Foundation ZURB

Sou Developer Senior WEB com foco em UX/UI, responsável pelo setor de desenvolvimento da agência Diretriz Digital.

CEO - DsignerByCreator

www.tiagoserra.com.br

contato@tiagoserra.com.br

@tiagoserraweb

Tiago Serra

Intro

Sobre

Foi desenvolvido pela companhia ZURB, criada em 1998 por Bryan Zmijewski.

Lançou a versão 2.0 em outubro de 2011.

E em 2014 foi lançada a versão 5.4.0.

Elementos

- Grade

- Detalhes

- Tipografia

- Botões

- Navegação

- Forms

- Elementos UI

- Guias

- Orbit

start = function() {

O que você está construindo?

Temos três pacotes diferentes para você começar:

CSS

SASS

Construir APP

while(start==POWER){

http://foundation.zurb.com/develop/download.html
http://foundation.zurb.com/docs/

Basic

<!DOCTYPE html>
<!--[if IE 9]><html class="lt-ie10" lang="pt-br" > <![endif]-->
<html class="no-js" lang="pt-br" >

<head>
  <meta charset="utf-8">
  <!-- If you delete this meta tag World War Z will become a reality -->
  <meta name="viewport" content="width=device-width, initial-scale=1.0">
  <title>Foundation 5</title>

  <!-- If you are using the CSS version, only link these 2 files, you may add app.css to use for your overrides if you like -->
  <link rel="stylesheet" href="css/normalize.css">
  <link rel="stylesheet" href="css/foundation.css">

  <!-- If you are using the gem version, you need this only -->
  <link rel="stylesheet" href="css/app.css">

  <script src="js/vendor/modernizr.js"></script>

</head>
<body>

  <!-- body content here -->

  <script src="js/vendor/jquery.js"></script>
  <script src="js/foundation.min.js"></script>
  <script>
    $(document).foundation();
  </script>
</body>
</html>

Media Queries

// Small screens
@media only screen { } /* Define mobile styles */

@media only screen and (max-width: 40em) { } /* max-width 640px, mobile-only styles, use when QAing mobile issues */

// Medium screens
@media only screen and (min-width: 40.063em) { } /* min-width 641px, medium screens */

@media only screen and (min-width: 40.063em) and (max-width: 64em) { } /* min-width 641px and max-width 1024px, use when QAing tablet-only issues */

// Large screens
@media only screen and (min-width: 64.063em) { } /* min-width 1025px, large screens */

@media only screen and (min-width: 64.063em) and (max-width: 90em) { } /* min-width 1025px and max-width 1440px, use when QAing large screen-only issues */

// XLarge screens
@media only screen and (min-width: 90.063em) { } /* min-width 1441px, xlarge screens */

@media only screen and (min-width: 90.063em) and (max-width: 120em) { } /* min-width 1441px and max-width 1920px, use when QAing xlarge screen-only issues */

// XXLarge screens
@media only screen and (min-width: 120.063em) { } /* min-width 1921px, xxlarge screens */

1 em = 16px

1/16 = 0.0625em

Grid

<div class="row">
  <div class="small-2 large-4 columns">...</div>
  <div class="small-4 large-4 columns">...</div>
  <div class="small-6 large-4 columns">...</div>
</div>
<div class="row">
  <div class="large-3 columns">...</div>
  <div class="large-6 columns">...</div>
  <div class="large-3 columns">...</div>
</div>
<div class="row">
  <div class="small-6 large-2 columns">...</div>
  <div class="small-6 large-8 columns">...</div>
  <div class="small-12 large-2 columns">...</div>
</div>
<div class="row">
  <div class="small-3 columns">...</div>
  <div class="small-9 columns">...</div>
</div>
<div class="row">
  <div class="large-4 columns">...</div>
  <div class="large-8 columns">...</div>
</div>
<div class="row">
  <div class="small-6 large-5 columns">...</div>
  <div class="small-6 large-7 columns">...</div>
</div>
<div class="row">
  <div class="large-6 columns">...</div>
  <div class="large-6 columns">...</div>
</div>

Block Grid

<ul class="small-block-grid-3">
  <li><!-- Your content goes here --></li>
  <li><!-- Your content goes here --></li>
  <li><!-- Your content goes here --></li>
</ul>

<ul class="small-block-grid-2 medium-block-grid-3 large-block-grid-4">
  <li><!-- Your content goes here --></li>
  <li><!-- Your content goes here --></li>
  <li><!-- Your content goes here --></li>
  <li><!-- Your content goes here --></li>
  <li><!-- Your content goes here --></li>
  <li><!-- Your content goes here --></li>
</ul>

