Assignment 9
Due 11/27
glTF
Graphics Layer Transmission Format
glTF can be:
JSON - based (.gtlf)
JSON - based (.gtlf) + external binary data (.bin)
only binary (.glb)
JSON
JavaScript Object Notation
{
"meshes": [
{
"primitives": [
"mode": 4,
"attributes": {
"POSITION": 0
},
"indices": 1
]
}
],
"nodes": [
{
"mesh": 0
}
],
"scenes": [
{
"nodes": [
0
]
}
],
"scene": 0
}
{
"meshes": [
{
"primitives": [
"mode": 4,
"attributes": {
"POSITION": 0
},
"indices": 1
]
}
],
"nodes": [
{
"mesh": 0
}
],
"scenes": [
{
"nodes": [
0
]
}
],
"scene": 0
}
Triangles
Accessors
{
// ...
"meshes": [
{
"primitives": [
"mode": 4,
"attributes": {
"POSITION": 0
},
"indices": 1
]
}
],
"nodes": [
{
"mesh": 0
}
],
"scenes": [
{
"nodes": [
0
]
}
],
"scene": 0
}
{
"accessors": [
{
},
{
}
],
// ...
}
{
// ...
"meshes": [
{
"primitives": [
"mode": 4,
"attributes": {
"POSITION": 0
},
"indices": 1
]
}
],
"nodes": [
{
"mesh": 0
}
],
"scenes": [
{
"nodes": [
0
]
}
],
"scene": 0
}
{
"accessors": [
{
"bufferView": 0,
"byteOffset": 0,
"componentType": 5126,
"count": HOWMANY,
"type": "VEC3",
"max": [MAX_X, MAX_Y, MAX_Z],
"min": [MIN_X, MIN_Y, MIN_Z]
},
{
"bufferView": 1,
"byteOffset": 0,
"componentType": 5123,
"count": HOWMANY,
"type": "SCALAR",
"max": [MAX],
"min": [MIN]
}
],
// ...
}
Vertices
Indices
Float
U_Short
U_Int
{
"accessors": [
{
"bufferView": 0,
"byteOffset": 0,
"componentType": 5126,
"count": HOWMANY,
"type": "VEC3",
"max": [MAX_X, MAX_Y, MAX_Z],
"min": [MIN_X, MIN_Y, MIN_Z]
},
{
"bufferView": 1,
"byteOffset": 0,
"componentType": 5123,
"count": HOWMANY,
"type": "SCALAR",
"max": [MAX],
"min": [MIN]
}
],
// ...
}
Vertices
Indices
{
// ...
"bufferViews": [
{
},
{
}
],
"buffers": [
{
},
{
}
]
// ...
}
{
"accessors": [
{
"bufferView": 0,
"byteOffset": 0,
"componentType": 5126,
"count": HOWMANY,
"type": "VEC3",
"max": [MAX_X, MAX_Y, MAX_Z],
"min": [MIN_X, MIN_Y, MIN_Z]
},
{
"bufferView": 1,
"byteOffset": 0,
"componentType": 5123,
"count": HOWMANY,
"type": "SCALAR",
"max": [MAX],
"min": [MIN]
}
],
// ...
}
Vertices
Indices
{
// ...
"bufferViews": [
{
"buffer": 0,
"byteOffset": 0,
"byteLength": HOWMANYBYTES,
"target": 34962
},
{
"buffer": 1,
"byteOffset": 0,
"byteLength": HOWMANYBYTES,
"target": 34963
}
],
"buffers": [
{
},
{
}
]
// ...
}
ELEMENT_ARRAY_BUFFER
ARRAY_BUFFER
{
"accessors": [
{
"bufferView": 0,
"byteOffset": 0,
"componentType": 5126,
"count": HOWMANY,
"type": "VEC3",
"max": [MAX_X, MAX_Y, MAX_Z],
"min": [MIN_X, MIN_Y, MIN_Z]
},
{
"bufferView": 1,
"byteOffset": 0,
"componentType": 5123,
"count": HOWMANY,
"type": "SCALAR",
"max": [MAX],
"min": [MIN]
}
],
// ...
}
Vertices
{
// ...
"bufferViews": [
{
"buffer": 0,
"byteOffset": 0,
"byteLength": HOWMANYBYTES,
"target": 34962
},
{
"buffer": 1,
"byteOffset": 0,
"byteLength": HOWMANYBYTES,
"target": 34963
}
],
"buffers": [
{
"uri": "data:application/octet-stream;base64, ....",
"byteLength": HOWMANYBYTES
},
{
"uri": "data:application/octet-stream;base64, ....",
"byteLength": HOWMANYBYTES
}
]
// ...
