Advanced

OpenValue

Rachèl Heimbach

Principal Consultant @ OpenValue

Solution Architect @ Rabobank

"The Great Divide"

https://css-tricks.com/the-great-divide/

Front-of-the-front-End

vs.

Back-of-the-front-End

development

https://bradfrost.com/blog/post/front-of-the-front-end-and-back-of-the-front-end-web-development/

A front-of-the-front-end developer is a web developer who specializes in writing HTML, CSS, and presentational JavaScript code.

https://bradfrost.com/blog/post/front-of-the-front-end-and-back-of-the-front-end-web-development/

A back-of-the-front-end developer is a web developer who specializes in writing JavaScript code necessary to make a web application function properly.

Back-of-the-front-end

Writing application business logic.
Wiring up, integrating with, and even authoring data sources, services, and APIs.
Consuming the UI code.
Optimizing the performance of JS code.

Writing end-to-end, integration, and other tests.
Architecting and managing JS-based infra.
Managing devops stuff.
Working with front-of-the-front-end devs.
Working with the product team.
Working with other backend devs and IT

https://bradfrost.com/blog/post/front-of-the-front-end-and-back-of-the-front-end-web-development/

Front-of-the-front-end

Crafting semantic HTML.
Creating CSS code.
Authoring JS that primarily manipulates objects in the DOM.
Testing across browsers and devices.
Optimizing the performance of FE code.
Working with back-of-the-front-end devs.

Working with designers.
Creating a lib of presentational UI comp.
Authoring and documenting a robust intuitive component API for each component.
Writing unit tests for UI component library.
Architecting the flexibility/composability of the component library.
Maintaining the presentational components as a product.

https://bradfrost.com/blog/post/front-of-the-front-end-and-back-of-the-front-end-web-development/

Training Objectives day 1

Master Angular fundamentals Front-of-the-Frontend
Maintain design system effectively at scale

Understanding Design Systems

Key principles and benefits of design systems.

UI Design

Accessibility
Theming
Dark mode
High contrast mode
Redesigns

Benefits Design System

Consisten UI
Faster development
Separation of concerns
Building blocks...

Atomic Design Methodology

Breaking down UI into fundamental building blocks.

Atomic Design

https://atomicdesign.bradfrost.com/chapter-2/

Custom Properties

.button {
  background-color: #2563eb;
}

Custom Properties

:root {
  --color-blue: #2563eb;
}


button {
  background-color: var(--color-blue);
}

Custom Properties

:root {
  --button-bg-color: #2563eb;
}


button {
  background-color: var(--button-bg-color);
}

Custom Properties

:root {

  // ...
  --color-primary-500: #3b82f6;
  --color-primary-600: #2563eb;
  --color-primary-700: #1d4ed8;
  // ...

  --button-bg-color: var(--color-primary-600);
}


button {
  background-color: var(--button-bg-color);
}

Custom Properties

:root {

  // ...
  --color-primary-500: #3b82f6;
  --color-primary-600: #2563eb;
  --color-primary-700: #1d4ed8;
  // ...
  --color-secondary-500: #a855f7;
  --color-secondary-600: #9333ea;
  --color-secondary-700: #7e22ce;
  // ...

  --button-primary-bg-color: var(--color-primary-600);
  --button-secondary-bg-color: var(--color-secondary-600);
  // ...
}


button.primary {
  background-color: var(--button-primary-bg-color);
}

button.secondary {
  background-color: var(--button-secondary-bg-color);
}

Custom Properties

:root {
  /* ... */
  --button-primary-bg-color: var(--color-primary-600);
  --button-secondary-bg-color: var(--color-secondary-600);
}


button.primary {
  background-color: var(--button-primary-bg-color);
}

button.secondary {
  background-color: var(--button-secondary-bg-color);
}

/* Dark Theme */
[data-theme='dark'] {
  --button-primary-background: var(--color-primary-500);
  --button-secondary-background: var(--color-secondary-500);
  /* ... */
}