Básico

Avançado

Top Bar

<nav class="top-bar" data-topbar role="navigation">
  <ul class="title-area">
    <li class="name">
      <h1><a href="#">My Site</a></h1>
    </li>
     <!-- Remove the class "menu-icon" to get rid of menu icon. Take out "Menu" to just have icon alone -->
    <li class="toggle-topbar menu-icon"><a href="#"><span>Menu</span></a></li>
  </ul>

  <section class="top-bar-section">
    <!-- Right Nav Section -->
    <ul class="right">
      <li class="active"><a href="#">Right Button Active</a></li>
      <li class="has-dropdown">
        <a href="#">Right Button Dropdown</a>
        <ul class="dropdown">
          <li><a href="#">First link in dropdown</a></li>
          <li class="active"><a href="#">Active link in dropdown</a></li>
        </ul>
      </li>
    </ul>

    <!-- Left Nav Section -->
    <ul class="left">
      <li><a href="#">Left Nav Button</a></li>
    </ul>
  </section>
</nav>

Orbit

<ul class="example-orbit" data-orbit>
  <li>
    <img src="../assets/img/examples/satelite-orbit.jpg" alt="slide 1" />
    <div class="orbit-caption">
      Caption One.
    </div>
  </li>
  <li class="active">
    <img src="../assets/img/examples/andromeda-orbit.jpg" alt="slide 2" />
    <div class="orbit-caption">
      Caption Two.
    </div>
  </li>
  <li>
    <img src="../assets/img/examples/launch-orbit.jpg" alt="slide 3" />
    <div class="orbit-caption">
      Caption Three.
    </div>
  </li>
</ul>

Orbit

<ul class="example-orbit-content" data-orbit>
  <li data-orbit-slide="headline-1">
    <div>
      <h2>Headline 1</h2>
      <h3>Subheadline</h3>
    </div>
  </li>
  <li data-orbit-slide="headline-2">
    <div>
      <h2>Headline 2</h2>
      <h3>Subheadline</h3>
    </div>
  </li>
  <li data-orbit-slide="headline-3">
    <div>
      <h2>Headline 3</h2>
      <h3>Subheadline</h3>
    </div>
  </li>
</ul>

Content Sliders

Orbit

<a data-orbit-link="headline-1" class="small button">
  Goto Slide 1
</a>
<a data-orbit-link="headline-2" class="small button">
  Goto Slide 2
</a>
<a data-orbit-link="headline-3" class="small button">
  Goto Slide 3
</a>

Deep Linking

Buttons

<a href="#" class="button">Default Button</a>

Basic

Button Sizing

<a href="#" class="button tiny">Tiny Button</a>
<a href="#" class="button small">Small Button</a>
<a href="#" class="button">Default Button</a>
<a href="#" class="button disabled">Disabled Button</a>
<a href="#" class="button large">Large Button</a>
<a href="#" class="button expand">Expanded Button</a>
<!-- Radius Classes -->
<a href="#" class="button round">Round Button</a>
<a href="#" class="button radius">Radius Button</a>

<!-- Color Classes -->
<a href="#" class="button">Default Button</a>
<a href="#" class="button success">Success Button</a>
<a href="#" class="button secondary">Secondary Button</a>
<a href="#" class="button alert">Alert Button</a>
<a href="#" class="button info">Info Button</a>
<a href="#" class="button disabled">Disabled Button</a>

Button Colors

Forms

<form>
  <div class="row">
    <div class="large-12 columns">
      <label>Input Label
        <input type="text" placeholder="large-12.columns" />
      </label>
    </div>
  </div>
  <div class="row">
    <div class="large-4 columns">
      <label>Input Label
        <input type="text" placeholder="large-4.columns" />
      </label>
    </div>
    <div class="large-4 columns">
      <label>Input Label
        <input type="text" placeholder="large-4.columns" />
      </label>
    </div>
    <div class="large-4 columns">
      <div class="row collapse">
        <label>Input Label</label>
        <div class="small-9 columns">
          <input type="text" placeholder="small-9.columns" />
        </div>
        <div class="small-3 columns">
          <span class="postfix">.com</span>
        </div>
      </div>
    </div>
  </div>
  <div class="row">
    <div class="large-12 columns">
      <label>Select Box
        <select>
          <option value="husker">Husker</option>
          <option value="starbuck">Starbuck</option>
          <option value="hotdog">Hot Dog</option>
          <option value="apollo">Apollo</option>
        </select>
      </label>
    </div>
  </div>
  <div class="row">
    <div class="large-6 columns">
      <label>Choose Your Favorite</label>
      <input type="radio" name="pokemon" value="Red" id="pokemonRed"><label for="pokemonRed">Red</label>
      <input type="radio" name="pokemon" value="Blue" id="pokemonBlue"><label for="pokemonBlue">Blue</label>
    </div>
    <div class="large-6 columns">
      <label>Check these out</label>
      <input id="checkbox1" type="checkbox"><label for="checkbox1">Checkbox 1</label>
      <input id="checkbox2" type="checkbox"><label for="checkbox2">Checkbox 2</label>
    </div>
  </div>
  <div class="row">
    <div class="large-12 columns">
      <label>Textarea Label
        <textarea placeholder="small-12.columns"></textarea>
      </label>
    </div>
  </div>
</form>

