Fair Threaded Task Scheduler Verified in TLA+
Vladislav Shpilevoy
Plan
Task scheduling
Typical solutions
New task scheduler
Scheduling gears
Verification
Benchmarks
Future plans
Task scheduling
is just execution of code
Thread pool
Event loop
Coroutine engine
Trivial scheduler
class TrivialSched:
Thread myThread;
Mutex myLock;
ConditionVariable myCond;
List<Callback> myQueue;
TrivialSched::Post(const Callback& aFunc)
{
myLock.Lock();
myQueue.Append(aFunc);
myCond.Signal();
myLock.Unlock();
}
TrivialSched::Run()
{
while(!IsStopped()) {
myLock.Lock();
while (myQueue.IsEmpty())
myCond.Wait();
Callback cb = myQueue.Pop();
myLock.Unlock();
cb.Execute();
}
}
Single thread
Grind the tasks one by one
Simple locked queue
Append under a lock
Pop under a lock
Execute one by one
The real task
Handling savegames
Locks
Saves
x10k RPS
CPU-intensive
lock a user profile
download a saveblob
change the blob
upload the blob
unlock the profile
Multiple steps:
Network exchange
Trivial scheduler problems
Won't scale
Choking on CPU
Can't postpone a blocked task
Need multiple threads
Need coroutines
task1
task2
task3
Waiting for events
Trivial scheduler v2
Tasks stick to threads
Round-robin distribution
Periodic update of each task
Updater "updates" all tasks all the time
Thread pool
Trivial scheduler v2 problems
Uneven CPU usage
High latency
Waste of CPU
Min latency is 215 ms
5 ms
100 ms
Got events
Unnecessary waiting
Unnecessary wakeup, cost = 10 us
x10 000 tasks = 100 ms wasted
Summary requirements
Fairness
Coroutines
Events
TaskScheduler
Front Queue
Ready Queue
Worker threads
Workers compete for scheduling
Wait Queue
Who processes the queues?
TaskScheduler example
Front Queue
Ready Queue
Worker threads
Wait Queue
TaskScheduler
Front Queue
Ready Queue
Worker threads
Wait Queue
TaskScheduler
Front Queue
Ready Queue
Worker threads
Wait Queue
TaskScheduler
Front Queue
Ready Queue
Worker threads
Wait Queue
TaskScheduler
Front Queue
Ready Queue
Worker threads
Wait Queue
TaskScheduler
Front Queue
Ready Queue
Worker threads
Wait Queue
TaskScheduler
Front Queue
Ready Queue
Worker threads
Wait Queue
TaskScheduler
Front Queue
Ready Queue
Worker threads
Wait Queue
TaskScheduler
Front Queue
Ready Queue
Worker threads
Wait Queue
Dependencies
Mutex
Condition variable
Containers
Lock-free atomics
Lock-free atomics
AtomicExchange(var, new_value)
{
old_value = var;
var = new_value;
return old_value;
}
AtomicCompareExchange(var, new_value, check)
{
if (var != check)
return false;
var = new_value;
return true;
}
Atomically set if the old value equals something
Atomically set a new value and get the old value
Atomically get the old value
AtomicLoad(var)
{
return var;
}
* Google "memory models" about why it has to be atomic
Front queue
Multi-Producer-Single-Consumer*
All threads
Sched-worker
* Common notation for queues: MPSC, MPMC, SPSC, SPMC
Front queue
Multi-Producer-Single-Consumer
All threads
Sched-worker
High contention
class NormalQueue:
T* myHead;
T* myTail;
NormalQueue::Push(T* aItem)
{
if (myHead == nullptr)
myHead = aItem;
else
myTail->myNext = aItem;
myTail = aItem;
}
NormalQueue::Pop()
{
if (myHead == nullptr)
return nullptr;
T* res = myHead;
myHead = res->myNext;
return res;
}
Normally a queue needs 2 members: head and tail
Doing it in a lock-free way is hardly possible - too many variables
Front queue
Multi-Producer-Single-Consumer
All threads
Sched-worker
High contention
class MPSCQueue:
T* myTop;
MPSCQueue::Push(T* aItem)
{
T* oldTop;
do {
oldTop = AtomicLoad(myTop);
aItem->myNext = oldTop;
} while (not AtomicCompareExchange(
myTop, aItem, oldTop));
}
