Configuring iRODS for

High Availability

June 7-9, 2016

iRODS User Group Meeting 2016

Chapel Hill, NC

Justin James

Application Engineer

iRODS Consortium

High Availability iRODS - Goal

Our goal is to create a fault tolerant iRODS Zone to achieve high availability.



This design is based on High Availability iRODS System (HAIRS) by Yutaka Kawai at KEK and Adil Hasan at the University of Liverpool.





High Availability iRODS - Overview

To achieve full redundancy within an iRODS Zone, the following iRODS components should be replicated:



  • iCAT Database - Implementing redundancy for RDBMS databases is outside the scope for this demonstration



  • Catalog Provider (iCAT Server) - Redundancy is achieved by having two iCAT servers behind a load balancer



  • Catalog Consumer (Resource Server) - The built-in replication resource hierarchy will provide data redundancy.



High Availability iRODS - Basic Setup

For this demonstration... 7 virtual servers.

  • LoadBalancer.example.org – 192.168.1.150
  • ICAT1.example.org – 192.168.1.151
  • ICAT2.example.org – 192.168.1.152
  • DB1.example.org – 192.168.1.153
  • Resource1.example.org – 192.168.1.155
  • Resource2.example.org – 192.168.1.156
  • CLI1.example.org – 192.168.1.154

High Availability iRODS - Initial Conditions

We need to have each server set up with the appropriate hostname and IP address.





The LoadBalancer will refer to the two iCAT servers as

  • ICAT1.example.org and
  • ICAT2.example.org



Internally, the two iCAT servers will each refer to themselves as LoadBalancer.example.org

  • Their own /etc/hostname should be LoadBalancer.example.org
  • This is how other servers will refer to them





Once this is configured, make sure that each server can ping the other servers by IP.

High Availability iRODS - Configuring /etc/hosts

The next step is to make sure each server can map its peers' fully qualified domain names to their IP address.



All components when acting as a client, will access the iCAT servers via the load balancer.


The following table lists the hosts that need to be known for each server.

Server Needs to Resolve
LoadBalancer.example.org Both iCAT Servers
ICAT(n).example.org The database server and each resource server
Resource(n).example.org The other resource server and the load balancer
DB1.example.org Each iCAT server
CLI1.example.org Needs access to at least one iRODS server for the primary connection

High Availability iRODS - /etc/hosts setup

For this example, just update the /etc/hosts files to perform host to IP mapping.



LoadBalancer.example.org:








ICAT1.example.org:









ICAT2.example.org:

127.0.0.1        LoadBalancer.example.org localhost
192.168.1.151    ICAT1.example.org
192.168.1.152    ICAT2.example.org
127.0.0.1        LoadBalancer.example.org localhost
192.168.1.153    DB1.example.org
192.168.1.155    Resource1.example.org
192.168.1.156    Resource2.example.org
127.0.0.1        LoadBalancer.example.org localhost
192.168.1.153    DB1.example.org
192.168.1.155    Resource1.example.org
192.168.1.156    Resource2.example.org

High Availability iRODS - /etc/hosts setup

Resource1.example.org:








Resource2.example.org



127.0.0.1        Resource1.example.org localhost
192.168.1.156    Resource2.example.org
192.168.1.150    LoadBalancer.example.org
127.0.0.1        Resource2.example.org localhost
192.168.1.155    Resource1.example.org
192.168.1.150    LoadBalancer.example.org

High Availability iRODS - /etc/hosts setup

DB1.example.org:










CLI1.example.org





127.0.0.1        CLI1.example.org localhost
192.168.1.155    Resource1.example.org
192.168.1.156    Resource2.example.org
192.168.1.150    LoadBalancer.example.org
127.0.0.1        DB1.example.org localhost
192.168.1.151    ICAT1.example.org
192.168.1.152    ICAT2.example.org

High Availability iRODS - Configuring the Load Balancer

In our test setup we use HAProxy to perform software level HTTP and TCP load balancing.  HAProxy can be downloaded on Ubuntu 14.04 systems using the following commands:







echo deb http://archive.ubuntu.com/ubuntu trusty-backports main \
universe |  sudo tee /etc/apt/sources.list.d/backports.list
sudo apt-get update
sudo apt-get install haproxy -t trusty-backports

High Availability iRODS - Configuring the Load Balancer

Next we will configure the load balancer to use TCP routing.  Incoming requests on port 1247 will be redirected in a round-robin fashion to one of the two iCAT servers.



Save the following contents into /etc/haproxy/haproxy.cfg

    global
        daemon
        maxconn 256

    defaults
        mode tcp
        timeout connect 5000ms
        timeout client 50000ms
        timeout server 50000ms

    frontend irods-in
        bind *:1247
        default_backend servers

    backend servers
        option tcp-check
        tcp-check connect
        tcp-check send PING\n
        tcp-check expect string <MsgHeader_PI>\n<type>RODS_VERSION</type>

        server ICAT1.example.org 192.168.1.151 check port 1247
        server ICAT2.example.org 192.168.1.152 check port 1247

High Availability iRODS - Configuring the Load Balancer

To determine if a particular iCAT server is up, any string can be sent (in the above case we send "PING") to port 1247 and iRODS will respond with text beginning with "<MsgHeader_PI>".  This is used as a health check on the iRODS server.



This is sufficient to determine if an iCAT instance is up or down.





