Linear Autoregressive Models
ML in Feedback Sys #7
Fall 2025, Prof Sarah Dean
Linear auto-regression
"What we do"
- Given: data \(\{y_k\}_{k=1}^{n+1}\) with \(y_k\in\mathbb R^{d_y}\) and window length \(L\)
- The linear auto-regressive least squares
- Split data into predictors $$\bar y_{k:k-L+1} = \begin{bmatrix} y_k^\top & ... & y_{k-L+1}\end{bmatrix}^\top \in\mathbb R^{Ld_y}$$ and targets \(y_{k+1}\) for \(k=L,...,n\)
- Solve linear least squares optimization $$\min_{\Theta\in \mathbb R^{Ld_y\times d_y}} \sum_{k=L}^n\| \Theta^\top \bar y_{k:k-L+1} - y_{k+1}\|_2^2$$
- Make predictions with $$\hat y_{t+1} = \hat\Theta^\top \hat{\bar y}_{t:t-L+1} = \sum_{\ell=0}^{L-1} \hat \Theta_{\ell+1}^\top \hat y_{t-\ell} $$
Linear auto-regression
"Why we do it"
- Fact 1: Auto-regressive models with length \(L\) are equivalent to partially observed linear dynamical systems (PO-LDS) which satisfy:
- The PO-LDS is observable
- Sufficient state dimension \(d_s\)
- Fact 2: from an output perspective, PO-LDS do not have a unique state space representation, but they do define a unique subspace which can be learned from data
Partially observed dynamics
- A partially observed dynamical system is defined by a difference equation and an observation (or measurement) equation $$s_{t+1} = F(s_t),\quad y_t = H(s_t)$$
- Linear dynamics (PO-LDS) are defined by a dynamics matrix and an observation matrix $$s_{t+1} = Fs_t,\quad y_t = Hs_t$$
- Fact 1a: given a linear autoregressive model, we can always construct a PO-LDS with \(d_s= Ld_y\) which has identical outputs
Partially observed dynamics
- Linear dynamics (PO-LDS) are defined by a dynamics matrix and an observation matrix $$s_{t+1} = Fs_t,\quad y_t = Hs_t, \quad s_0$$
- Fact 1a: given a linear autoregressive model, we can always construct a PO-LDS with \(d_s= Ld_y\) which has identical outputs
-
Example: Fibonacci sequence: $$1,1, 2, 3, 5, 8, 13, 21, ...$$
- Auto-regressive model:
- \(y_{t+1} = y_t + y_{t-1}\)
- State space model:
- \(s_{t+1} = \begin{bmatrix} 1 & 1 \\ 1 & 0 \end{bmatrix} s_t,~~ y_t = \begin{bmatrix} 1 &0\end{bmatrix}s_t,~~s_0=\begin{bmatrix} 1 \\ 0\end{bmatrix}\)
- Auto-regressive model:
Partially observed dynamics
- Linear dynamics (PO-LDS) are defined by a dynamics matrix and an observation matrix $$s_{t+1} = Fs_t,\quad y_t = Hs_t,\quad s_0$$
- Fact 1a: given a linear autoregressive model \( y_{t+1} = \Theta^\top {\bar y}_{t:t-L+1}\) we can always construct a PO-LDS with \(d_s= Ld_y\) which has identical outputs
-
Proof by construction
-
let \(s_t = \begin{bmatrix}y_t^\top & ... & y_{t-L+1}^\top \end{bmatrix}^\top \in\mathbb R^{Ld_y}\)
-
$$ \text{let}~~ F = \begin{bmatrix}&& \Theta^\top \\ I & 0\\ & I & 0\\ && \ddots&& \\ &&& I &0\\\end{bmatrix},\quad H =\begin{bmatrix} I & 0 & ... \end{bmatrix}$$
-
\(y_k\) for \(k\leq 0\) are free variables
-
Limits of partial observation
Example: The state \(s=[\theta,\omega]\), output \(y=\theta\), and
$$\theta_{t+1} = 0.9\theta_t + 0.1 \omega_t,\quad \omega_{t+1} = 0.9 \omega_t$$
- What can we predict about \(y_t\) and \(s_t\) as \(t\to\infty\)?
