WORKING WITH STATE MACHINES IN ANGULAR

@stefanos_lig

  • WHAT IS XSTATE, STATE MACHINES & STATECHARTS
  • HOW TO  CREATE/USE THEM WITH ANGULAR

  • WHEN TO USE THEM

  • WHY THIS PRESENTATION
  • TAKEAWAY


@stefanos_lig

  • WHAT IS A STATE MACHINE, A STATECHART, XSTATE
  • HOW TO  CREATE/USE THEM WITH ANGULAR

  • WHEN TO USE THEM


Agenda

  • WHY THIS PRESENTATION
  • TAKEAWAY


The Journey to state machines

@stefanos_lig

It might be the software entropy

@stefanos_lig

The Journey to state machines

Out of the tar pit

The Journey to state machines

@stefanos_lig

 Ben Moseley - Peter Marks

What is the complexity of a system?

The Journey to state machines

@stefanos_lig

Lack of understanding

What we try to do most of the time is to read the source code and understand it

What is the complexity of a system?

The Journey to state machines

@stefanos_lig

State

Control

Lack of understanding

What we try to do most of the time is to read the source code and understand it

The Journey to state machines

@stefanos_lig

State

Control

What is the complexity of a system?

The Journey to state machines

@stefanos_lig

Lack of understanding

What we try to do most of the time is to read the source code and understand it

In a team, we want all the participants to be able to speak the same language

XState

@stefanos_lig

The Journey to state machines

THE JOURNEY TO STATE MACHINES

@stefanos_lig

Lack of understanding

In a team, we want all the participants to be able to speak the same language

Stefanos Lignos

Front-end developer

@stefanos_lig

github.com/stefanoslig

http://stefanos-lignos.com/

Not always dressed like this

@stefanos_lig

Angular Athens

  • WHAT IS XSTATE, STATE MACHINES & STATECHARTS
  • HOW TO  CREATE/USE THEM WITH ANGULAR

  • WHEN TO USE THEM

  • WHY THIS PRESENTATION
  • TAKEAWAY


@stefanos_lig

  • HOW TO  CREATE/USE THEM WITH ANGULAR

  • WHEN TO USE THEM

  • WHY THIS PRESENTATION

Agenda

Disclaimer: This is not a detailed explanation of XState, I couldn't do this in thirty minutes. It's a presentation about something that you might find useful/inspiring to apply in your project!
  • TAKEAWAY

  • WHAT IS A STATE MACHINE, A STATECHART, XSTATE

A library for creating finite state machines and statecharts



Xstate



@stefanos_lig

What is

@DavidKPiano - Creator of XState

@DavidKPiano - Creator of XState

@stefanos_lig

What is

 A FINITE STate machine

The life of a programmer as a finite state machine

  • David Harel - 1982
  • A common language for all the engineers in Israel Aircraft Industries
  • Finite State Machines extended with the notions of orthogonality and hierarchy

@stefanos_lig

What is

 A statechart

@stefanos_lig

What is

 A statechart

What is

 A statechart

@stefanos_lig

Hierarchy
Orthogonality

The life of a programmer as a statechart

Guarded Transitions
History nodes
Delayed events & transitions
  • WHAT IS XSTATE, STATE MACHINES & STATECHARTS
  • HOW TO  CREATE/USE THEM WITH ANGULAR

  • WHEN TO USE THEM

  • WHY THIS PRESENTATION
  • TAKEAWAY


A second developer

who works in parallel

@stefanos_lig

  • HOW TO  CREATE/USE THEM WITH ANGULAR

  • WHEN TO USE THEM

  • WHY THIS PRESENTATION

Agenda

  • TAKEAWAY

  • WHAT IS A STATE MACHINE, A STATECHART, XSTATE

@stefanos_lig

Demo

CREATE A STATE MACHINE WITH XSTATE

A state machine for an authentication process

stefanoslig/xstate-angular

gothinkster/realworld

xstate-angular

@stefanos_lig

private authMachine = Machine<
    AuthMachineContext,
    AuthMachineSchema,
    AuthMachineEvent
  >(
    {
      id: 'auth',
      initial: 'unauthorized',
      states: {
        unauthorized: {},
        signin: {},
        signup: {},
        authorized: {},
        updating: {},
      },
    },
  1. Define the states

