Using JS State Machines to fight monsters

Robots vs Monsters

What Are State Machines?

Wikipedia defines a finite-state machine (FSM) as:

An abstract machine that can be in exactly one of a finite number of states at any given time

The FSM can change from one state to another in response to some external inputs; the change from one state to another is called a transition

An FSM is defined by a list of its states, its initial state, and the conditions for each transition.

The IMportant Bits

A finite list of possible states and an initial state
The machine can be in exactly one state at any given time
Can change (transition) from one state to another in response to some external input

What is State?

A state is a description of the status of a system that is waiting to execute a transition

The Robots attack

Critical Hit

Roll

Double Click

Do Nothing

Use Tech

Check HP

Idle

Tech Effect

Attack

Play Attack

Play Special Attack

Play Destroyed

async function attack(robot, target) {
  if (!robot.isIdle) {
    return;
  }
  const roll = engine.rollAttack(robot);
  if (roll.isCritical) {
    await SpecialAttackAnimation(robot);
  } else {
    await AttackAnimation(robot);
  }
  robot.power > 0 ? PoweredIdleAnimation(robot) : IdleAnimation(robot);
}

async function useTech(robot, tech) {
  if (!robot.isIdle) {
    return;
  }
  const roll = engine.useTech(robot, tech);
  await TechAnimation(robot, tech);
  if (robot.hp <= 0) {
    await DestroyedAnimation(robot);
  } else {
    robot.power > 0 ? PoweredIdleAnimation(robot) : IdleAnimation(robot);
  }
}

5 flags (Boolean States)

Is HP below 0
Is Power above 0
Is the Attack Critical
Is the robot currently idle
Are we "awaiting" an animation end

32 Possible States

async function attack(robot, target) {
  if (!robot.isIdle) {
    return;
  }
  const roll = engine.rollAttack(robot);
  if (roll.isCritical) {
    await SpecialAttackAnimation(robot);
  } else {
    await AttackAnimation(robot);
  }
  robot.power > 0 ? PoweredIdleAnimation(robot) : IdleAnimation(robot);
}

async function useTech(robot, tech) {
  if (!robot.isIdle) {
    return;
  }
  const roll = engine.useTech(robot, tech);
  await TechAnimation(robot, tech);
  if (robot.hp <= 0) {
    await DestroyedAnimation(robot);
  } else {
    robot.power > 0 ? PoweredIdleAnimation(robot) : IdleAnimation(robot);
  }
}

The Robots attack

Idle

Attacking

Critical Hit

Roll

Special
Attacking

Use Tech

Check HP

Destroyed

Using Tech

Attack

Powered Idle

export let robotAttackMachine = {
  state: 'idle',
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
  },
  states: {
    idle: {},
    attacking: {},
    specialAttacking: {},
    usingTech: {},
    destroyed: {},
  },
};

export let robotAttackMachine = {
  state: 'idle',
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {},
    attacking: {},
    specialAttacking: {},
    usingTech: {},
    destroyed: {},
  },
};

export let robotAttackMachine = {
  state: 'idle',
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {},
    attacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    specialAttacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTech: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    destroyed: {},
  },
};

export let robotAttackMachine = {
  state: 'idle',
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {},
    attacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    specialAttacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTech: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    destroyed: {
      type: 'final',
    },
  },
};

export let robotAttackMachine = {
  state: 'idle',
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    if (state.type === 'final') {
      return;
    }
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {},
    attacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    specialAttacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTech: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    destroyed: {
      type: 'final',
    },
  },
};

function attack(event) {
  const roll = engine.roll(event.robot);
  if (roll.isCritical) {
    this.state = 'specialAttacking';
  } else {
    this.state = 'attacking';
  }
}

export let robotAttackMachine = {
  state: 'idle',
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    if (state.type === 'final') {
      return;
    }
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {},
    attacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    specialAttacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTech: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    destroyed: {
      type: 'final',
    },
  },
};

function attack(event) {
  const roll = engine.roll(event.robot);
  if (roll.isCritical) {
    this.state = 'specialAttacking';
  } else {
    this.state = 'attacking';
  }
}

