The Archive and Package (arcp) URI scheme

Stian Soiland-Reyes

eScience lab, The University of Manchester

Adapted from RDA talk on Research Objects
2018-03-22

A Research Object bundles and relates digital resources of a scientific experiment or investigation:



Data used and results produced in experimental study

Methods employed to produce and analyse that data

Provenance and settings for the experiments

People involved in the investigation

Annotations about these resources, to improve understanding and interpretation

Research Object

id:        doi:10.15490/seek.1.investigation.56
createdOn: 2015-07-10T16:46:00Z
createdBy: http://orcid.org/0000-0001-9842-9718

aggregates:
 - id:         data/sequence/specimen5.bam
   conformsTo: http://gemrb.org/iesdp/file_formats/ie_formats/bam_v1.htm

 - id:         http://example.com/blog/about-specimen5
   authoredBy: http://orcid.org/0000-0001-7066-3350

 - id:         http://www.myexperiment.org/workflows/3355
   history:    provenance/workflow-evolution.ttl

annotations:
 - about:       data/sequence/specimen5.bam
   content:     annotations/specimen5-properties.jsonld
   createdBy:   http://orcid.org/0000-0001-7066-3350

 - about:       data/sequence/specimen5.bam
   content:     http://example.com/blog/about-specimen5
   motivatedBy: oa:questioning

Research Object manifest

(simplified)

Reuse standards:
OAI-ORE, BagIt, W3C JSON-LD, PROV, Web Annotation Model

metadata/manifest.json
data/sequence/specimen5.bam
provenance/workflow-evolution.ttl
http://example.com/blog/about-specimen5
http://www.myexperiment.org/workflows/335

http://orcid.org/0000-0001-7066-3350
http://gemrb.org/iesdb/
   file_formats_ie_formats_bam_v1.html
activity(run:2e1287e0-6dfb-11e7-8acf-0242ac110002, , ,
   [prov:type='wfprov:WorkflowRun', prov:label="Run of workflow/packed.cwl#main"])
    // main workflow run started outside somehow (we're don't know how)
    wasStartedBy(run:4305467e-6dfb-11e7-885d-0242ac110002, -, -,
                 -, 2017-10-27T15:00:00Z)
    // ...
    // step is a nested workflow, so also a WorkflowRun
    activity(run:4305467e-6dfb-11e7-885d-0242ac110002, -, -,
      [prov:type='wfprov:WorkflowRun', prov:label="Run of workflow/packed.cwl#main/nested1"])
        // started by the mother activity
        wasStartedBy(run:4305467e-6dfb-11e7-885d-0242ac110002, -, -,
                     run:2e1287e0-6dfb-11e7-8acf-0242ac110002, 2017-10-27T15:00:30Z)

        // inner step of nested workflow, ProcessRun as this is a command line execution
        activity(run:c42dc36e-6dfd-11e7-bc24-0242ac110002, -, -
          [prov:type='wfprov:ProcessRun', prov:label="Run of workflow/packed.cwl#nested/innerStep1"])

        wasStartedBy(run:c42dc36e-6dfd-11e7-bc24-0242ac110002, -, -,
                     run:4305467e-6dfb-11e7-885d-0242ac110002, 2017-10-27T15:01:00Z)
        // ...

Identifying intermediate data

Output 1B file is also Input 2C and Input 3D downstream

Simple filenames -> duplications

  ./data/step1/outputB.txt
./data/step2/inputC.txt
./data/step3/inputD.txt



Content-adressable

SHA-256 hash of bytes as filename:

./data/51/51fb8af0c4ae0422fbe88340d91880ecb9d7537cf57339c1cf1256b7ca58f32d

RFC6920 URI as global identifier:

nih:sha-256;51fb8af0c4ae0422fbe88340d91880ecb9d7537cf57339c1cf1256b7ca58f32d

Randomly generated

arcp://uuid,32a423d6-52ab-47e3-a9cd-54f418a48571/css/base.css
>>> uuid.uuid4()
UUID('32a423d6-52ab-47e3-a9cd-54f418a48571')

UUID v4

External-Identifier: urn:uuid:32a423d6-52ab-47e3-a9cd-54f418a48571

Self-declared UUID in bagit-info.txt

{ "id" "urn:uuid:32a423d6-52ab-47e3-a9cd-54f418a48571",
  "name": "HCV1a [taxonomy:31646 ledipasvir"
  ... }

from bco.json ?