Visualization

CREATE A STATE MACHINE WITH XSTATE

@stefanos_lig

private authMachine = Machine<
    AuthMachineContext,
    AuthMachineSchema,
    AuthMachineEvent
  >(
    {
      id: 'auth',
      initial: 'unauthorized',
      states: {
        unauthorized: {
          on: {
            SIGNIN: 'signin',
            SIGNUP: 'signup',
          },
        },
        signin: {},
        signup: {},
        authorized: {
          on: {
            UPDATE_USER: 'updating',
            LOGOUT: { target: 'unauthorized' },
          },
        },
        updating: {},
      },
    },
  1. Define the states
  2. Create the events for the transitions

Visualization

CREATE A STATE MACHINE WITH XSTATE

@stefanos_lig

private ɵauthMachine = Machine<
    AuthMachineContext,
    AuthMachineSchema,
    AuthMachineEvent
  >(
    {
      id: 'auth',
      initial: 'unauthorized',
      states: {
        unauthorized: {
          on: {
            SIGNIN: 'signin',
            SIGNUP: 'signup',
          },
        },
        signin: {
          invoke: { src: 'signIn' },
          on: {
            SIGNIN_SUCCESS: { target: 'authorized' },
            SIGNIN_FAILURE: { target: 'unauthorized' },
          },
        },
        signup: {
          invoke: { src: 'signUp' },
          on: {
            SIGNUP_SUCCESS: { target: 'authorized' },
            SIGNUP_FAILURE: { target: 'unauthorized' },
          },
        },
        authorized: {
          on: {
            UPDATE_USER: 'updating',
            LOGOUT: { target: 'unauthorized' },
          },
        },
        updating: {},
      },
      {
      services: {
        signIn: (context, event: SignIn) =>
          this.authService
            .login({ email: event.username, password: event.password })
            .pipe(
              map((user) => SignInSuccess(user)),
              catchError((result) => of(SignInFail(result.error.errors)))
            ),
        signUp: (context, event: SignUp) =>
          this.authService
            .register({
              username: event.username,
              email: event.email,
              password: event.password,
            })
            .pipe(
              map((user) => SignUpSuccess(user)),
              catchError((result) => of(SignUpFail(result.error.errors)))
            ),
      },
    },
  1. Define the states
  2. Define the events for the unauthorized state
  3. Define the effects

Visualization

CREATE A STATE MACHINE WITH XSTATE

@stefanos_lig

CREATE A STATE MACHINE WITH XSTATE

Extended state/context: Data that can be potentially infinite

@stefanos_lig

private ɵauthMachine = Machine<
    AuthMachineContext,
    AuthMachineSchema,
    AuthMachineEvent
  >(
    {
      id: 'auth',
      initial: 'unauthorized',
      context: {
        user: {
          email: '',
          token: '',
          username: '',
          bio: '',
          image: '',
        },
        errors: [],
      },
      states: {
        unauthorized: {
          on: {
            SIGNIN: 'signin',
            SIGNUP: 'signup',
          },
        },
        signin: {
          invoke: { src: 'signIn' },
          on: {
            SIGNIN_SUCCESS: { target: 'authorized' },
            SIGNIN_FAILURE: { target: 'unauthorized' },
          },
        },
        signup: {
          invoke: { src: 'signUp' },
          on: {
            SIGNUP_SUCCESS: { target: 'authorized' },
            SIGNUP_FAILURE: { target: 'unauthorized' },
          },
        },
        authorized: {
          on: {
            UPDATE_USER: 'updating',
            LOGOUT: { target: 'unauthorized' },
          },
        },
        updating: {},
      },
    },
  1. Define the states
  2. Define the events for the unauthorized state
  3. Define the effects
  4. Define the context

