Jetpack Compose Animations

From Beginner to Hero

Wajahat Karim

wajahatkarim.com

🔥 Google Dev Expert (GDE) in Android
⭐️ Android Engineering at Nebula
📱 Over 10 years in Android
💻 Open Source Contributor .
📝 Technical Blogs & Books Writer
🎤 International Public Speaker

Howdy! This is Wajahat Karim

Jetpack Compose

a modern UI toolkit which simplifies and accelerates UI development on Android with less code, powerful tools, and intuitive Kotlin APIs.

d.android.com/jetpack/compose

Made with Jetpack Compose

Alex Lockwood

Gurupreet Singh

Animations in Jetpack Compose

  • The animateContentSize() Modifier
  • The AnimatedVisibility Composable
  • Single Value Animations with animatec methods
  • Repeated Animations with Animatable
  • Utilizing transitions to make solid animations

Animations in Jetpack Compose

  • The animateContentSize() Modifier
  •
  • The AnimatedVisibility Composable
  • Single Value Animations with animate*AsState() methods
  • Repeated Animations with Animatable
  • Utilizing transitions to make solid animations

animateContentSize() Modifier

@Composable
fun ExpandableText() {
    val shortText = "Click me"
    val longText = "Very long text passage that spans
    		\nacross multiple lines, paragraphs
            	\nand pages"
    var short by remember { mutableStateOf(true) }
    Box(
        modifier = Modifier
            .background(
                Color.Blue,
                RoundedCornerShape(15.dp)
            )
            .clickable { short = !short }
            .padding(20.dp)
            .wrapContentSize()
            .animateContentSize()
    ) {
        Text(
            if (short) {
                shortText
            } else {
                longText
            },
            style = TextStyle(color = Color.White)
        )
    }
}

animateContentSize() Modifier

@Composable
fun PortraitModeImage() {
  var portraitMode by remember { mutableStateOf(true) }
  Box(
    Modifier.clickable { portraitMode = !portraitMode }
      .sizeIn(maxWidth = 300.dp, maxHeight = 300.dp)
      .background(
          if (portraitMode) Color.Yellow else Color.Green)
      .animateContentSize(
          animSpec = tween(500, easing = LinearEasing),
          endListener = { startSize, endSize ->
             Log.d("Compose", "$startSize -> $endSize")
          }
      )
      .aspectRatio(if (portraitMode) 3 / 4f else 16 / 9f)
    ) {
        Text(
          if (portraitMode) {
             "3 : 4"
          } else {
             "16 : 9"
          },
          style = TextStyle(color = Color.Black)
      )
    }
}

Animations in Jetpack Compose

  • The AnimatedVisibility Composable
  • The animateContentSize() Modifier
  •
  • Single Value Animations with animate*AsState() methods
  • Repeated Animations with Animatable
  • Utilizing transitions to make solid animations

AnimatedVisbility Composable

@OptIn(ExperimentalAnimationApi::class)
@Composable
fun VisibilityAnimationFAB() {
    var expanded by remember { mutableStateOf(true) }
    FloatingActionButton(
        onClick = { expanded = !expanded },
    ) {
        Row(Modifier.padding(start = 16.dp, end = 16.dp)) {
            Icon(
                imageVector = Icons.Default.Favorite,
                contentDescription = "Favorite Icon",
                Modifier.align(Alignment.CenterVertically)
            )
            AnimatedVisibility(
                expanded,
                modifier = Modifier.align(Alignment.CenterVertically)
            ) {
                Text(modifier = Modifier.padding(start = 8.dp), text = "Like")
            }
        }
    }
}

AnimatedVisbility Composable

@OptIn(ExperimentalAnimationApi::class)
@Composable
fun VisibilityAnimationFAB() {
    var expanded by remember { mutableStateOf(true) }
    FloatingActionButton(
        onClick = { expanded = !expanded },
    ) {
        Row(Modifier.padding(start = 16.dp, end = 16.dp)) {
            Icon(
                imageVector = Icons.Default.Favorite,
                contentDescription = "Favorite Icon",
                Modifier.align(Alignment.CenterVertically)
            )
            AnimatedVisibility(
                expanded,
                modifier = Modifier.align(Alignment.CenterVertically),
                enter = slideInHorizontally(
                    initialOffsetX = { 300 },
                    animSpec = tween(durationMillis = 2000)
                ),
                exit = slideOutVertically(
                    targetOffsetY = { 100 },
                    animSpec = tween(durationMillis = 2000)
                )
            ) {
                Text(text = "Like")
            }
        }
    }
}

Default

Enter

Enter + Exit

AnimatedVisbility Composable

cs.android.com

AnimatedVisibility in LazyColumn

AnimatedVisibility in multiple Composables

Animations in Jetpack Compose

  • Single Value Animations with animate*AsState() methods
  • The animateContentSize() Modifier
  • The AnimatedVisibility Composable
  • Single Value Animations with animate*AsState() methods
  • Repeated Animations with Animatable
  • Utilizing transitions to make solid animations

The animate*AsState() methods

The fire-and-forget functions to create single value based animations.