Restart haproxy:

sudo service haproxy restart

High Availability iRODS - Installing and Configuring DB

Install PostgreSQL on DB1.example.org:







Configure the PostgreSQL database for iRODS:











myuser@DB1:~$ sudo apt-get install postgresql
myuser@DB1:~$ sudo su - postgres
postgres@DB1:~$ psql
psql (9.3.13)
Type "help" for help.

postgres=# CREATE USER irods WITH PASSWORD 'testpassword';
CREATE ROLE
postgres=# CREATE DATABASE "ICAT";
CREATE DATABASE
postgres=# GRANT ALL PRIVILEGES ON DATABASE "ICAT" TO irods;
GRANT
postgres=# \q

High Availability iRODS - Installing and Configuring DB

Update /etc/postgresql/9.3/main/postgresql.conf to allow remote connections from any host.





Update /etc/postgresql/9.3/main/pg_hba.conf to allow users from 192.168.1.X addresses to connect to the ICAT database with the irods user.




Restart PostgreSQL:

listen_addresses = '*'          # what IP address(es) to listen on;
host    ICAT            irods           192.168.1.0/24          md5
myuser@DB1:~$ sudo service postgresql restart

High Availability iRODS - Install iRODS on the ICAT Servers

First, test that the iCAT server can connect remotely to the database server.













Install iRODS on each iCAT server.













Enter DB1.example.org as the DB server when prompted.

myuser@ICAT1:~$ wget ftp://ftp.renci.org/pub/irods/releases/4.1.8\
/ubuntu14/irods-icat-4.1.8-ubuntu14-x86_64.deb
myuser@ICAT1:~$ wget ftp://ftp.renci.org/pub/irods/releases/4.1.8\
/ubuntu14/irods-database-plugin-postgres-1.8-ubuntu14-x86_64.deb
myuser@ICAT1:~$ sudo dpkg -i irods-icat-4.1.8-ubuntu14-x86_64.deb \
irods-database-plugin-postgres-1.8-ubuntu14-x86_64.deb
myuser@ICAT1:~$ sudo apt-get -f install
myuser@ICAT1:~$ sudo /var/lib/irods/packaging/setup_irods.sh
myuser@ICAT1:~$ sudo apt-get install postgresql-client-9.3
myuser@ICAT1:~$ psql -d ICAT -h 192.168.1.153 -U irods -W
Password for user irods:
psql (9.3.13)
SSL connection (cipher: DHE-RSA-AES256-GCM-SHA384, bits: 256)
Type "help" for help.

ICAT=>

Note:  Ignore the error about being unable to put a file into iRODS on the second iCAT installation.  Go ahead and start the server with ~irods/irodsctl start.  The root cause of the error will be addressed when we delete the resource on the iCAT servers.

High Availability iRODS - iRODS on Resource Servers

myuser@Resource1:~$ sudo wget ftp://ftp.renci.org/pub/irods/releases/4.1.8/\
ubuntu14/irods-resource-4.1.8-ubuntu14-x86_64.deb
myuser@Resource1:~$ sudo dpkg -i irods-resource-4.1.8-ubuntu14-x86_64.deb
myuser@Resource1:~$ sudo apt-get -f install
myuser@Resource1:~$ sudo /var/lib/irods/packaging/setup_irods.sh

Install iRODS on each resource server.













When prompted for the address of the iCAT server, enter LoadBalancer.example.org which will resolve to the load balancer.

High Availability iRODS - Create Resources

Now we will create a resource tree using a replication resource.



Login to iRODS under the administrator account (default is irods).  You can do this on either iCAT or resource servers.



Run the following commands to create a replication hierarchy and delete the default resource.

















Verify the resource hierarchy:









iadmin mkresc BaseResource replication
iadmin mkresc Resource1 'unixfilesystem' Resource1.example.org:/var/lib/irods/Vault
iadmin mkresc Resource2 'unixfilesystem' Resource2.example.org:/var/lib/irods/Vault
iadmin addchildtoresc BaseResource Resource1
iadmin addchildtoresc BaseResource Resource2
iadmin rmresc demoResc
iadmin rmresc Resource1Resource
iadmin rmresc Resource2Resource
$ ilsresc --tree
  BaseResource:replication
  |____Resource1
  |____Resource2


High Availability iRODS - Create Resources

We have removed demoResc which was on the iCAT server.



Let's update the default resources in all of the /etc/irods/core.re files.

acSetRescSchemeForCreate {msiSetDefaultResc("BaseResource","null"); }
acSetRescSchemeForRepl {msiSetDefaultResc("BaseResource","null"); }

High Availability iRODS - Setup a Client

Install iRODS CLI on CLI1.example.org:









Create ~/.irods/irods_environment.json and have it connect to the LoadBalancer.example.org and use BaseResource as the default resource.













Run iinit to confirm the connection succeeds.

myuser@CLI1:~$ wget ftp://ftp.renci.org/pub/irods/releases/\
4.1.8/ubuntu14/irods-icommands-4.1.8-ubuntu14-x86_64.deb
myuser@CLI1:~$ sudo dpkg -i irods-icommands-4.1.8-ubuntu14-x86_64.deb
{
    "irods_default_resource": "BaseResource",
    "irods_host": "LoadBalancer.example.org",
    "irods_port": 1247,
    "irods_user_name": "rods",
    "irods_zone_name": "tempZone"
}

High Availability iRODS - Testing

  • Put a file into iRODS
    • Verify that it has been stored on both resource servers.

  • Bring one Resource server down
    • Run iget to retrieve the data object just uploaded.
      • You may have to select the replica number (iget -n) when retrieving the data object.
      • If a resource server is not yet marked 'down' in the catalog, your request may still be routed to the server that cannot answer.

  • Bring one iCAT server down
    • Verify that the iCommands still work.
