Week 3
Software Development Life Cycle, Steps 4-6
Fraction Project
Update the parameterized constructor to call the setter methods to validate the input, rather than potentially assigning invalid values to the attributes.
public Fraction(int numerator, int denominator) {
setNumerator(numerator);
setDenominator(denominator);
}The following assertions seem logical, but they don't fully test it.
To correctly test the greatest common denominator of two integers, we must test for positive and negative values.
Call assertTrue by passing a single boolean expression.
@Test
void gcdWithNegatives() {
// Act
int result1 = Fraction.gcd(5, 7);
int result2 = Fraction.gcd(-5, 7);
int result3 = Fraction.gcd(5, -7);
int result4 = Fraction.gcd(-5, -7);
// Assert
assertTrue(result1 == result2 && result2 == result3 && result3 == result4);
}@Test
void gcd() {
// Act and assert
assertEquals(15, Fraction.gcd(75, 45));
assertEquals(2, Fraction.gcd(2, 4));
assertEquals(1, Fraction.gcd(5, 7));
}We will use this solution.
If you run the unit test now, it will fail.
Update the Fraction class gcd method to return Math.abs(a).
public static int gcd(int a, int b) {
if (b == 0) {
return Math.abs(a);
}
return gcd(b,a % b);
}Continued from Week 2
We ended day 4 talking about the lcm() method.
To test the lcm method, we should consider several cases:
Two standard positive integers.
Two prime numbers.
Cases where one number is a multiple of the other.
Cases involving the number 1.
Edge cases, such as involving the number 0.
We can break each case into a separate @Test method.
We can add a @DisplayName annotation to explain its purpose.
The fundamental rule of unit testing is "one test tests one thing." In the previous examples, if the first assertEquals fails, the second test never runs, potentially hiding another bug.
@Test
@DisplayName("Test LCM with two positive integers")
void testLcmWithPositiveIntegers() {
assertEquals(24, Fraction.lcm(6, 8));
}
@Test
@DisplayName("Test LCM where one number is a multiple of the other")
void testLcmWithMultiple() {
assertEquals(12, Fraction.lcm(4, 12));
}
@Test
@DisplayName("Test LCM with two prime numbers")
void testLcmWithPrimes() {
// The lcm of two prime numbers is their product.
assertEquals(77, Fraction.lcm(7, 11));
}
@Test
@DisplayName("Test LCM with the number 1")
void testLcmWithOne() {
assertEquals(9, Fraction.lcm(1, 9));
assertEquals(9, Fraction.lcm(9, 1));
}
@Test
@DisplayName("Test LCM with identical numbers")
void testLcmWithIdenticalNumbers() {
assertEquals(5, Fraction.lcm(5, 5));
}
@Test
@DisplayName("Test LCM where one of the inputs is zero")
void testLcmWithZero() {
assertEquals(0, Fraction.lcm(10, 0));
assertEquals(0, Fraction.lcm(0, 10));
assertEquals(0, Fraction.lcm(0, 0));
}We will use this solution.
The best approach is reduction by the GCD.
Add a simple if statement to get the test where one of the inputs is zero to pass.
​Without it, the test will encounter an ArithmeticException because it cannot divide by 0.