- Suppose \(y_0 = 1\). Can we predict \(y_1\) or estimate \(s_0\)?
- What if we also know that \(y_1 = 1\)?
Example: The state \(s=[\theta,\omega]\), output \(y=\theta\), and
$$\theta_{t+1} = 0.9\theta_t ,\quad \omega_{t+1} = 0.9 \omega_t$$
Definition: A PO system is observable if outputs \(y_{0:t}\) uniquely determine the state trajectory \(s_{0:t}\) for some finite \(t\).
- i.e., the map \(\Phi_{0\to t}:\mathcal S\to \mathcal Y^{t+1}\) is injective
Observability
\(s_{t+1} = F(s_t)\)
\(y_t = H(s_t)\)
\((y_0,...,y_t) = \Phi_{0\to t}(s_0)\)
Theorem: A linear system is observable if and only if
$$\mathrm{rank}\Big(\underbrace{\begin{bmatrix}H\\HF\\\vdots \\ HF^{d_s-1}\end{bmatrix}}_{\mathcal O}\Big) = d_s$$
- \(y_0 = H(s_0)\)
- \(y_1 = H(F(s_0))\)
- \(y_2 = H(F(F(s_0)))\)
Observability
\(s_{t+1} = F s_t\)
\(y_t = H s_t\)
Theorem: A linear system is observable if and only if
$$\mathrm{rank}\Big(\underbrace{\begin{bmatrix}H\\HF\\\vdots \\ HF^{d_s-1}\end{bmatrix}}_{\mathcal O}\Big) = d_s$$
\(\begin{bmatrix} y_0\\y_1\\\vdots\\y_t\end{bmatrix}=\)
\(\begin{bmatrix} Hs_0\\HFs_0\\\vdots\\HF^ts_0\end{bmatrix}\)
Proof: The system response \(\Phi_{0\to t}\) is defined in terms of \(F\in\mathbb R^{d_s\times d_s}\) and \(H\in\mathbb R^{d_s\times d_y}\)
1) \(\mathrm{rank}(\mathcal O) = d_s \implies\) observable
$$\begin{bmatrix} y_0 \\ \vdots \\ y_{d_s-1}\end{bmatrix} = \begin{bmatrix}H\\HF\\\vdots \\ HF^{d_s-1}\end{bmatrix} s_0 $$
2) \(\mathrm{rank}(\mathcal O) = d_s \impliedby\) observable
- There is a unique solution \(s_0\) when \(\mathcal O\) is rank \(d_s\)
- \(s_0 = (\mathcal O^\top \mathcal O)^{-1} \mathcal O^\top y_{0:d_s-1}\)
- Thus, \(s_{0:t}\) is uniquely determined (for \(t\geq d_s\))
Proof:
2) \(\mathrm{rank}(\mathcal O) < d_s \implies\) not observable
-
Claim: \(\mathrm{rank}(\mathcal O_t) \leq \mathrm{rank}(\mathcal O)\) for all \(t\).
Thus \(\mathrm{rank}(\mathcal O_t) <d_s\) so \(s_0\) is not uniquely determined - Need to justify claim for \(t\geq d_s\), when \(\mathcal O_t\) has more rows than \(\mathcal O\)
- Theorem (Cayley-Hamilton): a matrix satisfies its own characteristic polynomial (of degree \(d_s\)).
- Therefore, \(F^k\) for \(k\geq d_s\) is a linear combo of \(I, F,\dots ,F^{d_s-1}\)
- Thus, \(\mathrm{rank}(\mathcal O_t) \leq \mathrm{rank}(\mathcal O)\) as claimed.
