8,
                             "policy_to_invoke" : "irods_policy_query_processor",
                             "configuration" : {
                                 "lifetime" : "IRODS_TOKEN_QUERY_SUBSTITUTION_END_TOKEN(SELECT META_RESC_ATTR_VALUE WHERE META_RESC_ATTR_NAME = 'irods::storage_tiering::time' AND RESC_NAME = 'IRODS_TOKEN_SOURCE_RESOURCE_END_TOKEN')",
                                 "query_string" : "{0}",
                                 "query_limit" : 0,
                                 "query_type" : "general",
                                 "number_of_threads" : 8,
                                 "policy_to_invoke" : "irods_policy_data_replication",
                                 "configuration" : {
                                     "comment" : "source_resource, and destination_resource supplied by the resource metadata event generator"
                                 }
                             }
                         }
                     }
                ]
             }
         }
    }
}
INPUT null
OUTPUT ruleExecOut

Policy Composed Capability

Asynchronous Discovery and Replication

Policy Composed Capability

Synchronous Configuration for Storage Tiering

{
    "instance_name": "irods_rule_engine_plugin-event_handler-data_object_modified-instance",
    "plugin_name": "irods_rule_engine_plugin-event_handler-data_object_modified",
    "plugin_specific_configuration": {
        "policies_to_invoke" : [
            {
                "active_policy_clauses" : ["post"],
                "events" : ["put", "get", "create", "read", "write", "rename", "register", "unregister", "replication", "checksum", "copy", "seek", "truncate"],
                 "policy" : "irods_policy_access_time",
                 "configuration" : {
                    "log_errors" : "true"
                 }
            },
            {
                "active_policy_clauses" : ["post"],
                "events" : ["read", "write", "get"],
                "policy"    : "irods_policy_data_restage",
                "configuration" : {
                }
            },
            {
                "active_policy_clauses" : ["post"],
                "events" : ["replication"],
                    "policy"    : "irods_policy_tier_group_metadata",
                    "configuration" : {
                    }

            },
            {
                "active_policy_clauses" : ["post"],
                "events" : ["replication"],
                    "policy"    : "irods_policy_data_verification",
                    "configuration" : {
                    }

            },
            {
                "active_policy_clauses" : ["post"],
                "events" : ["replication"],
                    "policy"    : "irods_policy_data_retention",
                    "configuration" : {
                        "mode" : "trim_single_replica",
                        "log_errors" : "true"
                    }

            }
        ]
    }
}

Policy Composed Capability

Possible Metadata Driven Restage for Storage Tiering

{
    "instance_name": "irods_rule_engine_plugin-event_handler-metadata_modified-instance",
    "plugin_name": "irods_rule_engine_plugin-event_handler-metadata_modified",
    "plugin_specific_configuration": {
        "policies_to_invoke" : [
            {
                "active_policy_clauses" : ["post"],
                "events" : ["set", "add"],
                "attribute" : "irods::storage_tiering::restage",
                "value"     : "*.*",
                "policy"    : "irods_policy_data_restage",
                "configuration" : {
                }
            }
        ]
    }
}

Data Transfer Nodes Pattern

Policy Composed Data Transfer Node

  • Asynchronous Discovery
  • Asynchronous Retention
  • Synchronous Replication
  • Resource associated metadata
  • Identified by 'replication groups'
{
    "policy" : "irods_policy_enqueue_rule",
    "delay_conditions" : "<EF>REPEAT FOR EVER</EF>",
    "payload" : {
        "policy" : "irods_policy_execute_rule",
        "payload" : {
            "policy_to_invoke" : "irods_policy_query_processor",
            "parameters" : {
                "query_string" : "SELECT USER_NAME, COLL_NAME, DATA_NAME, RESC_NAME WHERE COLL_NAME like '/tempZone/home/rods%' AND RESC_NAME IN ('edge_resource_1', 'edge_resource_2')",
                "query_limit" : 10,
                "query_type" : "general",
                "number_of_threads" : 4,
                "policy_to_invoke" : "irods_policy_data_retention",
                "configuration" : {
                    "mode" : "trim_single_replica",
                    "source_resource_list" : ["edge_resource_1", "edge_resource_2"]
                }
            }
        }
    }
}

