Assignment 8

Assignment 8

A

79%

Assignment 9

Assignment 10

Load a .PLY/.OBJ/.STL file and convert it to a valid .GLTF file

Load the armadillo and add multiple lights and materials (incl. toon)

Due 11/27

Due 12/02

Includes Final Project Choice

40% of your grade

chance to pair your learned skills
with your creative ideas

can be done as a team or solo

Final Project

Fast Forward (30-60 seconds)

Final Project Presentation

Report on Overleaf

Code on Github

Wed 12/04

Mon 12/09 Wed 12/11
Fri 12/13

Fri 12/20

Fri 12/20

11/22

11/25

11/27

12/02

12/06

Recap II

glTF II

Fieldtrip

Skybox

Final Recap

Fri

Mon

Fri

Mon

Wed

Lecture 1

GPU Access!

Lecture 2

<canvas></canvas>

var c = document.createElement("canvas");

document.body.appendChild(c);

*.html

*.js

Lecture 3

Browser

Editor

Lecture 4

Web Developer Tools

Spector.js is a Web Developer Tool for WebGL

Lecture 5

Frustum

zNear

zFar

Viewport

Camera

(Eye)

Perspective Projection

Camera

Eye

Position (0,0,100)

Focus (0,0,0)

Scene

Center

Up (0,1,0)

Translate (Move in x,y)

Zoom (Move in z)

Rotate

X

Y

Z

c = new X.cube();

c2 = new X.cube();

c.center = [0, 0, 0];

c.lengthX

c.lengthY

c.lengthZ

gap

= 20

c2.center = [25, 0, 0];

= 5

c.color = [0, 0, 1];

c2.color = [1, 1, 1];

25, 0, 0

0, 0, 0

Z-Fighting

Lecture 6

easy

hard

XTK

Three.js

WebGL

limited

freedom

Complexity

Functionality

XTK

X.renderer3D

Renderer

Scene

Interaction

Loop

Three.js

THREE.WebGLRenderer

THREE.Scene

THREE.TrackballControls

Loop

Canvas

Canvas

Camera

THREE.PerspectiveCamera

Lighting

THREE.AmbientLight

THREE.DirectionalLight

ambientlight = new THREE.AmbientLight()

geometry = new THREE.BoxBufferGeometry

                                                  ( 20, 20, 20 )

lengthX, lengthY, lengthZ

Geometry defines the shape!

material = new THREE.MeshStandardMaterial

                                             ( { color: 0xffffff } )

Material defines the appearance!

 new THREE.Mesh( geometry, material )

 cube =

Lecture 7

Wireframe

12 Triangles

V1

V2

V3

V4

V6

V5

(x, y, z)

(x, y, z)

(x, y, z)

(x, y, z)

(x, y, z)

(x, y, z)

Vertex

/ Vertices

Face

Face

Frame Buffer

Screen Space

width x height Pixels

Rasterization

var geometry = new THREE.Geometry();
geometry.vertices.push(
	new THREE.Vector3(-10, 10, 0),
	new THREE.Vector3(-10, -10, 0),
	new THREE.Vector3(10, -10, 0)
);
geometry.faces.push( new THREE.Face3(0, 1, 2));

GPU

Vertex Shader

Fragment Shader

Viewport

From 3D..

..to 2D

Lecture 8

0, 0

width, height

renderer.domElement.onclick = function(e) {

  pixel_coords = new THREE.Vector2(e.clientX, e.clientY);

};

400, 200

400     ,     200

Screen Space Coordinates

-1, -1

renderer.domElement.onclick = function(e) {

  pixel_coords = new THREE.Vector2( e.clientX, e.clientY );
  vp_coords = new THREE.Vector2(
    ( pixel_coords.x / window.innerWidth ) * 2 - 1, // X
    - ( pixel_coords.y / window.innerHeight ) * 2 + 1 ); // Y
};

-0.2, 0.3

-0.2

Viewport Coordinates

1, 1

0, 0

0.3

THREE.Raycaster

zNear

zFar

Ray

Position (x,y,z)

needs 2 points to define Ray

raycaster = new THREE.Raycaster();
raycaster.setFromCamera(vp_coords_near, camera);

