Today's task

Learn to write a simple IDE plugin in 30 minutes!

Today's task

Simple means:

• one basic functionality

• no fancy UI (standard input dialog instead)

Today's task

search for posts (having a specific term) on Stack Overflow

Setup

https://github.com/antonsarov/codepot-ide-workshop

https://slides.com/duxanton/codepot-ide-workshop

Eclipse

Eclipse

1) File -> New -> Plug-in Project

check 'plug-in will make contributions to the UI'

set create a 3.x rich client application to 'No'

Eclipse

Extension

Extension Point

Eclipse

Menus

Commands

Bindings

Handlers

org.eclipse.ui.menus

org.eclipse.ui.commands

org.eclipse.ui.bindings

IHandler interface

Eclipse

Ctrl / Cmd

Shift

Alt

M1

M2

M3

scheme ID: org.eclipse.ui.defaultAcceleratorConfiguration

context ID: org.eclipse.ui.contexts.window

Bindings Tips and Tricks

Eclipse

extend AbstractHandler instead of implementing IHandler

use the HandlerUtil class for UI interaction

Handlers Tips and Tricks

Eclipse

Launching the plugin

right click on the project -> Run As -> Eclipse Application

or

define a Run Configuration (of type Eclipse Application) manually

Eclipse

Distribute your plugin

Export plug-in in directory / as archive

or

Create a feature wrapping your plugin and then provide it via an update site

Eclipse

Distribute your plugin (with a Feature)

1) File -> New -> Feature Project

2) Select your plugin

3) Export your feature as Deployable feature to some location (e.g. local folder)

4) Use the Eclipse Install New Software wizard to install your feature from the above location

Eclipse

Recommended starting points

• http://www.vogella.com/tutorials/EclipsePlugIn/article.html
• https://marketplace.eclipse.org/

IntelliJ IDEA

IntelliJ IDEA

1) File -> New -> Project -> IntelliJ Platform Plugin

2) New Project SDK -> Java SDK (if not already set) -> Home directory for IntelliJ Platform Plugin (CE installation)

IntelliJ IDEA

1. on 'src' folder -> New -> Action

2. fill neccessary information

3. implement custom logic

or ...

IntelliJ IDEA

1. Write a class which extends AnAction

2. Implement the only method

public void actionPerformed(AnActionEvent e);

3. Reference the class in the META-INF/plugin.xml (and edit plugin.xml further if needed)

IntelliJ IDEA

Launching the plugin

Run -> Edit configurations -> Add new Plugin configuration

Tips:

check 'Single instance only'

check 'Show idea.log'

IntelliJ IDEA

Distribute your plugin

Build -> Prepare Plugin Module ... For Deployment

IntelliJ IDEA

Recommended starting points

• http://www.jetbrains.org/intellij/sdk/docs/index.html
• https://plugins.jetbrains.com/?idea

NetBeans

NetBeans

File -> New Project -> NetBeans Modules -> Module

NetBeans

1) Write a class which implements ActionListener

2) Implement the only method

public void actionPerformed(ActionEvent e);

NetBeans

Ctrl+Shift+S

Alt+Enter

Alt+Shift+S

DS-S

O-ENTER

OS-S

ActionReference Shortcuts

NetBeans

Run -> Run Project

or

right-click on the Module -> Install/Reload in Development IDE (not recommended)

Launching the plugin

NetBeans

right-click on the Module -> Create NBM

Distribute your plugin

NetBeans

Recommended starting points

• https://platform.netbeans.org/tutorials/nbm-google.html
• http://plugins.netbeans.org/PluginPortal/
