Communicate an NFC reader with a web application
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
Gautier Darchen
- 23 🎂
-
Fullstack dev at Takima since 2018
Working at Cartier in a lab- React
- Node.js
- Java / Spring
- Devops
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/5584824/takima.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6714165/cartier-blanc.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/7032352/haute-jo.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/7012344/71NlGMRzpzL._SY879_.jpg)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/7012344/71NlGMRzpzL._SY879_.jpg)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/7012344/71NlGMRzpzL._SY879_.jpg)
- Easily know the remaining tasks to be performed on a piece of jewelry for a given person
- Bar code / QR code
-
Innovation & a lot of data to hold
-
Innovation & a lot of data to hold
-
RFID- Short-range
- Short-range
- NFC ✅
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6714264/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
NFC today
- Omnipresent in our daily life
- Contactless payment, access badge, etc.
- Cheap (NTAG 213 : about $ 0.08 per chip)
- Different types: frequency, encryption, etc.
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6955309/pasted-from-clipboard.png)
Target application 🎯
Loading page
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6955388/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6955391/pasted-from-clipboard.png)
Result page
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6955391/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6955402/pasted-from-clipboard.png)
Local server NFC Reader and web-sockets
1st iteration
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
Summary
-
Buy a NFC Reader 💸
- ACR 122U — USB NFC Reader
Advanced Card System Ltd.
- ACR 122U — USB NFC Reader
- Node.js server on the client ➡️ plugged devices 🔌
- Use a PC/SC library 📕
- Communicate the read payload to the web app via web-sockets 🧦
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6714275/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
Connection workflow
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6887507/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
NTAG 213
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6955343/pasted-from-clipboard.png)
Memory organization
Local server
// src/index.js
// ...
io.on('connection', (socket) => {
socket.on('require-scan', () => {
const nfc = new NFC();
nfc.on('reader', (reader) => {
const pageNumber = 4;
const bufferLength = 48;
reader.on('card', async (card) => {
try {
const data = await reader.read(pageNumber, bufferLength);
const extractedPayload = data.toString().split('/')[1];
socket.emit('nfc-tag-scanned', extractedPayload);
} catch (err) {
// boilerplate code to handle the error
}
});
});
});
});
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6955343/pasted-from-clipboard.png)
Client app
// src/pages/home/components/HomeContainer.jsx
// ...
const HomeContainer = () => {
const [socket, setSocket] = useState();
const [readTag, setReadTag] = useState();
useEffect(() => {
setSocket(SocketIO.connect(APILocalSocketUrl));
}, [APILocalSocketUrl]);
useEffect(() => {
if (!socket) {
return () => {};
}
socket.emit("require-scan");
socket.on("nfc-tag-scanned", payload => {
setReadTag(payload);
});
return () => socket.close();
}, [socket]);
return <Home readTag={readTag} />;
};
export default HomeContainer;
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
Demo 1
![](https://media0.giphy.com/media/xTiN0CNHgoRf1Ha7CM/giphy.gif)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914393/pasted-from-clipboard.png)
Cons
- Node.js on the client 🛠
- Start the web-socket server 👷
-
Update on each client web-socket server if needed 🔄
- Works well on servers, what about desktop apps?
- Change our distribution mode
Pros
- Last version of the app ⚡️
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
Key learnings
- Easy installation 🛠️
- Easy distribution 🚚
- Desktop app 🖥️
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
How to do it with web technologies? 🤔
Electron application using a NFC Reader
2nd iteration
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
Electron
Build cross platform desktop apps with JavaScript, HTML, and CSS
- Easy installation on the client side
- Node.js server on the client side
- File-system, hardware, etc.