MPSCQueue::PopAll(T* aItem)
{
T* top = AtomicExchange(myTop, nullptr);
return ReverseList(top);
}
Make it a stack to reduce the number of variables
Retry atomic push of a new top. Stack grows
Pop takes all and turns stack to queue
Completely lock-free
Wait queue
Quickly get expired tasks
Binary heap
Sched-worker
Wait queue
Binary heap
Quickly get expired tasks
Sched-worker
O(log(N))O(1)−update−get top
\begin{aligned}
O(log(N)) &- update\\
O(1) &- get\ top
\end{aligned}
0
3
1
4
5
6
2
Quickly get expired tasks
Very good time complexity
Perfectly balanced binary tree
Node >= children
Sort tasks by deadlines - the closest on top
Ready queue
Multi-Consumer-Single-Producer
All threads
Sched-worker
High contention
Ready queue
Multi-Consumer-Single-Producer
All threads
Sched-worker
High contention
There is no simple unbounded lock-free MCSP queue
* Google "ABA-problem" about why
Bounded lock-free MCSP queue
But there are these:
Unbounded lock-based MCSP queue
Ready queue - Bounded Lock-Free
class LockFreeBounded:
uint64 myIdxBegin;
uint64 myIdxEnd;
uint32 mySize;
T* myBuffer;
LockFreeBounded::Push(T* aItem)
{
uint64 idxEnd = AtomicLoad(myIdxEnd);
if (idxEnd - AtomicLoad(myIdxBegin) == mySize)
return false;
myBuffer[idxEnd % mySize] = aItem;
AtomicExchange(myIdxEnd, idxEnd + 1);
}
LockFreeBounded::Pop()
{
T* res;
do {
uint64 idxBegin = AtomicLoad(myIdxBegin);
if (idxBegin == AtomicLoad(myIdxEnd))
return nullptr;
res = myBuffer[idxBegin % mySize];
} while (not AtomicCompareExchange(
myIdxBegin, idxBegin + 1, idxBegin));
return res;
}
Cyclic array with atomic indexes
Single producer atomically bumps 'end index'
Consumers read by atomically incremented 'begin index'
Ready queue - Unbounded Locked
class LockedUnbounded:
Mutex myLock;
List<T> myQueue;
LockedUnbounded::Push(T* aItem)
{
myLock.Lock();
myQueue.Append(aItem);
myLock.Unlock();
}
LockedUnbounded::Pop()
{
myLock.Lock();
T* res = nullptr;
if (myQueue.IsEmpty())
res = myQueue.PopFirst();
myLock.Unlock();
return res;
}
Trivial mutex and list
Lock on push and pop
Ready queue
Combine
Ready queue
Lock-free
Lock-protected
Lock-based queue of lock-free queues
Single producer
Multiple consumers
Consumers need an explicit state
Lock is taken once per sub-queue size
Ready queue example
B
A
Ready queue example
B
A
Ready queue example
B
A
Ready queue example
B
A
Ready queue example
B
A
Ready queue example
B
A
Ready queue example
B
A
Ready queue example
B
A
Ready queue example
B
A
Ready queue example
B
A
Ready queue example
B
A
Ready queue example
B
A
Ready queue example
B
A
Ready queue example
B
A
Ready queue example
B
A
Our progress
Task scheduling
Typical solutions
New task scheduler
Scheduling gears
Verification
Benchmarks
Future plans
TaskScheduler parts
Coroutines
Coroutines
Start a download
Handle the result
Need to step away to let other tasks work
Need some timeout for the waiting
Need to wakeup when get a response
Can yield
Can set a deadline
Can be woken up explicitly
Coroutines
MyTask *t = new MyTask(); t->SetCallback(Download); sched.Post(t);
TaskScheduler sched; HTTPClient http;
Download(t):
t->SetCallback(HandleResult);
http->GetAsync(url, {
sched.Wakeup(t);
});
sched.PostDeadline(t, now + 5 sec);
HandleResult(t):
if (t->IsExpired()) {
http->Cancel();
sched.PostWait(t);
return;
}
if (http->IsSuccess())
HandleSuccess();
else
HandleFailure();
delete t;
Prepare the next step
Send an async request, wakeup() on completion
Yield until +5 secs or wakeup
Check if the deadline is up. Cancel then
Not expired = completed. Handle it
Completely lock-free, very low overhead
How to verify a multithreaded algorithm?
