PacMan Facts

Pygame

                           GPL License
                   SDL

Simple DirectMedia Layer
 development library which
 provide low level access to
  audio, keyboard, mouse,
  joystick, and graphics hardware
          via
  OpenGL and Direct3D.

import pygame, sys
from pygame.locals import *

pygame.init()
DISPLAYSURF = pygame.display.set_mode((400, 300))
pygame.display.set_caption('Hello World!')while True: # main game loop
    for event in pygame.event.get():
        if event.type == QUIT:
            pygame.quit()
            sys.exit()
    pygame.display.update()

The Game itself

import

import pygame._view

black = (0,0,0)
white = (255,255,255)
blue = (0,0,255)
green = (0,255,0)
red = (255,0,0)
purple = (255,0,255)
yellow = ( 255, 255, 0)

Trollicon=pygame.image.load('images/Trollman.png')
pygame.display.set_icon(Trollicon)

#Add music
pygame.mixer.init()
pygame.mixer.music.load('pacman.mp3')
pygame.mixer.music.play(-1, 0.0)

 class Wall(pygame.sprite.Sprite):
    # Constructor function
    def __init__(self,x,y,width,height, color):
        # Call the parent's constructor
        pygame.sprite.Sprite.__init__(self)

        # Make a blue wall, of the size specified in the parameters
        self.image = pygame.Surface([width, height])
        self.image.fill(color)

        # Make our top-left corner the passed-in location.
        self.rect = self.image.get_rect()
        self.rect.top = y
        self.rect.left = x

Draw the map

def setupRoomOne(all_sprites_list):
    # Make the walls. (x_pos, y_pos, width, height)
    wall_list=pygame.sprite.RenderPlain()

    # List of walls.
    walls = [ [0,0,6,600], [0,0,600,6], [0,600,606,6], [600,0,6,606],
              [300,0,6,66], [60,60,186,6] ......
            ]

    for item in walls:
        wall=Wall(item[0],item[1],item[2],item[3],blue)
        wall_list.add(wall)
        all_sprites_list.add(wall)

    return wall_list


 class Player(pygame.sprite.Sprite):
    # Set speed vector
    change_x=0
    change_y=0

    def __init__(self,x,y, filename):
        pygame.sprite.Sprite.__init__(self)

        # Set height, width
        self.image = pygame.image.load(filename).convert()

        self.rect = self.image.get_rect()
        self.rect.top = y
        self.rect.left = x
        self.prev_x = x
        self.prev_y = y

    def prevdirection(self):
        self.prev_x = self.change_x
        self.prev_y = self.change_y

    def changespeed(self,x,y):
        self.change_x+=x
        self.change_y+=y

 def update(self,walls,gate):
        old_x=self.rect.left
        new_x=old_x+self.change_x
        prev_x=old_x+self.prev_x
        self.rect.left = new_x

        old_y=self.rect.top
        new_y=old_y+self.change_y
        prev_y=old_y+self.prev_y

    # Did this update cause us to hit a wall?
        x_collide = pygame.sprite.spritecollide(self, walls, False)
        if x_collide:
            self.rect.left=old_x
        else:
            self.rect.top = new_y

            y_collide = pygame.sprite.spritecollide(self, walls, False)
            if y_collide:
                self.rect.top=old_y

        if gate != False:
            gate_hit = pygame.sprite.spritecollide(self, gate, False)
            if gate_hit:
                self.rect.left=old_x
                self.rect.top=old_y

class Ghost(Player):
    def changespeed(self,list,ghost,turn,steps,l):
      try:
        z=list[turn][2]
        if steps < z:
          self.change_x=list[turn][0]
          self.change_y=list[turn][1]
          steps+=1
         else:
          if turn < l:
            turn+=1
          elif ghost == "clyde":
            turn = 2
          else:
            turn = 0

          self.change_x=list[turn][0]
          self.change_y=list[turn][1]
          steps = 0
        return [turn,steps]
      except IndexError:
         return [0,0]