  • Previously, the animate() method. - DEPRECATED
  • The animatedColorAsState() for Colors
  • The animatedDpAsState() for DP values
  • And more...

The animate*AsState() methods - 1

@Composable
fun ScaleAndColorAnimation() {
    val enabled = remember { mutableStateOf(true) }

    val color: Color by animateColorAsState(
        if (enabled.value) Color.Blue else Colors.green)

    val height: Dp by animateDpAsState(if (enabled.value) 40.dp else 60.dp)
    val width: Dp by animateDpAsState(if (enabled.value) 150.dp else 300.dp)

    Button(
        onClick = { enabled.value = !enabled.value },
        colors = ButtonDefaults.buttonColors(backgroundColor = color),
        modifier = Modifier
            .padding(16.dp)
            .preferredHeight(height)
            .preferredWidth(width),
    ) {
        Text("Scale & Color")
    }
}

The animate*AsState() methods - 2

@Composable
fun GenderSelectAnimation() {
  val female = remember { mutableStateOf(true) }
  Row(horizontalArrangement = Arrangement.Center,
      modifier = Modifier.padding(8.dp).fillMaxWidth(),
      verticalAlignment = Alignment.CenterVertically
  ) {
      Image(
        painter = painterResource(R.drawable.male),
        contentDescription = "Male Image",
        contentScale = ContentScale.Crop,
        modifier = Modifier
            .preferredSize(animateDpAsState(if (female.value) 100.dp else 250.dp).value)
            .border(width = animateDpAsState(if (female.value) 0.dp else 4.dp).value,
                color = animateColorAsState(if (female.value) Color.Transparent else Color.Red).value)
            .padding(8.dp)
            .clickable { female.value = !female.value }
      )
      Image(
        painter = painterResource(R.drawable.female),
        contentDescription = "Female Image",
        contentScale = ContentScale.Crop,
        modifier = Modifier
        // ...
        // Like previous image
      )
  }
}

Examples of animate*AsState() methods

By Gurupreet Singh

github.com/Gurupreet/ComposeCookBook

Animations in Jetpack Compose

  • Repeated Animations with Animatable
  • The animateContentSize() Modifier
  • The AnimatedVisibility Composable
  • Single Value Animations with animate methods
  • Repeated Animations with Animatable
  • Utilizing transitions to make solid animations

Repeated Animations with Animatable

@Composable
fun HeartBeatDemo() {
    val animScale = remember { Animatable(initialValue = 1f) }
    val animColor = remember { Animatable(initialValue = Color.Red) }

    LaunchedEffect(animScale) {
        animScale.animateTo(
            targetValue = 2f,
            animationSpec = infiniteRepeatable(
                animation = tween(durationMillis = 300, delayMillis = 1000),
                repeatMode = RepeatMode.Reverse
            )
        )
    }

    LaunchedEffect(animColor) {
        animColor.animateTo(
            targetValue = Color.Blue,
            animationSpec = repeatable(iterations = 2,
                animation = tween(durationMillis = 300, delayMillis = 1000),
                repeatMode = RepeatMode.Reverse
            )
        )
    }

    Image(imageVector = Icons.Default.Favorite,
    	contentDescription = "Favourite Icon",
        modifier = Modifier.padding(10.dp).size((40*animScale.value).dp),
        colorFilter = ColorFilter.tint(animColor.value)
    )
}

Compose Canvas 101

A simple Spacer() to allow you to draw anything on it

@Composable
fun Canvas
(
   modifier: Modifier,
   onDraw: DrawScope.() -> Unit
) = Spacer(modifier.drawBehind(onDraw))

Compose Canvas 101

DrawScope - Handles the drawing API

drawRect()

drawOval()

drawLine()

drawImage()

drawRoundRect()

drawCircle()

drawArc()

drawPath()

fun DrawScope.drawMyShape() { }

Compose Canvas 101

Custom View Example in Canvas

Canvas(modifier = Modifier.fillMaxSize()) {
    drawCircle(
        color = Color.Red,
        radius = 300f
    )

    drawCircle(
        color = Color.Green,
        radius = 200f
    )

    drawCircle(
        color = Color.Blue,
        radius = 100f
    )
}

Animatable on Canvas

@Composable
fun MovingSquare() {
    val animPosX = remember { Animatable(initialValue = 0f) }

    LaunchedEffect(animPosX) {
        animPosX.animateTo(
            targetValue = 500f,
            animationSpec = infiniteRepeatable(
                animation = tween(durationMillis = 1000)
            )
        )
    }

