Let's describe problem by use case

View counter for globally accessible resources (a.k.a. Youtube views counter)

We need replication

But how to keep state in sync?

We need replication

Publishing a video

We need replication

Updating view counter

X = 1

X = 2

X = ?

?

CAP Theorem

Partition tolerance

Consistency

Availability

CAP Theorem

X = 2

X = 3

X = 1

X = 1

Consistency

X = 2

X = 3

X = 1

X = 1

Availability

X = 2

X = 3

X = 2

X = 3

CRDTs

Highly available / Eventually consistent

It's all about Math

x • y = y • x

(x • y) • z = z • (y • z)

x • x = x

Idempotent

Associative

Commutative

Why does it matter?

So which operations meet that criteria?

Number addition?

• x + y = y + x
• (x + y) + z = x + (y + z)
• x + x ≠ x

So which operations meet that criteria?

Number max

• max(x, y) = max(y, x)
• max(max(x, y), z) = max(x, max(y, z))
• max(x, x) = x

So which operations meet that criteria?

Set union

• x ∪ y = y ∪ x
• (x ∪ y) ∪ z = x ∪ (y ∪ z)
• x ∪ x = x

CRDT types

• Commutative

• Convergent

CRDT libs/DBs

• (JVM) akka.ddata
• (Erlang VM) Riak
• (Elixir / Erlang VM) Phoenix Presence
• (Go) Roshi
• (Erlang VM) AntidoteDB
• (JVM) eventuate

G-Counter

Increment-only counter

G-Counter

// empty value
empty → { }

// increment - every replica increments
// only its own replica entry
inc({ a: 1, b: 1 }) → { a: 2, b: 1 }   // replica a ++

// merge - max number of all replicas
{ a: 2, b: 1 } ∪ { a: 1, b: 2 } → { a: 2, b: 2 }

// value - sum of all replicas
value({ a: 1, b: 2 }) → 3

PN-Counter

Increment/decrement counter

PN-Counter

Implementation

Just compose 2 G-Counters:

• increments
• decrements

G-Set

Growing-only set

Nothing to see here... just an ordinary set

// empty value - empty set
empty → {}

// add element
add({}, 123) → { 123 }

// merge - union sets
{ 123, 234 } ∪ { 234, 345 } → { 123, 234, 345 }

// value - just return a set
value({ 123, 234 }) → { 123, 234 }

What if we want to remove element?

// state of a G-Set on replicas A & B
A(X) → { 123, 234 }
B(X) → { 123, 234 }

// remove 123 on replica A
A(X) → { 234 }
B(X) → { 123, 234 }

// merge both replicas
A(X) ∪ B(X) → { 123, 234 }  // WRONG!

2P-Set

2 Phase (add/remove) set

Again... just compose 2 sets:

• add set
• rem set  a.k.a. tombstones

// empty value - 2 empty sets
empty → { add: {}, rem: {} }

// add element
X = add(empty, 123) → { add: { 123 }, rem: {} }
X = add(X, 234) → { add: { 123, 234 }, rem: {} }

// remove element
X = rem(X, 123) → { add: { 123, 234 }, rem: { 123 } }

// value - diff between add & rem
value(X) → { 234 }

// merge - union corresponding add/rem
X → { add: { 123, 234 }, rem: { 123 } }
Y → { add: { 123, 345 }, rem: {} }
X ∪ Y → { add: { 123, 234, 345 }, rem: { 123 } }

1. What if tombstones grow big?

2. What if we want to add removed element again?

Version vector

Should we relly on system timestamps?

Version vector

Logic time

C:1

B:1
C:1

B:2
C:1

A:1
B:2
C:1

A:2
B:2
C:1

B:3
C:1

A:2
B:4
C:1

B:3
C:2

A:2
B:5
C:1

A:2
B:5
C:4

B:3
C:3

A:3
B:3
C:3

A:2
B:5
C:5

A:4
B:5
C:5

A

B

C

Version vector

Comparison operator

Less

Greater

Equal

Concurrent

a:1
b:0
c:0

a:2
b:1
c:2

<

a:1
b:0
c:0

a:1
b:0
c:0

=

a:4
b:1
c:2

a:3
b:0
c:0

>

a:4
b:1
c:2

a:3
b:2
c:2

?!

Highly Available Transactions

Problem: how to keep consistency between different keys?

A

B

set(x=1)

set(y=1)

Highly Available Transactions

Read Atomic Transaction Isolation

• Synchronization independence
• Partition independence

RAMP-Fast

Introduction

Each record is identified by:

• key
• value
• metadata (dependencies)
• timestamp

RAMP-Fast

Writes

Prepare {X=1, ts:1, dep: [Y]}

Prepare {Y=1, ts:1, dep: [X]}

Prepared

Prepared

Commit {ts:1}

Commit {ts:1}

Committed

Committed

RAMP-Fast

Reads (happy case)

Get {X}

{X=1, ts:1, dep: [Y]}

{Y=1, ts:1, dep: [X]}

Get {Y}

RAMP-Fast

Reads (repair)

Get {X}

{X=1, ts:1, dep: [Y]}

{Y=0, ts:0, dep: []}

Get {Y}

Mismatch

Get {Y, ts:1}

{Y=1, ts:1, dep: [X]}
