State Management

Kumar Ratnam Pandey

Software Engineer at

GeekyAnts

@ratnam99

Why

State Management?

• State Synchronization



• Re-rendering

Why State Management?

Type of states:


1. Server state.

2. Persistent state.

3. The URL and router state.

4. Client state.

5. Transient client state.

6. Local UI state.

State Synchronization

• The persistent state and the server state store the same information. So do the client state and the URL. Because of this we have to synchronize them.

State Synchronization

Re-rendering

Data Layer

UI

Changes

Changes

Example

• The application has two main routes: one that displays a list of contacts, and the other one showing detailed information about each contact.

export interface Contact {
  id: number;
  name: string;
  number: string;
  email: string;
  isFav: boolean;
}

export interface Filters {
  name: string;
  fav: boolean;
}

Application Model

@Injectable()
export class ApiCalls {
  _contacts: {[id:number]: Contact} = {};
  _list: number[] = [];

  filters: Filters = {name: null, fav: false};

  constructor(private http: Http) {}

  get contacts(): Contact[] {
    return this._list.map(n => this._contacts[n]);
  }

  findContact(id: number): Observable<Talk> {
    return of(this._contacts[id]);
  }

  makeFav(id: number, fav: number): void {
    const contact = this._contacts[id];
    contact.isFav = fav;
    this.http.post(`/fav`, {id: contact.id, isFav: fav}).forEach(() => {});
  }

  changeFilters(filters: Filters): void {
    this.filters = filters;
    this.refetch();
  }

  private refetch(): void {
    const params = new URLSearchParams();
    params.set("name", this.filters.name);
    params.set("fav", this.filters.fav);
    this.http.get(`/contacts`, {search: params}).forEach((r) => {
      const data = r.json();
      this._contacts = data.contacts;
      this._list = data.list;
    });
  }
}

Backend

export class WatchService {
  watched: {[k:number]:boolean} = {};

  watch(contact: Contact): void {
    console.log("watch", contact.id);
    this.watched[contact.id] = true;
  }

  isWatched(contact: Contact): boolean {
    return this.watched[contact.id];
  }
}

Watch Service

Everything looks fine?

• Syncing Persistent and Server State.

Problems

• Syncing URL and Client State

Problems

State Management?

Let's see what

manages each type

of state in this application.

Refactoring 1:

Separating State Management

Architecture

3 simple steps

Defining all the actions our application can perform.

Eg-: export type Filter = {
                    type: 'FILTER',
                    filters: Filters
                };

Step 1

​Then the state.

Step 2

// all non-local state of the application
          export type State = {
                       contacts: { [id: number]: Contact },
                       filters: Filters,
          };
// init state
          export const initState: State = {
                              contacts: {},
                              filters: {fav: null}
          };

​And, finally, the reducer.

Step 3

// a factory to create reducer
export function reducer(backend: Backend, watch: WatchService) {
  return (store: Store<State, Action>, state: State, action: Action) => {
    switch (action.type) {
      case 'FILTER':
        return backend.findContacts(action.filters).
            map(r => ({...state, ...r, filters: action.filters}));
     case 'SHOW_DETAIL':
        if (state.contacts[action.contactId]) return state;
        return backend.findContact(action.contactId).
            map(c => ({...state, contacts: {...state.contacts, [c.id]: c}));
     default:
        return state;
    }
  }
}

• State management and computation/services are separated. The reducer is the only place where we manipulate non-local state.


• We no longer use mutable objects for persistent and client state.

Analysis

Redux should be the means of achieving a goal, not the goal

Alternatives

Mobx

2 simple steps

Making the store observable.

