HTTP/2

Intro & Practice

Old Problems

- FIFO can't use duplex  connection

- browsers use a lot of connections in concurrency

- big header problem

- setup a connection is expensive and we don't reuse it

- server push is hard to implement

Key features

- Binary Framing

- Multiplexing

- Header Compression

- Server Push

- Others ref to RFC 7540: https://tools.ietf.org/html/rfc7540

Verify plan

- Setup a simple website in HTTP/1.1

- Setup two websites with different HTTP/2 features

- Use docker-compose to map different ports

- Use wireshark to verify binary framing

- Setup self-signed certificate to use TLS in default

Practice location: https://github.com/yc-zhang/http2-practice

Binary Framing & Multiplexing

• Goal: one domain, one connection
• Implementation:  Binary Framing & Streams
• Binary Framing: instead of RAW ASCII, seal data into different frames
  • HEADERS\DATA\PRIORITY\SETTINGS...
• Streams: the carrier of frame in logical, HTTP2 use it to deal with multiplexing
  • 1 connection - N streams
  • could be used for single or shared
  • independent, bidirectional sequence of frame exchange
  • stream groups share context & flow-control
• One connection:  TCP-SLOW START problem & bandwidth

Header compression

• Save bits: find a algorithm and apply it
• HPACK - rfc7541
• GZIP security risk:
  • CRIME could attack with stream compression
  • https://en.wikipedia.org/wiki/CRIME

Server push

• Server to provide content to clients without waiting for a request
• Save time & Improve user experience
• It's not designed to replace web-socket
• Suitable time and consider the cache
• Not EASY to deal, follow the best practice before you go

Others

• Security consideration
• HTTP/2 is a new protocol which supports HTTP/1.1 syntax
• Hard to implement below the application layer
• What about keep-alive
• What about load balance (HTTP LB or TCP LB)
• What about customized forwarder or PROXY?
• Could server push replace web-socket or the other RPC?
• Impact to WebServices
• ...

Thanks~