CREATE A STATE MACHINE WITH XSTATE

@stefanos_lig

private ɵauthMachine = Machine<
    AuthMachineContext,
    AuthMachineSchema,
    AuthMachineEvent
  >(
    {
      id: 'auth',
      initial: 'unauthorized',
      context: {
        user: {
          email: '',
          token: '',
          username: '',
          bio: '',
          image: '',
        },
        errors: [],
      },
      states: {
        unauthorized: {
          on: {
            SIGNIN: 'signin',
            SIGNUP: 'signup',
          },
        },
        signin: {
          invoke: { src: 'signIn' },
          on: {
            SIGNIN_SUCCESS: { target: 'authorized', actions: 'assignUser' },
            SIGNIN_FAILURE: { target: 'unauthorized', actions: 'assignErrors' },
          },
        },
        signup: {
          invoke: { src: 'signUp' },
          on: {
            SIGNUP_SUCCESS: { target: 'authorized', actions: 'assignUser' },
            SIGNUP_FAILURE: { target: 'unauthorized', actions: 'assignErrors' },
          },
        },
        authorized: {
          on: {
            UPDATE_USER: 'updating',
            LOGOUT: { target: 'unauthorized', actions: 'logout' },
          },
        },
        updating: {},
      },
      {
      actions: {
        resetUser: assign<AuthMachineContext, AuthMachineEvent>(() => ({
          user: initialContext.user,
        })),
        resetErrors: assign<AuthMachineContext, AuthMachineEvent>(() => ({
          errors: initialContext.errors,
        })),
        goToHomePage: (ctx: AuthMachineContext, event: AuthMachineEvent) =>
          this.router.navigateByUrl(''),
        assignUser: assign<AuthMachineContext, AuthMachineEvent>(
          (ctx, event) => ({
            user: event.response.user,
          })
        ),
        assignErrors: assign<AuthMachineContext, AuthMachineEvent>(
          (_, event) => {
            const eventErrors = (event as SignInFail).errors;
            return {
              errors: Object.keys(eventErrors || {}).map(
                (key) => `${key} ${eventErrors[key]}`
              ),
            };
          }
        ),
        logout: () => {
          localStorage.setItem('authState', null);
          this.router.navigateByUrl('login');
        },
      },
      services: {
        signIn: (context, event: SignIn) =>
          this.authService
            .login({ email: event.username, password: event.password })
            .pipe(
              map((user) => new SignInSuccess(user)),
              catchError((result) => of(new SignInFail(result.error.errors)))
            ),
        signUp: (context, event: SignUp) =>
          this.authService
            .register({
              username: event.username,
              email: event.email,
              password: event.password,
            })
            .pipe(
              map((user) => new SignUpSuccess(user)),
              catchError((result) => of(new SignUpFail(result.error.errors)))
            ),
      },
    },
  1. Define the states
  2. Define the events for the unauthorized state
  3. Define the invoked effects
  4. Define the context
  5. Define the fire & forget effects

CREATE A STATE MACHINE WITH XSTATE

@stefanos_lig

private ɵauthMachine = Machine<
    AuthMachineContext,
    AuthMachineSchema,
    AuthMachineEvent
  >(
    {
      id: 'auth',
      initial: 'unauthorized',
      context: {
        user: {
          email: '',
          token: '',
          username: '',
          bio: '',
          image: '',
        },
        errors: [],
      },
      states: {
        unauthorized: {
          on: {
            SIGNIN: 'signin',
            SIGNUP: 'signup',
          },
        },
        signin: {
          entry: 'resetErrors',
          invoke: { src: 'signIn' },
          on: {
            SIGNIN_SUCCESS: { target: 'authorized', actions: 'assignUser' },
            SIGNIN_FAILURE: { target: 'unauthorized', actions: 'assignErrors' },
          },
        },
        signup: {
          entry: 'resetErrors',
          invoke: { src: 'signUp' },
          on: {
            SIGNUP_SUCCESS: { target: 'authorized', actions: 'assignUser' },
            SIGNUP_FAILURE: { target: 'unauthorized', actions: 'assignErrors' },
          },
        },
        authorized: {
          on: {
            UPDATE_USER: 'updating',
            LOGOUT: { target: 'unauthorized', actions: 'logout' },
          },
        },
        updating: {},
      },
    },
  1. Define the states
  2. Define the events for the unauthorized state
  3. Define the effects
  4. Define the context
  5. Define the fire & forget effects