Fragment Shader

Vertex Shader

gl_Position

gl_FragColor

for every vertex

for every pixel

Lecture 9

XTK

X.renderer3D

X.cube

Three.js

THREE.WebGLRenderer

THREE.Scene

THREE.TrackballControls

THREE.PerspectiveCamera

THREE.AmbientLight

THREE.DirectionalLight

WebGL

gl.viewport

gl.createShader

gl.shaderSource

gl.compileShader

gl.getShaderInfoLog

gl.createProgram

gl.attachShader

gl.linkProgram

gl.useProgram

gl.createBuffer

gl.bindBuffer

gl.BufferData

gl.getAttribLocation

gl.vertexAttribPointer

gl.enableVertexAttribArray

gl.clearColor

gl.clear

gl.drawArrays



THREE.Geometry

THREE.Material

THREE.Mesh

V0

V1

V2

V3

V4

V5

Viewport Coordinates

-1, -1

1, 1

-0.5, -0.5

-0.5, 0.5

0.5, 0.5

0.5, -0.5

      vertices = new Float32Array( [
                                     -0.5,  0.5, 0.0, // V0
                                     -0.5, -0.5, 0.0, // V1
                                      0.5,  0.5, 0.0, // V2

                                      0.5,  0.5, 0.0, // V3
                                     -0.5, -0.5, 0.0, // V4
                                      0.5, -0.5, 0.0  // V5
                                    ] );

1. Initialize WebGL

2. Shaders

3. Create Geometry

4. Connect Shader with Geometry

5. Draw!

setup Canvas

setup GL Context

compile vertex shader

compile fragment shader

attach and link shaders

create vertices

create and bind buffer

put data in

unbind buffer

bind buffer

find vertex attribute in shader source

configure vertex attribute

enable vertex attribute array

clear viewport

clear color buffer

draw vertex arrays

Lecture 10

V0

V1

V2

V3

V4

V5

      vertices = new Float32Array( [
                                     -0.5,  0.5, 0.0, // V0
                                     -0.5, -0.5, 0.0, // V1
                                      0.5,  0.5, 0.0, // V2

                                      0.5,  0.5, 0.0, // V3
                                     -0.5, -0.5, 0.0, // V4
                                      0.5, -0.5, 0.0  // V5
                                    ] );

gl.TRIANGLES

V0

V1

V2

V3

V4

V5

      vertices = new Float32Array( [
                                     -0.5,  0.5, 0.0, // V0

                                     -0.5, -0.5, 0.0, // V1

                                      0.5,  0.5, 0.0, // V2

                                      0.5,  0.5, 0.0, // V3

                                     -0.5, -0.5, 0.0, // V4

                                      0.5, -0.5, 0.0  // V5
                                    ] );

gl.POINTS

V0

V1

V2

V3

V4

V5

      vertices = new Float32Array( [
                                     -0.5,  0.5, 0.0, // V0
                                     -0.5, -0.5, 0.0, // V1

                                      0.5,  0.5, 0.0, // V2
                                      0.5,  0.5, 0.0, // V3

                                     -0.5, -0.5, 0.0, // V4
                                      0.5, -0.5, 0.0  // V5
                                    ] );

gl.LINES

Rendering Primitives

V0

V1

V2

V3

V4

V5

      vertices = new Float32Array( [
                                     -0.5,  0.5, 0.0, // V0      // 0
                                     -0.5, -0.5, 0.0, // V1, V4  // 1
                                      0.5,  0.5, 0.0, // V2, V3  // 2
                                      0.5, -0.5, 0.0  // V5      // 3
                                    ] );
var indices = new Uint8Array( [ 0, 1, 2,     // Triangle 1
                                2, 1, 3 ] ); // Triangle 2

0

1

2

3

Indexed Geometry

Before: 6 x 32 bits, Now: 4 x 32 bits

6 x 8 bits == 48 bits

We still save 16 bits.

We save 2 x 32 bits.

Lecture 11

Uniforms

createRectangle()

Rendering Loop

And, they move!

