COMP6771

Advanced C++ Programming

Week 5.2

Smart Pointers

Author: Hayden Smith

In this lecture

Why?

Managing unnamed / heap memory can be dangerous, as there is always the chance that the resource is not released / free'd properly. We need solutions to help with this.

What?

Smart pointers
Unique pointer, shared pointer
Partial construction

Recap: RAII - Making unnamed objects safe

// myintpointer.h

class MyIntPointer {
 public:
  // This is the constructor
  MyIntPointer(int* value);

  // This is the destructor
  ~MyIntPointer();

 int* GetValue();

 private:
  int* value_;
};

// myintpointer.cpp
#include "myintpointer.h"

MyIntPointer::MyIntPointer(int* value): value_{value} {}

int* MyIntPointer::GetValue() {
  return value_
}

MyIntPointer::~MyIntPointer() {
  // Similar to C's free function.
  delete value_;
}

Don't use the new / delete keyword in your own code

We are showing for demonstration purposes

void fn() {
  // Similar to C's malloc
  MyIntPointer p{new int{5}};
  // Copy the pointer;
  MyIntPointer q{p.GetValue()};
  // p and q are both now destructed.
  // What happens?
}

demo551-safepointer.cpp

Smart Pointers

Ways of wrapping unnamed (i.e. raw pointer) heap objects in named stack objects so that object lifetimes can be managed much easier
Introduced in C++11
Usually two ways of approaching problems:
- unique_ptr + raw pointers ("observers")
- shared_ptr + weak_ptr/raw pointers

Type	Shared ownership	Take ownership
std::unique_ptr<T>	No	Yes
raw pointers	No	No
std::shared_ptr<T>	Yes	Yes
std::weak_ptr<T>	No	No

Unique pointer

std::unique_pointer<T>
- The unique pointer owns the object
- When the unique pointer is destructed, the underlying object is too
raw pointer (observer)
- Unique Ptr may have many observers
- This is an appropriate use of raw pointers (or references) in C++
- Once the original pointer is destructed, you must ensure you don't access the raw pointers (no checks exist)
- These observers do not have ownership of the pointer

Also note the use of 'nullptr' in C++ instead of NULL

Unique pointer: Usage

#include <memory>
#include <iostream>

int main() {
  auto up1 = std::unique_ptr<int>{new int};
  auto up2 = up1; // no copy constructor
  std::unique_ptr<int> up3;
  up3 = up2; // no copy assignment

  up3.reset(up1.release()); // OK
  auto up4 = std::move(up3); // OK
  std::cout << up4.get() << "\n";
  std::cout << *up4 << "\n";
  std::cout << *up1 << "\n";
}

demo552-unique1.cpp

Observer Ptr: Usage

#include <memory>
#include <iostream>

int main() {
  auto up1 = std::unique_ptr<int>{new int{0}};
  *up1 = 5;
  std::cout << *up1 << "\n";
  auto op1 = up1.get();
  *op1 = 6;
  std::cout << *op1 << "\n";
  up1.reset();
  std::cout << *op1 << "\n";
}

Can we remove "new" completely?

demo553-observer.cpp

Unique Ptr Operators

#include <iostream>
#include <memory>

auto main() -> int {
	// 1 - Worst - you can accidentally own the resource multiple
	// times, or easily forget to own it.
	// auto* silly_string = new std::string{"Hi"};
	// auto up1 = std::unique_ptr<std::string>(silly_string);
	// auto up11 = std::unique_ptr<std::string>(silly_string);

	// 2 - Not good - requires actual thinking about whether there's a leak.
	auto up2 = std::unique_ptr<std::string>(new std::string("Hello"));

	// 3 - Good - no thinking required.
	auto up3 = std::make_unique<std::string>("Hello");

	std::cout << *up2 << "\n";
	std::cout << *up3 << "\n";
	// std::cout << *(up3.get()) << "\n";
	// std::cout << up3->size();
}

This method avoids the need for "new". It has other benefits that we will explore.

demo554-unique2.cpp

Shared pointer

std::shared_pointer<T>
Several shared pointers share ownership of the object
- A reference counted pointer
- When a shared pointer is destructed, if it is the only shared pointer left pointing at the object, then the object is destroyed
- May also have many observers
  - Just because the pointer has shared ownership doesn't mean the observers should get ownership too - don't mindlessly copy it
std::weak_ptr<T>
- Weak pointers are used with share pointers when:
  - You don't want to add to the reference count
  - You want to be able to check if the underlying data is still valid before using it.

