History of Browser 3D Graphics

• VRML
• X3D
• Web3D

Virtual Reality Markup Language

• Web3D Consortium standard
• Version 1.0 defined in 1994
• Version 2.0 defined in 1997
• Poor adoption due to technological limitations
• Still available as third-party browser addons: OpenVRML, Cortona3D, etc.

X3D

• ISO Standard since 2004
• VRML successor with vastly enriched feature set:
  • CAD, Geospatial, NURBS
  • Advanced shading, rendering and optimization techniques
  • DOM & XPath support
• Multiple scene formats (XML, binary, OpenInventor)
• Currently available as an HTML5/WebGL shim for X3DOM support

Web3D

• Umbrella term for various technologies for displaying 3D content and Virtual Reality in the browser
• Adobe Shockwave (plugin)
• Java ecosystem: Java 3D, JavaFX, JOGL (plugin)
• Unity (plugin/native)
• Unreal Engine, asm.js (native)
• Blender ecosystem: Burster, Blend4Web (plugin/native)
• WebGL (native)

WebGL

• Designed and maintained by Khronos Group
• First standard released March 2011
• Based on OpenGL ES 2.0
• WebGL 2 in progress as we speak

WebGL (contd.)

• GPU processing for the masses
• Mix-n-match with other HTML elements
• Exposed through HTML5 Canvas context
• About 67% browser support (source: caniuse.com), including most of the mobile browsers
• JavaScript control code + GLSL shaders
• Usage-agnostic, complex API aimed at platform creators, see API reference card:
  http://www.khronos.org/files/webgl/webgl-reference-card-1_0.pdf
• No built-in support for content formats

WebGL Rendering Pipeline

• JavaScript code feeds geometry information and custom data buffers into the WebGL subsystem
• GLSL shader programs execute on the GPU:
  • Vertex shader generates point screen coordinates for each geometry vertex and saves it in the gl_Position variable
  • Fragment shader generates a color for each of these points and saves it in the gl_FragColor variable
• Variables (uniforms, attributes and varyings) store and transport data:
  • between JavaScript and shader programs
  • between vertex and fragment shaders
• Frame buffers contain the final rendering result

WebGL Workflow

1. Acquire & prepare rendering context:
   document.getElementById('canvas').getContext('webgl')
2. Load shaders from <script> tags or external files
3. Compile shaders:
   createShader, shaderSource, shaderCompile
4. Setup shader program:
   createProgram, attachShader, linkProgram, useProgram
5. Setup shader variables:
   getAttribLocation, enableVertexAttribArray, getUniformLocation
6. Transfer vertex data (Vertex Buffer Objects):
   createBuffer, bindBuffer, bufferData/bufferSubData
7. Setup textures:
   createTexture, bindTexture, texImage2D, texParameteri
8. Draw!
   drawArrays, drawElements

Sample Shaders

attribute vec3 aVertexPosition;
attribute vec4 aVertexColor;

// model-view matrix
uniform mat4 uMVMatrix;
// projection matrix
uniform mat4 uPMatrix;

varying vec4 vColor;

void main(void) {
    gl_Position =
        uPMatrix *
        uMVMatrix *
        vec4(aVertexPosition, 1.0);
    vColor = aVertexColor;
}

Vertex Shader

Fragment Shader

varying vec4 vColor;

void main(void) {
    gl_FragColor = vColor;
}

Higher-level Frameworks

• WebGL by itself is quite cumbersome and unstructured for usage in complex projects
• It provides too little in terms of:
  • scene organization
  • transformations
  • 3D content support
  • advanced shading and effects
  • animation
  • physics
• Frameworks to the rescue: Three.js, Babylon.js, etc.

Three.js

• Open-source, started in 2009 as an ActionScript framework
• Modular architecture, supports Canvas2D and SVG rendering modes alongside WebGL

• Provides scene graph, object hierarchy and transformations and content loaders for multiple 3D file formats
• Provides camera, projections and raycasting utilities
• Provides a lot of built-in geometry types as well as a high-performance raw buffer geometry
• Provides particle systems
• Provides shading models called "materials" and implements a few of the popular ones
• Support for animation, post-processing filters, custom shaders, advanced rendering modes and a lot more

• Will revisit later in detail + demo

Babylon.js

• Open-source, built by Microsoft in 2013 to showcase IE11 WebGL support
• Particular focus on game development

• Provides scene graph, object hierarchy and transformations and content loaders for several 3D file formats
• Provides camera, projections and user interaction controls
• Provides sprites and particle systems
• Provides physics and collision detection
• Very good performance through various optimizations
• Unified material model with multiple shading features
• Support for animation, post-processing filters, custom shaders, advanced rendering modes and a lot more

Other WebGL Frameworks

• Turbulenz: open-source/commercial 2D & 3D game engine with frontend and backend API for advanced rendering, physics, networking, sound, input, game components, etc.
• Pixi.js: open-source 2D rendering engine with Canvas2D fallback, scene graph & asset loader, handles input and animation, very simple API
• CopperLicht: free 3D rendering engine, has built-in world editor (CopperCube), supports multiple 3D file formats, lots of advanced rendering features, handles input, animation and simple physics
• GLGE: open-source 3D rendering engine, has some advanced rendering features, supports animation & COLLADA file format
• MathBox: math diagramming with WebGL
• Unreal Engine, Unity, Blend4Web, Processing.js, Kuda, O3D, SpiderGL, PhiloGL, etc. - possibilities are endless... Yay WebGL!

Three.js demo

• Renderer, Camera & Render Loop
• Lights
• Geometry
• Materials & Shaders
• Meshes & Particle Systems
• Interaction

• Live demo at:
  https://weber.chaosgroup.com/threejs-webinar
• Code available at:
  https://github.com/olygofren/threejs-webinar
• Tips & Tricks at the end
• Q&A at the very end

Renderer, Camera & Render Loop

• creating and configuring THREE.WebGLRenderer
• creating and configuring THREE.PerspectiveCamera
• creating a THREE.Scene
• setting up a render loop and animation
  • animate camera movement
  • animate snow accumulation (revisit after particle system)
• handling resize and full-screen rendering

All of the above provided by the excellent ThreeStrap library.

Manually setting up "sky", shadow map and fog.

Lights

• AmbientLight for atmosphere
  • low intensity, otherwise scene will be drowned in light
  • works well with fog in this scene
• SpotLight to simulate (weak) sunlight
  • must configure shadow map settings to cast shadows

Geometry

• Procedurally generated terrain
  • using Diamond-Square algorithm
  • based on a PlaneGeometry
  • recompute normals for correct shading

Materials & Shaders

• Ground material
  • simple texture map (repeated)
• Snow material
  • texture map based on Canvas (cool, eh?)
  • bump map
  • transparency
• Ray material
  • very simple custom shader material
  • shaders defined in <script> tag
  • passing time and texture as uniforms

Meshes & Particle Systems

• Ground and snow share the same geometry
  • but use different materials
  • cast shadow, receive shadow
• Falling snow uses a particle system
  • recently renamed to PointCloud
  • positions generated at random
  • using a simple snowflake texture
  • adding vertex colors for some variability

Interaction

• Handle mouse events in the standard JavaScript/DOM way
• Use mouse coordinates to intersect with terrain
• Draw on texture canvas using intersection coordinates