\(\begin{bmatrix} y_0\\y_1\\\vdots\\y_t\end{bmatrix}=\underbrace{\begin{bmatrix} H\\HF\\\vdots\\HF^t\end{bmatrix}}_{\mathcal O_t} s_0\)
Proof:
1) \(\mathrm{rank}(\mathcal O) = d_s \implies\) observable
$$\begin{bmatrix} y_0 \\ \vdots \\ y_{d_s-1}\end{bmatrix} = \begin{bmatrix}H\\HF\\\vdots \\ HF^{d_s-1}\end{bmatrix} s_0 $$
- There is a unique solution \(s_0\) when \(\mathcal O\) is rank \(d_s\)
- \(s_0 = (\mathcal O^\top \mathcal O)^{-1} \mathcal O^\top y_{0:d_s-1}\)
- Thus, \(s_{0:t}\) is uniquely determined (for \(t\geq d_s\))
- Fact 1: Auto-regressive models with length \(L\) are equivalent to partially observed linear dynamical systems (PO-LDS) which are observable and have sufficient dimension
- We proved 1a: AR (\(L\)) \(\implies\) PO-LDS (\(d_s=Ld_y\))
- Now, we prove 1b: PO-LDS \(\implies\) AR
- High level idea: \(d_s\) outputs are sufficient to back out the state, and the state is sufficient to predict future
- Give \(F\) and \(H\) construct $$\begin{bmatrix} y_t\\y_{t-1}\\\vdots\\y_{t-d_s-1}\end{bmatrix}= \begin{bmatrix}HF^{d_s-1} \\ \vdots \\ HF\\H \end{bmatrix}s_{t-d_s-1} =\tilde{\mathcal O} s_{t-d_s-1}$$
- Then we have for \(L=d_s\) $$y_{t+1} = Hs_{t+1} = HF^{d_s} s_{t-d_s-1} = HF^{d_s} (\tilde{\mathcal O}^\top \tilde{\mathcal O})^{-1} \tilde{\mathcal O}^\top \bar y_{t:t-L+1}$$
Equivalence
Non-unique state space
There is inherent ambiguity in state space representations
for partially observed dynamics
Example: Consider the sequence: $$1,1, 2, 3, 5, 8, 13, 21, ...$$
- \(s_{t+1} = \begin{bmatrix} 1 & 1 \\ 1 & 0 \end{bmatrix} s_t\), \(s_0 = \begin{bmatrix} 1 \\ 0\end{bmatrix}\)
- \(y_t = \begin{bmatrix} 1 & 0\end{bmatrix}\)
- \(s_{t+1} = \begin{bmatrix} 1 & 4 \\ \frac{1}{4} & 0 \end{bmatrix} s_t\), \(s_0 = \begin{bmatrix} 2 \\ 0\end{bmatrix}\)
- \(y_t = \begin{bmatrix} \frac{1}{2} & 0\end{bmatrix}\)
Non-unique state space
There is inherent ambiguity in state space representations
for partially observed dynamics
- \(y_0 =\hat H\hat s_0\)
- \(\hat s_1 = \hat F\hat s_0\)
- ...
- \(\hat s_t = \hat F\hat s_{t-1}\)
- \(y_t = \hat H\hat s_{t} \)
Suppose \(\hat F, \hat H, \hat s_0\) satisfies the equations
- \(y_0 =\hat H\textcolor{cyan}{MM^{-1}}\hat s_0\)
- \(\textcolor{cyan}{M^{-1}}\hat s_1 = \textcolor{cyan}{M^{-1}}\hat F\textcolor{cyan}{MM^{-1}}\hat s_0\)
- ...
