Compiling .pioenvs/tiva/FrameworkEnergia/wiring_pulse.c.o
Compiling .pioenvs/tiva/FrameworkEnergia/wiring_shift.c.o
Archiving .pioenvs/tiva/libFrameworkEnergia.a
Indexing .pioenvs/tiva/libFrameworkEnergia.a
Linking .pioenvs/tiva/firmware.elf
Checking size .pioenvs/tiva/firmware.elf
Building .pioenvs/tiva/firmware.bin
Memory Usage -> http://bit.ly/pio-memory-usage
DATA:    [=         ]  13.1% (used 4288 bytes from 32768 bytes)
PROGRAM: [====      ]  42.1% (used 110448 bytes from 262144 bytes)
============================ [SUCCESS] Took 15.59 seconds ============================

====================================== [SUMMARY] ======================================
Environment mega        [SKIP]
Environment nano        [SKIP]
Environment tiva        [SUCCESS]
============================ [SUCCESS] Took 15.59 seconds ============================

[platformio]
env_default = tiva

[common_env_data]
lib_deps =
    AsharaStudios/GuruxDLMS.c
build_flags =
    -g3
    -ggdb
    -DDEBUG_MSG
    ; -DSERIAL_MODE
    ; -DGX_DLMS_MICROCONTROLLER

[env:mega]
platform = atmelavr
board = megaatmega1280
framework = arduino
lib_deps =
    ${common_env_data.lib_deps}
build_flags =
    ${common_env_data.build_flags}
    -DMEGAboard

[env:nano]
board = nanoatmega328
platform = atmelavr
framework = arduino
lib_deps =
    ${common_env_data.lib_deps}
build_flags =
    ${common_env_data.build_flags}
    -DNANOboard

[env:tiva]
platform = titiva
board = lptm4c1230c3pm
framework = energia
lib_deps =
    ${common_env_data.lib_deps}
    AsharaStudios/DateTime_Library
build_flags =
    ${common_env_data.build_flags}
    -DTIVAboard
extra_scripts =
    post:.prepareDebug.py

#include <Arduino.h>
#include <avr/interrupt.h>
#include "lookup_tables.h"


#ifdef ATTINYx5
#define SD    PIN_B4 //TODO: support for shutdown
#define H1    PIN_B0
#define L1    PIN_B1
#define H2    PIN_B3
#define L2    PIN_B4

#elif ATTINYX61
#define POT1  A5 //debug pins
#define SEL1  A6 //debug pins
#define SD    PIN_B4 //TODO: support for shutdown
#define H1    PIN_B0
#define L1    PIN_B1
#define H2    PIN_B2
#define L2    PIN_B3
#endif


//#define DEADRISING 5
//#define DEADFALLING 5

volatile uint8_t pwmValue1 = 0;
volatile uint8_t pwmValue2 = 0;
volatile uint8_t index = 0;

#define MAX_COUNTER 1
uint16_t counter = 0;

/* UPDATE PWM
// f_wave := f_PCK / (prescaler * (OCR1C+1) * ARRAY_LEN * (MAX_COUNTER+1)) ~= 60.24Hz
// f_PCK := 32Mhz
// prescaler := 8
// OCR1C := 199
// ARRAY_LEN := 166
// MAX_COUNTER := 1
*/
ISR(TIMER1_OVF_vect) {
  if (counter++ >= MAX_COUNTER){
    counter = 0;
    index++;
    index %= ARRAY_LEN;

    OCR1A = pwmValue1;
    OCR1B = pwmValue2;
  }
}

void setup() {
  #ifdef ATTINYX61
  pinMode(POT1, INPUT);
  pinMode(SEL1, INPUT);
  #endif
  pinMode(SD, OUTPUT);
  pinMode(H1, OUTPUT); // OC1A
  pinMode(L1, OUTPUT); // not OC1A
  pinMode(H2, OUTPUT); // OC1B
  pinMode(L2, OUTPUT);

  digitalWrite(SD,LOW); // IR2112 active
  SREG = _BV(7); // Global interruption enabled

  /*timer1 conf*/
  PLLCSR = _BV(LSM) | _BV(PLLE); //activates Low Speed Mode in PCK and enables it.
  delay(1);
  while(!(PLLCSR & _BV(PLOCK))); //wait until PLL is in steady state.
  PLLCSR |= _BV(PCKE); //enable PCK source for timer1 (asynchronous mode).

  //PWM freq = 20khz, page 88 in datasheet (PCK = 32Mhz)
  TIMSK = _BV(TOIE1); // interrupt enable when TCNT1 overflows (TCNT1 == OCR1A).
  OCR1C = 199; // top value for TCNT1 for PWM freq = 20khz, R = 7.6
  OCR1A = 100; // initial value of comparation
  #ifdef ATTINYx5
  TCCR1 = _BV(PWM1A) | _BV(COM1A0) | _BV(CS12); //activates complementary mode in A and 1:8 prescaler
  GTCCR = _BV(PWM1B) | _BV(COM1B0);
  //DT1A = (0xF0 & (DEADRISING << 4)) | (0x0F & DEADFALLING);
  #elif ATTINYX61
  TCCR1A = _BV(PWM1A) | _BV(PWM1B) | _BV(COM1A0) | _BV(COM1B0); //activates PMW complementary mode in A and B
  TCCR1B = _BV(CS11) | _BV(CS10); //1:4 prescaler
  //DT1 = (0xF0 & (DEADRISING << 4)) | (0x0F & DEADFALLING);
  #endif
  //DTPS1 = _BV(DTPS10); //prescaler 1:1
}

uint16_t tmp = 0;

void loop() {

  Serial.println(tmp);
  #ifdef ATTINYX61
  tmp = analogRead(SEL1);
  if (tmp <= 512) {
    pwmValue1 = analogRead(POT1) >> 2;
    pwmValue2 = ~pwmValue1;
  } else {
  #endif
    pwmValue1 = pgm_read_byte(&(D[index]));
    //WARNING: if 0 > 255 use other index or index type
    pwmValue2 = pgm_read_byte(&(D[(index+PHASE180)%ARRAY_LEN]));
  #ifdef ATTINYX61
  }
  #endif
}

#ifndef LOOKUP_TABLES_H
#define LOOKUP_TABLES_H

#include <Arduino.h>

/*
Document for value calculus:
https://docs.google.com/spreadsheets/d/1UtXzdGsx8a0OHYvLXqKkCJ48qxz2pVwkHPIFW54Rmx0/edit?usp=sharing
*/
#define ARRAY_LEN 166

#if ARRAY_LEN%2 != 0
  error("ARRAY_LEN must be divisible in 2")
#endif
#define PHASE180 ARRAY_LEN/2

#if ARRAY_LEN+PHASE180 > 255
  error("define other index for second PWM and remove this error")
#endif

// D(t) = (1 + sin(2*pi*60*t)) / 2
static const uint8_t D[ARRAY_LEN]  PROGMEM = {
  128,
  132,
  137,
  142,
  147,
  151,
  156,
  161,
  166,
  170,
  175,
  179,
  183,
  188,
  192,
  196,
  200,
  204,
  208,
  211,
  215,
  219,
  222,
  225,
  228,
  231,
  234,
  236,
  239,
  241,
  243,
  245,
  247,
  248,
  250,
  251,
  252,
  253,
  254,
  254,
  255,
  255,
  255,
  255,
  254,
  254,
  253,
  252,
  251,
  250,
  248,
  247,
  245,
  243,
  241,
  239,
  236,
  234,
  231,
  228,
  225,
  222,
  219,
  215,
  211,
  208,
  204,
  200,
  196,
  192,
  188,
  183,
  179,
  175,
  170,
  166,
  161,
  156,
  151,
  147,
  142,
  137,
  132,
  128,
  123,
  118,
  113,
  108,
  104,
  99,
  94,
  89,
  85,
  80,
  76,
  72,
  67,
  63,
  59,
  55,
  51,
  47,
  44,
  40,
  36,
  33,
  30,
  27,
  24,
  21,
  19,
  16,
  14,
  12,
  10,
  8,
  7,
  5,
  4,
  3,
  2,
  1,
  1,
  0,
  0,
  0,
  0,
  1,
  1,
  2,
  3,
  4,
  5,
  7,
  8,
  10,
  12,
  14,
  16,
  19,
  21,
  24,
  27,
  30,
  33,
  36,
  40,
  44,
  47,
  51,
  55,
  59,
  63,
  67,
  72,
  76,
  80,
  85,
  89,
  94,
  99,
  104,
  108,
  113,
  118,
  123
};

#endif
