Big-O Notation
Understanding relative representation of the complexity of an algorithm.
No, not that Big O
What is Big O?
- Big O notation is used to describe the performance or complexity of an algorithm.
- Big O specifically describes the worst-case scenario.
- Used to describe the execution time required or the space used by an algorithm.
Big O complexity can be visualized with this graph
Algorithm's Scale as follows...
*listed in order of complexity
O(1)
- O(1) describes an algorithm that will always execute in the same time regardless of the size of the input data set.
constant complexity
// For example, accessing any single element in an array takes
// constant time as only one operation has to be performed to locate it.
var arr = [ 'accessing', 'an', 'array', 'element', 'takes', 'constant', 'time']
var index = arr[4] // return 'takes'
O(N)
- O(N) describes an algorithm whose performance will grow linearly and in direct proportion to the size of the input data set.
Linear complexity
// For example, a procedure that
// adds up all elements
// of a list requires time
// proportional to the length of the list.
var start= new Date().getTime();
var arr = []
var j = 0;
while ( j < 100000 ) {
arr.push(j);
j++;
}
var sum = 0;
for ( var i = 0; i < arr.length; i++ ) {
sum += arr100[i];
}
var end = new Date().getTime();
var time = end - start;
console.log('Execution time: ' + time);
O( )
- O( ) represents an algorithm whose performance is directly proportional to the square of the size of the input data set.
quadratic time
// This is common with algorithms
// that involve nested iterations
//over the data set. Deeper nested
//iterations will result in O(N3), O(N4) etc.
var grid = document.createElement('table');
grid.className = 'grid';
for (var r = 0; r < this._rows; ++r) {
var tr = grid.appendChild(document.createElement('tr'));
for (var c = 0; c < this._cols; ++c) {
var cell = tr.appendChild(document.createElement('td'));
cell.id = "grid" + i++
}
}
N^2
N2
N^2
N2
O( )
- O( ) The growth curve of an O( ) function is exponential - starting off very shallow, then rising meteorically.
exponential time
// An example of this is trying to break a password by testing
// every possible combination (assuming numerical
// password of length N). This results in O(10^N) complexity.
2^N
2N
2^N
2N
2^N
2N
O( log N )
- Algorithms taking logarithmic time are commonly found in operations on binary trees or when using binary search.
- An O(log n) algorithm is considered highly efficient, as the operations per instance required to complete decrease with each instance.
logarithmic time
O( log N )
Continued...
// An example of logarithmic algorithm is an algorithm that cuts
// a string in half, then cuts the right half in half, and so on. It will take
// O(log n) time (n being the length of the string) since we chop the string
// in half before each print
// Function to recursively print the right half of a string
var right = function(str){
var length = str.length;
// Helper function
var help = function(index){
// Recursive Case: Print right half
if(index < length){
// Prints characters from index until the end of the array
console.log(str.substring(index, length));
// Recursive Call: call help on right half
help(Math.ceil((length + index)/2));
}
// Base Case: Do Nothing
}
help(0);
}
Resources
