Angular Training

Abdullah Fathi

www.fotia.com.my

What is angular?

  • Javascript framework
  • Allows you to create reactive single-page-applications (SPAs)

Angular Training
course Structure

  • The Basics
  • Components & Databinding
  • Directives
  • Services & Dependency Injection
  • Routing
  • Observables
  • Forms
  • Http

Installation/UPDATE

Nodejs & angular installation

fresh installation

NODEJS

  • Go to nodejs.org and download the latest verison.



ANGULAR

  • [sudo] npm install -g @angular/cli@latest

update existing angular

UPDATE NPM

  • [sudo] npm install -g npm (sudo is only required on Mac/Linux)



UPDATE CLI

  • [sudo] npm uninstall -g angular-cli @angular/cli
  • npm cache clean
  • [sudo] npm install -g @angular/cli

Root

Header

Shopping List

Recipe Book

Shopping List

Shopping List Edit

Recipe List

Recipe Item

Recipe Detail

Ingredient

Recipe

Feature

Component

Model

PLANNING THE APP

IDE (VISUAL STUDIO CODE)

PROJECT SETUP

Steps to create new project in angular

- Navigate to your workspace/folder

ng new my-first-app

- Go into my-first-app folder

ng serve

- Open browser and go to http://localhost:4200

INSTALL BOOTSTRAP

- Edit default styles in "angular.json" file

npm install --save bootstrap@3
"styles": [
    "../node_modules/bootstrap/dist/css/bootstrap.min.css",
    "src/styles.css"
]
ng serve

- Start app to view bootstrap loaded in head

Create Component

- OR

ng generate component COMPONENT-NAME --spec false
ng g c COMPONENT-NAME --spec false

DATA BINDING

TypeScript Code
(Business Logic)

Template (HTML)

Output Data

String Interpolation ( {{ data }})

Property Binding ([property] = "data")

React to (User) Events

Event Binding ((event)="expression")

Combination of Both: Two-Way-Binding ( [(ngModel)] = "data" )

Communication between TypeScript Code and Template (HTML)

LIFECYCLE HOOKS

Called after a bound input property changes

Called once the component is initialized

Called during every change detection run

Called after content (ng-content) has been projected into view

ngOnChanges

ngOnInit

ngDoCheck

ngAfterContentInit

ngAfterContentChecked

ngAfterViewInit

ngAfterViewChecked

ngOnDestroy

Called every time the projected content has been checked

Called after the component’s view (and child views) has been initialized

Called every time the view (and child views) have been checked

Called once the component is about to be destroyed

Attribute VS STRUCTURAL

Attribute Directives

Structural Directives

Look like a normal HTML Attribute (possibly with databinding or event binding)

Only affect/ change the element they are added to

Look like a normal HTML Attribute but have a leading * (for desugaring)

Affect a whole area in the DOM (elements get added/ removed)

HIERARCHICAL INJECTOR

AppModule

Same Instance of Service is available Application-wide

AppComponent

Same Instance of Service is available for all Components (but not for other Services)

Any Other Component

Same Instance of Service is available for the Component and all its child components

ROUTING

router-outlet

Mark the place where angular should load the component based on path (url)

routerLink

Create absolute path/link

[routerLink]

Pass array to configure segment of path (url)

routerLinkActive

Apply CSS class to active/clicked router

FORMS

two approaches

  • Easy to use
  • Two-way data binding -> Minimal component code
  • Automatically tracks form and input element state
  • Angular infers the Form Object from the DOM
  • More flexible -> more complex scenarios
  • Immutable data model
  • Easier to perform an action on a value change
  • Easily add input elements dynamically
  • Form is created programmatically and synchronized with the DOM

Template-driven

Reactive

FORM TEMPLATE

<div class="row">
  <div class="col-xs-12">
    <form>
      <div class="row">
        <div class="col-xs-12">
          <button type="submit" class="btn btn-success">Save</button>
          <button type="button" class="btn btn-danger">Cancel</button>
        </div>
      </div>
      <div class="row">
        <div class="col-xs-12">
          <div class="form-group">
            <label for="name">Name</label>
            <input
              type="text"
              id="name"
              class="form-control"
            >
          </div>
        </div>
      </div>
      <div class="row">
        <div class="col-xs-12">
          <div class="form-group">
            <label for="imagePath">Image URL</label>
            <input
              type="text"
              id="imagePath"
              class="form-control"
            >
          </div>
        </div>
      </div>
      <div class="row">
        <div class="col-xs-12">
         <img src="" class="img-responsive">
        </div>
      </div>
      <div class="row">
        <div class="col-xs-12">
          <div class="form-group">
            <label for="description">Description</label>
            <textarea
              type="text"
              id="desription"
              class="form-control"
              rows="6"
            >
            </textarea>
          </div>
        </div>
      </div>
      <div class="row">
        <div class="col-xs-12">
          <div class="row">
            <div class="col-xs-8">
              <input
                type="text"
                class="form-control"
              >
            </div>
            <div class="col-xs-2">
              <input
                type="number"
                class="form-control"
              >
            </div>
            <div class="col-xs-2">
              <button class="btn btn-danger">X</button>
            </div>
          </div>
        </div>
      </div>
    </form>
  </div>
</div>

How does authentication work?

"Traditional" Web App

SPA

Client (Frontend)

Client (Frontend)

Server (Backend)

Server (Backend)

Server stores the Session!

Server doesn't remember the Client !

Send Auth Information

Set Session Cookie

Identify via cookie

Send Auth Information

Send Token

Authenticate via Token

There are no secrets to success. It is the result of preparation, hard work, and learning from failure. - Colin Powell

THANK YOU