public static int lcm(int a, int b) {
if (a == 0 || b == 0) {
return 0;
}
return a * (b / gcd(a, b));
}@Test
@DisplayName("Test 1/1 + 2/3 = 5/3")
void addWholeNumberToFraction() {
// Act
Fraction result = f1.add(f2);
// Assert
assertEquals(5, result.getNumerator());
assertEquals(3, result.getDenominator());
}
@Test
@DisplayName("Test -1/4 + 2/3 = 5/12")
void addNegativeFractionToPositive() {
// Arrange
f1 = new Fraction(25, -100); // Represents -1/4
f2 = new Fraction(-10, -15); // Represents 2/3
// Act
Fraction result = f1.add(f2);
// Assert
assertEquals(5, result.getNumerator());
assertEquals(12, result.getDenominator());
}
@Test
@DisplayName("Test 1/4 + 1/4 = 1/2")
void addFractionsThatNeedSimplification() {
// Arrange
f1 = new Fraction(1, 4);
f2 = new Fraction(1, 4);
// Act
Fraction result = f1.add(f2);
// Assert
assertEquals(1, result.getNumerator());
assertEquals(2, result.getDenominator());
}@Test
@DisplayName("Test 1/1 - 2/3 = 1/3")
void subtractWholeNumberToFraction() {
// Act
Fraction result = f1.subtract(f2);
// Assert
assertEquals(1, result.getNumerator());
assertEquals(3, result.getDenominator());
}
@Test
@DisplayName("Test -1/4 - 2/3 = -11/12")
void subtractNegativeFractionToPositive() {
// Arrange
f1 = new Fraction(25, -100); // Represents -1/4
f2 = new Fraction(-10, -15); // Represents 2/3
// Act
Fraction result = f1.subtract(f2);
// Assert
assertEquals(-11, result.getNumerator());
assertEquals(12, result.getDenominator());
}
@Test
@DisplayName("Test 1/4 - 1/4 = 0/1")
void subtractFractionsThatNeedSimplification() {
// Arrange
f1 = new Fraction(1, 4);
f2 = new Fraction(1, 4);
// Act
Fraction result = f1.subtract(f2);
// Assert
assertEquals(0, result.getNumerator());
assertEquals(1, result.getDenominator());
}public Fraction add(Fraction other) {
int newNumerator = this.numerator * other.denominator + this.denominator * other.numerator;
int newDenominator = this.denominator * other.denominator;
Fraction result = new Fraction(newNumerator, newDenominator);
result.simplify();
return result;
}
public Fraction subtract(Fraction other) {
int newNumerator = this.numerator * other.denominator - this.denominator * other.numerator;
int newDenominator = this.denominator * other.denominator;
Fraction result = new Fraction(newNumerator, newDenominator);
result.simplify();
return result;
}flowchart TD
A@{ shape: circle, label: "Start" } --> B@{ shape: lean-r, label: "Input Fraction 1 (n1/d1)<br>Input Fraction 2 (n2/d2)" };
B --> C@{ shape: rect, label: "Set new numerator by cross multiplying<br>(n1 * d2 + d1 * n2)" };
C --> D@{ shape: rect, label: "Set new denominator<br>(d1 * d2)" };
D --> E@{ shape: rect, label: "Display result as a simplified mixed number" };
E --> F@{ shape: circle, label: "End" };
@Test
void simplifyNumeratorGreaterThanDenominator() {
f1.setNumerator(75);
f1.setDenominator(45);
f1.simplify();
assertEquals("5/3",f1.toString());
}
@Test
void simplifyNumeratorLessThanDenominator() {
f1.setNumerator(2);
f1.setDenominator(4);
f1.simplify();
assertEquals("1/2",f1.toString());
}
@Test
void simplifyPrimeNumbers() {
f1.setNumerator(5);
f1.setDenominator(7);
f1.simplify();
assertEquals("5/7",f1.toString());
}@Test
void simplifyNegativeNumerator() {
f1.setNumerator(-2);
f1.setDenominator(4);
f1.simplify();
assertEquals("-1/2",f1.toString());
}
@Test
void simplifyNegativeDenominator() {
f1.setNumerator(2);
f1.setDenominator(-4);
f1.simplify();
assertEquals("-1/2",f1.toString());
}
@Test
void simplifyNegativeNumeratorAndDenominator() {
f1.setNumerator(-2);
f1.setDenominator(-4);
f1.simplify();
assertEquals("1/2",f1.toString());
}Find the greatest common divisor of the Fraction object's numerator and denominator.
Update the numerator to be the current numerator divided by the greatest common divisor
Update the denominator to be the current denominator divided by the greatest common divisor.
public void simplify() {
int gcd = gcd(numerator, denominator);
numerator /= gcd;
denominator /= gcd;
}Below is a set of assertions to test the toMixedNumber method.