Building

Forms

<form>
  <div class="row">
    <div class="small-8">
      <div class="row">
        <div class="small-3 columns">
          <label for="right-label" class="right">Label</label>
        </div>
        <div class="small-9 columns">
          <input type="text" id="right-label" placeholder="Inline Text Input">
        </div>
      </div>
    </div>
  </div>
</form>

Inline Labels

<form>
  <div class="row">
    <div class="small-8 columns">
      <div class="row">
        <div class="small-3 columns">
          <label for="right-label" class="right inline">Label</label>
        </div>
        <div class="small-9 columns">
          <input type="text" id="right-label" placeholder="Inline Text Input">
        </div>
      </div>
    </div>
  </div>
</form>

Forms

<form>
  <fieldset>
    <legend>Fieldset Legend</legend>

    <label>Input Label
      <input type="text" placeholder="Inputs and other form elements go inside...">
    </label>
  </fieldset>
</form>

Defining a Fieldset

<form>
  <div class="row">
    <div class="large-6 columns">
      <label class="error">Error
        <input type="text" class="error" />
      </label>
      <small class="error">Invalid entry</small>
    </div>
    <div class="large-6 columns error">
      <label>Another Error
        <input type="text" />
      </label>
      <small class="error">Invalid entry</small>
    </div>
  </div>
  <textarea class="error" placeholder="Message..."></textarea>
  <small class="error">Invalid entry</small>
</form>

Error States

Forms

<form>
  <div class="row collapse">
    <div class="small-3 large-2 columns">
      <span class="prefix">http://</span>
    </div>
    <div class="small-9 large-10 columns">
      <input type="text" placeholder="Enter your URL...">
    </div>
  </div>
  <div class="row">
    <div class="large-12 columns">
      <div class="row collapse">
        <div class="small-10 columns">
          <input type="text" placeholder="Hex Value">
        </div>
        <div class="small-2 columns">
          <a href="#" class="button postfix">Go</a>
        </div>
      </div>
    </div>
  </div>
  <div class="row">
    <div class="large-6 columns">
      <div class="row collapse prefix-radius">
        <div class="small-3 columns">
          <span class="prefix">Label</span>
        </div>
        <div class="small-9 columns">
          <input type="text" placeholder="Value">
        </div>
      </div>
    </div>
    <div class="large-6 columns">
      <div class="row collapse postfix-radius">
        <div class="small-9 columns">
          <input type="text" placeholder="Value">
        </div>
        <div class="small-3 columns">
          <span class="postfix">Label</span>
        </div>
      </div>
    </div>
  </div>
  <div class="row">
    <div class="large-6 columns">
      <div class="row collapse prefix-round">
        <div class="small-3 columns">
          <a href="#" class="button prefix">Go</a>
        </div>
        <div class="small-9 columns">
          <input type="text" placeholder="Value">
        </div>
      </div>
    </div>
    <div class="large-6 columns">
      <div class="row collapse postfix-round">
        <div class="small-9 columns">
          <input type="text" placeholder="Value">
        </div>
        <div class="small-3 columns">
          <a href="#" class="button postfix">Go</a>
        </div>
      </div>
    </div>
  </div>
</form>

Pre/Postfix Labels & Actions

Tabs

<ul class="tabs" data-tab>
  <li class="tab-title active"><a href="#panel1">Tab 1</a></li>
  <li class="tab-title"><a href="#panel2">Tab 2</a></li>
  <li class="tab-title"><a href="#panel3">Tab 3</a></li>
  <li class="tab-title"><a href="#panel4">Tab 4</a></li>
</ul>
<div class="tabs-content">
  <div class="content active" id="panel1">
    <p>This is the first panel of the basic tab example. </p>
  </div>
  <div class="content" id="panel2">
    <p>This is the second panel of the basic tab example. </p>
  </div>
  <div class="content" id="panel3">
    <p>This is the third panel of the basic tab example. </p>
  </div>
  <div class="content" id="panel4">
    <p>This is the fourth panel of the basic tab example. </p>
  </div>
</div>

