Following through

with animation

@opherv / dec 2016

Blizzard

Art by DarrenGeers

Hi! I'm Opher

I'm a creative developer at Interlude Eko



The Lion King (1994)

01  Squash and Stretch

02  Anticipation

03  Staging

04  Straight Ahead Action and Pose to Pose

05  Follow Through and Overlapping Action

06  Slow In and Slow Out

07  Arc

08  Secondary Action

09  Timing

12  Appeal

10  Exaggeration

11  Solid drawing

05  Follow Through and Overlapping Action

art by thecommaspace

art by thecommaspace

What are we making?

Animation specs:

Four circles



Total Iteration time:  1 second


Circle moment time: 0.5 seconds



Circle stagger time: 0.15 seconds

Our tools

* Web animation API

Implementation 1

Pros

Good performance across devices (GPU accelerated *)



Defined using CSS

Cons

Limited features /
complex animations are tricky



No dynamic animations



Hard to debug

CSS Animation - quick recap

@keyframes move {
  0%   { transform: translateX(0); }
  25% { transform: translateX(100px); }
  100% { transform: translateX(400px); }
}

span{
    animation: move 2s infinite;
}

Let's add animation-delay

hmm... what just happened?

animation-delay affects only the start delay. It doesn't affect animation repeats!

Making sense of it all

0s = 0%
0.3s = 0.3 / 1s * 100 =  30%
0.8s = (0.3 + 0.5) / 1s * 100 = 80%
1s = 100%
@keyframes circle3{
  0%{ transform: translateX(0); }
  ???% { transform: translateX(0); }
  ???% { transform: translateX(60px); }
  100% { transform: translateX(60px); }
}

The solution

@mixin createCircleAnimation($i, $animTime, $totalTime, $delay){
      @include keyframes(circle#{$i}){
         0%{
            @include transform(translateX(0));
          }
          #{($i * $delay)/$totalTime * 100}% {
            @include transform(translateX(0));
          }
          #{($i * $delay + $animTime)/$totalTime * 100}% {
            @include transform(translateX(60px));
          }
          100% {
            @include transform(translateX(60px));
          }
        }
}

$animTime: 0.5s;
$totalTime: 1s;
$staggerTime: 0.15s;

@for $i from 0 through 3 {
 @include createCircleAnimation($i, $animTime, $totalTime, $staggerTime);
 span:nth-child(#{($i + 1)}){
 animation: circle#{(3 - $i)} $totalTime infinite;
 left: #{$i * 60 - 60 }px;
 }
}

mixin

@mixin createCircleAnimation($i, $animTime, $totalTime, $delay){
      @include keyframes(circle#{$i}){
         0%{
            @include transform(translateX(0));
          }
          #{($i * $delay)/$totalTime * 100}% {
            @include transform(translateX(0));
          }
          #{($i * $delay + $animTime)/$totalTime * 100}% {
            @include transform(translateX(60px));
          }
          100% {
            @include transform(translateX(60px));
          }
        }
}

usage

$animTime: 0.5s;
$totalTime: 1s;
$staggerTime: 0.15s;

@for $i from 0 through 3 {
 @include createCircleAnimation($i, $animTime, $totalTime, $staggerTime);

  span:nth-child(#{($i + 1)}){
      animation: circle#{(3 - $i)} $totalTime infinite;
      left: #{$i * 60 - 60 }px;
 }
}

by Will Stone

Implementation 2

Pros

Great, robust API


Dynamic animations



Handles browser inconsistencies

Cons

JS is implementation-sensitive


no display/logic seperation



Thanks!

@OpherV

opherv.com

opherv@gmail.com

github.com/opherv
