intro - Cloud Composer
The service to run Apache Airflow on Google Cloud
Contents
what is cloud composer?
Airflow and DAGs
Cloud Composer
CPU
RAM
Cluster Management
Security
Simplified Architecture
GKE Cluster
Schedulers x n
DAGs
updates metadata
triggers
Workers x n
views
runs on
syncs to
CI/CD
Webserver and security
HTTPS
DAGs GUI
Command Line Tools
gcloud composer environments run example-environment \
--location us-central1 dags trigger -- sample_quickstart \
--run-id=5077gcloud composer environments run example-environment \
dags list -- --output=jsonKubernetes Executor
Git repository
- java
- go
- custom python packages
- CPU x n
- RAM x n
- Autoscaling enabled
Schedulers x n
DAGs
triggers
triggers
VPC Native and Private IP Cluster
Cloud Composer
on-prem network
primary (nodes): 10.1.0.0/16
secondary (pods): 10.2.0.0/20
VM (Bastion Host)
Cloud NAT
Cloud Composer
primary (nodes): 10.1.0.0/16
secondary (pods): 10.2.0.0/20
SaaS on the internet
Composer 1 vs Composer 2
- Manager your own node pool
- Fixed node size at cluster creation time
- Support Airflow 1 & 2
- Pay on node resources
- GCP manages nodes and node pool
- Node size changeable after cluster creation
- Support Airflow 2 only
- Pay on POD resources
- Workload Identify enabled by default
Composer 1 vs Composer 2
Summary
- Use Airflow 2
- Use Composer 2
- Always use VPC Native Private Cluster
- Always use Cloud NAT
