How To Program Equivalence

Higher Inductive Type Approach

2022 James B. Wilson

Colorado State University

Problem: To a computer(...to you...), what is \[\mathbb{R}^4/\mathsf{Null}\left(\begin{bmatrix} 1 & 0 & 3 & 4 \\ 0 & 1 & 9 & -1\\0 & 0 & 0 & 0 \end{bmatrix}\right)?\]

An equivalence relation \[u\equiv v\Leftrightarrow \begin{bmatrix}1& 0 & 3 & 4\\ 0 & 1 & 9 & -1\\ 0 & 0 & 0 & 0\end{bmatrix}(u-v)=0?\]
The partition\[\left\{\left\{\begin{bmatrix}s\\ t\\ 0 \\ 0 \end{bmatrix} +\begin{bmatrix} -3 & -4\\ -9 & 1 \\ 1 & 0\\0 & 1\end{bmatrix}\begin{bmatrix}x\\y\end{bmatrix}\middle|x,y\in \mathbb{R}\right\}\middle|s,t\in\mathbb{R}\right\}?\]
A function \(\pi:\mathbb{R}^4\to \mathbb{R}^2\) where \[\pi(v)=\begin{bmatrix}1 & 0 & 3 & 4 \\ 0 & 1 & 9 & -1\end{bmatrix}v?\]

Problem: To a computer(...to you...), what is \[\mathbb{Q}[x]/(2+x^3)?\]

The partition\[\left\{a(x)+(2+x^3)\mid a(x)\in \mathbb{Q}[x]\right\}?\] Well computers can't really handle infinite sets.
An equivalence relation \[a(x)\equiv b(x)\Leftrightarrow (2+x^3)\mid (a(x)-b(x))?\] Trouble is, the computer still sees \(9+x+x^{3}\) and \(11+x\) as different...and so do most programs that use that data.
A function \(\pi:\mathbb{R}[x]\to \mathbb{M}_2(\mathbb{R})\) where \[\pi\left(\sum_{i} a_i x^9\right)=\sum_{i} a_i \begin{bmatrix} 0 & 0 & -2\\ 1 & 0 & 0\\ 0 & 1 & 0 \end{bmatrix}^i?\] Good enough, if you can guess such a function and don't mind the wasted memory and slower arithmetic.

Recall:

An Inductive Type Is "Polynomials"

(Under suitable conditions)

Polynomial=Induction

\((x+3)^2\)

\(x:=9\)

\((x+3)^2|_{x:=9} \rhd (9+3)^2\)

--- Borrow from context
import K:Comm, I:Type from Gamma
--- Make a new type
data Vec K I where ...

Free Module : FORMATION

\[\frac{K:Comm\qquad I:Set}{K^I:Type}\quad(F_{vec})\]

// Borrow from context
import K:Comm, I:Type from Gamma
// Make a new type
class Vec[K,I] { ... }

Procedural

Functional

\(K^I\)

\(I\)

\(\Gamma\vdash K,I\)

import K:Comm, I:Type from Gamma
data Vec K I where
  Unit : {K:Comm} -> {I:Type} -> (i:I) -> (Unit K I)

> Unit Float (Fin 3) 2
Unit 2 : Unit Float (Fin 3)

Free Module : INTRODUCTION

\[\frac{i:I}{e_i:K^I}\quad(I_{e-vec})\]

import K:Comm, I:Type from Gamma
class Vec[K,I]
case class Unit[K,I](i:I) extends Vec[K,I]

// e_2 in R^3
> e2 = new Unit[Float,range(3)](2)

Procedural

Functional

\(K^I\)

\(I\)

\(e\)

\(\Gamma\vdash K,I\)

import K:Comm, I:Type from Gamma
data Vec K I where
  Unit : {K:Comm} -> {I:Type} -> (i:I) -> (Vec K I)
   Sum : (u:Vec K I) -> (v:Vec K I) -> (Vec K I)
   Scl : (a:K) -> (u:Vec K I) -> (Vec K I)

Free Module : IMPLICIT INTRODUCTIONS

\[\frac{a:K\qquad u:K^I}{a*u:K^I}\quad(I_{*-vec})\]

import K:Comm, I:Type from Gamma
class Vec[K,I]
case class Unit[K,I](i:I) extends Vec[K,I]
case class Sum[K,I](u:Vec[K,I],v:Vec[K,I]) extends Vec[K,I]
case class Scl[K,I](a:K, u:Vec[K,I]) extends Vec[K,I]

Procedural

Functional

\[\frac{u,v:K^I}{u+v:K^I}\quad(I_{+-vec})\]

Multiple intros called "Inductive Type"

import K:Comm, I:Type from Gamma
data Vec K I where
  Unit : (i:I) -> (Vec K I)
   Sum : (u:Vec K I) -> (v:Vec K I) -> (Vec K I)
   Scl : (a:K) -> (u:Vec K I) -> (Vec K I)

