Armagan Amcalar
JSIST 2014, Istanbul
Sep 27th, 2014
Armagan Amcalar
Co-founder, Chief Software Architect
Startup Kitchen
dashersw
We love it.
We develop all kinds of software with it.
We love to daemonize it.
It doesn't scale well.
Programming model encourages stateful app design
Works great as single process
Works OK as a cluster
What if you need more computing power?
How about horizontal scalability?
Easy to set up if you're familiar with nginx
Hard to maintain
Yet another technology dependency
Hard to set up even if you're familiar
Hard to maintain
Very low level
Because we have more problems
We're not just building express apps
We were programming the DOM, we need that flexibility
Be fast with your API response
Asynchronous processing (e.g., analytics)
You may need to scale very dynamically
Fault tolerance
THE YEAR'S 2014, WHERE ARE THE EVENTS?
Single code base
One process to rule them all
A bug anywhere crashes the whole system
May consume lots of stale resources
Hard to scale; needs even more stale resources
Request–response flow is one huge piece
Easy to manage
Separate code base
Multi processes for each service
A bug in a service crashes only that service
Consumes minimal resources
Scales well, needs minimal additional resources
Supports event-driven architecture
Request–response flow breakdown
Hard to manage
Just like DOM events, what we're used to build.
Instead of click events, you have custom events (e.g. in jQuery)
Instead of DOM element interaction, you have daemon interaction
First-of-its-kind event driven pattern
You observe an object property, not an arbitrary event
Like all your click handlers have to have the same name
Limits possibilities
Originally a NoSQL database
Key-value pair server with lots of great features like sets, etc.
Pub-sub capability
Supports events based on channels and patterns
Very cool node.js library
redis
d1
d4
d3
d2
publishes foo
notifies of foo
notifies of foo
notifies of foo
client request
session storage
logs
API
var redis = require('redis'),
client = redis.createClient(6379, '127.0.0.1');
client.publish('request', JSON.stringify({
body: 'some cool request'
}));
var redis = require('redis'),
logger = redis.createClient(6379, '127.0.0.1');
logger.subscribe('request');
logger.on('message', function(channel, message) {
if (channel == 'request')
console.log(JSON.parse(message));
});
Client
Logger
A message broker for distributed applications
Like redis pubsub, with heavy focus on additional features
such as very flexible message routing
work queues, topics, etc.
QoS management
round robin load balancing
message acks
rate limiting
unfriendly node.js library
var amqp = require('amqp'),
connection = amqp.createConnection(),
workId = 0;
connection.on('ready', function() {
connection.queue('work_queue', {autoDelete: false, durable: true}, function(queue) {
setInterval(function() {
connection.publish('work_queue', 'message #' + ++workId, { deliveryMode: 2 });
console.log('sent message #' + workId);
}, 1000);
});
});
var amqp = require('amqp'),
connection = amqp.createConnection();
connection.on('ready', function () {
connection.queue('work_queue', {autoDelete: false, durable: true}, function(queue) {
queue.subscribe({ack: true, prefetchCount: 1}, function(msg) {
var body = msg.data.toString('utf-8');
console.log("received", body);
queue.shift(); // basic_ack equivalent
});
});
});
node.js framework for fault tolerant, distributed apps
developed at Startup Kitchen
partially funded by TUBITAK
auto-discovery
mesh network, peer-to-peer communication
pubsub pattern
requester/responder pattern
client-side communication with websockets
load balancing with different strategies
daemon monitor
var Publisher = require('cote').Publisher,
publisher = new Publisher({
name: 'publisher',
broadcasts: ['update']
}),
workId = 0;
publisher.on('ready', function() {
setInterval(function() {
console.log('emitting', ++workId);
publisher.publish('update', workId);
}, 3000);
});
var Subscriber = require('cote').Subscriber,
subscriber = new Subscriber({
name: 'subscriber'
});
subscriber.on('update', function(message) {
console.log('update', message);
});
With Redis, RabbitMQ or cote.js we can;
Apply sophisticated programming paradigms
Scale nearly infinitely
Have fault-tolerant systems
Armagan Amcalar
armagan@amcalar.com
twitter: @aamcalar
github: dashersw
blog: arm.ag
examples at https://github.com/dashersw/node-scale
By Armağan Amcalar
Node.js has proven itself as a very useful environment for building network applications. Yet, JavaScript being single-threaded, a problem remains on scaling your application horizontally to accommodate client requests. In this talk, we’ll explore multi process scaling with Redis pub-sub, a message queuing topology with RabbitMQ, and a step further to fault tolerant microservices with cote.js.