export let robotAttackMachine = {
  state: 'idle',
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    if (state.type === 'final') {
      return;
    }
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {
      on: {
        ATTACK: attack,
      },
    },
    attacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    specialAttacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTech: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    destroyed: {
      type: 'final',
    },
  },
};

function attack(event) {
  const roll = engine.roll(event.robot);
  if (roll.isCritical) {
    this.state = 'specialAttacking';
  } else {
    this.state = 'attacking';
  }
}

function useTech(event) {
  const robot = this.robot;
  engine.useTech(robot, event.tech);
  if (robot.hp <= 0) {
    this.state = 'usingTechLethal';
  } else {
    this.state = 'usingTech';
  }
}

export let robotAttackMachine = {
  state: 'idle',
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    if (state.type === 'final') {
      return;
    }
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {
      on: {
        ATTACK: attack,
      },
    },
    attacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    specialAttacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTech: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    destroyed: {
      type: 'final',
    },
  },
};

function attack(event) {
  const roll = engine.roll(event.robot);
  if (roll.isCritical) {
    this.state = 'specialAttacking';
  } else {
    this.state = 'attacking';
  }
}

function useTech(event) {
  const robot = this.robot;
  engine.useTech(robot, event.tech);
  if (robot.hp <= 0) {
    this.state = 'usingTechLethal';
  } else {
    this.state = 'usingTech';
  }
}

export let robotAttackMachine = {
  state: 'idle',
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    if (state.type === 'final') {
      return;
    }
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {
      on: {
        ATTACK: attack,
        USE_TECH: useTech,
      },
    },
    attacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    specialAttacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTech: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    destroyed: {
      type: 'final',
    },
  },
};

function attack(event) {
  const roll = engine.roll(event.robot);
  if (roll.isCritical) {
    this.state = 'specialAttacking';
  } else {
    this.state = 'attacking';
  }
}

function useTech(event) {
  const robot = this.robot;
  engine.useTech(robot, event.tech);
  if (robot.hp <= 0) {
    this.state = 'usingTechLethal';
  } else {
    this.state = 'usingTech';
  }
}

export let robotAttackMachine = {
  state: 'idle',
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    if (state.type === 'final') {
      return;
    }
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {
      on: {
        ATTACK: attack,
        USE_TECH: useTech,
      },
    },
    attacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    specialAttacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTech: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTechLethal: {
      on: {
        ANIMATION_END: 'destroyed',
      },
    },
    destroyed: {
      type: 'final',
    },
  },
};

function attack(event) {
  const roll = engine.roll(event.robot);
  if (roll.isCritical) {
    this.state = 'specialAttacking';
  } else {
    this.state = 'attacking';
  }
}

function useTech(event) {
  const robot = this.robot;
  engine.useTech(robot, event.tech);
  if (robot.hp <= 0) {
    this.state = 'usingTechLethal';
  } else {
    this.state = 'usingTech';
  }
}

export let robotAttackMachine = {
  state: 'idle',
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    if (state.type === 'final') {
      return;
    }
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {
      on: {
        ATTACK: attack,
        USE_TECH: useTech,
      },
    },
    attacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    specialAttacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTech: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTechLethal: {
      on: {
        ANIMATION_END: 'destroyed',
      },
    },
    destroyed: {
      type: 'final',
    },
  },
};

function attack(event) {
  const roll = engine.roll(event.robot);
  if (roll.isCritical) {
    this.state = 'specialAttacking';
  } else {
    this.state = 'attacking';
  }
}

function useTech(event) {
  const robot = this.robot;
  engine.useTech(robot, event.tech);
  if (robot.hp <= 0) {
    this.state = 'usingTechLethal';
  } else {
    this.state = 'usingTech';
  }
}

export let robotAttackMachine = {
  state: 'idle',
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    if (state.type === 'final') {
      return;
    }
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {
      on: {
        enter() {
          if (this.robot.power > 0) {
            this.state = 'poweredIdle';
          }
        },
        ATTACK: attack,
        USE_TECH: useTech,
      },
    },
    attacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    specialAttacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTech: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTechLethal: {
      on: {
        ANIMATION_END: 'destroyed',
      },
    },
    destroyed: {
      type: 'final',
    },
  },
};

