Who is this guy?

Dmitry Paunin

Technical Group Manager at Lazada, OPS department

What is docker?

Docker is an open-source project that automates the deployment of applications inside software containers.

How to build a good image?

What is kubernetes

Kubernetes/K8s is "Open source container cluster", which allows:

• Deploy your applications quickly and predictably
• Scale your applications on the fly
• Seamlessly roll out new features
• Optimize use of your hardware

Why containers?Why Kubernetes?

• Agile application creation and deployment
• Continuous development, integration, and deployment
• Dev and Ops separation of concerns
• Environmental consistency across development, testing, and production
• Cloud and OS distribution portability
• Application-centric management
• Loosely coupled, distributed, elastic, liberated micro-services
• Resource isolation
• Resource utilization

Answering question about "good images"!

130 checkboxes in our list...

Checklist URL

https://github.com/paunin/soa-checklist

Administrative
(people, flows, responsibilities)

• Blueprint/template for a new service
• Documentation, standards, guides
  • how-to, know-how documents
• Team support
  • Understanding of the whole process by each member
  • Pro-active development and support
  • Accepted responsibilities and duties for each stage of a service
• Plan for service live circle
  • Pre-production development
  • Launching
  • Rollout backward compatible version of a service
  • Hotfixing
  • Rollout backward incompatible version of a service
    • Data migration
    • Switchover
    • Service rollback

Automated processes

• Continuous development
  • Tests
    • Automated(Unit tests, Functional tests, Code style: lints and sniffers, Code quality monitoring (Sonar, Scrutinizer), Code coverage checks
    • Manual (Feature acceptance/Business acceptance, A/B tests)
  • Conditions of integration: Code style checks, Test results, Code coverage percentage
  • Conditions of disintegration a feature: Error rate after deploy live, Helthchecks
  • Storing a new tested snapshots/artefact of a service
    • Artefact storage (Docker registry)
      • Cleanup policy (Delete old tags with timeout)
• Continuous delivery of stable artefacts
  • Images builder
  • Services provisioning (Ansible)

Implementation

Architecture Layers

Implementation
vol.1

Hardware: Servers and networks

• Scaling (adding new nodes) should not affect consistency of other layers
• Degradation (removing nodes) should not affect consistency of other layers
• Monitoring
  • Hardware
  • Network
  • Resources and load
• Alerting policy

Implementation
vol.2

Cluster: Services management system

• Monitoring
  • Availability of each node in the cluster
  • All services up and running
  • Connectivity between different pods and services
  • Public endpoints accessibility
• Alerting policy
• Restart (full or partial) should bring cluster and systems up without destruction
• Log aggregation system - collect all logs from all containers

• Execution environment
  • Meta-project with topology of the system
    • Showroom + Staging
      • Separate namespace for each showroom
      • Fixed showroom for the staging (last stable pre-release)
    • Production
      • Configuration
        • Secrets
        • Configs should be a part of the meta-project

Implementation
vol.3

Service: Application and any service

• Service itself (Docker image)
  • Backward compatibility for a few generations
    • Cleanup policy for deprecated/unused:
      • Logic branches
      • Data structures (RDBMS/NoSql)
  • One container - one process
    • Segregated commands even in one image (management layer can pick any to run)
    • Built in commands
      • Test service/source code (docker compose to setup required test ENV)
    • DEV/DEBUG mode
  • Logging
    • Writing in stdout (without using containers’ file system) will enforce cluster layer to keep all logs

• ...Service itself (Docker image)
  • Monitoring
    • Application and business checks (New Relic: throughput, metrics)
    • Self health checks (metrics+Prometeus+Grafana)
      • Queues content (amount of messages)
      • Db content (custom checks)
      • Cache utilization check
  • Alerting policies (Prometeus, NewRelic)

• ...Service itself (Docker image)
  • Self-sufficiency
    • Interfaces documentation
      • Restful API
        • Swagger
      • Port and service description (README.md files)
    • Service should be able to set itself up
      • Wait for required related services and ports (dockerize)
      • Configuring from environment variables (confd)
      • Warming up
        • Run data migration (needed maintenance service)
        • Cache fulfilment

• Replication, balancing and scaling on service level
• Failover and self-reorganisation in case of:
  • Service crashed
  • Physical node out of cluster
  • Resources problems on specific node
• Logs system
  • Service to collect and access logs grabbed from Cluster layer
    • ELK stack/Gray Log/etc
• Persistent volumes to keep data
  • EBS AWS
  • Ceph
  • NFS

Implementation
vol.4

Common services

• Single sign-on service
  • Authentication service (JWT)
  • Authorization requests from all services
• Detached processing (CQRS)
  • Request-Queue-Processor schema
  • Stream data addressing and processing (Reactor)
• Real Time data requests processing
  • Reliable data provider/API gateway (sync data retrieving)
    • Request-Manager-Service solution
• Reliable data-bus for events
  • Event-Broker-Subscriber solution (Apache Camel)
    • Http/TCP API endpoint to accept events
    • Event fulfilment (Earn required information for subscribers)
    • Event delivery
    • Event delivery policies: Retry, Reque, Giveup

• RDBMS: Postgres cluster
• DB backups: PG backupper
• Key-value + Queue: Redis cluster
• Messages system: Rabbit MQ cluster
• Healthcheck system
• Alerting system
