Data Capsule

Sane key/value store access layer

Some more use cases

• Local cache of blobs of data
• Draft / Unsaved changes
• Passing data between pages

How do we remember?

• DOM Storage (aka sessionStorage / localStorage)
  • Easy, Fast, (Mostly) reliable
  • Will not persistent between machines
  • Might be cleared by user
  • Usually would be used where it is not a big deal if data is lost (or if it is short term storage)
• Remote DB
  • Usually would be used where it is important to remember

DOM Storage

localStorage / sessionStorage

Session Storage is a lie!

Session cookie is even a worse lie

We never use session storage/cookie

DOM Storage is per origin

• Storage is shared between all the pages that run on the same origin
• Storage is shared between all the people who use the same browser (think internet cafe, universities)
• Storage is shared between all the sites our same person builds
• Storage is *not* shared between http://www.wix.com and https://www.wix.com
• Storage is *not* shared between https://de.wix.com and https://fr.wix.com
• Problems: global namespace, shared quota (5MB), privacy

DOM Storage doesn't always work

• Incognito
• Quota exceeded
• Biggest problem: 3rd party storage policies

Conclusions

• Access to local storage needs to be namespaced
• Access to local storage needs to be scoped
• Local storage quota needs to be managed
• Access to local storage needs to be protected
• Wanted: better abstraction!

Introducing

Data Capsule

(aka wixStorage/wixCache)

import {LocalStorageCapsule} from 'data-capsule';

const capsule = new LocalStorageCapsule({namespace: 'engage'});
await capsule.setItem('shahata', 123);
console.log(await capsule.getItem('shahata')); // logs 123

How to use it

import {DataCapsule, LocalStorageStrategy} from 'data-capsule';
import secs from 'secs';

const capsule = new DataCapsule({
  strategy: new LocalStorageStrategy(),
  scope: {userId, siteId}, //optional
  namespace: 'engage' //required
});

await capsule.setItem('shahata', 123, {
  expiration: secs('2 days') //optional
});

console.log(await capsule.getItem('shahata')); // logs 123

Scope & Expiration

class BaseStrategy {
  setItem(key, value, {namespace, scope, expiration})
  getItem(key, {namespace, scope})
  removeItem(key, {namespace, scope})
  getAllItems({namespace, scope})
}

Strategies

Local Storage Strategy

const capsule = new DataCapsule({
  strategy: new LocalStorageStrategy()
});

• Manages expiration
• Auto cleans on quota exceeded
• Maintains LRU
• Consistent namespace & scope handling

Wix Storage Strategy

const capsule = new DataCapsule({
  strategy: new WixStorageStrategy()
});

• Saves to remote DB using user preferences service
• Scope are automatically per user, can be optionally per site
• Expiration is rounded to days

Cached Storage Strategy

const capsule = new DataCapsule({
  strategy: new CachedStorageStrategy({
    remoteStrategy: new WixStorageStrategy(),
    localStrategy: new LocalStorageStrategy()
  })
});

• Every value you get from server is cached locally (even if not found)
• Every time you set or remove, it is cached locally
• Expiration of local cache is up to 1 hour so it won't become stale

Frame Storage Strategy

const capsule = new DataCapsule({
  strategy: new FrameStorageStrategy(window.top, '*', 'secret'))
});

• Commands are sent with postMessage to top window
• Listener can get strategy in constructor (default is LocalStorageStrategy)
• Listener can authenticate using callback

Write your own strategy!

• IndexDBStrategy
• InMemoryStrategy
• EncryptedStrategy
• PigeonPostStrategy

Use it!

• https://github.com/wix/data-capsule
• Published to npm & bower
• Can be used both in new and old stack
• Test coverage 100%
• Open source

• https://github.com/wix/greedy-split
• https://github.com/wix/describe-jsdom
• https://github.com/wix/secs

Questions???