Visualization

CREATE A STATE MACHINE WITH XSTATE

xstate & angular

  • It's quite easy to start using XState in Angular, however...
  • There are not enough examples/ a common pattern, helper functions to create a state machine
  • Maybe some of the reasons that it hasn't been adopted yet from the Angular community

@stefanos_lig

xstate & angular

import { Machine, interpret } from 'xstate';
import { from } from 'rxjs';

const machine = Machine(/* ... */);
const service = interpret(machine).start();

const state$ = from(service);

state$.subscribe(state => {
  // ...
});

A stateless, enriched version of the FSM configuration

A stateful, subscribable instance of the FSM

An Observable from the Observable-like service

Observe the changes in the instance of the state machine

@stefanos_lig

xstate & angular

@stefanos_lig

  • We might have more requirements:
    • Start the state machine with a rehydrated state
    • Pass a configuration object to our state machine
    • Stop the state machine automatically after the component is destroyed
    • Share the values of the Observable among several subscribers
import { Injectable } from '@angular/core';
import { OnDestroy } from '@angular/core';
import {
  EventObject,
  MachineOptions,
  interpret,
  State,
  InterpreterOptions,
  Interpreter,
  StateMachine,
  Typestate,
} from 'xstate';
import { filter, shareReplay, takeUntil } from 'rxjs/operators';
import { from, ReplaySubject } from 'rxjs';
import { InterpretedService, UseMachineOptions } from './types';

@Injectable()
export class XstateAngular<
  TContext,
  TStateSchema,
  TEvent extends EventObject = EventObject,
  TTypestate extends Typestate<TContext> = { value: any; context: TContext }
> implements OnDestroy {
  private service: Interpreter<TContext, TStateSchema, TEvent, TTypestate>;
  private readonly unsubscribeSubject$ = new ReplaySubject<void>(1);
  readonly unsubscribe$ = this.unsubscribeSubject$.asObservable();

  useMachine(
    machine: StateMachine<TContext, TStateSchema, TEvent, TTypestate>,
    options: Partial<InterpreterOptions> &
      Partial<UseMachineOptions<TContext, TEvent>> &
      Partial<MachineOptions<TContext, TEvent>> = {}
  ): InterpretedService<TContext, TStateSchema, TEvent, TTypestate> {
    const {
      context,
      guards,
      actions,
      activities,
      services,
      delays,
      state: rehydratedState,
      ...interpreterOptions
    } = options;

    const machineConfig = {
      context,
      guards,
      actions,
      activities,
      services,
      delays,
    };

    const createdMachine = machine.withConfig(machineConfig, {
      ...machine.context,
      ...context,
    } as TContext);

    this.service = interpret(createdMachine, interpreterOptions).start(
      rehydratedState ? (State.create(rehydratedState) as any) : undefined
    );

    const state$ = from(this.service).pipe(
      filter(
        ({ changed, event }) =>
          changed ||
          (changed === undefined && !!rehydratedState) ||
          (changed === undefined && !!(event?.type === 'xstate.init'))
      ),
      shareReplay(1),
      takeUntil(this.unsubscribe$)
    );

    return { state$, send: this.service.send, service: this.service };
  }

  ngOnDestroy() {
    this.service.stop();
    this.unsubscribeSubject$.next();
  }
}

xstate-angular
rehydratedState = JSON.parse(localStorage.getItem('authState'));

authMachine = useMachine(this.authMachineConfig, {
  devTools: !environment.production,
  state: this.rehydratedState,
});