@Test
void toMixedNumber1Over1() {
assertEquals("1", f1.toMixedNumber(), "1/1 should be 1");
}
@Test
void toMixedNumber0Over1() {
f1.setNumerator(0);
assertEquals("0", f1.toMixedNumber(), "0/1 should be 0");
}
@Test
void toMixedNumberNotImproper() {
assertEquals("2/3", f2.toMixedNumber(), "2/3 should be 2/3");
}
@Test
void toMixedNumberIsImproper() {
f1.setNumerator(7);
f1.setDenominator(4);
assertEquals("1 3/4", f1.toMixedNumber(), "7/4 should be 1 3/4");
}
@Test
void toMixedNumberIsImproperNegative() {
f1.setNumerator(-7);
assertEquals("-1 3/4", f1.toMixedNumber(), "-7/4 should be -1 3/4");
}public String toMixedNumber() {
simplify();
if(denominator == 1) {
return numerator + "";
} else {
return toString();
}
}public String toMixedNumber() {
simplify();
if(denominator == 1) {
return numerator + "";
} else if(Math.abs(numerator) > denominator) {
int wholeNumber = Math.abs(numerator) / denominator;
int remainder = Math.abs(numerator) % denominator;
return (numerator < 0 ? "-" : "") + wholeNumber + " " + remainder + "/" + denominator;
} else if(numerator == 0) {
return "0";
} else {
return toString();
}
}Below is a possible implementation of the toMixedNumber method.
public String toMixedNumber() {
simplify();
if(denominator == 1) {
return numerator + "";
} else if(Math.abs(numerator) > denominator) {
int wholeNumber = Math.abs(numerator) / denominator;
int remainder = Math.abs(numerator) % denominator;
return (numerator < 0 ? "-" : "") + wholeNumber + " " + remainder + "/" + denominator;
} else if(numerator == 0) {
return "0";
} else {
return toString();
}
}@Test
void compareToEqual() {
f2 = new Fraction();
assertEquals(0, f1.compareTo(f2), "1/1 == 1/1");
f2 = new Fraction(2, 2);
assertEquals(0, f1.compareTo(f2), "1/1 == 2/2");
}
@Test
void compareToGreaterThan() {
f2 = new Fraction(1,2);
assertTrue(f1.compareTo(f2) > 0, "1/1 > 1/2");
f2 = new Fraction(2,4);
assertTrue(f1.compareTo(f2) > 0, "1/1 > 2/4");
}
@Test
void compareToLessThan() {
f2 = new Fraction(1,2);
assertTrue(f2.compareTo(f1) < 0, "1/2 < 1/1");
f2 = new Fraction(2,4);
assertTrue(f2.compareTo(f1) < 0, "2/4 < 1/1");
}
@Test
@DisplayName("Test comparison with negative fractions (-1/2 vs 1/4)")
void compareToWithNegativeFractions() {
Fraction f1 = new Fraction(-1, 2);
Fraction f2 = new Fraction(1, 4);
Fraction f3 = new Fraction(-3, 4);
assertTrue(f1.compareTo(f2) < 0, "-1/2 is less than 1/4");
assertTrue(f2.compareTo(f1) > 0, "1/4 is greater than -1/2");
assertTrue(f3.compareTo(f1) < 0, "-3/4 is less than -1/2");
}n1/d1 and n2/d2) is to use cross-multiplication. n1/d1 vs n2/d2 is equivalent to comparing the integer results of n1 * d2 vs n2 * d1.@Override
public int compareTo(Fraction o) {
long thisNumerator = (long)this.numerator;
long thisDenominator = (long)this.denominator;
long otherNumerator = (long)o.numerator;
long otherDenominator = (long)o.denominator;
long a = thisNumerator * otherDenominator;
long b = otherNumerator * thisDenominator;
return Long.compare(a, b);
}@Override
public boolean equals(Object other)
{
boolean isEqual = false;
if (this != null && other != null)
{
if (this instanceof Fraction && other instanceof Fraction)
{
isEqual = ((this.getNumerator() == ((Fraction) other).getNumerator()) &&
(this.getDenominator() == ((Fraction) other).getDenominator()));
}
}
return isEqual;
}@Test
void equals() {
f2 = new Fraction();
assertTrue(f1.equals(f2), "1/1 == 1/1");
}
@Test
void equalsNotSimplified() {
f2 = new Fraction(2, 2);
assertTrue(f1.equals(f2), "1/1 == 2/2");
}@Override
public boolean equals(Object other)
{
boolean isEqual = false;
if (this != null && other != null)
{
if (this instanceof Fraction && other instanceof Fraction)
{
this.simplify();
((Fraction)other).simplify();
isEqual = ((this.getNumerator() == ((Fraction) other).getNumerator()) &&
(this.getDenominator() == ((Fraction) other).getDenominator()));
}
}
return isEqual;
}Create a new package: "edu.kirkwood.view".
