Getting Started With d3.js

bit.ly/d3js_presentation

@delainewendling

Delaine Wendling

What is d3.js?

D3 (Data-Driven Documents or D3.js) is a JavaScript library for visualizing data

Goals of this Talk

Explain why data visualizations are powerful
Compare different data libraries and their respective advantages and disadvantages
Become more familiar with d3 syntax and patterns so that its numerous examples are less intimidating
Create a few charts

Where and why are data visualizations used?

Google Forms

Mint.com

The government

What's out there?

ChartJs - supports 6 different chart styles.

Dygraphs - supports line charts and can handle a lot of data.

ZingChart - supports multiple charts, has very few customization options.

Google Charts - supports multiple chart options.

*High Charts and Fusion Charts are only free for non-commercial use

PROS

CONS

Highly customizable

Steep learning curve

Lightweight

Large community with a lot of examples for inspiration

IE 6-8 not supported

Many projects built on top of d3 (NVD3, crossfilter, DC)

Chart export

Label Management

Why d3.js?

https://codepen.io/dwendlingRHS/pen/JNqQLx

Why do we even need a visualization library?

ENTER

EXIT

Update

ENTER

UPDATE

<div class="chart">
  <img>
  <img>
</div>

HTML

const dataArr = [
{id: 1, alive: true, img: "http://bit.ly/romeo_character"},
{id: 2, alive: true, img:"http://bit.ly/juliet_character"}];

let chart = d3.select(".chart");

let selection = chart.selectAll("img")
            .data(dataArr)
            .attr("src", d => d.img)
            .style({left: (d, i) => i*110 + "px"});

JavaScript

https://codepen.io/dwendlingRHS/pen/pwZRRx?editors=1010

ENTER

<div class="chart">
  <img>
  <img>
</div>

HTML

let dataArr = [
{id: 1, alive: true, img: "http://bit.ly/romeo_character"},
{id: 2, alive: true, img:"http://bit.ly/juliet_character"}];

dataArr = [...dataArr,
{id: 3, alive: true, img: "http://bit.ly/lordcapulet_character"},
{id: 4, alive: true, img:"http://bit.ly/ladycapulet_character"}];

let chart = d3.select(".chart");

let selection = chart.selectAll("img")
            .data(dataArr)
selection.attr("src", d => d.img)
            .style({left: (d, i) => i*110 + "px"});
selection.enter().append("img")
            .attr("src", d => d.img)
            .style({left: (d, i) => i*110 + "px"});

JavaScript

https://codepen.io/dwendlingRHS/pen/gRjgGx

<div class="chart"></div>

HTML

const dataArr = [
{id: 1, alive: true, img: "http://bit.ly/romeo_character"},
{id: 2, alive: true, img:"http://bit.ly/juliet_character"}];

function createPlay(data){
  let chart = d3.select(".chart");

  let selection = chart.selectAll("img")
                       .data(data)
  selection.enter().append("img")
           .attr("src", d => d.img)
           .style({left: (d, i) => i*110 + "px"});
}

createPlay(dataArr);

const newData = [...dataArr,
{id: 3, alive: true, img: "http://bit.ly/lordcapulet_character"},
{id: 4, alive: true, img:"http://bit.ly/ladycapulet_character"}];

createPlay(newData);

JavaScript

https://codepen.io/dwendlingRHS/pen/JJBEBX

EXIT

const dataArr = [
{id: 1, alive: true, img: "http://bit.ly/romeo_character"},
{id: 2, alive: true, img:"http://bit.ly/juliet_character"},
{id: 3, alive: true, img: "http://bit.ly/lordcapulet_character"},
{id: 4, alive: true, img:"http://bit.ly/ladycapulet_character"}];

function createPlay(data){
  let chart = d3.select(".chart");

  let selection = chart.selectAll("img")
                       .data(data)
  selection.enter().append("img")
           .attr("src", d => d.img)
           .style({left: (d, i) => i*110 + "px"});
  selection.exit().remove();
}

createPlay(dataArr);

const newData = dataArr.filter(d => +d.id === 2);

createPlay(newData);

https://codepen.io/dwendlingRHS/pen/gRjEwg

EXIT

Existing

New Data

const dataArr = [
{id: 1, alive: true, img: "http://bit.ly/romeo_character"},
{id: 2, alive: true, img:"http://bit.ly/juliet_character"},
{id: 3, alive: true, img: "http://bit.ly/lordcapulet_character"},
{id: 4, alive: true, img:"http://bit.ly/ladycapulet_character"}];

function createPlay(data){
  let chart = d3.select(".chart");

  let selection = chart.selectAll("img")
                       .data(data, d => +d.id)
  selection.enter().append("img")
           .attr("src", d => d.img)
           .style({left: (d, i) => i*110 + "px"});
  selection.exit().remove();
}

createPlay(dataArr);

const newData = dataArr.filter(d => +d.id === 2);

createPlay(newData);

https://codepen.io/dwendlingRHS/pen/vZaPJX

Existing

New Data

Update

const dataArr = [
{id: 2, alive: true, img:"http://bit.ly/juliet_character"}];

function createPlay(data){
  let chart = d3.select(".chart");

  let selection = chart.selectAll("img")
                       .data(data, d => d.img)
  selection.enter().append("img")
           .attr("src", d => d.img)
           .style({left: (d, i) => i*110 + "px"});
  selection.exit().remove();
}

createPlay(dataArr);

const newData =  dataArr.map(character => {
  return {...character,
img: "http://bit.ly/julietdead_character"}
});

createPlay(newData);

https://codepen.io/dwendlingRHS/pen/OgwqvO

ENTER

const dataArr = [
{id: 2, alive: false, img: "http://bit.ly/julietdead_character"}];

function createPlay(data){
  let chart = d3.select(".chart");

  let selection = chart.selectAll("img")
                       .data(data, d => d.img)
  selection.enter().append("img")
           .attr("src", d => d.img)
           .style({left: (d, i) => i*110 + "px"});
  selection.exit().remove();
}

createPlay(dataArr);

const newData =  [...dataArr, {id:1, alive: true,
img:"https://bit.ly/romeo_character"}];

createPlay(newData);

https://codepen.io/dwendlingRHS/pen/awjMxv

UPDATE

const dataArr = [{id:1, alive: true, img:"https://bit.ly/romeo_character"},
{id: 2, alive: false, img: "http://bit.ly/julietdead_character"}];

function createPlay(data){
  let chart = d3.select(".chart");

  let selection = chart.selectAll("img")
                       .data(data, d => d.img)
  selection.enter().append("img")
           .attr("src", d => d.img)
           .style({left: (d, i) => i*110 + "px"});
  selection.exit().remove();
}

createPlay(dataArr);

const newData = dataArr.map(character => {
  return character.id == 1 ? {...character, alive: false,
img: "http://bit.ly/romeodead_character"} : character
});

createPlay(newData);

https://codepen.io/dwendlingRHS/pen/owMOvB

Let's Review

SVG

<svg>
  <rect x="25" y="25" width="200" height="200"
        fill="lime" stroke-width="4" stroke="pink" />
  <circle cx="125" cy="125" r="75" fill="orange" />
  <polyline points="50,150 50,200 200,200 200,100"
        stroke="red" stroke-width="4" fill="none" />
  <line x1="50" y1="50" x2="200" y2="200"
        stroke="blue" stroke-width="4" />
</svg>
