Off the rails

A journey to explore the alternative options when it comes to building web services

@marjaimate - BP.RB 2016 March

We help forging your software, product and company

@theproductworks

theproduct.works

Rails all the things?

Rails is the standout option when people start to write a new application. But should we start here always?

Sinatra

Sinatra

• Supports other engines (like thin) not just WEBrick
• Built in support for templating languages
• Error handling
• Helpers and callbacks
• Comprehensive guides

Sinatra

require "sinatra"
require 'sinatra/base'

class Libre < Sinatra::Base
  get "/" do
    redirect "/ciudades"
  end

  get "/ciudades" do
    ciudades = YAML.load_file("ciudades.yml")
    ciudades.to_json
  end

  get "/ciudades/:ciudad" do |ciudad|
    ciudades = YAML.load_file("ciudades.yml")
    ciudades[ciudad].to_json
  end

end

Sinatra

get '/' do
  .. show something ..
end

post '/' do
  .. create something ..
end

put '/' do
  .. replace something ..
end

patch '/' do
  .. modify something ..
end

delete '/' do
  .. annihilate something ..
end

options '/' do
  .. appease something ..
end

# Request param binding
get '/hello/:name' do
  # matches "GET /hello/foo" and "GET /hello/bar"
  "Hello #{params['name']}!"
end

# Splats
get '/download/*.*' do
  # matches /download/path/to/file.xml
  params['splat'] # => ["path/to/file", "xml"]
end

# Regular expressions
get %r{/hello/([\w]+)} do |c|
  # Matches "GET /meta/hello/world", etc.
  "Hello, #{c}!"
end

Grape

Grape

• REST-like API micro-framework
• Can be used alongside Sinatra or Rails
• Geared towards APIs (routing engine, versioning)
• Requirement definition per param, per resource
• Exception and error handling
• Comprehensive guides

Grape

require "grape"

class Libre < Grape::API
  format :json

  helpers do
    def ciudades
      YAML.load_file("ciudades.yml")
    end
  end

  desc "Ciudades"
  resource :ciudades do
    get do
      ciudades.to_json
    end

    route_param :ciudad do
      get do
        ciudades[params[:ciudad]].to_json
      end
    end
  end
end

Grape

# Describing methods
desc 'Returns your public timeline.' do
  detail 'more details'
  params  API::Entities::Status.documentation
  success API::Entities::Entity
  failure [[401, 'Unauthorized', 'Entities::Error']]
  named 'My named route'
  headers XAuthToken: {
            description: 'Validates your identity',
            required: true
          },
          XOptionalHeader: {
            description: 'Not really needed',
            required: false
          }

end
get :public_timeline do
  Status.limit(20)
end

# Parameter validation
params do
  requires :id, type: Integer
  optional :text, type: String, regexp: /\A[a-z]+\z/
  group :media do
    requires :url
  end
  optional :audio do
    requires :format, type: Symbol, values: [:mp3, :wav, :aac, :ogg], default: :mp3
  end
  mutually_exclusive :media, :audio
end
put ':id' do
  # params[:id] is an Integer
end

Webmachine

Webmachine

• Port of webmachine, an Erlang library
• More of a toolkit for building HTTP-friendly applications
• Streaming/chunked response bodies
• Implemented as a Finite State Machine - It uses the facts about your resource to determine the flow though the FSM in order to produce a response.
• Comprehensive guides

Webmachine

class CiudadesResource < Webmachine::Resource
  def allowed_methods
    ['GET','HEAD']
  end

  def content_types_provided
    [['application/json', :to_json]]
  end

  # Return a Truthy or Falsey value
  def resource_exists?
    ciudades
  end

  def ciudades
    @ciudades = YAML.load_file("ciudades.yml")
  end

  def to_json
    ciudades.to_json
  end
end

Webmachine

# Routing
MyApp = Webmachine::Application.new do |app|
  # Configure your app like this:
  app.configure do |config|
    config.port = 9292
    config.adapter = :WEBrick
  end
  # And add routes like this:
  app.add_route ['ciudades'], CiudadesResource
  app.add_route ['ciudades', :ciudad], CiudadResource
end

# Authentication using HTTP Auth
class MySecureResource < Webmachine::Resource
  include Webmachine::Resource::Authentication

  def is_authorized?(authorization_header)
    basic_auth(authorization_header, "My Application") do |username, password|
      @user = User.find_by_username(username)
      !@user.nil? && @user.auth?(password)
    end
  end
end

Cuba

Cuba

• Real micro framework - less than 200 lines of code
• Cuba does one thing and does it well, handle HTTP requests
• Easy to mount other engines for RACK (thin), or templates (jbuilder, haml)
• Supports plugins and helpers
• Comprehensive guides

Cuba

Cuba.define do
  on get do
    on "ciudades" do
      ciudades = YAML.load_file("ciudades.yml")
      # Index Cities
      on root do
        res.write ciudades.to_json
      end

      # Show City
      on ":ciudad" do |ciudad|
        res.write ciudades[ciudad].to_json
      end
    end

    on root do
      res.redirect "/ciudades"
    end
  end
end

Cuba

# CSRF
Cuba.use Rack::Session::Cookie, :secret => "s3cr3t"
Cuba.plugin Cuba::Safe

Cuba.define do
  on csrf.unsafe? do
    csrf.reset!

    res.status = 403
    res.write("Not authorized")

    halt(res.finish)
  end

  # Here comes the rest of your application
  # ...
end

Cuba.define do
  on get do
    on "hello" do
      on root do
        res.write "hello world"
      end
    end
  end
end

# Requests:
#
# GET /            # 404
# GET /hello       # 200
# GET /hello/world # 404

Comparison

• 1000 requests concurrency of 10
• ruby 2.2.0p0 [x86_64-darwin13]

Links to examples

• https://github.com/marjaimate/libre-sinatra
• https://github.com/marjaimate/libre-grape
• https://github.com/marjaimate/libre-webmachine
• https://github.com/marjaimate/libre-cuba
• https://github.com/marjaimate/libre-rails