In the "view" package, create three classes that were used in the Java 1 project: "UserInput", "UIUtility", and "Helpers".
The UserInput class contains overloaded methods to get integers, Strings, booleans, doubles, and dates from the user via keyboard input.
package edu.kirkwood.view;
import java.time.LocalDate;
import java.time.format.DateTimeFormatter;
import java.time.format.DateTimeParseException;
import java.util.Scanner;
import static edu.kirkwood.view.Helpers.formatDateLong;
import static edu.kirkwood.view.Helpers.isValidString;
import static edu.kirkwood.view.UIUtility.displayError;
public class UserInput {
private static Scanner scanner = new Scanner(System.in);
public static Integer getInt(String prompt) {
return getInt(prompt, true, Integer.MIN_VALUE, Integer.MAX_VALUE);
}
public static Integer getInt(String prompt, boolean required) {
return getInt(prompt, required, Integer.MIN_VALUE, Integer.MAX_VALUE);
}
public static Integer getInt(String prompt, boolean required, int min) {
return getInt(prompt, required, min, Integer.MAX_VALUE);
}
public static int getInt(String prompt, boolean required, int min, int max) {
int value = 0;
String minMax = "";
// if min is set and max is not set
if(min != Integer.MIN_VALUE && max == Integer.MAX_VALUE) {
minMax = String.format(" [minimum %d]", min);
}
// if min and max are both set
if(min != Integer.MIN_VALUE && max != Integer.MAX_VALUE) {
minMax = String.format(" [between %d and %d]", min, max);
}
while(true) {
System.out.print(prompt + minMax + (required ? " (*)" : "") + ": ");
String valueStr = scanner.nextLine();
try {
value = Integer.parseInt(valueStr);
} catch (NumberFormatException e) {
if(!required) {
return Integer.MIN_VALUE;
} else {
displayError("Invalid integer");
continue;
}
}
if(value < min) {
displayError("Value too low");
} else if(value > max) {
displayError("Value too high");
} else {
break;
}
}
return value;
}
public static String getString(String prompt) {
return getString(prompt, true);
}
public static String getString(String prompt, boolean required) {
String value = "";
while(true) {
System.out.print(prompt + (required ? " (*)" : "") + ": ");
value = scanner.nextLine().trim();
if(required && !isValidString(value)) {
displayError("Input required");
} else {
break;
}
}
return value;
}
public static boolean getBoolean(String prompt) {
return getBoolean(prompt, true);
}
public static boolean getBoolean(String prompt, boolean required) {
boolean value = true;
while(true) {
String valueStr = getString(prompt + " [y/n]", required);
if(required && !(valueStr.equalsIgnoreCase("y") ||
valueStr.equalsIgnoreCase("n") ||
valueStr.equalsIgnoreCase("yes") ||
valueStr.equalsIgnoreCase("no"))
) {
displayError("Invalid input");
} else {
value = valueStr.equalsIgnoreCase("y") || valueStr.equalsIgnoreCase("yes");
break;
}
}
return value;
}
public static double getDouble(String prompt) {
return getDouble(prompt, true, -Double.MAX_VALUE, Double.MAX_VALUE);
}
public static double getDouble(String prompt, boolean required) {
return getDouble(prompt, required, -Double.MAX_VALUE, Double.MAX_VALUE);
}
public static double getDouble(String prompt, boolean required, int min) {
return getDouble(prompt, required, min, Double.MAX_VALUE);
}
public static double getDouble(String prompt, boolean required, double min, double max) {
double value = 0;
String minMax = "";
// if min is set and max is not set
if(min != -Double.MAX_VALUE && max == Double.MAX_VALUE) {
minMax = String.format(" [minimum %.1f]", min);
}
// if min and max are both set
if(min != -Double.MAX_VALUE && max != Double.MAX_VALUE) {
minMax = String.format(" [between %.1f and %.1f]", min, max);
}
while(true) {
System.out.print(prompt + minMax + (required ? " (*)" : "") + ": ");
String valueStr = scanner.nextLine();
try {
value = Double.parseDouble(valueStr);
} catch (NumberFormatException e) {
if(!required) {
return -Double.MAX_VALUE;
} else {
displayError("Invalid number");
continue;
}
}
if(value < min) {
displayError("Value too low");