Fragment Shader

Vertex Shader

attribute vec3 position;

different data for each vertex

uniform vec3 offset;

different data for each gl.drawArray or gl.drawElements call

uniform vec4 color;

Lecture 12

Lecture 13

Transformations

Translate

Rotate

Scale

Matrix

1   0   0   t_x

0   1   0   t_y

0   0   1   t_z

0   0   0   1

x, y, z

x, y, z

new

Translation

Matrix

s_x   0   0   t_x

0   s_y   0   t_y

0   0   s_z   t_z

0   0      0     1

x, y, z

x, y, z

new

Scaling

Matrix

r   r   r   t_x

r   r   r   t_y

r   r   r   t_z

 0   0   0     1

x, y, z

x, y, z

new

Rotation

var m = new Float32Array( [
  r, r, r, 0,
  r, r, r, 0,
  r, r, r, 0,
  t_x, t_y, t_z, 1
]);

column-major ordering!

Lecture 14

0.5   0   0   0

0   0.5   0   0

0   0   0.5   0

0   0   0   1

2, 2, 2

?

cos(T)   -sin(T)   0   0

sin(T)   cos(T)   0    0

    0          0        1    0

    0          0       0     1

2, 2, 2

?

with T = Pi/2

 = 90°

X

Y

Z

Scene

1   0   0   0

0   1   0   0

0   0   1   0

0   0   0   1

1   0   0   0

0   1   0   0

0   0   1   0

0   0   0   1

1   0   0   0

0   1   0   0

0   0   1   0

0   0   0   1

1   0   0   0

0   1   0   0

0   0   1   0

0   0   0   1

1   0   0   0

0   1   0   0

0   0   1   0

0   0   0   1

1   0   0   0

0   1   0   0

0   0   1   0

0   0   0   1

1   0   0   0

0   1   0   0

0   0   1   0

0   0   0   1

1   0   0   0

0   1   0   0

0   0   1   0

0   0   0   1

1   0   0   0

0   1   0   0

0   0   1   0

0   0   0   1

1   0   0   0

0   1   0   0

0   0   1   0

0   0   0   1

1   0   0   0

0   1   0   0

0   0   1   0

0   0   0   1

1   0   0   0

0   1   0   0

0   0   1   0

0   0   0   1

1   0   0   0

0   1   0   0

0   0   1   0

0   0   0   1

1   0   0   0

0   1   0   0

0   0   1   0

0   0   0   1

1   0   0   0

0   1   0   0

0   0   1   0

0   0   0   1

Scene Graph is a Tree-like Hierarchy!

*

*

*

Lecture 15

cos(T)   -sin(T)   0   0

sin(T)   cos(T)   0    0

    0          0        1    0

    0          0       0     1

2, 2, 2

with T = Pi/2

0

0

1

2 Pi

Pi

Pi/2

1.5 Pi

90°

1

1

-2

2

2

-1

Frame of Reference

X

Y

Z

World Frame

Frame of Reference

X

Y

Z

Object Frame

Frame of Reference

X

Y

Z

Eye Frame

Camera

(Eye)

cos(T)         0       sin(T)    0

    0           1              0     0

-sin(T)    0       cos(T)     0

    0           0              0     1

rotation around Y

cos(T/2)

sin(T/2) * 0

sin(T/2) * 1

sin(T/2) * 0

Matrix

Quaternion

Lecture 16

cos(T)   -sin(T)   0   0

sin(T)   cos(T)   0    0

    0          0        1    0

    0          0       0     1

2, 2, 2

with T = Pi/2

0

0

1

2 Pi

Pi

Pi/2

1.5 Pi

-1

-2, 2, 2

cos(T/2)

sin(T/2) * 0

sin(T/2) * 0

sin(T/2) * 1

Quaternion

w

x

y

z

~0.7

~0.7

0

0

~0.7

0

0

~0.7

0

2

2

2

w

x

y

z

*

Quaternion

?

~0.7

0

0

~0.7

0

2

2

2

*

~0.7

- 0

- 0

- ~0.7

Inverse

page 64, Gortler: 3D Computer Graphics

Rigid Body Transformation

Quaternion

Translation Vector

w

x

y

z

x

y

z

0

Arcball

Trackball

Controls

Natural Feeling

Spins twice as fast

Completely path independent

Lecture 17

var q = new THREE.Quaternion( sin( T / 2 ) * x ,
                              sin( T / 2 ) * y ,
                              sin( T / 2 ) * z ,
                              cos( T / 2 ) );

