TensorFlow for Scala 3

by Bartek Tonia

Introduction

Goal

Provide API for TensorFlow in Scala 3 for data scientists and ML enthusiasts

Background

Fork of github.com/shadaj/scalapy-tensorflow

Works based on `scalapy-numpy` and `scalapy-core`

All originally developed by Shadaj Laddad



TensorFlow

Machine learning models

import numpy as np
from tensorflow import keras
from tensorflow.keras import layers

max_features = 20000
maxlen = 200

(x_train, y_train), (x_val, y_val) = keras.datasets.imdb.load_data(num_words=max_features)
x_train = keras.preprocessing.sequence.pad_sequences(x_train, maxlen=maxlen)
x_val = keras.preprocessing.sequence.pad_sequences(x_val, maxlen=maxlen)

model = keras.models.Sequential(layers = [
  layers.Embedding(max_features, 128, input_length = maxlen),
  layers.Bidirectional(layers.LSTM(64)),
  layers.Dropout(0.5),
  layers.Dense(1, activation = "sigmoid")
])

model.compile("adam", "binary_crossentropy", metrics=["accuracy"])
model.fit(x_train, y_train, batch_size=32, epochs=2, validation_data=(x_val, y_val))

Tensor calculations

import tensorflow as tf
import numpy as np

xData = np.random.rand(100)
yData = (xData * 0.1) + 0.3
W = tf.Variable(tf.random.uniform(shape = [1], minval = -1, maxval = 1))
b = tf.Variable(tf.zeros([1]))

def y():
    return (W * xData) + b
def loss():
    return tf.reduce_mean(tf.square(y() - yData))

opt = tf.keras.optimizers.SGD(learning_rate=0.1, momentum=0.9)
num_epochs = 400
for epoch in range(num_epochs):
    step_count = opt.minimize(loss, [W,b]).numpy()
print("W: {},  b: {}".format(W.numpy(), b.numpy()))

Library

scalapy-tensorflow

The part in Scala 2 remains due to redesigned Scala 3

macros and complex interaction with CPython

Scala 2

@py.native
trait Optimizer extends py.Object {
  def apply_gradients(grads_and_vars: Seq[(Tensor, Variable)]): Operation = py.native
}

sealed class |[A, B](val value: scala.Any, val isLeft: Boolean) {}
  def eval(code: String): Unit = {
  	CPythonAPI.PyRun_String(Platform.toCString(code), ...)
  }

Scala 3

class Sequential private[api] (val underlying: PySequential) extends PythonType[PySequential] {

  def add(layer: Layer): Unit = underlying.add(layer.underlying)

  def compile(
      optimizer: String | Optimizer = "rmsprop",
      loss: Option[PyFunction] = None,
      metrics: Seq[Metrics] = Seq.empty,
      lossWeights: Option[Seq[(Double, Double)]] = None
  ) =
    underlying.compile(
      optimizer,
      loss,
      metrics,
      lossWeights
    )
}

Deployment

Validated for MacOS and Linux with conda and pip



Uses jitpack to manage dependancies from github repositories



Performance kept similar to python version by performance testing

New Features

Union types

  def kernelSize: Int | (Int, Int) = underlying.kernel_size

  implicit def fromPythonTypesUnion[
  X <: py.Any,
  Y <: py.Any,
  A <: PythonType[X],
  B <: PythonType[Y]
  ](
      u: A | B
  )(implicit ev1: ClassTag[A], ev2: ClassTag[B]): py.|[X, Y] =
    u match {
      case a: A => a.underlying
      case b: B => b.underlying
      case _    => throw new IllegalArgumentException()
    }

Enums

enum DataFormat(override private[api] val v: String) extends PythonEnum(v){
  case ChannelsLast   extends DataFormat("channels_last")
  case ChannelsFirst  extends DataFormat("channels_first")
}
  def dataFormat: DataFormat = DataFormat.valueOf(underlying.data_format)