Basic

Tabs

<ul class="tabs" data-tab role="tablist">
  <li class="tab-title active" role="presentation"><a href="#panel2-1" role="tab" tabindex="0" aria-selected="true" aria-controls="panel2-1">Tab 1</a></li>
  <li class="tab-title" role="presentation"><a href="#panel2-2" role="tab" tabindex="0" aria-selected="false" aria-controls="panel2-2">Tab 2</a></li>
  <li class="tab-title" role="presentation"><a href="#panel2-3" role="tab" tabindex="0" aria-selected="false" aria-controls="panel2-3">Tab 3</a></li>
  <li class="tab-title" role="presentation"><a href="#panel2-4" role="tab" tabindex="0" aria-selected="false" aria-controls="panel2-4">Tab 4</a></li>
</ul>
<div class="tabs-content">
  <section role="tabpanel" aria-hidden="false" class="content active" id="panel2-1">
    <h2>First panel content goes here...</h2>
  </section>
  <section role="tabpanel" aria-hidden="true" class="content" id="panel2-2">
    <h2>Second panel content goes here...</h2>
  </section>
  <section role="tabpanel" aria-hidden="true" class="content" id="panel2-3">
    <h2>Third panel content goes here...</h2>
  </section>
  <section role="tabpanel" aria-hidden="true" class="content" id="panel2-4">
    <h2>Fourth panel content goes here...</h2>
  </section>
</div>

Accessibility

Tipografia

<h1>h1. This is a very large header.</h1>
<h2>h2. This is a large header.</h2>
<h3>h3. This is a medium header.</h3>
<h4>h4. This is a moderate header.</h4>
<h5>h5. This is a small header.</h5>
<h6>h6. This is a tiny header.</h6>

Headers

<h1 class="subheader">h1.subheader</h1>
<h2 class="subheader">h2.subheader</h2>
<h3 class="subheader">h3.subheader</h3>
<h4 class="subheader">h4.subheader</h4>
<h5 class="subheader">h5.subheader</h5>
<h6 class="subheader">h6.subheader</h6>

Subheaders

<h1>h1. <small>Small segment header.</small></h1>
<h2>h2. <small>Small segment header.</small></h2>
<h3>h3. <small>Small segment header.</small></h3>
<h4>h4. <small>Small segment header.</small></h4>
<h5>h5. <small>Small segment header.</small></h5>
<h6>h6. <small>Small segment header.</small></h6>

Small Header Segments

Tipografia

<p>This is a paragraph. Paragraphs are preset with a font size, line height and spacing to match the overall vertical rhythm. To show what a paragraph looks like this needs a little more content so, did you know that there are storms occurring on Jupiter that are larger than the Earth? Pretty cool. Wrap strong around type to <strong>make it bold!</strong>. You can also use em to <em>italicize your words</em>.</p>

Paragraphs

<p>Links are very standard, and the <a href="http://www.youtube.com/watch?v=zT2aVoUkSDg">color is preset</a> to the Foundation primary color.</p>

Links

<ul class="disc">
  <li>List item with a much longer description or more content.</li>
  <li>List item</li>
  <li>List item
    <ul>
      <li>Nested list item</li>
      <li>Nested list item</li>
      <li>Nested list item</li>
    </ul>
  </li>
  <li>List item</li>
  <li>List item</li>
  <li>List item</li>
 </ul>

Lists

Tipografia

<blockquote>Those people who think they know everything are a great annoyance to those of us who do.<cite>Isaac Asimov</cite></blockquote>

Blockquotes

<ul class="vcard">
  <li class="fn">Gaius Baltar</li>
  <li class="street-address">123 Colonial Ave.</li>
  <li class="locality">Caprica City</li>
  <li><span class="state">Caprica</span>, <span class="zip">12345</span></li>
  <li class="email"><a href="#">g.baltar@example.com</a></li>
</ul>

V-Cards

PRATICAR!

Apesar de haver várias particularidades ainda do Foundation Zurb, o IDEAL é praticar para melhorar seu conhecimento!

Tiago Serra

contato@tiagoserra.com.br

Foundation ZURB

By Tiago Serra

Foundation ZURB

Tiago Serra

tiagoserra.com.br

Foundation ZURB

Tiago Serra

Intro

Sobre

Elementos

start = function() {

Temos três pacotes diferentes para você começar:

while(start==POWER){

Basic

Media Queries

Grid

Block Grid

Top Bar

Orbit

Orbit

Content Sliders

Orbit

Deep Linking

Buttons

Basic

Button Sizing

Button Colors

Forms

Building

Forms

Inline Labels

Forms

Defining a Fieldset

Error States

Forms

Pre/Postfix Labels & Actions

Tabs

Basic

Tabs

Accessibility

Tipografia

Headers

Subheaders

Small Header Segments

Tipografia

Paragraphs

Links

Lists

Tipografia

Blockquotes

V-Cards

PRATICAR!

Apesar de haver várias particularidades ainda do Foundation Zurb, o IDEAL é praticar para melhorar seu conhecimento!

Tiago Serra

contato@tiagoserra.com.br

Foundation ZURB

More from Tiago Serra