TLA+ Verification
Temporal Logic of Actions
Math logic with "time" concept
Language
Runtime
State C
State A
State B
Your system / algorithm
State D
Initial
Fullscan and checking
TLA+ Example
Init == /\ Pipe = << >> /\ LastReceived = 0 /\ LastSent = 0
CONSTANT Count CONSTANT Lim VARIABLES Pipe, LastReceived, LastSent
Decide on granularity of the system: objects, actions on them
Actions consist of conditions. First is usually "init"
Examples of expressions:
X and Y are true: x /\ y
List of items x, y, z:
<<x, y, z>>
X equals Y: x = y
All items in set Y are equal 10: \A x \in Y: x = 10
X∧Y
X \land Y
(x,y,z)
(x, y, z)
X=Y
X = Y
∀x∈Y:x=10
\forall x \in Y: x = 10
TLA+ Example
Init == /\ Pipe = << >> /\ LastReceived = 0 /\ LastSent = 0
Send == /\ Len(Pipe) < Lim /\ LastSent < Count /\ Pipe' = Append(Pipe, LastSent + 1) /\ LastSent' = LastSent + 1
CONSTANT Count CONSTANT Lim VARIABLES Pipe, LastReceived, LastSent
Conditions for the action to be possible
Conditions which "change" the state if the action is possible
Single quote _'_ refers to the next value of the variable
Next value of X equals X + 1: X' = X + 1
TLA+ Example
Init == /\ Pipe = << >> /\ LastReceived = 0 /\ LastSent = 0
Send == /\ Len(Pipe) < Lim /\ LastSent < Count /\ Pipe' = Append(Pipe, LastSent + 1) /\ LastSent' = LastSent + 1
Recv == /\ Len(Pipe) > 0 /\ LastReceived' = Head(Pipe) /\ Pipe' = Tail(Pipe)
CONSTANT Count CONSTANT Lim VARIABLES Pipe, LastReceived, LastSent
PipeInvariant == /\ \A i \in 1..Len(Pipe) - 1: Pipe[i] + 1 = Pipe[i + 1] /\ Len(Pipe) =< Lim /\ \/ Len(Pipe) = 0 \/ Pipe[1] = LastReceived + 1
Items are ordered
The queue never overflows
The first item is always the next to receive (or the queue is empty)
TaskScheduler TLA+
TaskScheduler spec: ~750 lines
MCSP queue spec: ~430 lines
How to run it:
Study TLA+, great course from its author:
Benchmarks - parts
Comparative - algorithm vs its naive trivial version
- 5 push-threads
- ~9 mln/sec
- x1.5 faster vs trivial
Example: Debian Linux, 8 cores, 2.3GHz, hyperthreading
- 10 push-threads
- ~5.8 mln/sec
- x2.6 faster vs trivial
- 5 pop-threads
- ~2.5 mln/sec
- x2.6 faster vs trivial
- x0.0009 lock-contention
Front Queue
Ready Queue
- 10 pop-threads
- ~1.7 mln tasks/sec
- x4.5 faster vs trivial
- x0.0007 lock-contention
Benchmarks - scheduler
Example: Debian Linux, 8 cores, 2.3GHz, hyperthreading
- 1 worker
- ~11 mln/sec
- x2.2 faster vs trivial
- x0 lock-contention
- 10 workers
- ~5.2 mln/sec
- x7.5 faster vs trivial
- x0.003 lock-contention
- 5 workers
- ~4 mln/sec
- x3 faster vs trivial
- x0.002 lock-contention
Real usage
Savegame blobs multistep processing
This is a thread-safe box. Can do here anything, not just deadlines. Like add epoll or IOCP
The algorithm is extendible
"Updater":
- 4 workers
- ~100-300 RPS
- ~500 ms latency
x10 speed up right away
"TaskScheduler":
- 4 workers
- >10000 RPS
- ~100 ms latency
Debian Linux, 8 cores, 2.3GHz, hyperthreading
Future plans
Try on ARM
Other languages
Optimizations
TLA+ specs and C++ code:
My talks (and this one too):
Feedback
Additional content
Signal
An event storage
Threads shouldn't poll
Signal
An event storage
Thread 1:
hasEvent = true;
sig.Send();
Thread 2:
sig.BlockingReceive()
assert(hasEvent);
// Won't receive again:
assert(sig.IsEmpty());
Signal sig; bool hasEvent = false;
Threads shouldn't poll
Signal
An event storage
class Signal:
Mutex myLock;
ConditionVariable myCond;
bool myFlag;
Signal::Send()
{
myLock.Lock();
myFlag = true;
myCond.Signal();
myLock.Unlock();
}
Signal::BlockingReceive()
{
myLock.Lock();
while (not myFlag)
myCond.Wait();
myFlag = false;
myLock.Unlock();
}
Usual implementation
Expensive mutex lock on each operation
Threads shouldn't poll
Signal
An event storage
class Signal:
Mutex myLock;
ConditionVariable myCond;
bool myFlag;
Signal::Send()
{
myLock.Lock();
AtomicExchange(myFlag, true);
myCond.Signal();
myLock.Unlock();
}
Signal::BlockingReceive()
{
if (AtomicExchange(myFlag, false))
return;
myLock.Lock();
while (not AtomicExchange(myFlag, false))
myCond.Wait();
myLock.Unlock();
}
Threads shouldn't poll