0

0

1

2 Pi

Pi

Pi/2

1.5 Pi

-1

90°

180°

270°

360°

180°

around Y-axis

T is the angle

x y z is the axis

 T = Math.PI

0, 1, 0

var q = new THREE.Quaternion( Math.sin( Math.PI / 2 ) * 0 ,
                              Math.sin( Math.PI / 2 ) * 1 ,
                              Math.sin( Math.PI / 2 ) * 0 ,
                              Math.cos( Math.PI / 2 ) );

zNear

Ray

Position (x,y,z)

Invisible Plane

raycaster = THREE.Raycaster();
raycaster.setFromCamera(vp_coords_near, camera);
intersects = raycaster.intersectObject( invisiblePlane );

Raycasting

Framebuffer (hidden)

1

2

3

4

( 1, 0, 0, 1 )

( 0, 1, 0, 1 )

( 1, 1, 0, 1 )

( 0, 0, 1, 1 )

( 0, 0, 0, 1 )

gl.readPixels

(r, g, b, a)

map to object ID

( 0, 1, 0, 1 )

2

Object Picking

Object Picking

Raycasting

More complex

Quick'n'Dirty

Very precise (Face picking)

Object precision

Occlusion not a problem

Objects can be hidden

Lecture 18

Lecture 19

Assignment 5

r    g    b    a

alpha

0: fully transparent

     ....

255: fully opaque

0: minimum

     ....

255: maximum

red

green

blue

#000000

#ffffff

minimum

maximum

Hex

#00000000

#ffffffff

minimum

maximum

Hex8

alpha

alpha

HSL

H:

S:

L:

Hue

Saturation

Lightness

0/360°

180°

240°

65%

40%

0%

100%

0%

100%

hsl(240, 65%, 40%)

rgb(36, 36, 168)

#2424a8

Gamut

range of colors in an imaging system

Lecture 20

Lecture 21

Scene Graph

Quaternions

Skeletons

Object Oriented

Slerp

Animations

Textures

Anaglyph

6

Robot

Head

Neck

Torso

Lower Arm

Upper Arm

Hand

Upper Arm

Lower Arm

Hand

Upper Leg

Upper Leg

Lower Leg

Lower Leg

Foot

Foot

L

L

L

R

R

R

L

L

L

R

R

R

Head

Y

X

Object Frame

Neck

Torso

Upper Arm

Lower Arm

Hand

neck.position.y = -10;
torso.position.y = -30;

-10

-40

left_upper_arm.position.y = -5;
left_upper_arm.position.x = 5;
left_lower_arm.position.y = -15;
left_lower_arm.position.x = 5;
left_hand.position.y = -5;
left_hand.position.x = 5;

Position is relative to parent!

Head

Upper Arm

q

q (0, 0, 0, 1)

Identity

X

q2 (Math.sin(T/2),

0,

0,

Math.cos(T/2))

Rotate 180° in X

T = Math.PI

q

q2

Arm down

Arm up

Time

Frames

Keyframe 2

Keyframe 1

slerp Interpolation

Lecture 22

Skinning

Skeleton -> Mesh

Rigging

Mesh -> Skeleton

Kinematics

Forward Kinematics

Inverse Kinematics

Move down the scene graph

Move up in the scene graph

q

Upper Arm

Hand

q

Upper Arm

Hand

q

Upper Arm

Hand

Multiple Solutions!

Lecture 23

Time

<!DOCTYPE html>
<html>
  <head>
    <meta charset="utf-8" />
    <title>CS460 Computer Graphics at the University of Massachusetts Boston</title>
    <script type="text/javascript" src="../../js/xtk_edge.js"></script>
    <link rel="stylesheet" type="text/css" href="../../styles/fonts.css"/>
    <style>
      html, body {
        background-color:#000;
        margin: 0;
        padding: 0;
        height: 100%;
        overflow: hidden !important;
        font-family: din_condensed;
        font-size: 18pt;
      }
    </style>

    <script type='text/javascript'>
      window.onload = function() {

        // create a new test_renderer
        r = new X.renderer3D();
        r.init();

        // UMASS BOSTON
        //
        // create a cube
        umassboston = new X.cube();
        // skin it..
        umassboston.texture.file = 'umassboston.png';
        // hide it for now!
        umassboston.visible = false;

        r.add(umassboston);


        // BOSTON GFX
        //
        // create a cube
        bostongfx = new X.cube();
        // skin it..
        bostongfx.texture.file = 'bostongfx.png';
        // hide it for now!
        bostongfx.visible = false;

        r.add(bostongfx);

        // setup the camera
        r.camera.position = [00, 00, 60];

        // .. and render it
        r.render();

      };

      clicked = false;
      window.onclick = function() {

        if (clicked) return; // sometimes you click again by accident,
                             // and restart the animation.. let's not!