Custom Properties

:root {
  /* Core spacing variables */
  --space-xxs: 4px; /* 0.25 × base */
  --space-xs: 8px; /* 0.5 × base */
  --space-sm: 12px; /* 0.75 × base */
  --space-md: 16px; /* 1 × base */
  --space-lg: 24px; /* 1.5 × base */
  --space-xl: 32px; /* 2 × base */
  --space-xxl: 48px; /* 3 × base */
  /* ... */
  --button-padding: var(--space-xs) var(--space-md);
}

Custom Properties

:root {
  /* Font Sizes */
  --font-xs: 0.75rem; /* 12px */
  --font-sm: 0.875rem; /* 14px */
  --font-base: 1rem; /* 16px */
  --font-lg: 1.125rem; /* 18px */
  --font-xl: 1.25rem; /* 20px */
  --font-2xl: 1.5rem; /* 24px */
  --font-3xl: 1.875rem; /* 30px */
  --font-4xl: 2.25rem; /* 36px */
  --font-5xl: 3rem; /* 48px */

  /* Font Weights */
  --font-thin: 100;
  --font-extralight: 200;
  --font-light: 300;
  --font-normal: 400;
  --font-medium: 500;
  --font-semibold: 600;
  --font-bold: 700;
  --font-extrabold: 800;
}

Atomic Design

https://atomicdesign.bradfrost.com/chapter-2/

https://atomicdesign.bradfrost.com/chapter-2/

https://atomicdesign.bradfrost.com/chapter-2/

https://atomicdesign.bradfrost.com/chapter-2/

https://atomicdesign.bradfrost.com/chapter-2/

UI Components in Angular

Creating reusable and efficient UI components.

"Build UIs without the grunt work"

Component Isolation

"Build components without starting a complex dev setup, force certain data into your database, or navigate around your application"

https://storybook.js.org/docs/get-started/why-storybook

Atomic Design Storybook demo

Design tokens + UI components library

Portrait

landscape

Primary

Max

Min

Max

Min

Max

Min

Primary

Max

Min

Max

Min

Style | Layout

Product

It should display product information

<section class="product">
  <ov-thumbnail></ov-thumbnail>
  <div class="info">
    <ov-sub-title></ov-sub-title>
    <ov-title></ov-title>
    <div class="details">
      <div>
        <ov-rating></ov-rating>
        <ov-price></ov-price>
      </div>
    </div>
  </div>
</section>

Product

It should display product information
It should display availability

<section class="product">
  <ov-thumbnail></ov-thumbnail>
  <div class="info">
    <ov-sub-title></ov-sub-title>
    <ov-title></ov-title>
    <div class="details">
      <div>
        <ov-rating></ov-rating>
        <ov-price></ov-price>
      </div>
      <div>
        <ov-quantity-picker>
        </ov-quantity-picker>
      </div>
    </div>
    <div class="footer">
      <ov-message type="ok"></ov-message>
    </div>
  </div>
</section>

Product

It should display product information
It should display availability
It should warn about limited availability

<section class="product">
  <ov-thumbnail></ov-thumbnail>
  <div class="info">
    <ov-sub-title></ov-sub-title>
    <ov-title></ov-title>
    <div class="details">
      <div>
        <ov-rating></ov-rating>
        <ov-price></ov-price>
      </div>
      <div>
        <ov-quantity-picker>
        </ov-quantity-picker>
      </div>
    </div>
    <div class="footer">
      <ov-message type="ok"
        *ngIf="!isLimited; else limited">
      </ov-message>
      <ng-template #limited>
        <ov-message type="warn"></ov-message>
      </ng-template>
    </div>
  </div>
</section>