}
ARRAY_BUFFER
ELEMENT_ARRAY_BUFFER
Indices
Indices Data
Vertices Data
[0.,0.,0., 0.,1.,0., 1.,0.,0.]
Base64
Encode bytes as string
"AAAAAAAAAAAAAAAAAAAAAAAAgD8AAAAAAACAPwAAAAAAAAAA"
"buffers": [
{
"uri": "data:application/octet-stream;base64,AAAAAAAAAAAAAAAAAAAAAAAAgD
8AAAAAAACAPwAAAAAAAAAA"
}
]
Base64
Decode strings to bytes
"AAAAAAAAAAAAAAAAAAAAAAAAgD8AAAAAAACAPwAAAAAAAAAA"
[0.,0.,0., 0.,1.,0., 1.,0.,0.]
// ...
"bufferViews": [
{
"buffer": 0,
"byteOffset": 0,
"byteLength": HOWMANYBYTES,
"target": 34962
},
// ...
// ...
"accessors": [
{
"bufferView": 0,
"byteOffset": 0,
"componentType": 5126,
"count": HOWMANY,
"type": "VEC3",
"max": [MAX_X, MAX_Y, MAX_Z],
"min": [MIN_X, MIN_Y, MIN_Z]
}
// ...
Base64
Decode strings to bytes
"AAAAAAAAAAAAAAAAAAAAAAAAgD8AAAAAAACAPwAAAAAAAAAA"
[0.,0.,0., 0.,1.,0., 1.,0.,0.]
// ...
"bufferViews": [
{
"buffer": 0,
"byteOffset": 0,
"byteLength": HOWMANYBYTES,
"target": 34962
},
// ...
// ...
"accessors": [
{
"bufferView": 0,
"byteOffset": 0,
"componentType": 5126,
"count": 3,
"type": "VEC3",
"max": [MAX_X, MAX_Y, MAX_Z],
"min": [MIN_X, MIN_Y, MIN_Z]
}
// ...
Base64
Decode strings to bytes
"AAAAAAAAAAAAAAAAAAAAAAAAgD8AAAAAAACAPwAAAAAAAAAA"
[0.,0.,0., 0.,1.,0., 1.,0.,0.]
// ...
"bufferViews": [
{
"buffer": 0,
"byteOffset": 0,
"byteLength": HOWMANYBYTES,
"target": 34962
},
// ...
// ...
"accessors": [
{
"bufferView": 0,
"byteOffset": 0,
"componentType": 5126,
"count": 3,
"type": "VEC3",
"max": [1., 1., 0.],
"min": [0., 0., 0.]
}
// ...
FLOAT
4 bytes, 4 bytes, 4 bytes, .....
32 bit
Base64
Decode strings to bytes
"AAAAAAAAAAAAAAAAAAAAAAAAgD8AAAAAAACAPwAAAAAAAAAA"
[0.,0.,0., 0.,1.,0., 1.,0.,0.]
// ...
"bufferViews": [
{
"buffer": 0,
"byteOffset": 0,
"byteLength": 36,
"target": 34962
},
// ...
// ...
"accessors": [
{
"bufferView": 0,
"byteOffset": 0,
"componentType": 5126,
"count": 3,
"type": "VEC3",
"max": [1., 1., 0.],
"min": [0., 0., 0.]
}
// ...
{
"accessors": [
{
"bufferView": 0,
"byteOffset": 0,
"componentType": 5126,
"count": HOWMANY,
"type": "VEC3",
"max": [MAX_X, MAX_Y, MAX_Z],
"min": [MIN_X, MIN_Y, MIN_Z]
},
{
"bufferView": 1,
"byteOffset": 0,
"componentType": 5123,
"count": HOWMANY,
"type": "SCALAR",
"max": [MAX],
"min": [MIN]
}
],
"bufferViews": [
{
"buffer": 0,
"byteOffset": 0,
"byteLength": HOWMANYBYTES,
"target": 34962
},
{
"buffer": 1,
"byteOffset": 0,
"byteLength": HOWMANYBYTES,
"target": 34963
}
],
"buffers": [
{
"uri": "data:application/octet-stream;base64, ....",
"byteLength": HOWMANYBYTES
},
{
"uri": "data:application/octet-stream;base64, ....",
"byteLength": HOWMANYBYTES
}
],
"meshes": [
{
"primitives": [{
"mode": 4,
"attributes": {
"POSITION": 0
},
"indices": 1
}]
}
],
"nodes": [
{
"mesh": 0
}
],
"scenes": [
{
"nodes": [
0
]
}
],
"scene": 0
}
