Android
data
binding

About me

Alejandro Vidal Rodriguez
Agile Engineer @TribalScale

We are HIRING!!!!!

Agenda

• Enable data binding in our project.

• No more findViewById

• Setting the model to the view

• Binding adapters

• Callbacks on the view

• Observability

• Two-way data binding

Lets build the best app ever

App with two activities and no functionality :D

• List view with all the talks
• Detail view each talk

Repository with steps by tags

    git clone git@github.com:antoinecampbell/android-advanced-data-binding.git

    git checkout step-1

Unleash the beast

android {
    ....
    dataBinding {
        enabled = true
    }
}

Well done!

Get rid of findViewById

private void initViews() {
    talkImage = (ImageView) findViewById(R.id.talk_detail_image);
    talkTitle = (TextView) findViewById(R.id.talk_detail_title);
    talkRating = (TextView) findViewById(R.id.talk_detail_rating);
}

ActivityTalkListBinding binding =
                DataBindingUtil.setContentView(this, R.layout.activity_talk_list);

with

Data binding takes care

@Override
public void onDataAvailable(List<Talk> data) {
    binding.listOfTalks.setLayoutManager(new LinearLayoutManager(this));
    binding.listOfTalks.setAdapter(new TalkAdapter(data, this, this));
}

a class with the XML name in camel case will be created, in our case  ActivityTalksListsBinding

public ActivityTalkListBinding(android.databinding.DataBindingComponent bindingComponent, View root) {
    super(bindingComponent, root, 0);
    final Object[] bindings = mapBindings(bindingComponent, root, 3, sIncludes, sViewsWithIds);
    this.headerImage = (android.widget.ImageView) bindings[1];
    this.listOfTalks = (android.support.v7.widget.RecyclerView) bindings[2];
    this.mboundView0 = (android.widget.LinearLayout) bindings[0];
    this.mboundView0.setTag(null);
    setRootTag(root);
    // listeners
    invalidateAll();
}

prepare your view xml

<layout xmlns:android="http://schemas.android.com/apk/res/android">

    <data>

        <variable
            name="model"
            type="gof.com.databindingtalk.models.Talk"/>

    </data>

...

</layout>

 <TextView
    android:id="@+id/talk_title"
    style="@style/talk_title"
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:text="@{model.title}"
    tools:text="Talk title"/>

how to fill that <data> object

View contactView = LayoutInflater.from(parent.getContext())
                    .inflate(R.layout.talk_item, parent, false);

@Override
public void onBindViewHolder(TalkViewHolder holder, int position) {
    Talk currentTalk = talks.get(position);
    holder.getBinding().setModel(currentTalk);
    Picasso.with(context).load(currentTalk.imageUrl)
                         .into(holder.getBinding().talkItemImage);
    holder.getBinding().executePendingBindings(); // important!
}

 DataBindingUtil.inflate(LayoutInflater.from(parent.getContext()),
                                R.layout.talk_item, parent, false);

from

to

data

Awesome!

BindingAdapters

or how to create your own XML tags

<ImageView
    android:id="@+id/talk_item_image"
    android:layout_width="120dp"
    android:layout_height="120dp"
    android:background="@color/light_gray"
    app:loadImageFromUrl="@{model.imageUrl}"/>

The powerful and dangerous

@BINDINGADAPTER

public class TalkBindingAdapters {

    @BindingAdapter("loadImageFromUrl")
    public static void loadImageFromUrl(ImageView imageView, String url) {
        if (imageView != null) {
            Picasso.with(imageView.getContext()).load(url).into(imageView);
        }
    }

    @BindingAdapter({"placeHolder", "loadImageFromUrl"})
    public static void loadImageFromUrlWithPlaceHolder(ImageView imageView,
                                        Drawable placeHolder, String url) {
        if (imageView != null) {
            Picasso.with(imageView.getContext()).load(url)
                                 .placeholder(placeHolder).into(imageView);
        }
    }
}

binding adapters don't need to be static and can be injected.

Actions & lambdas on XML

<?xml version="1.0" encoding="utf-8"?>
<layout xmlns:android="http://schemas.android.com/apk/res/android"
        xmlns:app="http://schemas.android.com/apk/res-auto">

    <data>

        <variable
            name="model"
            type="gof.com.databindingtalk.models.Talk"/>

        <variable
            name="navigation"
            type="gof.com.databindingtalk.base.AppNavigation"/>

    </data>

    <android.support.v7.widget.CardView
        xmlns:tools="http://schemas.android.com/tools"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_margin="12dp"
        android:clickable="true"
        android:foreground="?android:attr/selectableItemBackground"
        android:onClick="@{() -> navigation.navigateToTalkDetail(context, model.id)}">

careful there...

Observability

public class Talk {
    public String title;
    public int rating;
    public String imageUrl;
    public String id;

    public Talk(String title, int rating, String imageUrl, String id) {
        this.title = title;
        this.rating = rating;
        this.imageUrl = imageUrl;
        this.id = id;
    }
}

public class Talk {
    public ObservableInt rating = new ObservableInt();
    ...

    public Talk(String title, int rating, String imageUrl, String id) {
        ...
        this.rating.set(rating);
    }
}

from

to

lets fake an update

public class TalkListPresenter extends BasePresenter {
    public TalkListPresenter() {
    }

    public void getTalks() {
        final List<Talk> talks = new ArrayList<>();
        talks.add(new Talk("Databinding with android", 3, "...", "1"));
        ...
        view.onDataAvailable(talks);
        delayUpdate(talks);
    }

    private void delayUpdate(final List<Talk> talks) {
        new Handler().postDelayed(new Runnable() {
            @Override
            public void run() {
                talks.get(0).rating.set(1000);
            }
        }, 2000);
    }
}

Auto updates the UI

Animate with @bindingAdapter

any binding adapter can receive old and new values

Two way databinding

if we can get model updates with:

we can update our model with:

Beware of responsibility

Never put biz logic in view

android:onClick="@{() -> service.purchaseItem(model.itemId)}">

Your code must be readable

android:visibility="@{model.age > 18 ?
        Collection.split(model.name).get(0,8) :
        String.format(model.surname + model.country)}"


android:visibility="@{model.publicName}"


Too powerful @bindingAdapters

@BindingAdapter({AUTO_SCROLL_LINEAR_LAYOUT, ELAPSED_TIME})
public static void autoScrollRecyclerView(final RecyclerView view, final boolean autoScroll, final long elapsed) {
if (!autoScroll) return;

view.addOnAttachStateChangeListener(new View.OnAttachStateChangeListener() {
    TimerTask task;

    @Override
    public void onViewAttachedToWindow(View v) {
        Timer autoScrollTimer = new Timer();
        RecyclerView recyclerView = (RecyclerView) v;
        recyclerView.smoothScrollToPosition(0);

        task = new TimerTask() {
            @Override
            public void run() {

                new UiJob(() -> {
                    if (recyclerView != null) {
                        final LinearLayoutManager manager = (LinearLayoutManager) recyclerView.getLayoutManager();
                        if (manager != null) {
                            int current = manager.findFirstVisibleItemPosition();
                            int count = manager.getItemCount();
                            recyclerView.smoothScrollToPosition(current == count - 1 ? 0 : current + 1);
                        }
                    }
                });
            }
        };

        autoScrollTimer.scheduleAtFixedRate(task, elapsed, elapsed);
    }

    @Override
    public void onViewDetachedFromWindow(View v) {
        task.cancel();
    }
});
}
