The Case for Socket IO for mobile

Interactions

Author: Pronab Pal, Technical Architect, TCS

About me

• Longtime java developer[2001+] in Sydney  /Canberra major Banks,IBM,Medicare, IPA ,Western union etc.pre-Java experience includes Nokia Game platform development.
• promoter of use-case based development (Australian Innovation Patent)
• ESB,Webservice specialisation for last 7 years
• developing platform for mobile back end data interactivity  and context management :
• Github: [Quadroo Server]
• https://github.com/TheCuesFlowsToStoryProject/CuesFlow

Personal Mobile Phones as Multichanneler

for Devices

with notification + intelligent machine 2 machine conversation

Devices & Mobile

• Devices like google glass/apple watch, Beacons are coming standard part of interaction..Virgin has embraced it fully
• Device triggers asychronous process in mobile that may call for server coordination e.g sending location specific instructions to passenger going through departure lounge.
• asynchronous sockets interaction allows this to happen smoothly without tying up UI .
• Server also should be able to feed data in small context dependent chunks

Reason For Device Flooding

•  Mobiles carry lots of intelligent parts [accelerometer,gyrometer, magnetometer, blutooth adapters]
•  Mass manufacturing Mobile made them cheap
• TCP Communication stack is well established [pre web]
• aurdino/raspberry pie like microplatforms easily accessible to devices
• Younger generation/enterpreneurs get them easily

  What is Disruptive With Devices? Why we need a Fresh approach

• context infestation from user ; sockets heardly used.
• sockets provide multichannel duplex absent with HTTP
• small converstaion -new information in extended context
• demand for constant update [micro services]
• Rest based interaction can not define microservices
• XML or JSON does not provide context carry over
• Rest by design is  not asynchronous apps model

    Mobile Development Today

 !Continuous improvement in  the UI layer matching GPU units [e.g maturity with material design, lollipop,recognition of physics in human space]

x Service invocation  spills in easily to the UI thread. [lack of data model]

x No general use of  tcp sockets -still unnecessary  http dependency [http was a web legacy]

x Age old problem of spaggeti-ness.

Carry over web issues: x sessions continuity, lack of immediate data source to reconnect after a drop out.

x bad sync issues with native and web components with work arounds. x missing strategy  for  web componenets & native componenets coexistance X vagueness with microservice -what it can be ?

Demo :NodeJava  Tunnel

Fast & Simple

Interaction:

Reasons 4 change

multiple Http Connection establishment costly

2-Way communication , makes notification easy

Bring contextual data in small chunks,readily updatable.

Gives oppertunity to trickle transition to new tech, cleaner codebase

Gives platform to go with  "micro services".

Comparison 2 old

socket overhead : in reality no more than http as it remains in its own thread.

New infrastructure : a Quadroo server sitting between apache webserver and mobiles  -instead of oracle application server

Akamai is not able to break content in small chunks [micro service]

Solution Components

• UCL : uniform context locator for complexity management  & understandaibility, a jason structure with dictionary of contexts.
• Node.js : interactivity through evented async process driver .
• Context creation and Content access are two async processes, each having user interaction
• Sockets : event driven 2-Way interaction .
• Java : strong development model in small chunks [verbs]

UCL's

• Put simply  json or XML with  dictionary
• Removes variety in spelling,
• predefined domain contexts e.g pnr/segment/seatno/breakfast
• enables small chunks of contextual data

Traditional PNR (xml) 800 lines

UCL PNR

pnr{3H4NLL}

pnr.segment {3H4NLL,DelBom}

pnr.segment.flightno

{3H4NLL,DelBom,QF22}

pnr.segment.seatno{3H4NLL,DelBom,E45}

pnr.segment.seatno.breakfast{3H4NLL,DelBom,E45,{egg ,toast,coffee,}}