        // we need user feedback, to allow the music to play..
        // let's do it on click!
        clicked = true;
        animation();

      }


      function animation() {

        // start the music
        var music = document.getElementById('music');
        music.autoplay = true;
        music.load();

        setTimeout(function() {
          umassboston.visible = true;
        }, 400);

        setTimeout(function() {
          umassboston.visible = false;
          r.camera.position = [0, 0, -25];
          bostongfx.visible = true;
        }, 3200);

        setTimeout(rotate_bostongfx, 6200);

      };



      function rotate_bostongfx() {

        var rotateCounter = 0;

        var spinner1 = setInterval(function(){
          rotateCounter += 1;

          // console.log(rotateCounter*2);
          if (rotateCounter*2 >= 90) {
            clearInterval(spinner1); // this is not time-based now...

            bostongfx.visible = false;

            // now the real CS460 logo..
            create_cs460_logo();
            return;

          }

          bostongfx.transform.rotateY(rotateCounter*2);
        },100);



      };



      function create_cs460_logo() {

        document.getElementById('caption').style.display = 'block';

        // create a new X.object
        cs460logo = new X.object();

        // add the points, normals and colors
        //
        // this means 648000 / 3 == 216000 vertices
        // on my work machine I could set 24000000 / 3 == 8 mio vertices
        cs460logo.points = new X.triplets(648000);
        cs460logo.normals = new X.triplets(648000);
        cs460logo.colors = new X.triplets(648000);

        // and set the type to POINTS
        cs460logo.type = 'POINTS';

        // create the points, normals and colors
        for ( var x = 0; x < 60; x++) {
          for ( var y = 0; y < 60; y++) {
            for ( var z = 0; z < 60; z++) {

              cs460logo.points.add(x, y, z);
              cs460logo.normals.add(1, 1, 1);
              cs460logo.colors.add(x/60, y/60, z/60);

            }
          }
        }

        // add the object
        r.add(cs460logo);

        // setup the camera
        r.camera.position = [500, 500, 500];

        setTimeout(zoom_into_cs460logo, 2000);

      };



      function zoom_into_cs460logo() {

        var zoomer = setInterval(function() {

          // we can stop once we are far away enough
          if (r.camera.view[14] > 1000) {
            clearInterval(zoomer);
            // console.log('zooming done');

            setTimeout(function() {
              document.getElementById('caption').style.display = 'none';

              start_content();
            }, 2000);

            return;

          }

          // zoom in
          r.camera.zoomIn();

        }, 10);

      };


      function start_content() {

        // reduce music volume
        var music = document.getElementById('music');
        music.volume = .1;

        // activate speech
        var voice = document.getElementById('voice');
        voice.autoplay = true;
        voice.volume = 1;
        voice.load();

        frames = ['content1', 'content2', 'content3', 'content4', 'content5', null];
        times = [0, // Today...
                 1000, //
                 4200, // And
                 6000, //
                 10000, // this is lecture 19
                 14000];

        //
        // this is (like the whole animation concept), a little hacky!!
        //
        for (var f in frames) {

          setTimeout(function(f) {

            if (f > 0) {
              document.getElementById(frames[f-1]).style.display = 'none';
            }

            if (frames[f] != null) {
              document.getElementById(frames[f]).style.display = 'block';
            } else {
              music.volume = .1;

              setTimeout(function(f) {
                fadeout = setInterval(function(f) {
                  if (music.volume <= 0.) {
                    clearInterval(fadeout);
                    return;
                  }
                  music.volume -= .05;

                }, 500);
              },3000);


            }

          }.bind(this,f), times[f]);

        }

      };


    </script>
  </head>
  <body>
  <div style="visibility:hidden">
    <audio id='music'>
      <source src="bensound-evolution.mp3">
    </audio>
    <audio id='voice'>
      <source src="lecture23.mp3">
    </audio>
  </div>