Lock-free receipt if already signaled
Signal
An event storage
class Signal:
Mutex myLock;
ConditionVariable myCond;
bool myFlag;
Signal::Send()
{
if (AtomicExchange(myFlag, true))
return;
myLock.Lock();
myCond.Signal();
myLock.Unlock();
}
Signal::BlockingReceive()
{
if (AtomicExchange(myFlag, false))
return;
myLock.Lock();
while (not AtomicExchange(myFlag, false))
myCond.Wait();
myLock.Unlock();
}
Threads shouldn't poll
Lock-free receipt if already signaled
Lock-free send if already signaled
Smart usage of cmpxchg
AtomicCompareExchange(var, new_value, check)
{
if (old_value == check)
return false;
var = new_value;
return true;
}
Smart usage of cmpxchg
AtomicCompareExchangeGetOld(var, new_value, check)
{
if (old_value == check)
return old_value;
var = new_value;
return old_value;
}
AtomicCompareExchange(var, new_value, check)
{
return AtomicCompareExchangeGetOld(
val, new_value, check) == check;
}
Smart usage of cmpxchg
class MPSCQueue:
T* myTop;
MPSCQueue::Push(T* aItem)
{
T* oldTop;
do {
oldTop = AtomicLoad(myTop);
aItem->myNext = oldTop;
} while (not AtomicCompareExchange(
myTop, aItem, oldTop));
}
MPSCQueue::PopAll(T* aItem)
{
T* top = AtomicExchange(myTop, nullptr);
return ReverseList(top);
}
Smart usage of cmpxchg
class MPSCQueue:
T* myTop;
MPSCQueue::Push(T* aItem)
{
T* oldTop;
T* res = AtomicLoad(myTop);
do {
oldTop = res;
aItem->myNext = oldTop;
res = AtomicCompareExchangeGetOld(myTop, aItem, oldTop);
} while (res != oldTop);
}
MPSCQueue::PopAll(T* aItem)
{
T* top = AtomicExchange(myTop, nullptr);
return ReverseList(top);
}
Load the top once
Atomically retry setting a new top and getting the old one
Task signal
Download(t):
t->SetCallback(HandleResult);
http->GetAsync(url,
{
http->SetReady();
sched.Wakeup(t);
});
sched.PostDeadline(t, now + 5 sec);
HandleResult(t):
if (http->IsReady())
{
Process(http->GetResult());
delete t;
return;
} http->Cancel(); sched.PostWait(t);
TaskScheduler sched; HTTPClient http;
Check the completion before the expiration
The code will eventually crash here
HTTP threads set 'ready' flag
Thread A
1
2
Thread B
Scheduler thread wakes up by timeout and deletes the task
3
HTTP thread uses a deleted task
Task signal
Download(t):
t->SetCallback(HandleResult);
http->GetAsync(url,
{
sched.Signal(t);
});
sched.PostDeadline(t, now + 5 sec);
HandleResult(t):
if (t->ReceiveSignal())
{
Process(http->GetResult());
delete t;
return;
} http->Cancel(); sched.PostWait(t);
TaskScheduler sched; HTTPClient http;
Signal is atomic "wakeup + set flag"
- Hello, my name is Vlad, I am a C/C++ developer with 8 years of experience and right now work at a gamedev company Ubisoft, mostly with low-level networking and system programming.
- In Ubisoft while doing a complete rewrite of networking stack in one of game engines I created a cool algorithm for doing so called "task scheduling" which very much improved perf of our online backend.
- Today I share the algorithm in a form of the talk and an open-sourced C++ implementation. Although can also be done in some other language. Today we focus only on the algorithms.
- There is a lot of content, so we will be going quick, and I ask you people to concentrate with all your might.
## For readers
In the speaker notes the sign (>>) means you need to press 'Space' to go to the next frame.
Fair Threaded Task Scheduler Verified in TLA+ Vladislav Shpilevoy github.com/ubisoft/task-scheduler
Highload 2022: Fair threaded task scheduler verified in TLA+
By Vladislav Shpilevoy
Highload 2022: Fair threaded task scheduler verified in TLA+
Algorithm for a multithreaded task scheduler for languages like C, C++, C#, Rust, Java. C++ version is open-sourced. Features: (1) formally verified in TLA+, (2) even CPU usage across worker threads, (3) coroutine-like functionality, (4) almost entirely lock-free, (5) up to 10 million RPS per thread. Key points for the potential audience: fair task scheduling with multiple worker threads; open source; algorithms; TLA+ verified; up to 10 million RPS per thread; for backend programmers; algorithm for languages like C++, C, Java, Rust, C# and others.
- 644