Hashed from archive download URL

arcp://uuid,b7749d0b-0e47-5fc4-999d-f154abe68065/pics/flower.jpeg
>>> uuid.uuid5(uuid.NAMESPACE_URL, "http://example.com/data.zip")
UUID('b7749d0b-0e47-5fc4-999d-f154abe68065')

UUID v5

Location-independent archive identifier (BDBag)

>>> uuid.uuid5(uuid.NAMESPACE_URL, "http://identifiers.org/ark/ark:/57799/b91w9r")
UUID('4f11f216-e2dc-57cd-a714-300409a430ce')
stain@biggie:~$  sha256sum archive.zip
7f83b1657ff1fc53b92dc18148a1d65dfc2d4b1fa3d677284addd200126d9069

RFC6920 (Naming Thing with Hashes) URI

>>> urlsafe_b64encode("7f83b1657ff1fc53b92dc18148a1d65dfc2d4b1fa3d677284addd200126d9069"
     .decode("hex"))
'f4OxZX_x_FO5LcGBSKHWXfwtSx-j1ncoSt3SABJtkGk='
arcp://ni,sha-256;f4OxZX_x_FO5LcGBSKHWXfwtSx-j1ncoSt3SABJtkGk/src/luhn.c

Hash checksum of archive

ni:///sha-256;f4OxZX_x_FO5LcGBSKHWXfwtSx-j1ncoSt3SABJtkGk/
wget http://repo.example.com/.well-known/
    ni/sha-256/f4OxZX_x_FO5LcGBSKHWXfwtSx-j1ncoSt3SABJtkGk/

Retrievable/verifiable

arcp URI Python library

>>> from arcp import *

>>> arcp_random()
'arcp://uuid,dcd6b1e8-b3a2-43c9-930b-0119cf0dc538/'

>>> arcp_random("/foaf.ttl", fragment="me")
'arcp://uuid,dcd6b1e8-b3a2-43c9-930b-0119cf0dc538/foaf.ttl#me'

>>> arcp_hash(b"Hello World!", "/folder/")
'arcp://ni,sha-256;f4OxZX_x_FO5LcGBSKHWXfwtSx-j1ncoSt3SABJtkGk/folder/'

>>> arcp_location("http://example.com/data.zip", "/file.txt")
'arcp://uuid,b7749d0b-0e47-5fc4-999d-f154abe68065/file.txt'
pip install arcp

Parsing arcp URIs

>>> is_arcp_uri("arcp://uuid,b7749d0b-0e47-5fc4-999d-f154abe68065/file.txt")
True
>>> u = parse_arcp("arcp://uuid,b7749d0b-0e47-5fc4-999d-f154abe68065/file.txt")
ARCPSplitResult(scheme='arcp',prefix='uuid',
  name='b7749d0b-0e47-5fc4-999d-f154abe68065',
  uuid='b7749d0b-0e47-5fc4-999d-f154abe68065',
  path='/file.txt',query='',fragment='')

>>> u.path
'/file.txt'
>>> u.prefix
'uuid'
>>> u.uuid
UUID('b7749d0b-0e47-5fc4-999d-f154abe68065')
>>> u.uuid.version
5

>>> parse_arcp("arcp://ni,sha-256;f4OxZX_x_FO5LcGBSKHWXfwtSx-j1ncoSt3SABJtkGk/folder/")
     .hash
('sha-256', '7f83b1657ff1fc53b92dc18148a1d65dfc2d4b1fa3d677284addd200126d9069')