  <div id='caption' style='display:none;position: absolute;color:white;top:45%;left:50%;margin-left:50px;font-size:440%'>CS460</div>

  <div id='content1' style='display:none;position: absolute;color:white;top:25%;left:30%;margin-left:50px;font-size:440%'>Today...</div>

  <div id='content2' style='display:none;position: absolute;color:white;top:30%;left:20%;margin-left:50px;font-size:440%'>We will learn more about animations..</div>

  <div id='content3' style='display:none;position: absolute;color:white;top:20%;left:10%;margin-left:50px;font-size:440%'>And...</div>

  <div id='content4' style='display:none;position: absolute;color:white;top:35%;left:20%;margin-left:50px;font-size:440%'>We will talk to an emmy winning prime-time animator!</div>

  <div id='content5' style='display:none;position: absolute;color:white;top:45%;left:40%;margin-left:50px;font-size:440%'>This is lecture 23.</div>

  </body>
</html>

1. Setup

2. UMB
400 ms

3. GFX
3200 ms

3. rotate
6200 ms

4. CS460
180°

5. zoom
2000 ms

6. content
camera.z > 1000

7. end
XXX ms

Lecture 24

Lecture 25

Texture Mapping

X

Y

0

0

width

height

U

V

0

0

1

1

Fragment Shader

Fragment Shader

Vertex Shader

vec2(      )

vec2(      )

vec2(       )

vec3 a_Position;

vec2 a_TexCoord;

vec2 v_TexCoord;

0, 0

1, 1

0, 1

u, v

varying

vec2 v_TexCoord;

varying

sampler2D u_Sampler;

Sampling

Nearest Neighbor

Linear

Interpolation

Lecture 26

Assignment 6

Normals

V1

V2

V3

V4

V6

V5

(x, y, z)

(x, y, z)

(x, y, z)

(x, y, z)

(x, y, z)

(x, y, z)

Vertex

/ Vertices

Face

Face

N1 (x, y, z)

N2 (x, y, z)

Face

Normals

V1

V2

V3

V4

V6

V5

(x, y, z)

(x, y, z)

(x, y, z)

(x, y, z)

(x, y, z)

(x, y, z)

Vertex

/ Vertices

Face

Face

N1 (x, y, z)

N2 (x, y, z)

Vertex

N3 (x, y, z)

N6 (x, y, z)

N5 (x, y, z)

N4 (x, y, z)

No Shading

Normals

used for Material

used for Lighting

No Normals

Face Normals

Vertex Normals

V1

V2

V3

Bump Map

Normals

Pixel

  var mesh = new THREE.SkinnedMesh( geometry, material );
  var skeleton = new THREE.Skeleton( bones );
  mesh.add( bones[ 0 ] );
  mesh.bind( skeleton );

5 Skinned Meshes

5 Cylinder Geometries

Lecture 27

GLTF

.gltf

.glb

STL

OBJ

PLY

Collada

.dae

.stl

.ply

.obj

And more:

Stereo Lithography (STL)

solid SOMENAME
   facet normal 1 0 0
      outer loop
         vertex 0 0 1
         vertex 1 0 0
         vertex 0 1 0
      endloop
   endfacet
   facet normal 1 0 0
      outer loop
         vertex 0 0 1
         vertex 1 1 0
         vertex 1 1 1
      endloop
   endfacet
   ...
endsolid

Face 1

Face 2

Stanford Polygon File (PLY)

ply
format ascii 1.0
comment i love cs460
element vertex 4
property float x
property float y
property float z
element face 3
property list uchar int vertex_index
end_header
0 0 0
0 0 1
0 1 1
0 1 0
3 0 1 2
3 1 2 3
3 1 2 4

Vertices

Faces

Header

Wavefront Object (OBJ)

Vertices

Faces

v -0.5 -0.5 0.5
v 0.5 -0.5 0.5
v -0.5 0.5 0.5
v 0.5 0.5 0.5
v -0.5 0.5 -0.5
v 0.5 0.5 -0.5
v -0.5 -0.5 -0.5
v 0.5 -0.5 -0.5
f 1 2 4
f 1 4 3
f 3 4 6
f 3 6 5
f 5 6 8
f 5 8 7
f 7 8 2
f 7 2 1
f 2 8 6
f 2 6 4
f 7 1 3
f 7 3 8
f 7 3 5