--- The Universal Mapping Property
umap:{U:Mod}->(Vec K I)->(f:I->U)->U

Free Module : ELIMINATION

import K:Comm, I:Type from Gamma
class Vec[K,I] {
  // Universal Mapping Property
  abstract def umap[U<:Mod[K]](f:I->U):U
}
case class Unit(i:I) extends Vec[K,I]
case class Sum(u:Vec[K,I],v:Vec[K,I]) extends Vec[K,I]
case class Scl(a:K, u:Vec[K,I]) extends Vec[K,I]

Procedural

Functional

\[\frac{v:K^I\quad U:{_K Mod}\quad f:I\to U}{\hat{f}(v):U}\quad(E_{vec})\]

\(K^I\)

\(I\)

\(e\)

\(U\)

\(\exists!\hat{f}\)

\(f\)

\(\Gamma\vdash K,I\)

import K:Comm, I:Type from Gamma
data Vec K I where
  Unit : (i:I) -> (Vec K I)
   Sum : (u:Vec K I) -> (v:Vec K I) -> (Vec K I)
   Scl : (a:K) -> (u:Vec K I) -> (Vec K I)

umap:(U:Mod)->(Vec K I)->(f:I->U)->U
---Implement the computation
umap U (Unit i) f  = f i

Free Module : COMPUTATION

import K:Comm, I:Type from Gamma
class Vec[K,I] {
  abstract def umap[U<:Mod[K]](f:I->U):U
}
case class Unit(i:I) extends Vec[K,I] {
  // Implement the computation
  override def umap(f:I->U):U = f(i)
}
case class Sum(u:Vec[K,I],v:Vec[K,I]) extends Vec[K,I]
case class Scl(a:K, u:Vec[K,I]) extends Vec[K,I]

Procedural

Functional

\[\frac{i:I\quad U:{_K Mod}\quad f:I\to U}{\hat{f}(e_i)=f(i)}\quad(C_{e-vec})\]

\(K^I\)

\(I\)

\(e\)

\(U\)

\(\exists!\hat{f}\)

\(f\)

\(\Gamma\vdash K,I\)

import K:Comm, I:Type from Gamma
data Vec K I where
  Unit : (i:I) -> (Vec K I)
   Sum : (u:Vec K I) -> (v:Vec K I) -> (Vec K I)
   Scl : (a:K) -> (u:Vec K I) -> (Vec K I)

--- The Universal Mapping Property
umap:(U:Mod)->(Vec K I)->(f:I->U)->U
umap U (Unit i) f  = f i
umap U (Sum x y) f = (umap U x f)+(umap U y f)
umap U (Scl a x) f = a*(umap U x f)

Free Module : IMPLICIT COMPUTATION

import K:Comm, I:Type from Gamma
class Vec[K,I] {
  abstract def umap[U<:Mod[K]](f:I->U):U
}
case class Unit(i:I) extends Vec[K,I] {
  override def umap(f:I->U):U = f(i)
}
case class Sum(u:Vec[K,I],v:Vec[K,I]) extends Vec[K,I] {
  override def umap(f:I->U):U = u.umap(f)+v.umap(f)
}
case class Scl(a:K, u:Vec[K,I]) extends Vec[K,I]{
  override def umap(f:I->U):U = a*u.umap(f)
}

Procedural

Functional

\[\frac{u,v:K^I\quad U:{_K Mod}\quad f:I\to U}{\hat{f}(u+v)=f(u)+f(v)}\quad(C_{+-vec})\]

\[\frac{a:K\quad v:K^I\quad U:{_K Mod}\quad f:I\to U}{\hat{f}(a*v)=a*f(v)}\quad(C_{*-vec})\]

Summary

Functions defined from recursion are "unique" only if we compare function input-to-ouput (extensional) instead of step-by-step (intentional)
Extensional Type Theory undecidable.
Intentional Type Theory decidable but recursion has room for programs to tinker (Loops, folds, zips, trampolines...)

Technicalities

UMPs give types
Free UMP gives inductive type

Idea:

A Quotient Type Is "Polynomials with rewriting rules"

That's a lousy solution

Under the hood

// [ 3.14159, 2.71828]
v = Sum( Scl(3.14159, Unit(1)), Scl(2.71828, Unit(2))

Bulky syntax, but that can be fixed with a function; let that go.