} else if(value > max) {
displayError("Value too high");
} else {
break;
}
}
return value;
}
public static LocalDate getDate(String prompt) {
return getDate(prompt, true);
}
public static LocalDate getDate(String prompt, boolean required) {
LocalDate date = null;
while(true) {
String dateStr = getString(prompt + " [MM/DD/YYYY]", required);
try {
DateTimeFormatter dateFormatInput = DateTimeFormatter.ofPattern("M/d/yyyy");
date = LocalDate.parse(dateStr, dateFormatInput);
break;
} catch(DateTimeParseException e) {
if(!required) {
return LocalDate.MIN;
} else {
displayError("Invalid date");
}
}
}
return date;
}
}The UIUtility class contains methods to display messages, warnings, print menus, prompt the user to press enter to continue, etc.
package edu.kirkwood.view;
public class UIUtility {
public static void displayMessage(String message) {
displayMessage(message, "");
}
public static void displayMessage(String message, String type) {
System.out.printf("*** %s%s ***\n", (!type.equals("") ? type.toUpperCase() + " - " : ""), message);
}
public static void displayError(String message) {
displayMessage(message, "error");
}
public static void displayWarning(String message) {
displayMessage(message, "warning");
}
public static void displaySuccess(String message) {
displayMessage(message, "success");
}
public static void pressEnterToContinue() {
UserInput.getString("Press enter to continue", false);
}
public static void printLine() {
printLine(40);
}
public static void printLine(int length) {
for (int i = 0; i < length; i++) {
System.out.print("-");
}
System.out.println();
}
public static void printMenu(String title, String[] menuItems) {
System.out.println();
printLine();
displayMessage(title);
for (int i = 0; i < menuItems.length; i++) {
System.out.println((i + 1) + ") " + menuItems[i]);
}
printLine();
}
public static String separator(int[] columnWidths) {
StringBuilder sb = new StringBuilder();
for (int width : columnWidths) {
sb.append("+ ");
for (int i = 0; i < width; i++) {
sb.append('-');
}
sb.append(' ');
}
sb.append("+");
return sb.toString();
}
}
The Helpers class contains methods to perform a variety of tasks.
The only method we technically need for this project is "isValidString" to check that input is neither null or an empty string.
package edu.kirkwood.view;
import java.text.NumberFormat;
import java.time.LocalDate;
import java.time.format.DateTimeFormatter;
import java.time.format.FormatStyle;
import java.math.BigDecimal;
import java.math.RoundingMode;
public class Helpers {
public static boolean isValidString(String str) {
return str != null && !str.equals("");
}
public static String round(double number, int numDecPlaces) {
BigDecimal bigDecimal = new BigDecimal(Double.toString(number));
bigDecimal = bigDecimal.setScale(numDecPlaces, RoundingMode.HALF_UP).stripTrailingZeros();
return bigDecimal.toString();
}
public static String toCurrency(double amt) {
NumberFormat formatter = NumberFormat.getCurrencyInstance();
return formatter.format(amt);
}
public static String formatDateLong(LocalDate date) {
DateTimeFormatter dateFormatOutput = DateTimeFormatter.ofLocalizedDate(FormatStyle.LONG);
return dateFormatOutput.format(date);
}
public static String formatDateShort(LocalDate date) {
DateTimeFormatter dateFormatOutput = DateTimeFormatter.ofPattern("M/d/yyyy");
return dateFormatOutput.format(date);
}
public static boolean isDateInThePast(LocalDate date) {
if (date == null) {
throw new IllegalArgumentException("Date cannot be null");
}
return date.isBefore(LocalDate.now()); // Check if the date is before today
}
public static boolean isDateInRange(LocalDate date, LocalDate startDate, LocalDate endDate) {
if (date == null || startDate == null || endDate == null) {
throw new IllegalArgumentException("None of the dates can be null");
}
return (date.isEqual(startDate) || date.isAfter(startDate)) &&
(date.isEqual(endDate) || date.isBefore(endDate));
}
}Inside the "view" package, create a class called "Messages".