Option



  def inputShape: Option[(Int, Int, Int)] = underlying.input_shape

implicit def option2PyOption[A]: Conversion[Option[A], py.NoneOr[A]] =
  _ match {
    case None    => py.|.fromLeft(py.None)
    case Some(v) => py.|.fromRight(v)
  }

and new implicit conversion syntax

Trait parameters



trait Layer private[api] (val underlying: PyLayer) extends PythonType[PyLayer] {}

class Dense private[api] (override val underlying: PyDense) extends Layer(underlying) {
  ...
}

Scala 3 examples

Machine learning models

sealed class |[A, B](val value: scala.Any, val isLeft: Boolean) {}
object BidirectionalLSTMExample extends Runnable {
  def run() = {
    import me.shadaj.scalapy.tensorflow.api.{TensorFlow => tf}
    val sequence = tf.keras.preprocessing.sequence

    val ((xTrain, yTrain), (xTest, yTest)) = imdb.loadData(numWords = Some(maxFeatures))

    val xTrain1 = sequence.padSequences(xTrain, maxLen = Some(maxLen)).astype(np.float32)
    val xTest1 = sequence.padSequences(xTest, maxLen = Some(maxLen)).astype(np.float32)
    val yTrain1 = yTrain.astype(np.float32)
    val yTest1 = yTest.astype(np.float32)

    val model = keras1.models.Sequential(layers = Seq(
      layers.Embedding(maxFeatures, 128, inputLength = Some(maxLen)),
      layers.Bidirectional(layers.LSTM(64, returnSequences=true)),
      layers.Bidirectional(layers.LSTM(64)),
      layers.Dense(1, activation = Some(Activation.Sigmoid))
    ))

    model.compile(Optimizers.Adam,
    	loss = Some(keras1.backend.binaryCrossentropy), metrics = Metrics.Accuracy)
    model.fit(xTrain1, yTrain1, batchSize = Some(batchSize),
    	epochs = epochs, validationData = Some((xTest1, yTest1)))
  }
}

Side by side comparison

object BidirectionalLSTMExample extends Runnable {
  def run() = {
    import me.shadaj.scalapy.tensorflow.api.{TensorFlow => tf}
    val sequence = tf.keras.preprocessing.sequence

    val ((xTrain, yTrain), (xTest, yTest)) = imdb.loadData(numWords = Some(maxFeatures))

    val xTrain1 = sequence.padSequences(xTrain, maxLen = Some(maxLen)).astype(np.float32)
    val xTest1 = sequence.padSequences(xTest, maxLen = Some(maxLen)).astype(np.float32)
    val yTrain1 = yTrain.astype(np.float32)
    val yTest1 = yTest.astype(np.float32)

    val model = keras1.models.Sequential(layers = Seq(
      layers.Embedding(maxFeatures, 128, inputLength = Some(maxLen)),
      layers.Bidirectional(layers.LSTM(64, returnSequences=true)),
      layers.Bidirectional(layers.LSTM(64)),
      layers.Dense(1, activation = Some(Activation.Sigmoid))
    ))

    model.compile(Optimizers.Adam,
    	loss = Some(keras1.backend.binaryCrossentropy), metrics = Metrics.Accuracy)
    model.fit(xTrain1, yTrain1, batchSize = Some(batchSize),
    	epochs = epochs, validationData = Some((xTest1, yTest1)))
  }
}

import numpy as np
from tensorflow import keras
from tensorflow.keras import layers

max_features = 20000
maxlen = 200

(x_train, y_train), (x_val, y_val) = keras.datasets.imdb.load_data(num_words=max_features)
x_train = keras.preprocessing.sequence.pad_sequences(x_train, maxlen=maxlen)
x_val = keras.preprocessing.sequence.pad_sequences(x_val, maxlen=maxlen)

model = keras.models.Sequential(layers = [
  layers.Embedding(max_features, 128, input_length = maxlen),
  layers.Bidirectional(layers.LSTM(64, return_sequences=true)),
  layers.Bidirectional(layers.LSTM(64)),
  layers.Dense(1, activation = "sigmoid")
])

model.compile("adam", "binary_crossentropy", metrics=["accuracy"])
model.fit(x_train, y_train, batch_size=32, epochs=2, validation_data=(x_val, y_val))