Policy Composed Capability

Asynchronous Retention on Edge Resources

Synchronous Replication

{
    "instance_name": "irods_rule_engine_plugin-event_handler-data_object_modified-instance",
    "plugin_name": "irods_rule_engine_plugin-event_handler-data_object_modified",
    "plugin_specific_configuration": {
        "policies_to_invoke" : [
            {
                "conditional" : {
                    "logical_path" : "\/tempZone.*"
                },
                "pre_or_post_invocation" : ["post"],
                "events" : ["create", "write", "registration"],
                "policy" : "irods_policy_data_replication",
                "configuration" : {
                    "source_to_destination_map" : {
                        "edge_resource_0" : ["long_term_resource_0"],
                        "edge_resource_1" : ["long_term_resource_1"],
                    }
                }
            },
            {
                "conditional" : {
                    "logical_path" : "\/tempZone.*"
                },
                "active_policy_clauses" : ["pre"],
                "events" : ["get"],
                "policy" : "irods_policy_data_replication",
                "configuration" : {
                    "source_to_destination_map" : {
                        "long_term_resource_0" : ["edge_resource_0"],
                        "long_term_resource_1" : ["edge_resource_1"]
                    }
                }
            }
        ]
    }
}

Policy Composed Capability

Core Competencies

Policy

Capabilities

Indexing Capability

Core Competencies

Policy

Capabilities

Policy Composed Indexing

  • irods_policy_indexing_full_text_index_elasticsearch
  • irods_policy_indexing_full_text_purge_elasticsearch
  • irods_policy_indexing_metadata_index_elasticsearch
  • irods_policy_indexing_metadata_purge_elasticsearch

Policy implemented as separate policy engine plugins

Core Competencies

Policy

Capabilities

Indexing Policies

"instance_name": "irods_rule_engine_plugin-event_handler-data_object_modified-instance",
"plugin_name": "irods_rule_engine_plugin-event_handler-data_object_modified",
'plugin_specific_configuration': {
    "policies_to_invoke" : [
        {
            "active_policy_clauses" : ["post"],
            "events" : ["put", "write"],
            "policy"    : "irods_policy_event_delegate_collection_metadata",
            "configuration" : {
                "policies_to_invoke" : [
                    {
                        "conditional" : {
                            "metadata" : {
                                "attribute" : "irods::indexing::index",
                                "entity_type" : "data_object"
                            },
                        },
                        "policy"    : "irods_policy_indexing_full_text_index_elasticsearch",
                        "configuration" : {
                            "hosts" : ["http://localhost:9200/"],
                            "bulk_count" : 100,
                            "read_size" : 1024
                        }
                    }
                ]
            }
        }
        ...

Synchronously configured full text indexing

Core Competencies

Policy

Capabilities

Indexing Policies

        {
            "active_policy_clauses" : ["pre"],
            "events" : ["unlink", "unregister"],
            "policy"    : "irods_policy_event_delegate_collection_metadata",
            "configuration" : {
                "policies_to_invoke" : [
                    {
                        "conditional" : {
                            "metadata" : {
                                "attribute" : "irods::indexing::index",
                                "entity_type" : "data_object"
                            },
                        },
                        "policy"    : "irods_policy_indexing_full_text_purge_elasticsearch",
                        "configuration" : {
                            "hosts" : ["http://localhost:9200/"],
                            "bulk_count" : 100,
                            "read_size" : 1024
                        }
                    }
                ]
            }
        }
    ]
}

Synchronously configured full text purge



Capabilities become easily configured recipes.





A Policy GUI is now a possibility with

simple manipulation of server side JSON.



Summary - Configuration, Not Code

Data management

should be

data-centric and metadata driven.





Future-proof automated data management

requires

open formats and open source.

CS3 2021 - iRODS Policy Composition: Configuration, Not Code

By iRODS Consortium

CS3 2021 - iRODS Policy Composition: Configuration, Not Code

  • 120
Loading comments...

More from iRODS Consortium
