Introduction

to CSS


What is CSS?

  • CSS stands for Cascading Style Sheets
  • Used for the look and formatting of an
    HTML document
  • CSS is designed to separate the content
    from the presentation
    • HTML - structure
    • CSS - layout, fonts, colors, etc

CSS Saves a lot of Work!

  • When tags like <font> and color attributes
    were added in HTML 3.2, it started a nightmare
    for web developers
    • Development of large web sites where fonts
      and colors were added to every page became
      a long and expensive process
    • To solve the problem, the World Wide Web
      Consortium (W3C) created CSS
    • In HTML 4.0, all formatting could be removed
      from HTML and stored in a separate CSS file

Brief Timeline

  • CSS 1 - 1996
  • CSS 2 - 1998
  • CSS 2.1 - 2004
    • Finally published in 2011
  • CSS 3 - 2012
    • Working drafts published as
      early as 1999
  • CSS 4
    • No single CSS 4 integration
    • A few level 4 modules exist
      though

Live Editors & Text Editors


Ways to Implement CSS

  • Inline styles
    • <p style="color: blue;">This is blue.</p>
  • Internal styles
    • <head>
      <style>
      p { color: blue; }
      </style>
      </head>
  • External styles
    • <head>
      <link rel="stylesheet" type="text/css" href="styles.css">
      </head>

Syntax

  • A CSS rule combines two parts:
    • a selector
    • and one or more declarations

Syntax

Selectors

  • Selectors are used to declare which part of
    the markup (HTML) a style applies to
  • You can select elements by HTML tag or by
    user defined selectors
    • HTML tag
      • p { color: blue; }
    • id
      • #para1 { color: blue; }
    • class
      • .para2 { color: blue; }

Syntax

Selectors

  • id
    • An id is used to uniquely identify
      an element
  • class
    • A class is used to select many elements
      that share that class

Syntax

Declaration Block

  • Consists of a list of declarations in braces { }
  • Each declaration consists of a property,
    a colon (:), and a value
  • Multiple declarations in a block are separated
    by a semi-colon (;)

Backgrounds

  • background-color
    • hex value: #FF0000;
    • RGB value: rgb(255,0,0);
    • color name: red;
  • background-image
    • url('background.jpg');
  • background-repeat
    • repeat-x;
    • repeat-y;
    • no-repeat;
  • background-position
    • right top;
    • bottom left;

Shorthand Property

  • It is possible to specify all the properties
    in one single property
    • Called shorthand property
    • body { background: #FFFFFF
      url('background.jpg') no-repeat right top; }

Text Formatting

  • color
    • hex value: #FF0000;
    • RGB value: rgb (255,0,0);
    • color name: red;
  • text-align
    • center;
    • right;
    • justify;
  • text-decoration
    • underline;
    • line-through;
    • overline;
    • none;

Text Formatting

  • text-transform
    • uppercase;
    • lowercase;
    • capitalize;
      • first letter of each word
  • text-indent
    • indents the first line of a text
  • line-height
  • letter-spacing
  • text-shadow
    • 1px 1px 5px #000000;

Fonts

Font Families

  • The font family is a set with the font-family
    property
    • serif
      • Times New Roman, Georgia
    • sans-serif
      • Arial, Verdana
    • monospace
      • All characters have the same width
      • Courier New, Lucida Console

Fonts

Font Families

  • Works on a "fallback" system - if the browser
    does not support the first font, it tries the next
  • Start with the font you want and end with a
    generic family
    • p {
          font-family: "Times New Roman", Times, serif;
      }
  • Web Safe Font Combinations:
    http://www.w3schools.com/cssref/css_websafe_fonts.asp

Fonts

Font Style

  • font-style:
    • normal;
    • italic;
  • font-weight:
    • normal;
    • bold;
    • 100 - 900
      • Ex: font-weight: 700;
        • 400 is normal
        • 700 is bold

Fonts

Font Size

Links

  • Links can be styled like fonts (font-family, color, etc)
  • Can also be styled based on what state they are in
    • a:link - normal link
    • a:visited - a link the user has visited
    • a:hover - a link when the user mouses over it
    • a:active - a link the moment it is clicked

Links

  • a:hover must come after a:link and a:visited
  • a:active must come after a:hover
  • Ex:
    a:link { color: #FF0000; }
    a:visited { color: #00FF00; }
    a:hover { color: #FF00FF; }
    a:active { color: #0000FF; }

Lists

  • Change list item (li) markers
    • list-style-type: square;
    • list-style-type: lower-alpha;
    • list-style-type: upper-roman;
    • list-style-image: url('bullet.png');

The CSS Box Model

  • Consists of:
    • content
    • padding
    • border
    • margin


Content

  • height:
  • width:
  • max-height:
  • max-width:
  • min-height:
  • min-width:

Padding

  • padding:
    • 10px;
    • 20%;
  • Individual sides
    • padding-top:
    • padding-right:
    • padding-bottom:
    • padding-left:

Padding

  • Shorthand property
    • padding: 100px 50px;
    • can have up to 4 values
      • padding: 25px 50px 75px 100px;
        • top padding is 25px
        • right padding is 50px
        • bottom padding is 75px
        • left padding is 100px
      • Goes clockwise around element

Borders

  • border-style:
    • solid
    • dotted;
    • dashed;
    • double;
    • groove;
    • ridge;
    • inset;
    • outset;
  • border-width:
  • border-color:

Borders

  • You can apply borders to individual sides
    • border-bottom:
    • border-top-style:
    • border-left-color:
    • border-right-width:
  • border-radius
    • border-radius: 25px;
    • border-top-left-radius: 25px;
  • shorthand property
    • border: 1px solid black;

Margins

  • margin:
    • 10px;
      • Margin is 10px on all sides
      • Default value is 0px
    • 20%;
    • auto;
      • Automatically uses up the largest
        possible margin
    • inherit;
      • Specifies that the margin should be
        inherited from the parent element

Margins

  • You can apply margins to individual sides
    • margin-top
    • margin-bottom
  • Shorthand property
    • margin: 100px; 50px;
    • can have up to 4 values
      • margin: 25px 50px 75px 100px;
        • top margin is 25px
        • right margin is 50px
        • bottom margin is 75px
        • left margin is 100px
      • Goes clockwise around element

Display

  • The display property specifies if/how an
    element is displayed
    • display: block;
      • Takes up the full width available, and
        has a line break before and after it
    • display: inline;
      • Takes up as much width as necessary,
        and does not force line breaks
    • display: inline-block;
      •  Displays inline but retains block level
        formatting
    • display: none;

Float

  • Allows elements to be pushed to the left or
    right, allowing other elements to wrap around it
  • Elements are floated horizontally
  • Elements after the floating element will flow
    around it
    • Ex: flowing text around an image
    • Elements before the floating element will not
      be affected
  • float: right;

Horizontal Alignment

  • Using the margin property
    • margin-left: auto;
      margin-right: auto;
    • Setting the left and right margins to auto
      specifies that they should split the available
      margin equally

Comments

  • Help explain your code for yourself and others
  • Ignored by the browser
  • Begins with /* and ends with */
    • /* This is a comment */

Animations

  • It is possible to animate elements without using
    Flash or JavaScript
  • Keyframes
    • The @keyframes rule is where the animation
      is created
    • Specify a CSS style inside the @keyframes rule
      and the animation will gradually change from
      the current style to the new style
      • @keyframes
      • @-webkit-keyframes
        • Chrome and Safari
  • Techranger robot example

    Browser Support

    Continue Learning!

    More Resources