    Canvas(modifier = Modifier.preferredSize(100.dp), onDraw = {
        withTransform({
            translate(left = animPosX.value)
        }) {
            drawRect(color = Color.Red)
        }
    })
}

A simple moving square example

More Canvas Examples

Its all about mathematics & drawing

 github.com/wajahatkarim3/DinoCompose

By Alex Lockwood

github.com/alexjlockwood/bees-and-bombs-compose/

Animations in Jetpack Compose

  • Utilizing transitions to make solid animations
  • The animateContentSize() Modifier
  • The AnimatedVisibility Composable
  • Single Value Animations with animate methods
  • Repeated Animations with Animatable
  • Utilizing transitions to make solid animations

Transitions - 1

class DemoActivity : AppCompatActivity() {
   override fun onCreate(savedInstanceState: Bundle?) {
      super.onCreate(savedInstanceState)
      setContent {
         DemoTheme {
            Scaffold(
               topBar = {
                  TopAppBar( /* App Bar */ )
               },
               floatingActionButton = {
                  ExplodingFabButton()
               },
               bodyContent = {
                  // Content Composables
              }
           }
        }
    }
}

Transitions - 2

enum class FabSizeState {
    NORMAL, EXPLODED
}

@Composable
fun ExplodingFabButton() {
   var fabSizeState by remember { mutableStateOf(FabSizeState.NORMAL) }

   val fabTransition: Transition<FabSizeState> = updateTransition(fabSizeState)

   val fabSize: Float by fabTransition.animateFloat() { state ->
        when (state) {
            FabSizeState.NORMAL -> 80f
            FabSizeState.EXPLODED -> 5000f
        }
    }

    val fabColor: Color by fabTransition.animateColor() { state ->
        when (state) {
            FabSizeState.NORMAL -> secondaryColor
            FabSizeState.EXPLODED -> primaryColor
        }
    }
}

Transitions - 3

@Composable
fun ExplodingFabButton() {
   var fabSizeState by remember { mutableStateOf(FabSizeState.NORMAL) }

   val fabTransition: Transition<FabSizeState> = updateTransition(fabSizeState)

   val fabSize: Float by fabTransition.animateFloat() { /* from previous slide */ }
   val fabColor: Color by fabTransition.animateColor() { /* from previous slide */ }

   FloatingActionButton(
        onClick = {
            fabSizeState = if (fabSizeState == FabSizeState.NORMAL)
                FabSizeState.EXPLODED
            else FabSizeState.NORMAL
        },
        modifier = Modifier.size(fabSize.dp),
        backgroundColor = fabColor
    ) {
        Icon(
            imageVector = Icons.Default.Add,
            contentDescription = "Add"
        )
    }
}

Transitions - 4

val fabSize: Float by fabTransition.animateFloat(
        transitionSpec = {
            when {
                FabSizeState.NORMAL isTransitioningTo FabSizeState.EXPLODED -> {
                    keyframes {
                        durationMillis = 1000
                        80f at 0
                        35f at 200
                        5000f at 1000
                    }
                }
                FabSizeState.EXPLODED isTransitioningTo FabSizeState.NORMAL -> {
                    tween(durationMillis = 1000, easing = FastOutSlowInEasing)
                }
                else -> snap()
            }
        }
    ) { state ->
        when (state) {
            FabSizeState.NORMAL -> 80f
            FabSizeState.EXPLODED -> 5000f
        }
    }

Transitions - 5

Transitions - Examples

By Joe Birch

https://joebirch.co/

By Ray Wenderlich

https://www.raywenderlich.com/13282144-jetpack-compose-animations-tutorial-getting-started

By  Myself

https://github.com/wajahatkarim3/Flippable

https://joebirch.co/

Animation Inspector

Which animation API to use?

https://developer.android.com/jetpack/compose/animation

Resources

Alex Lockwood

https://github.com/alexjlockwood/bees-and-bombs-compose

https://github.com/alexjlockwood/android-2048-compose

Joe Birch

https://joebirch.co/exploring-jetpack-compose/

Gurupreet Singh

https://github.com/Gurupreet/ComposeCookBook

Leland Richardson

https://www.twitch.tv/intelligibabble

Official by Google

https://developer.android.com/courses/pathways/compose

Vinay Gaba

https://github.com/vinaygaba/Learn-Jetpack-Compose-By-Example

Thank You for Listening!

Code is available at

http://github.com/wajahatkarim3/ComposeAnimationsDemo

WajahatKarim

wajahatkarim.com/subscribe

wajahatkarim.com

Animating Your Jetpack Compose Apps

By Wajahat Karim

Made with Slides.com

Animating Your Jetpack Compose Apps

In this talk, we will see how to develop various animations in Jetpack Compose

  • 1,819

More from Wajahat Karim
