Structuring web applications with Backbone.js


Diego Cardozo
github.com/diegocard/backbone-presentation

Goals


  • This presentation isn't only a Backbone tutorial
  • We'll focus on complex client design
  • Using Backbone as the main tool
  • Most concepts won't be tool-specific
  • Can be applied to other tools like Angular or Knockout
  • We'll learn Backbone through examples

    What do I want you to learn?


    • Useful concepts for complex web client design
    • Basic Backbone knowledge
    • Motivation to keep learning

      For those who already know Backbone

    • Good practices
    • Combination with other tools

    Agenda


    1. Introduction
    2. Architecture
    3. Example
    4. Backbone components
    5. Structuring a web application

    Introduction (1)


    • Web clients have better resources every day
    • We can now build smart clients
    • But complex applications with jQuery...
      • Are hard to build
      • Lack structure
      • Do not favor reutilization
      • Creating your own structure is reinventing the wheel

    Introduction (2)



    Introduction (3)


    • Backbone gives us
      • Structure for our client-side JavaScript code
      • Several utilities
    • Basically, it is a MV* framework
    • We organize code in different components
      • Models
      • Collections
      • Views
      • Templates
      • Routers

    Architecture (1)



    Architecture (2)


    Advantages

    • Maintainability
    • Load distribution
    • Quicker start to the development process
    • UI is only another client
    • Great for testing
    • Perfect for combining with mobile apps




    Example

    github.com/diegocard/backbone-presentation/demo

    Components (1)


    Model
    var User = Backbone.Model.extend({      urlRoot: '/users'});

    Components (2)


    Collection
    var Users = Backbone.Collection.extend({        url: '/users'});


    Components (3)


    View
    var UserListView = Backbone.View.extend({
        el: '.page',
        render: function () {
            var that = this;
            var users = new Users();
            users.fetch({
                success: function (users) {
                    var template = _.template(
                        $('#user-list-template').html(),
                        {users: users.models}                );
                    that.$el.html(template);
                }
            })
        }
    });

    Components (4)


    Event handling
    var UserEditView = Backbone.View.extend({
        el: '.page',
        events: {
            'submit .edit-user-form': 'saveUser',
            'click .delete': 'deleteUser'
        },
        saveUser: function (ev) {
            var userDetails = $(ev.currentTarget).serializeObject();
            var user = new User();
            user.save(userDetails, {
                success: function (user) {
                    router.navigate('', {trigger:true});
                }
            });
        }
    });

    Components (5)


    Template
    <script type="text/template" id="user-list-template">
      <a href="#/new" class="btn btn-primary">New</a>
      <hr />
      <table class="table striped">
        <thead>
          <tr>
            <th>First Name</th><th>Last Name</th><th>Age</th><th></th>
          </tr>
        </thead>
        <tbody>
          <% _.each(users, function(user) { %>
            <tr>
              <td><%= htmlEncode(user.get('firstname')) %></td>
              <td><%= htmlEncode(user.get('lastname')) %></td>
              <td><%= htmlEncode(user.get('age')) %></td>
              <td><a class="btn" href="#/edit/<%= user.id %>">Edit</a></td>
            </tr>
          <% }); %>
        </tbody>
      </table>
    </script>

    Components (6)


    Router
     var Router = Backbone.Router.extend({
         routes: {
             "": "home",
             "edit/:id": "edit",
             "new": "edit",
         }
     });

    Structure (1)


    Structure (2)


    Suggested structure
    Root
    ├── imgs
    ├── css
    │   └── style.css
    ├── templates
    │   ├── projects
    │   │   ├── list.html
    │   │   └── edit.html
    │   └── users
    │       ├── list.html
    │       └── edit.html
    ├── js
    │   ├── libs
    │   │   ├── jquery
    │   │   │   ├── jquery.min.js
    │   │   ├── backbone
    │   │   │   ├── backbone.min.js
    │   │   └── underscore
    │   │   │   ├── underscore.min.js
    │   ├── models
    │   │   ├── users.js
    │   │   └── projects.js
    │   ├── collections
    │   │   ├── users.js
    │   │   └── projects.js
    │   ├── views
    │   │   ├── projects
    │   │   │   ├── list.js
    │   │   │   └── edit.js
    │   │   └── users
    │   │       ├── list.js
    │   │       └── edit.js
    │   ├── router.js
    │   ├── app.js   //Initialize the router
    │   ├── main.js
    │   ├── order.js //Require.js plugin
    │   └── text.js  //Require.js plugin
    └── index.html

    Structure (3)

    Example: Proyect list
    define([
      'jquery',
      'underscore',
      'backbone',
      // Using the text! plugin for Require.js,
      // we can load templates as plain text
      'text!templates/project/list.html'], function($, _, Backbone, projectListTemplate){
      var ProjectListView = Backbone.View.extend({
        el: $('#container'),
        render: function(){
          // Compile the template with underscore
          // and add the template to the view element
          var data = {};
          var compiledTemplate = _.template(projectListTemplate, data);
          this.$el.append(compiledTemplate);
        }
      });
      return ProjectListView; // Return the view
    });

    Resources



    ¿Questions?