function attack(event) {
  const roll = engine.roll(event.robot);
  if (roll.isCritical) {
    this.state = 'specialAttacking';
  } else {
    this.state = 'attacking';
  }
}

function useTech(event) {
  const robot = this.robot;
  engine.useTech(robot, event.tech);
  if (robot.hp <= 0) {
    this.state = 'usingTechLethal';
  } else {
    this.state = 'usingTech';
  }
}

export let robotAttackMachine = {
  state: 'idle',
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    if (state.type === 'final') {
      return;
    }
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {
      on: {
        enter() {
          if (this.robot.power > 0) {
            this.state = 'poweredIdle';
          }
        },
        ATTACK: attack,
        USE_TECH: useTech,
      },
    },
    poweredIdle: {
      on: {
        ATTACK: attack,
        USE_TECH: useTech,
      },
    },
    attacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    specialAttacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTech: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTechLethal: {
      on: {
        ANIMATION_END: 'destroyed',
      },
    },
    destroyed: {
      type: 'final',
    },
  },
};

function attack(event) {
  const roll = engine.roll(event.robot);
  if (roll.isCritical) {
    this.state = 'specialAttacking';
  } else {
    this.state = 'attacking';
  }
}

function useTech(event) {
  const robot = this.robot;
  engine.useTech(robot, event.tech);
  if (robot.hp <= 0) {
    this.state = 'usingTechLethal';
  } else {
    this.state = 'usingTech';
  }
}

export let robotAttackMachine = {
  _state: 'idle',
  get state() {
    return this._state;
  },
  set state(value) {
    this._state = value;
    const state = this.states[this._state];
    if (state?.on?.enter) {
      state.on.enter.call(this);
    }
  },
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    if (state.type === 'final') {
      return;
    }
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {
      on: {
        enter() {
          if (this.robot.power > 0) {
            this.state = 'poweredIdle';
          }
        },
        ATTACK: attack,
        USE_TECH: useTech,
      },
    },
    poweredIdle: {
      on: {
        ATTACK: attack,
        USE_TECH: useTech,
      },
    },
    attacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    specialAttacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTech: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTechLethal: {
      on: {
        ANIMATION_END: 'destroyed',
      },
    },
    destroyed: {
      type: 'final',
    },
  },
};

function attack(event) {
  const roll = engine.roll(event.robot);
  if (roll.isCritical) {
    this.state = 'specialAttacking';
  } else {
    this.state = 'attacking';
  }
}

function useTech(event) {
  const robot = this.robot;
  engine.useTech(robot, event.tech);
  if (robot.hp <= 0) {
    this.state = 'usingTechLethal';
  } else {
    this.state = 'usingTech';
  }
}

export let robotAttackMachine = {
  _state: 'idle',
  get state() {
    return this._state;
  },
  set state(value) {
    this._state = value;
    const state = this.states[this._state];
    if (state?.on?.enter) {
      state.on.enter.call(this);
    }
  },
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    if (state.type === 'final') {
      return;
    }
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {
      on: {
        enter() {
          if (this.robot.power > 0) {
            this.state = 'poweredIdle';
          }
        },
        ATTACK: attack,
        USE_TECH: useTech,
      },
    },
    poweredIdle: {
      on: {
        ATTACK: attack,
        USE_TECH: useTech,
      },
    },
    attacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    specialAttacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTech: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTechLethal: {
      on: {
        ANIMATION_END: 'destroyed',
      },
    },
    destroyed: {
      type: 'final',
    },
  },
};

function attack(event) {
  const roll = engine.roll(event.robot);
  if (roll.isCritical) {
    this.state = 'specialAttacking';
  } else {
    this.state = 'attacking';
  }
}

function useTech(event) {
  const robot = this.robot;
  engine.useTech(robot, event.tech);
  if (robot.hp <= 0) {
    this.state = 'usingTechLethal';
  } else {
    this.state = 'usingTech';
  }
}