HEAP

type:"Scl099F"
a0001: 0000 0003, 0000 374F
v0001: 7F66 A008

type:"Tree07A2"
l0001: 7F66 9800
r0001: 7F66 A000

type:"class"
name:"Vec001B"
K2B01:"Float64"
I0458:"FinAA03"
meth1:"eval"
+p1:"func"<X,Y>
+p2:K2B01
-r:<Y>

type:"Vec001B"
K2B01:"Float64"
I0458:"FinAA03"

type:"class"
name:"Unit70E0"
sup:"Vect001B"

type:"Vec001B"
K2B01:"Float64"
I0458:"FinAA03"

type:"class"
name:"FinAA03"
I0001:0000 0003

    ....

type:"Unit07A2"
i0001: 0000 0001

type:"Unit07A2"
i0001: 0000 0002

type:"Scl099F"
a0001: 0000 0002, 0001 1894
v0001: 7F66 A001

type:"foo9056"
...

type:"foo9056"
...

type:"foo9056"
...

type:"bazEE01"
...

type:"Tree07A2"
l0001: 7F66 9805
r0001: 7F66 A001

type:"Tree07A2"
l0001: 7F66 9801
r0001: 7F66 98A2

    ....

What you intend

// [ 3.14159, 2.71828]
v = Sum( Scl(3.14159, Unit(1)), Scl(2.71828, Unit(2))

HEAP

type:"Tree07A2"
l0001: 7F66 9800
r0001: 7F66 A000

type:"class"
name:"Vec001B"
K2B01:"Float64"
I0458:"FinAA03"
meth1:"eval"
+p1:"func"<X,Y>
+p2:K2B01
-r:<Y>

type:"Vec001B"
K2B01:"Float64"
I0458:"FinAA03"

type:"class"
name:"Unit70E0"
sup:"Vect001B"

type:"Vec001B"
K2B01:"Float64"
I0458:"FinAA03"

type:"class"
name:"FinAA03"
I0001:0000 0003

    ....

type:"vev009E"

a0001: 0000 0003, 0000 374F
a0001: 0000 0002, 0001 1894

type:"foo9056"
...

type:"foo9056"
...

type:"foo9056"
...

type:"bazEE01"
...

type:"Tree07A2"
l0001: 7F66 9805
r0001: 7F66 A001

    ....

Many designs

Blocks: keeping data together that is used together
Packing: fill in the 0000
Packeting: Size data to move through machine fast.
Flyweights: scrapping headers
...branch predictions, precomputing, reusing ...

Our design is terrible

So why are we so smug?

Scenario

We made a free-module type: MyVec
Engineers will make MUCH better ones: FactVec
PROBLEM: convert between them.

Mathematical detour

Prop. Any two free modules on \(I\) are naturally isomorphic.

Proof. Let \(\langle F_k, e^{(k)}:I\to F_k\rangle\) be free.

Then \(e^{(2)}:I\to F_2\) induces a linear map \(\hat{e}_2:F_1\to F_2\) and vice-versa \(\hat{e}^{(1)}:F_2\to F_1\). Furthermore \(\hat{e}_1\circ \hat{e}_2\circ e^{(1)}=e^{(1)}\). But so does the identity, so by uniqueness of UMP, \[\hat{e}_1\circ \hat{e}_2=id_{F_1}.\] Likewise if we reverse the composition. So these functions are isomorphisms.

Return to Code

Prop. Any two free modules on \(I\) are naturally isomorphic.

Proof. Let \(\langle F_k, e^{(k)}:I\to F_k\rangle\) be free.

PROOFS CARRY ALGORITHMIC CONTENT

(Curry-Howard Isomorphism Theorem)

Solution (from proof)

> my_u:MyVec[K,I] = ...
> f:I->YourVec[K,I] = i -> YourUnit[K,I](i)
> your_u = my_u.ump(f)

Prop. Any two free modules on \(I\) are naturally isomorphic.

Proof. Let \(\langle F_k, e^{(k)}:I\to F_k\rangle\) be free.

~~Then~~ \(e^{(2)}:I\to F_2\) induces a linear map \(\hat{e}_2:F_1\to F_2\) and vice-versa \(\hat{e}^{(1)}:F_2\to F_1\). ~~Furthermore \(\hat{e}_1\circ \hat{e}_2\circ e^{(1)}=e^{(1)}\). But so does the identity, so by uniqueness of UMP,~~ \[\hat{e}_1\circ \hat{e}_2=id_{F_1}.\] ~~Likewise if we reverse the composition. So these functions are isomorphisms.~~

Summary

Start with UMP, even a basic implementation
Later upgrades achieved automatically by UMP theory of essential uniqueness
Other UMP properties:
- Preserved under functors \(\Rightarrow\) Less re-programming.
- Unified naming/conventions \(\Rightarrow\) Less fatal style wars; easier to read other's work, easy to pass on.

Higher Inductive Types

By James Wilson

Higher Inductive Types

Using universal mapping properties to prescribe data types and using resulting theory to build useful algorithms.