Lecture 28

Light Simulations

N (x, y, z)

Material

Scattering

controls the physical appearance

magic mode uses (x, y, z) as color

Lecture 29

Assignment 7

Light Simulations

N (x, y, z)

Material

Scattering

controls the physical appearance

+ Light

Material

Light

+

Color

Direction

Color

Orientation

Two things control the color of an object

Physically Based Rendering

var color = 0xFFFFFF;
var intensity = 1;
var light = new THREE.PointLight(color, intensity);
light.position.set(0, 10, 0);
scene.add(light);

//...
gui.add(light, 'distance', 0, 40)

Lecture 30

Mike Halle, PhD

medical and scientific visualization

openanatomy.org

Image Volumes

2D

3D

Slice-based Volume Rendering

Volume Rendering with Ray Casting

Cinematic Volume Rendering

Lecture 31

Marching Cubes creates 3D Meshes

Bill Lorensen 1987

Label Maps

Marching Cubes in 3D

Create triangles to approximate the shape

Inside

Outside

glTF

Graphics Layer Transmission Format

glTF can be:

JSON - based (.gtlf)

JSON - based (.gtlf) + external binary data (.bin)

only binary (.glb)

{

  // Functions are not allowed in JSON!
  // 'dance': function() {
    //...
  // },

  'head': 123,

  'parameter1': 456,

  'nested objects': {
    'another object': {
      'property1': true,
      'list of stuff': [1, 2, 'hello']
    }
  }

}

JSON

For Data Description

{
    "nodes": [
        {
            "mesh": 0
        }
    ],
    "scenes": [
        {
            "nodes": [
                0
            ]
        }
    ],
    "scene": 0
}
{
    // ...
    "meshes": [
        {
            "primitives": [
                 "mode": 4,
                 "attributes": {
                     "POSITION": 0
                 },
                 "indices": 1
            ]
        }
    ]
    "nodes": [
        {
            "mesh": 0
        }
    ],
    "scenes": [
        {
            "nodes": [
                0
            ]
        }
    ],
    "scene": 0
}

Accessors

{
    "accessors": [
        {
            "bufferView": 0,
            "byteOffset": 0,
            "componentType": 5126,
            "count": HOWMANY,
            "type": "VEC3",
            "max": [MAX_X, MAX_Y, MAX_Z],
            "min": [MIN_X, MIN_Y, MIN_Z]
        },
        {
            "bufferView": 1,
            "byteOffset": 0,
            "componentType": 5123,
            "count": HOWMANY,
            "type": "SCALAR",
            "max": [MAX],
            "min": [MIN]
        }
    ],


   // ...
}

Vertices

Indices

Float

U_Short

U_Int

{
    "accessors": [
        {
            "bufferView": 0,
            "byteOffset": 0,
            "componentType": 5126,
            "count": HOWMANY,
            "type": "VEC3",
            "max": [MAX_X, MAX_Y, MAX_Z],
            "min": [MIN_X, MIN_Y, MIN_Z]
        },
        {
            "bufferView": 1,
            "byteOffset": 0,
            "componentType": 5123,
            "count": HOWMANY,
            "type": "SCALAR",
            "max": [MAX],
            "min": [MIN]
        }
    ],


   // ...
}

Vertices

Indices

{
    // ...

    "bufferViews": [
        {
            "buffer": 0,
          	"byteOffset": 0,
            "byteLength": HOWMANYBYTES,
            "target": 34962
        },
        {
            "buffer": 1,
            "byteOffset": 0,
            "byteLength": HOWMANYBYTES,
            "target": 34963
        }
    ],
    "buffers": [
        {

        },
        {

        }
    ]

   // ...
}

ELEMENT_ARRAY_BUFFER

ARRAY_BUFFER

Lecture 32

Vulkan, OpenGL, and OpenGL ES renderers for the Source 2 engine used by games such as Dota 2, Artifact, and Dota Underlords

Quiz today!

Lecture 33

By Daniel Haehn

Lecture 33

Slides for CS460 Computer Graphics at UMass Boston. See https://cs460.org!

  • 59

More from Daniel Haehn
