Cloud Security Corner

​Learn Cloud Security with AWS

Sangam Biradar

@sangamtwts

CloudSecurityCorner.com

 Sangam Biradar , Individual Open-Source Contributor

• Docker Community Leader Award Winner 2020

• Traefik , Okteto ambassador

• AWS Community Builder - 2022 - 2024

•BOS( Board of Studies – Alliance University , Bangalore )

•DevNetwork Board of DevRel Advisor

•Cybersecurity Innovator of Year 2023 by Bside Bangalore

•Packt Publication – Co author of Course on lightweight Kubernetes with K3s in 2019

•Prev worked as Principal Security advocate / Senior Product Marketing Manager, Developer Advocate

Threat Detection and Incidence Response

Principles of Incidence Response

educate

Prepare

Prepare

Prepare

simulate

Prepare

Iterate

Demo - 1 -  IAM User

Dealing with compromised users

Dealing with compromised users

If the user has been assigned Access Keys, consider deactivating them..

Be cautious when deleting keys, as this may impact applications that rely on them.

Review all policies assigned to the user.

Monitor Cloudtrail events for any unusual activity

Addressing Compromised Users

Delete the compromised user account and recreate it.

If the user has long-term access credentials, transition to using IAM roles.

Roles utilize short-term credentials, offering enhanced security.

  Demo 2- Best security practices for managing EC2 Instances

General Consideration

Install only the necessary components on the EC2 instance to minimize the attack surface

Use host-based protection software

Restrict network access to the instance

Establish a baseline server configuration and monitor any changes against this baseline

Ensure all changes to the EC2 instance are audited.

EC2 Instance

Private Subnet

EC2 Instance

Public  Subnet

Elastic Network Interface

Network Access Control List

Security Groups

Configure Security Groups: Set up security group: rules to allow only the minimum necessary traffic.

Use Network Access Control Lists (NACLs): Implement NACLs to manage traffic at the subnet level.

Control and monitor interactive access to EC2 instances.

Provide user access based on the principle of least privilege.

If an application on the EC2 instance needs to access other AWS services, assign an IAM role to the EC2 instance

Always encrypt data at rest and in transit

Regularly update the EC2 instance with the latest security patches

Ensure a change management process is in place for all updates to the EC2 instance.

Demo - AWS Guard Duty

What is AWS Guard Duty ?

This is a continuous security monitoring service

This service analyses the following data sources - VPC flow logs , AWS CloudTrail event logs , DNS logs

it is used to identity unexpected and potentially unauthorised and malicious activities from within your AWS account

this does this with help of existing threat intelligence feeds and list that contain malicious IP's and domains

The Threats it can detect

Escalation of privileges

Uses of exposed credentials

Communication with malicious IP's , URL's or Domains

Detect compromised EC2 Instance having malware

Can also detect unauthorised infrastructure deployments in your AWS environment

How can we use amazon GuardDuty

                                                                 We have to enable it

​it is region specific resources

To get better coverage , you can enable the service in every region

you can also invite other accounts to use amazon guardDuty . if you do this your account becomes the master account you can then get the finding of your member accounts

EC2 Encryption with key pairs

Configure Security Groups: Set up security group: rules to allow only the minimum necessary traffic.

Use Network Access Control Lists (NACLs): Implement NACLs to manage traffic at the subnet level.

Security logging and Monitoring

Amazon CloudWatch

Amazon CloudWatch agents

AWS CloudTrail

AWS Config

other tools available

Amazon CloudWatch

This service helps monitor all of  your AWS resources

​Monitoring Can be carried out in real time

CloudWatch can be used to collect and track metrics

these metrics help you understand how your AWS resources and behaving

You can then create alarms based on these metrics

Amazon CloudWatch Agents

CloudWatch agents allows you to get more system level metrics from amazon EC2 Instances ​

You can also collect metrics from on-premise servers

you can also collect logs from Amazon EC2 Instances or on premise servers which could be running either linux or windows

Amazon cloudtrail

This service helps you enable governance , compliance and  operational and risk auditing for your AWS account

All actions taken by a user , role or an AWS service are recorded as events in AWS cloudtrail

These events could have taken place into AWS management console , AWS CLI Interface , the AWS SDKs and APIs

You Can Then create a trail which would persists these events

You can search these events later on for any suspicious activities

AWS Config

This service helps you record configuration changes to your AWS resources

You can also see how resources are related to each other

You can also define AWS config rules to check whether your resources are compliant or noncompliant with your organisation's policies

other tools available

VPC Flow logs - This can be used to log the network traffic flowing in and out your VPC

Simple Storage Access Logs - Gives you a better representation of how your S3 objects are being accessed

Elastic Load Balancer logs - Gives you a better representation on requests and responses being made to the Elastic Load Balancer

The Purpose of Amazon CloudWatch Logs

Working with CloudWatch Logs

create AWS Lamada

Insights

Access Logs

The purpose of S3 access logs

This can be useful for security and access audit report purposes

by default server access logging is disabled . you have a explicitly enable it

the logs can be written to the same bucket or a different bucket . it is recommended to use a different bucket for log data

when server access logging is enabled via  the console , a bucket ACL grant for the log deliver group to write data is set on destination bucket

there is no charge for enabling S3 access logs

but there will be a charge for the storage of log data

create s3 bucket -> permission -> access control list -> s3 log delivery group - log delivery