export let robotAttackMachine = {
  _state: 'idle',
  get state() {
    return this._state;
  },
  set state(value) {
    this._state = value;
    const state = this.states[this._state];
    if (state?.on?.enter) {
      state.on.enter.call(this);
    }
  },
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    if (state.type === 'final') {
      return;
    }
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {
      on: {
        enter() {
          if (this.robot.power > 0) {
            this.state = 'poweredIdle';
          }
        },
        ATTACK: attack,
        USE_TECH: useTech,
      },
    },
    poweredIdle: {
      on: {
        ATTACK: attack,
        USE_TECH: useTech,
      },
    },
    attacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    specialAttacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTech: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTechLethal: {
      on: {
        ANIMATION_END: 'destroyed',
      },
    },
    destroyed: {
      type: 'final',
    },
  },
};

function attack(event) {
  const roll = engine.roll(event.robot);
  if (roll.isCritical) {
    this.state = 'specialAttacking';
  } else {
    this.state = 'attacking';
  }
}

function useTech(event) {
  const robot = this.robot;
  engine.useTech(robot, event.tech);
  if (robot.hp <= 0) {
    this.state = 'usingTechLethal';
  } else {
    this.state = 'usingTech';
  }
}

export let robotAttackMachine = {
  _state: 'idle',
  get state() {
    return this._state;
  },
  set state(value) {
    this._state = value;
    const state = this.states[this._state];
    if (state?.on?.enter) {
      state.on.enter.call(this);
    }
  },
  robot: { atk: 1, def: 0, hp: 1, power: 0 },
  dispatch(event) {
    const state = this.states[this.state];
    if (state.type === 'final') {
      return;
    }
    const transition = state.on[event.type];

    if (typeof transition === 'function') {
      transition.call(this, event);
    } else if (transition in this.states) {
      this.state = transition;
    }
  },
  states: {
    idle: {
      on: {
        enter() {
          if (this.robot.power > 0) {
            this.state = 'poweredIdle';
          }
        },
        ATTACK: attack,
        USE_TECH: useTech,
      },
    },
    poweredIdle: {
      on: {
        ATTACK: attack,
        USE_TECH: useTech,
      },
    },
    attacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    specialAttacking: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTech: {
      on: {
        ANIMATION_END: 'idle',
      },
    },
    usingTechLethal: {
      on: {
        ANIMATION_END: 'destroyed',
      },
    },
    destroyed: {
      type: 'final',
    },
  },
};

The Robots attack

Idle

Attacking

Critical Hit

Roll

Special
Attacking

Use Tech

Check HP

Destroyed

Using Tech

Attack

Powered Idle

But that Was A lot of code...

Let's Take a break from all this and Have Some FUN

Clap Like it's Over

Now Go Crazy and Cheer Really Loud!!

Someone yell "Bravo!"

NOW SILENCE!!!

Now overly EXAGGERATED Laughter!!!

Good Job

Using JS State Machines to fight monsters

By Adam L Barrett

Using JS State Machines to fight monsters

Finite State Machines are a powerful tool used to fight complexity in software. State Machines in JavaScript make our code more readable and maintainable. Let's learn about state machines and refactor a simple game where awesome battle robots fight horrible monsters from the deep.

Adam L Barrett PRO

Adam L Barrett is a JavaScript and Front-End consultant, a contributor to open source, and avid bike-shedder.

Using JS State Machines to fight monsters

Robots vs Monsters

What Are State Machines?

Wikipedia defines a finite-state machine (FSM) as:

The IMportant Bits

What is State?

The Robots attack

5 flags (Boolean States)

32 Possible States

32 Possible States

The Robots attack

The Robots attack

But that Was A lot of code...

Let's Take a break from all this and Have Some FUN

Clap Like it's Over

Now Go Crazy and Cheer Really Loud!!

Someone yell "Bravo!"

NOW SILENCE!!!

Now overly EXAGGERATED Laughter!!!

Good Job

Using JS State Machines to fight monsters

Using JS State Machines to fight monsters

More from Adam L Barrett