Eg: import {observable} from 'mobx';
    .
    .
    .
    export default filter observable=([
                       fav:boolean
                   ]);

Step 1

Make the component as an observer.

import {observer} from 'mobx';
.
.
.
@observer
export class ContactsAndFiltersComponent implements OnInit {
  contactList:Contact[]=[];
  current:string="Contact";
  filter:Filters={
    name:'',
    fav:false
  };
  constructor(public backend: Backend, private router: Router, private route: ActivatedRoute, private watchService:WatchService) {
  }

  viewContact(contact){
    this.watchService.id=contact.id;
    this.router.navigate(['contact']);
  }

  makeFav(contact:Contact){
    console.log("make Fav", contact);
    let newContactList=this.contactList.map((eachContact)=>{
      if(eachContact.id===contact.id){
        eachContact.isFav=!contact.isFav;
      }
      return eachContact;
    })
    this.contactList=newContactList;
    this.backend.makeFav(this.contactList);
  }

  viewFavlist(){
    let filters:Filters={
      name: this.filter.name,
      fav: true
    }
    this.router.navigate(['/contacts',this.createParams(filters)]);
  }

  viewAllContacts(){
    let filters:Filters={
      name: this.filter.name,
      fav: false
    }
    this.router.navigate(['/contacts',this.createParams(filters)]);
  }

  private createParams(filters: Filters): Params {
    const r:any = {};
    if (filters.name) r.name = filters.name;
    if (filters.fav) r.fav = filters.fav;
    return r;
  }

}

Step 2

Analysis

NgRx

4 simple steps

Defining the state of our application.

Eg-: export const initState: State = {
                 contacts: {},
                 filters: {fav: null}
              };

Step 1

Defining all the actions our application can perform.

Eg-: export type Filter = {
                    type: 'FILTER',
                    filters: Filters
                };

Step 2

Next, the effects class.

class TalksEffects {
  // @Effect() navigateToContacts = ...
  // @Effect() navigateToContact = ...
  // @Effect() favContact = ...
  constructor(
               private actions: Actions,
               private store: Store<State>,
               private backend: Backend,
               private watch: WatchService) {
  }
}

Step 3

Then, the reducer.

Step 4

function appReducer(state: AppState, action: Action): AppState {
  switch (action.type) {
    case 'CONTACTS': // ...
    case 'CONTACT_UPDATED': // ...
    case 'FAV': // ...
    case 'UNFAV': // ...
    default: return state;

  }
}

• If the router needs some information from Backend, it cannot reliably get it.

• if Backend needs something from the router or the URL, it cannot reliably get it.

• The reducer cannot stop the navigation.

• The synchronization is ad-hoc. If we add a new route, we will have to reimplement the synchronization code there as well.

Remaining Problems

Refactoring 2:

Store and Router.

Make navigation part of updating the store.
And finally we can make updating the store part of navigation.

imports: [
    //...
    RouterConnectedtoStore.forRoot(
      "reducer",
      [
        { path: '', pathMatch: 'full', redirectTo: 'talks' },
        { path: 'contacts',  component: ContactsAndFiltersCmp },
        { path: 'contact/:id', component: ContactDetailsCmp }
      ]
    )

  ],

RouterConnectedToStoreModule will set up the router in such a way that right after the URL gets parsed and the future router state gets created, the router will dispatch the an appropriate action (say STORE_ROUTE_NAVIGATION).

Refactoring 2: Store and Router.

Then we define the case for STORE_ROUTE_NAVIGATION action inside the reducer function.

Refactoring 2: Store and Router.

// a factory to create reducer
export function reducer(backend: Backend, watch: WatchService) {
  return (store: Store<State, Action>, state: State, action: Action) => {
    switch (action.type) {
      case 'STORE_ROUTE_NAVIGATION':
        // Logic for proper navigation
      case 'SHOW_DETAIL':
        if (state.contacts[action.contactId]) return state;
        return backend.findContact(action.contactId).
            map(c => ({...state, contacts: {...state.contacts, [c.id]: c}));
      default:
        return state;
    }
  }
}

• This refactoring tied the client state to the URL. The router navigation invokes the reducer, and then once the reducer is done, the navigation proceeds using the new state.

Analysis

• The main takeaway is you should be deliberate about how you manage state. It is a hard problem, and hence it requires careful thinking. Do not trust anyone saying they have “one simple pattern/library” fixing it — that’s never the case.


• Decide on the types of state, how to manage them, and how to make sure the state is consistent. Be intentional about your design.

Takeaway