Use this class to write messages to greet and say goodbye to the user.
package edu.kirkwood.view;
import static edu.kirkwood.view.UIUtility.displayMessage;
public class Messages {
public static void hello() {
displayMessage("Welcome to the Kirkwood Calculators Application");
}
public static void goodbye() {
displayMessage("Goodbye");
}
public static void fractionGreet() {
displayMessage("Welcome to Marc's Fraction Calculator");
System.out.println("Enter calculations in the format: [fraction] [operator] [fraction]");
System.out.println("Example: 1 1/2 + 3/4\n");
}
public static void fractionGoodbye() {
displayMessage("Thank you for using Marc's Fraction Calculator");
}
}
Inside the "view" package, create a class called MainMenu.
Add a show method with the following implementation.
In Java 1, we implemented a Menu interface, we won't do that in this example since we will have only one Menu.
package edu.kirkwood.view;
import edu.kirkwood.controller.FractionCalculator;
import static edu.kirkwood.view.UIUtility.printMenu;
import static edu.kirkwood.view.UserInput.getInt;
public class MainMenu {
public static void show() {
String[] menuItems = {"Marc's Fraction Calculator", "Student's Math Calculator", "Quit"};
while(true) {
printMenu("Main Menu", menuItems);
int choice = getInt("Choose an option", false,1, menuItems.length);
switch(choice) {
case 1:
break;
case 2:
break;
default:
return;
} // end switch
} // end loop
} // end show method
}Inside the "edu.kirkwood" package, create a class called CalculatorApp.
This class will contain the main method that starts our program.
You can run the program to test its functionality.
package edu.kirkwood;
import edu.kirkwood.view.MainMenu;
import static edu.kirkwood.view.Messages.*;
public class CalculatorApp {
public static void main(String[] args) {
hello();
MainMenu.show();
goodbye();
}
}
Create a new package: "edu.kirkwood.controller".
In the "controller" package, create a class called "FractionCalculator".
Add a static start() method.
package edu.kirkwood.controller;
import static edu.kirkwood.view.Messages.*;
import static edu.kirkwood.view.UIUtility.pressEnterToContinue;
public class FractionCalculator {
public static void start() {
fractionGreet();
fractionGoodbye();
pressEnterToContinue();
}
}Call the start method in the Main Menu class.
case 1:
FractionCalculator.start();
break;Add an infinite loop between the greet and goodbye method.
Prompt the user for input. Give them a way to exit the loop.
package edu.kirkwood.controller;
import static edu.kirkwood.view.Messages.*;
import static edu.kirkwood.view.UIUtility.pressEnterToContinue;
import static edu.kirkwood.view.UserInput.getString;
public class FractionCalculator {
public static void start() {
fractionGreet();
while(true) {
String value = getString("Enter your equation (or 'q' to quit): ");
if(value.equalsIgnoreCase("q") || value.equalsIgnoreCase("quit")) {
break;
}
// Todo: Validate the input
// Todo: Perform mathematical operation
// Todo: Display output
}
fractionGoodbye();
pressEnterToContinue();
}
}By Marc Hauschildt
Web Technologies and Computer Software Development Instructor at Kirkwood Community College in Cedar Rapids, IA.