Governance and Compliance

the event history is available for the past 90 days

​you can use the history to view , search and download activity during this time period

you can also create a trail to persist the events

the events can be send to CloudWatch Logs or to an S3 bucket

you can create a trail that applies to all regions

you can create a trail that just applies to one region

What is AWS CloudTrail

if  you have an an AWS organisation ​, you can  also  create an organisation trail

the trail is applied to the master account

the event get recorded for all of the member accounts as well

​All of the CloudTrail event log file are encrypted using amazon S3 server-side encryption

you can also use the Key Management service to encrypt the log files

When configuring a trail ,  you can choose to log data and management events

Data events events performed on a resource such as Amazon S3 object level API activity or AWS Lambda function execution

Management events are those events performed at the control plane . for example attaching an IAM role

AWS account

AWS account

AWS CloudTrail

AWS CloudTrail

S3 bucket

We have to ensure the bucket policy for the destination bucket allows for multiple to write data

bucket policy -> permission

Monitoring your VPC

What are VPC Flow Logs

this is a feature that enables you to capture information on the traffic flowing into and out of the network interface from within a VPC

The Flow log data can be sent to Amazon CloudWatch logs and Amazon S3

A Flow log can be created for VPC , a subset or just a network interface

when flow logs are activated it will take around several minutes to start receiving the data

We are going to enable VPC flow logs for a network interface

​we will send the logs to CloudWatch Logs

​we need to also have an IAM role in place to VPC flow logs to send the data to CloudWatch Logs

IAM role - ec2 - create policy - json

edit trust relationship

This is an interactive query service that allows you to analyse data directly from s3

AWS Athena is a serverless service

Here you don't need any infrastructure setup service

you can query and analyse unstructured , semi - structured and structured data stored in AWS s3

Tha data could be in various formats such as CSV , JSON , Apache Parquet or Apache ORC

Infrastructure security

What is VPC ?

Components of a VPC

Security for VPC

Security Groups - this is like a virtual firewall that cam control inbound and outbound traffic into your instance

in the security groups you add inbound an outbound rules to control the traffic

bye default no traffic is allowed into an instance

you have to explicitly add inbound rules in the security groups to allow traffic to flow into the instance

Security Groups are stateful - this means that if you send a request to the instance if the request is allowed the response will be allowed irrespective of the outbound rules set in the security group

Network access control list - this is like a virtual firewall that can control inbound and outbound traffic into your subnets

​each network access control list consists of inbound and outbound rules

​the network access control list by default allows all inbound and outbound traffic

each subset needs to be associated with a network access control list

network access control lists are stateless . even if a request is allowed via an inbound rule the response would be subject to the outbound rules

Demo - Setting up the  VPC

Create a new VPC in the Ohio regime

Create a new subnet in the VPC

Ensure the DNS hostnames assignment is set for the VPC

​Ensure the public IP address setting is made for the subnet in the VPC

Create an internet gateways and attach it to the VPC

Modify the route tables to ensure traffic destination from the internet can flow via the internet gateway

​Launch an EC2 Instance in the new VPC

Demo - Security Groups

Install apache2 on the server

Change the security groups to allow traffic into our instance

Amazon EC2 instance

inbound rules

port 80

Amazon RDS instance

mysql 3306

Amazon EC2 instance

Internet

We need to add an outbound rule to allow an outgoing request on port 80

IAM - identity and access management

This service allows you to securely control access to AWS resources

You can control who is allowed to sign in - the authentication process

You can also control who is allowed to use resources - the authorisation process

IAM User - this represents a person or a service that would interact with AWS

the user would either access the console or make programmatic access calls to AWS service

you could place the user in an IAM group

you could assign permission to the user

IAM  Groups - this is a collection of IAM user

you can assign permission at the group level

​IAM roles - this is an identity in AWS . you can assign permission to an IAM role

A role is not associated with any access key or password so it is  a secure way of accessing AWS resources

Policies and permissions

You Manage access to AWS resources with help of policies

Policies are mostly stored in AWS as JSON documents

there are different types of policies

​- identity based policies- these are attached to users , groups or roles

- Resource based Policies - some AWS service can have their own policies for example in the simple storage service you can create bucket Policies

- Permission Boundaries - this can be used to define the maximum permission that can be assigned to an IAM entity

- Organization Service Control Policy - this can be used to define the maximum permission that can be assigned to members of an organization

​- Access control list- some AWS service use access control lists an example is the simple storage service

- Session Policies these are policies used during a particular session

Data Protection

This is a service that allows you to store and retrieve virtually any amount of data from the web

in the service you go ahead and create buckets to store the data

Each object in the bucket is addressable via a URL

Each object has a key which is a unique identifier for the object with the bucket

In term of security the service provider the following capabilities

encryption of data at rest and transit - this can done with either server side or client side encryption

You can manage access to the bucket and its objects via identity and access management policies , bucket policies or access control lists

Access control List

Access control list can be used to manage access to buckets and underlying objects

these are just used to grant basic read / write permission

you can grant ACL's for both the buckets and there underlying objects

when to use ACL's

Granting access to individual objects using a bucket policy for gibing access to individual files is not recommended