//authMachine: {state$, send, service}

@stefanos_lig

xstate & angular

xstate-angular
import { Machine } from 'xstate';
import { InterpretedService, XstateAngular } from 'xstate-angular';
// other imports

const toggleMachine = Machine({
  id: 'toggle',
  initial: 'stateOff',
  states: {
    stateOn: {
      on: { TOGGLE: 'stateOff' },
    },
    stateOff: {
      on: { TOGGLE: 'stateOn' },
    },
  },
});

@Component({
  selector: 'xstate-angular-toggle',
  template: `
    <h3>stateOn: {{ stateOn$ | async }}</h3>
    <h3>stateOff: {{ stateOff$ | async }}</h3>
    <button (click)="toggle()">toggle</button>
  `,
  providers: [XstateAngular],
})
export class ToggleComponent implements OnInit {
  stateOn$: Observable<boolean>;
  stateOff$: Observable<boolean>;
  service: InterpretedService<
    ToggleMachineContext,
    ToggleMachineSchema,
    ToggleMachineEvent
  >;

  constructor(
    private readonly xstateAngular: XstateAngular<
      ToggleMachineContext,
      ToggleMachineSchema,
      ToggleMachineEvent
    >
  ) {
    this.service = this.xstateAngular.useMachine(toggleMachine);
  }

  ngOnInit() {
    this.stateOn$ = this.service.state$.pipe(map((s) => s.matches('stateOn')));
    this.stateOff$ = this.service.state$.pipe(
      map((s) => s.matches('stateOff'))
    );
  }

  toggle() {
    this.service.send({ type: 'TOGGLE' });
  }
}

@stefanos_lig

xstate & angular

xstate-angular

@stefanos_lig

  • HOW TO  CREATE/USE THEM WITH ANGULAR

  • WHEN TO USE THEM

  • WHY THIS PRESENTATION

Agenda

  • TAKEAWAY

  • WHAT IS A STATE MACHINE, A STATECHART, XSTATE

Why I should start Using xstate?

@stefanos_lig

But...you can ask yourself

@stefanos_lig

  1. Is the business logic embedded/spread across your components/templates?
  • One source of truth for the business logic/behavior
  • Framework agnostic - the backbone of your app can be migrated immediately to another framework
  • The business logic/behavior is decoupled from the components - easier to be tested
  • Readability
  • Easier to extend the current functionality

With XState:

But...you can ask yourself

@stefanos_lig

  • Everyone can understand the visualization of the state machines
  • Less back and forth communication between BA & devs
  • Can be a useful documentation

With XState:

2. Do I have a common language in my team?

3. Do I need documentation for the business logic?

But...you can ask yourself

@stefanos_lig

  • It forces us to think about the solution to a problem upfront
  • It prevents edge cases - edge cases more visible



With XState:

4. Is my codebase unpredictable and buggy?

  • WHAT IS XSTATE, STATE MACHINES & STATECHARTS
  • HOW TO  CREATE/USE THEM WITH ANGULAR

  • WHEN TO USE THEM

  • WHY THIS PRESENTATION
  • TAKEAWAY


@stefanos_lig

I AKSED MYSELF

  • A use case in my company
  • Two routes with three panels which are open/closed/half-open based on different conditions
  • The business logic was spread in 5 different components
  • Now, we have a common source of truth, the configuration of the state machine

@stefanos_lig

I AKSED MYSELF

@stefanos_lig

  • HOW TO  CREATE/USE THEM WITH ANGULAR

  • WHEN TO USE THEM

  • WHY THIS PRESENTATION

Agenda

  • TAKEAWAY

  • WHAT IS A STATE MACHINE, A STATECHART, XSTATE

My dream

@stefanos_lig

My dream

@stefanos_lig

  • The BA is responsible to create the state machine, to express the intended behavior
  • The devs can use the same state machine configuration for the implementation
  • The QA team can start implementing the E2E tests with test scenarios provided automatically from the state machine config
  • A common source of truth for the requirements, documentation, testing, development
  • You have the tools to work like this

Thank you ♡

Useful links:

xstate-angular

By Stefanos Lignos

xstate-angular

  • 1,207

More from Stefanos Lignos