- \(\textcolor{cyan}{M^{-1}}\hat s_t = \textcolor{cyan}{M^{-1}}\hat F\textcolor{cyan}{MM^{-1}}\hat s_{t-1}\)
- \(y_t = \hat H\textcolor{cyan}{MM^{-1}}\hat s_{t} \)
Then so does \(\tilde F=M^{-1}\hat F M, \tilde H=\hat HM, \tilde s_0=M^{-1}\hat s_0\)
Subspace identfication
$$\mathcal O_L = \begin{bmatrix}H\\HF\\\vdots \\ HF^{L-1}\end{bmatrix} $$
Recall the observability matrix
$$=\begin{bmatrix}HM\\HMM^{-1} FM\\\vdots \\ HMM^{-1} F^{L-1}M\end{bmatrix} $$
$$=\mathcal O_L M $$
Approach: subspace identification of the rank \(d_s\) column space of \(\mathcal O_L\) (\(L\geq d_s\))
Note: column space is invariant under similarity transforms
\tilde {\mathcal O}_L = \begin{bmatrix}\tilde H\\\tilde H\tilde F\\\vdots \\ \tilde H\tilde F^{L-1}\end{bmatrix}
What we do:
$$\begin{bmatrix}y_0\\\vdots \\ y_{L-1}\end{bmatrix} =\mathcal O_L s_0 $$
$$\begin{bmatrix}y_1\\\vdots \\ y_{L}\end{bmatrix} =\mathcal O_L s_{1} $$
\(\dots\)
$$\begin{bmatrix}y_m\\\vdots \\ y_{L+m-1}\end{bmatrix} =\mathcal O_L s_{k} $$
Hankel matrix
$$Y_{L,m} =\mathcal O_L \begin{bmatrix}s_0 & s_1 &\dots & s_m\end{bmatrix}$$
- The column space of the Hankel matrix is the same as \(\mathcal O_L\) (as long as \(s_{0:m}\) form a rank \(d_s\) matrix)
- also the same as the span of LS covariates \(\bar y_{k:k-L+1}\), \(k=L, L+1,...\)
Construct the Hankel matrix and consider its column space $$\begin{bmatrix}y_0 & \dots &y_m\\\vdots & \ddots&\vdots\\ y_{L-1}&\dots& y_{L+m-1}\end{bmatrix} =Y_{L,m} $$
Why we do it:
Step 1: Estimate \(\mathcal O_t\)
Step 2: Recover \(\hat F\) and \(\hat H\) from \(\hat{\mathcal O}\)
$$\hat{\mathcal O}_t = \begin{bmatrix}\hat{\mathcal O}_t [0]\\\hat{\mathcal O}_t [1]\\\vdots \\ \hat{\mathcal O}_t [t]\end{bmatrix}\approx \begin{bmatrix}H\\HF\\\vdots \\ HF^{t}\end{bmatrix} $$
So we set \(\hat H = \hat {\mathcal O}_t[0]\) and \(\hat F\) as solving
- \(\hat {\mathcal O}_t[0] F = \hat {\mathcal O}_t[1] \)
- ...
- \(\hat {\mathcal O}_t[t-1] F = \hat {\mathcal O}_t[t] \)
Subspace identfication
Extract column space using singular value decomposition (SVD) \(Y_{t,k} = \begin{bmatrix}U_{d_s} & U_{2}\end{bmatrix} \begin{bmatrix}\Sigma_{d_s} \\& 0\end{bmatrix}V^\top \)
Set \(\hat{\mathcal O}_t = U_{d_s}\)
Summary
- Linear AR model: $$\hat y_{t+1} = \Theta^\top \hat{\bar y}_{t:t-L+1} = \sum_{\ell=0}^{L-1} \hat \Theta_{\ell+1}^\top \hat y_{t-\ell} $$
- Fact 1: Linear AR model \(\iff\) partially observed LDS $$s_{t+1} = Fs_t,\quad y_t = Hs_t$$
- Fact 2: from an output perspective, PO-LDS do not have a unique state space representation, but they do define a unique subspace: the column space of \(\mathcal O\)
- equal to the column space of the Hankel matrix
- equal to the span of the AR covariates
Recap
- Autoregressive models
- Partially observed dynamical systems
- Observability and subspace ID
Next time: stochastic dynamics and filtering
Announcements
- Third assignment due Thursday
- Useful posts on Edstem about formatting PRs for submission
Reference: Callier & Desoer, "Linear Systems Theory" and Verhaegen & Verdult "Filtering and System Identification"