Product

<section class="product">
  <ov-thumbnail></ov-thumbnail>
  <div class="info">
    <ov-sub-title></ov-sub-title>
    <ov-title></ov-title>
    <div class="details">
      <div>
        <ov-rating></ov-rating>
        <ov-price></ov-price>
      </div>
      <div>
        <ov-quantity-picker
          *ngIf="!isOutOfStock; else outOfStock">
        </ov-quantity-picker>
        <ng-template #outOfStock>
          <ov-button>
            <ov-icon></ov-icon>
          </ov-button>
      	</ng-template>
      </div>
    </div>
    <div class="footer">
      <ov-message type="ok"
        *ngIf="!isLimited">
      </ov-message>
      <ov-message type="warn"
        *ngIf="isLimited">
      </ov-message>
      <ov-message type="error"
        *ngIf="isOutOfStock">
      </ov-message>
    </div>
  </div>
</section>

It should display product information
It should display availability
It should warn about limited availability
It could be out of stock and show a contact option

Product

<section class="product" *ngIf="!isReplaced">
  <ov-thumbnail></ov-thumbnail>
  <div class="info">
    <ov-sub-title></ov-sub-title>
    <ov-title></ov-title>
    <div class="details">
      <div>
        <ov-rating></ov-rating>
        <ov-price></ov-price>
      </div>
      <div>
        <ov-quantity-picker
          *ngIf="!isOutOfStock; else outOfStock">
        </ov-quantity-picker>
        <ng-template #outOfStock>
          <ov-button></ov-button>
      	</ng-template>
      </div>
    </div>
    <div class="footer">
      <ov-message type="ok"
        *ngIf="!isLimited">
      </ov-message>
      <ov-message type="warn"
        *ngIf="isLimited">
      </ov-message>
      <ov-message type="error"
        *ngIf="isOutOfStock">
      </ov-message>
    </div>
  </div>
</section>
<section *ngIf="isReplaced">
  ...
</section>

It should display product information
It should display availability
It should warn about limited availability
It could be out of stock and show a contact option
It could be completely replaced by an alternative product

Product

@Component({ ... })
export class ProductComponent {
  @Input() product!: Product;
}

It should display product information
It should display availability
It should warn about limited availability
It could be out of stock and show a contact option
It could be completely replaced by an alternative product

Product

@Component({ ... })
export class ProductComponent {
  @Input() product!: Product;

  @Input() isLimited = false;
}

It should display product information
It should display availability
It should warn about limited availability
It could be out of stock and show a contact option
It could be completely replaced by an alternative product

Product

@Component({ ... })
export class ProductComponent {
  @Input() product!: Product;

  @Input() isLimited = false;

  @Input() isOutOfStock = false;
}

It should display product information
It should display availability
It should warn about limited availability
It could be out of stock and show a contact option
It could be completely replaced by an alternative product

Product

@Component({ ... })
export class ProductComponent {
  @Input() product!: Product;

  @Input() isLimited = false;

  @Input() isOutOfStock = false;

  @Input() isReplaced? = false;
  @Input() replacement?: Product;
}

It should display product information
It should display availability
It should warn about limited availability
It could be out of stock and show a contact option
It could be completely replaced by an alternative product

Product

@Component({ ... })
export class ProductComponent {
  @Input() product!: Product;

  @Input() isLimited = false;

  @Input() isOutOfStock = false;

  @Input() isReplaced? = false;
  @Input() replacement?: Product;

  @Output() addToCart = new EventEmitter<number>();
  @Output() contactUs = new EventEmitter<Product>();
}

It should display product information
It should display availability
It should warn about limited availability
It could be out of stock and show a contact option
It could be completely replaced by an alternative product

Composition

Slots

Angular Advanced

By rachnerd

Advanced

"The Great Divide"

Front-of-the-front-End

vs.

Back-of-the-front-End

development

Back-of-the-front-end

Front-of-the-front-end

Training Objectives day 1

Understanding Design Systems

Key principles and benefits of design systems.

UI Design

Benefits Design System

Atomic Design Methodology

Atomic Design

Custom Properties

Custom Properties

Custom Properties

Custom Properties

Custom Properties

Custom Properties

Custom Properties

Custom Properties

Atomic Design

UI Components in Angular

"Build UIs without the grunt work"

Component Isolation

Atomic Design Storybook demo

Style | Layout

Product

Product

Product

Product

Product

Product

Product

Product

Product

Product

Composition

Angular Advanced

More from rachnerd