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6872160/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6872165/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6872167/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6872169/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
![](https://upload.wikimedia.org/wikipedia/commons/thumb/8/80/Atom_editor_logo.svg/1200px-Atom_editor_logo.svg.png)
![](https://upload.wikimedia.org/wikipedia/commons/thumb/9/9a/Visual_Studio_Code_1.35_icon.svg/1200px-Visual_Studio_Code_1.35_icon.svg.png)
![](https://a.slack-edge.com/80588/marketing/img/icons/icon_slack_hash_colored.png)
Summary
-
NFC reader bought for solution #1
- Electron ➡️ plugged devices 🔌
- Use a PC/SC library that we already master 📕
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6714275/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
Use the library
const HomeContainer = () => {
const nfc = new NFC();
const [readTag, setReadTag] = useState(undefined);
nfc.on("reader", reader => {
const pageNumber = 4;
const bufferLength = 48;
reader.on("card", card => {
reader.read(pageNumber, bufferLength).then(data => {
const extractedPayload = data.toString().split("/")[1];
setReadTag(extractedPayload);
});
});
});
return <Home readTag={readTag} />;
};
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
Demo 2
![](https://media1.giphy.com/media/5GoVLqeAOo6PK/giphy.gif)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914393/pasted-from-clipboard.png)
Limits
- Build for each target platform
- Reinstall on each device after updates
- Packaging and installation
- Slow and heavy release cycles
- Configuration to use native modules
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
![](https://media3.giphy.com/media/5z0cCCGooBQUtejM4v/giphy.gif)
Dream solution
- Web app 🌐
- Nothing installed client-side 🤤
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
Using WebUSB and an Arduino board
3rd iteration
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
WebUSB API
- API implemented in the browser 🌐
- "Plug and play" devices for web apps 🔌
- Security: "web origins" (white list) 🛡
-
Equivalent to CORS for HTTP requests
-
Equivalent to CORS for HTTP requests
- Native code & SDKs ➡️ cross-platform & "web-ready" libraries 📚
W3C spec draft: wicg.github.io/webusb
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
WebUSB API
Workflow
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6928371/webusb-workflow__1_.png)
NFC Reader
- Arduino Leonardo
Compatible devices here:
https://github.com/webusb/arduino#compatible-hardware
- Adafruit PN532 NFC/RFID Controller Shield
- A bit of solder 👨🏭
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914098/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914101/pasted-from-clipboard.png)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914104/pasted-from-clipboard.png)
1/2
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
NFC Reader
- $50 per device 💵
- Handicraft and not yet industrialized 👨🔬
- Will be subcontracted
2/2
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914115/IMG_20191001_150600.jpg)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914139/IMG_20191001_173242.jpeg)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
Arduino programming
Import libraries and configure the WebUSB Serial
// NFC Reading libraries
#include <Wire.h>
#include <PN532_I2C.h>
#include <PN532.h>
#include <NfcAdapter.h>
// WebUSB library
#include <WebUSB.h>
// Web origin
#define PROTOCOL_HTTP 0 /* http:// */
WebUSB WebUSBSerial(PROTOCOL_HTTP, "localhost:3000");
// NFC Shield configuration
PN532_I2C pn532_i2c(Wire);
NfcAdapter nfc = NfcAdapter(pn532_i2c);
#define BAUD_RATE 9600
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
Arduino programming
Reading loop
void loop() {
if (nfc.tagPresent()){
NfcTag tag = nfc.read();
if (tag.hasNdefMessage()) { // If your tag has a message
NdefMessage message = tag.getNdefMessage();
// If you have more than 1 record then it will cycle through them
int recordCount = message.getRecordCount();
for (int i = 0; i < recordCount; i++) {
NdefRecord record = message.getRecord(i);
int payloadLength = record.getPayloadLength();
byte payload[payloadLength];
record.getPayload(payload);
String payloadAsString = ""; // Processes the message as a string vs as a HEX value
for (int c = 0; c < payloadLength; c++) {
payloadAsString += (char)payload[c];
}
WebUSBSerial.write(payloadAsString.c_str());
}
}
};
WebUSBSerial.flush();
delay(250);
}
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
Client live coding
👨💻
![](https://media1.giphy.com/media/zOvBKUUEERdNm/giphy.gif)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914393/pasted-from-clipboard.png)
Working zone 🚧
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
- Draft Community status (since Aug. 2019)
- Enabled in Chrome 61 (Sept. 2017)
- Disabled for several months (security)
- Only available in secured context (HTTPs)
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6961007/pasted-from-clipboard.png)
Production 🏭
![](https://s3.amazonaws.com/media-p.slid.es/uploads/976549/images/6914389/pasted-from-clipboard.png)
- Only client-side code
- https://gdarchen.github.io/webusb-arduino-nfc/
Thank you! 🙏