Control Pac-man

if event.type == pygame.KEYDOWN:
              if event.key == pygame.K_LEFT:
                  Pacman.changespeed(-30,0)
              if event.key == pygame.K_RIGHT:
                  Pacman.changespeed(30,0)
              if event.key == pygame.K_UP:
                  Pacman.changespeed(0,-30)
              if event.key == pygame.K_DOWN:
                  Pacman.changespeed(0,30)

          if event.type == pygame.KEYUP:
              if event.key == pygame.K_LEFT:
                  Pacman.changespeed(30,0)
              if event.key == pygame.K_RIGHT:
                  Pacman.changespeed(-30,0)
              if event.key == pygame.K_UP:
                  Pacman.changespeed(0,30)
              if event.key == pygame.K_DOWN:
                  Pacman.changespeed(0,-30)

Ghost chasing algorithm

                                      chasing Pacman (A* algorithm)


                                      set a trap

                                      goes at random

                               Chase - Scatter - Chase

    Behavior is not identical due to error in orginal ASM code

def doNext(message,left,all_sprites_list,block_list,monsta_list,pacman_collide,wall_list,gate):
  while True:
      # ALL EVENT PROCESSING SHOULD GO BELOW THIS COMMENT
      for event in pygame.event.get():
        if event.type == pygame.QUIT:
          pygame.quit()
        if event.type == pygame.KEYDOWN:
          if event.key == pygame.K_ESCAPE:
            pygame.quit()
          if event.key == pygame.K_RETURN:
            del all_sprites_list
            del block_list
            del monsta_list
            del pacman_collide
            del wall_list
            del gate
            startGame()

      #Grey background
      w = pygame.Surface((400,200))  # the size of your rect
      w.set_alpha(10)                # alpha level
      w.fill((128,128,128))           # this fills the entire surface
      screen.blit(w, (100,200))    # (0,0) are the top-left coordinates

      #Won or lost
      text1=font.render(message, True, white)
      screen.blit(text1, [left, 233])

      text2=font.render("To play again, press ENTER.", True, white)
      screen.blit(text2, [135, 303])
      text3=font.render("To quit, press ESCAPE.", True, white)
      screen.blit(text3, [165, 333])

      pygame.display.flip()

      clock.tick(10)


startGame()


pygame.quit()

While running

Rule 1 runs every 0.1 secs calling the following methods to keep the Pacman moving and check if it's in ghost killing mode:

• Decide which way to move based on user input of arrow keys
• Move over certain agents (floor, pills, ghosts, etc)
• Kill ghosts if the "heat" value is set to -1000 rather than +1000 (meaning a power pill has been eaten)
• Heat can be explained more here.

Decide which way to move

Title

def startGame():
  all_sprites_list = pygame.sprite.RenderPlain()
  block_list = pygame.sprite.RenderPlain()
  monsta_list = pygame.sprite.RenderPlain()
  pacman_collide = pygame.sprite.RenderPlain()
  wall_list = setupRoomOne(all_sprites_list)
  gate = setupGate(all_sprites_list)

  p_turn = 0
  p_steps = 0

  b_turn = 0
  b_steps = 0

  i_turn = 0
  i_steps = 0

  c_turn = 0
  c_steps = 0

  Pacman = Player( w, p_h, "images/Trollman.png" )
  all_sprites_list.add(Pacman)
  pacman_collide.add(Pacman)

  Blinky=Ghost( w, b_h, "images/Blinky.png" )
  monsta_list.add(Blinky)
  all_sprites_list.add(Blinky)

  Pinky=Ghost( w, m_h, "images/Pinky.png" )
  monsta_list.add(Pinky)
  all_sprites_list.add(Pinky)

Title

 # Draw the grid
  for row in range(19):
      for column in range(19):
          if (row == 7 or row == 8) and (column == 8 or column == 9 or column == 10):
              continue
          else:
            block = Block(yellow, 4, 4)

            # Set a random location for the block
            block.rect.x = (30*column+6)+26
            block.rect.y = (30*row+6)+26

            b_collide = pygame.sprite.spritecollide(block, wall_list, False)
            p_collide = pygame.sprite.spritecollide(block, pacman_collide, False)
            if b_collide:
              continue
            elif p_collide:
              continue
            else:
              # Add the block to the list of objects
              block_list.add(block)
              all_sprites_list.add(block)

  bll = len(block_list)
  score = 0
  done = False
  i = 0
  while done == False:
