PHC7065 CRITICAL SKILLS IN DATA MANIPULATION FOR POPULATION SCIENCE

Big Data

Hui Hu Ph.D.

Department of Epidemiology

College of Public Health and Health Professions & College of Medicine

Introduction to Big Data



HDFS and MapReduce


Spark

Introduction to Big Data

Explosion of Data

Explosion of Data (continued)

  • The increase in amount of data we are generating opens up huge possibilities

  • But it comes with problems too:
    -  where do we have to store all this data?
    -  and process it too?​

Which one(s) of them do you consider as big data?

  • Order details for a store
  • All orders across hundreds of stores
  • A person's stock portfolio
  • All stock transactions for the NYSE

What is big data?

  • How will you define big data?

  • It's a very subjective term, and there is not one definition for big data

  • Most people would certainly consider a dataset of several TB to be big data

  • A reasonable definition:
    Data that are too big to be processed on a single machine

Big data  is a loosely defined term used to describe data sets so large and complex that they become awkward to work with using standard statistical software

Challenges with Big Data

  • Not just about the size

  • Data is created fast

  • Data from different sources in various formats

Volume

  • Store the data
    -  which one(s) of the following data do you think worth storing?
    transactions, logs, business, user, sensor, medical, social







  • Read and process the data efficiently

Variety

  • For a long time people stored data in relational databases

  • The problem is that to store data in such databases, the data need to be able to fit in pre-defined tables

  • Many data we are dealing nowadays are unstructured or semi-structured data

  • We want to store the data in its original format so we are not throwing any information away
    -  e.g. transcribe a call center conversation into text
    -  we have what people said to customer services representatives
    -  but if we had the actual recording, later we may able to develop algorithms to interpret the tone of voice

Velocity

  • We need to be able to store the data even it's coming in at a rate of TB per day
    -  if we can't store as it arrives, we have to discard some of the data

  • Many recommendation systems were developed based on a variety of data stored which arrives with a high velocity
    -  Amazon will recommend products to you
    -  Netflix will recommend movies you might be interested in

Hadoop

  • In around 2003, google published papers about their internally used distributed file systems and their processing framework, MapReduce.

  • A group tried to reimplement these in open source, and they developed hadoop, which later becomes the core part of today's big data processing platforms

  • Hadoop:
    -  store data: HDFS (Hadoop distributed file system)
    -  process data: MapReduce

  • Data are split and stored in a collection of machines (a cluster), and then the data are processed in where they are stored rather than retrieving the data to a central server

Hadoop Ecosystem

  • Some softwares are intended to make it easier to load data into the Hadoop cluster
  • Many are designed to make Hadoop easier to use

HDFS and MapReduce

HDFS

  • Data are stored in HDFS: Hadoop distributed file system

dat.txt (150 MB)

64 MB

64 MB

22 MB

blk_1

blk_2

blk_3

blk_1

blk_2

blk_3

Datanodes

Namenode

Is there a problem?

blk_1

blk_2

blk_3

  • Network failure

  • Disk failure on datanodes

  • Disk failure on the namenode

Data Redundancy

blk_1

blk_2

blk_3

Hadoop replicates each block three times

blk_1

blk_1

blk_2

blk_2

blk_3

blk_3

What if there is a problem with the namenode?

blk_1

blk_2

blk_3

  • If a network failure: data inaccessible

  • If a disk failure: data lost forever (no way to know which block belongs to which file)

blk_1

blk_1

blk_2

blk_2

blk_3

blk_3

NFS

MapReduce

Designed to process data in parallel

Example

  • National hospital inpatient cost
    - want to calculate the cost per city for the year
2017-01-01 Miami 2300.24
2017-01-01 Gainesville 3600.23
2017-01-02 Jacksonville 1900.34
2017-01-02 Miami 8900.45
  • Key-value pairs (Hashtable)

  • What are the problems if you have 1 TB data?

  • You may run out of memory, and computers will need a long time to read and process the data.

Example (continued)

Mappers

Miami

2300.24

NYC

9123.45

Boston

8123.45

LA

3123.45

Reducers

NYC, LA

Miami, Boston

NYC

7123.45

Boston

6123.45

NYC

7123.45

Boston

8123.45

Boston

6123.45

LA

3123.45

Miami

2300.24

NYC

9123.45

Example (continued)

Mappers

Intermediate records (key, value)

Shuffle and sort

Reducers

(key, value)

Results

blk_1

blk_2

blk_3

blk_1

blk_1

blk_2

blk_2

blk_3

blk_3

Job Tracker

Task Trackers

Code a MapReduce Problem

date time store item cost payment
2012-01-01 12:01 Orlando Music 13.98 Visa

How to find total sales per store? (what is the key-value pair)

import sys

def mapper():
    for line in sys.stdin:
        data = line.strip().split("\t")
        if len(data) == 6:
            date, time, store, item, cost, payment = data
            print "{0}\t{1}".format(store, cost)

Store, Cost

Code a MapReduce Problem

def reducer():
    salesTotal = 0
    oldKey = None

    for line in sys.stdin:
        data = line.strip().split("\t")

        if len(data) != 2:
            continue

        thisKey, thisSale = data

        if oldKey and oldKey != thisKey:
            print "{0}\t{1}".format(oldkey, salesTotal)

            salesTotal = 0
        oldKey = thisKey
        salesTotal += float(thisSale)

    if oldKey != None:
        print "{0}\t{1}".format(oldkey, salesTotal)
NYC 12.00
NYC 13.11
LA 11.23
LA 12.34
LA 11.98

Spark

Why Spark?

  • Shortcomings of Hadoop MapReduce:
    -  only for map and reduce based computations
    -  relies on reading data from HDFS (many machine learning uses iterative algorithms that require several reads of the data, which result in a performance bottleneck due to I/O)
    -  native support for Java only
    -  no interactive shell support
    -  no support for streaming

  • Advantages of Spark:
    -  expressive programming model
    -  in-memory processing
    -  support for diverse workloads
    -  interactive shell

The Spark Stack

What is in memory processing?

Resilient Distributed Datasets

Resilient Distributed Datasets

  • Resilient:
    -  recover from errors: e.g. node failure
    -  track history of each partition, re-run

  • Distributed:
    -  distributed across the cluster of machines
    -  divided in partitions, atomic chunks of data

  • Dataset:
    -  data storage created from HDFS, S3, HBase, JSON, text, local hierarchy of folders
    -  or created transforming another RDD (RDD is immutable)

Spark Architecture

Spark Architecture (continued)

  • Driver program:
    -  where the application starts
    -  it distributes the RDDs on cluster and make sure the transformation and actions of these RDDs are performed

  • Worker node:
    -  runs Java virtual machine (JVM) to call the executor
    -  executors can execute task related to mapping or reducing or other Spark specific pipelines