Tensor calculations

sealed class |[A, B](val value: scala.Any, val isLeft: Boolean) {}
object GradientDescentOptimizerExample extends Runnable {
  def run(): Unit = {
    val xData = np.random.rand(100).astype(np.float32)
    val yData = (xData * 0.1f) + 0.3f
    val W = tf.Variable(tf.random.uniform(shape = Seq(1), minval = -1, maxval = 1))
    val b = tf.Variable(tf.zeros(Seq(1)))

    def y = () => W * xData + b
    def loss = () => tf.reduceMean(tf.square(y() - yData))

    def grad(): Option[(Tensor, Seq[Tensor])] =
      CloseableResourceManager.withResource(tf.GradientTape()) { tape =>
        val lossValue = loss()
        val gradients: Seq[Tensor] = tape.gradient(lossValue, Seq(W, b))
        (lossValue, gradients)
      }

    val optimizer = tf.keras.optimizers.SGD(learningRate = 0.1, momentum = Some(0.9))
    for (epoch <- 1 to 200) {
      val (lossValue, grads) = grad().get
      optimizer.applyGradients(grads.zip(Seq(W, b)))
    }
    print(s"W: ${W.numpy()},  b: ${b.numpy()}")
  }
}

Side by side

object GradientDescentOptimizerExample extends Runnable {
  def run(): Unit = {
    val xData = np.random.rand(100).astype(np.float32)
    val yData = (xData * 0.1f) + 0.3f
    val W = tf.Variable(tf.random.uniform(shape = Seq(1), minval = -1, maxval = 1))
    val b = tf.Variable(tf.zeros(Seq(1)))

    def y = () => W * xData + b
    def loss = () => tf.reduceMean(tf.square(y() - yData))

    def grad(): Option[(Tensor, Seq[Tensor])] =
      CloseableResourceManager.withResource(tf.GradientTape()) { tape =>
        val lossValue = loss()
        val gradients: Seq[Tensor] = tape.gradient(lossValue, Seq(W, b))
        (lossValue, gradients)
      }

    val optimizer = tf.keras.optimizers.SGD(learningRate = 0.1, momentum = Some(0.9))
    for (epoch <- 1 to 200) {
      val (lossValue, grads) = grad().get
      optimizer.applyGradients(grads.zip(Seq(W, b)))
    }
    print(s"W: ${W.numpy()},  b: ${b.numpy()}")
  }
}

import tensorflow as tf
import numpy as np

xData = np.random.rand(100)
yData = (xData * 0.1) + 0.3
W = tf.Variable(tf.random.uniform(shape = [1], minval = -1, maxval = 1))
b = tf.Variable(tf.zeros([1]))

def y():
    return (W * xData) + b
def loss():
    return tf.reduce_mean(tf.square(y() - yData))

opt = tf.keras.optimizers.SGD(learning_rate=0.1, momentum=0.9)
num_epochs = 400
for epoch in range(num_epochs):
    step_count = opt.minimize(loss, [W,b]).numpy()
print("W: {},  b: {}".format(W.numpy(), b.numpy()))

Future development

Functional API

@tf.function
def f(x, y):
  return x ** 2 + y
x = tf.constant([2, 3])
y = tf.constant([3, -2])
f(x, y)

This would require calling Scala functions in Python

i.e. loss function

Other

  • Change resource manager to scala.Using
  • Consider adding documentation
  • Type classes i.e. Numeric
  • Increase API coverage

Summary

Performance

Scala Python
Total time 108.5 107.8
Epoch 1 46s 59ms/step 41s 52ms/step
Epoch 2 41s 53ms/step 48s 61ms/step
Loss 0.64 0.64
Accuracy 0.61 0.61

BidirectionalLSTMExample.scala used to compare learning speed

Results

scalapy-tensorflow provided similar experience and faced similar issues as other language versions of TensorFlow, for example: Swift or JavaScript