Shared pointer: Usage

#include <iostream>
#include <memory>

auto main() -> int {
	auto x = std::make_shared<int>(5);
	std::cout << "use count: " << x.use_count() << "\n";
	std::cout << "value: " << *x << "\n";
	x.reset(); // Memory still exists, due to y.
	std::cout << "use count: " << y.use_count() << "\n";
	std::cout << "value: " << *y << "\n";
	y.reset(); // Deletes the memory, since
	// no one else owns the memory
	std::cout << "use count: " << x.use_count() << "\n";
	std::cout << "value: " << *y << "\n";
}

Can we remove "new" completely?

demo555-shared.cpp

Weak Pointer: Usage

#include <iostream>
#include <memory>

auto main() -> int {
	auto x = std::make_shared<int>(1);

	auto wp = std::weak_ptr<int>(x); // x owns the memory

	auto y = wp.lock();
	if (y != nullptr) { // x and y own the memory
		// Do something with y
		std::cout << "Attempt 1: " << *y << '\n';
	}
}

demo556-weak.cpp

When to use which type

Unique pointer vs shared pointer
- You almost always want a unique pointer over a shared pointer
- Use a shared pointer if either:
  - An object has multiple owners, and you don't know which one will stay around the longest
  - You need temporary ownership (outside scope of this course)
  - This is very rare

Smart pointer examples

Linked list
Doubly linked list
Tree
DAG (mutable and non-mutable)
Graph (mutable and non-mutable)
Twitter feed with multiple sections (eg. my posts, popular posts)

Stack unwinding

Stack unwinding is the process of exiting the stack frames until we find an exception handler for the function
This calls any destructors on the way out
- Any resources not managed by destructors won't get freed up
- If an exception is thrown during stack unwinding, std::terminate is called

void g() {
  throw std::runtime_error{""};
}

int main() {
  auto ptr = new int{5};
  g();
  // Never executed.
  delete ptr;
}

void g() {
  throw std::runtime_error{""};
}

int main() {
  auto ptr = std::make_unique<int>(5);
  g();
}

Not safe

Safe

void g() {
  throw std::runtime_error{""};
}

int main() {
  auto ptr = new int{5};
  g();
  auto uni = std::unique_ptr<int>(ptr);
}

Not safe

Exceptions & Destructors

During stack unwinding, std::terminate() will be called if an exception leaves a destructor
The resources may not be released properly if an exception leaves a destructor
All exceptions that occur inside a destructor should be handled inside the destructor
Destructors usually don't throw, and need to explicitly opt in to throwing
- STL types don't do that

Partial construction

What happens if an exception is thrown halfway through a constructor?
- The C++ standard: "An object that is partially constructed or partially destroyed will have destructors executed for all of its fully constructed subobjects"
- A destructor is not called for an object that was partially constructed
- Except for an exception thrown in a constructor that delegates (why?)

#include <exception>

class my_int {
public:
   my_int(int const i) : i_{i} {
      if (i == 2) {
         throw std::exception();
      }
   }
private:
   int i_;
};

class unsafe_class {
public:
   unsafe_class(int a, int b)
   : a_{new my_int{a}}
   , b_{new my_int{b}}
   {}

  ~unsafe_class() {
    delete a_;
    delete b_;
  }
private:
   my_int* a_;
   my_int* b_;
};

int main() {
  auto a = unsafe_class(1, 2);
}

Spot the bug

demo557-bad.cpp

Partial construction: Solution

Option 1: Try / catch in the constructor
- Very messy, but works (if you get it right...)
- Doesn't work with initialiser lists (needs to be in the body)
Option 2:
- An object managing a resource should initialise the resource last
  - The resource is only initialised when the whole object is
  - Consequence: An object can only manage one resource
  - If you want to manage multiple resources, instead manage several wrappers , which each manage one resource

#include <exception>
#include <memory>

class my_int {
public:
   my_int(int const i)
   : i_{i} {
      if (i == 2) {
         throw std::exception();
      }
   }
private:
   int i_;
};

class safe_class {
public:
   safe_class(int a, int b)
   : a_(std::make_unique<my_int>(a))
   , b_(std::make_unique<my_int>(b))
   {}
private:
   std::unique_ptr<my_int> a_;
   std::unique_ptr<my_int> b_;
};

int main() {
  auto a = safe_class(1, 2);
}

demo558-partial1.cpp

Feedback
